INSTALLATION INSTRUCTIONS
Model 1066 Coaxial Kit
LINEAR CORPORATION
2055 CORTE DEL NOGAL CARLSBAD, CA 92009
Copyright © 1999 Linear Corporation 216658 A
INSTR,INSTL,MC106603,COAXIAL
LINEAR P/N: 216658 A
MATERIAL: 20 LB. MEAD BOND
INK: BLACK
SIZE: 8.500" x 11.000"
SCALE: 1-1
™
®
The Coaxial Kit permits the remote location of the
antenna on radio receivers equipped with a type F screw
connector. Theantennacanbemovedawayfroma metal
structure or to an outside location for better receiver
performance.
Refer to the appropriate receiver and transmitter instal-
lation instructions for mounting and connecting to the
door operator.
Locate and mount the antenna bracket securely at the
desired location making sure the coaxial cable will not
interfere with the operation of the power unit.
Remove the antenna from the receiver and plug onto the
receptacleatthebracket.Plug thecableontothereceiver
antenna connector.
It is recommended that the cable be protected in some
manner, such as a rubber grommet, at the point where it
passes through a structure.
