LineEye LE-170SA User manual

《Ver.1 2019.05 》
INSTRUCTION MANUAL
LE-170SA
DATA LINE MONITOR

Introduction
Thank you for your purchase of LE-series.
To use it correctly, you are advised to read and understand this
instruction manual thoroughly. Keep this together with thewarranty.
If you encounter any problems, you will nd helpful information in
this manual.
NOTICE

It is prohibited to reprint or duplicate any part of this manual without
priorpermission from LINEEYE.
The content of this manual and specication of the product is subject to
change without any notice.
This instruction manual has been designed and edited with great care to
giveyou all necessary information. If you have anyquestions, feel free to
direct your inquiries to LINEEYE.
LINEEYE makes no warranty or guarantee, either expressed or implied
with respect to its quality, performance,merchantability, or tness for a
particular purpose. LINEEYE shall not be liable for direct, in-direct, special,
incidental, orconsequential damages resulting from any defect in the product.
The warranty and remedies set forth above are exclusive andin lieu of all
others.
USER LIMITATION

This product has been developed for the purpose of using as an line monitor
only.
When you use this product with the following devices that are required to
function with a high degree of reliability, safety andaccuracy, use it under
considering the safe design of the system in order to maintain reliability and
safety for that system;
*Devices that are directly related to transportation such as airplanes, trains,
cars etc.
*Devices for crime prevention and disaster privension.
*Each kind of safety devices and so on.
This product has not been developed for the use that needs exclusivey
highreliability and safety: aerospace apparatus, trunk communication
apparatus, nuclear control apparatus, medical apparatus related with
lifemaintenance etc. Therefore, do no use for those purposes.
= = = Notice = = =
When youdispose of it, please follow the regulation of the region
2019 by LINEEYE CO.,LTD All rights reserved

-1-
Read this rst!!

This Safety Information includes the following important information
in order to not only have you learn the right way to use theline
monitor, but also prevent you from causing damage to people
and property. Before using, please read the main contents after
youunderstand the following symbols & marks.
Warning There is a possibility of getting hurt, such as a death or a
serious injury
Caution There is a possibility of getting injured or damaging the
product.
Prohibition
necessity
Safety Information
Warning
* Do not disassemble, modify or repair the line monitor.
This may result in an injury, electric shock, and ignition.
* Do not put the line monitor in a re or place near the heater.
This may result an injury, ignition and explosion.
* Do not use the line monitor if there is inammable gas.
This may result in ignition and explosion.
* Turn off the power and unplug the line monitor immediately
when emanating smoke or odor.
Continuous use may result in an electric shock burn and ignition.
* Turn off the power and unplug the line monitor immediately
when liquid or foreign substance gets into the line monitor.
Continuous use may result in ignition, elect ric shock and
malfunciton.

-2-
Warning
* Do not touch the line monitor with wet hand.
This may result in an electric shock and malfuncion.
* Do not give a strong impact on the product, such as dropping
and crashing.
* Use the batteries and USB charger which LINEEYE
recommends.
It may cause the generation of heart, ignition, electric shock
and malfunction.
* Do not use the batteries other than Ni-MH batteries or
alkaline batteries.
This may result generation of heat, ignition, leaking and
malfunction.
* Do not leave the batteries near children.
If drinking them, please go to see your doctor.
* Please check + / - of the batteries before inserting them. Do
not short the electrode of batteries.
It may cause the generation of heat, ignition, explosion, leaking
and malfunction.
* Do not charge the Alkali batteries.
It may cause leaking, generation of hear t, explosion and
malfunction.
* Do not touch the liquid of batteries.
It may result in serious injury, such as losing your eyesight.
If you touch it, wash out the part rst and go to see your doctor.
* Do not use the new battery and old battery at the same time.
Do not use the batteries which are different manufactures.
It may cause the leaking, generation of heat, explosion and
malfunction.
* Remove the batteries from the line monitor if you do not use
it for a while.
It m ay cause leaking, generation of heat, explosion a nd
malfunction.

-3-
Caution
* Do not place the line monitor in following conditions.
It may cause the generation of heat, burn, electric shock,
malfunction and degradation.
* Magnetic led or dusty place. Have static electricity.
* Temperature or humidity is above the specication.
* Temperature is changing rapidly. Have condensation.
* Not at or vibrated place.
* Place where leaking water or electricity.
* Receive direct sun. Place near the re or room with hot air.
Do not leave the line monitor i n the car during a hot summer.

* Do not use the line monitor near the following devices.
The radio emitted from this device (radiation noise) may cause a
malfunction of other devices in the following situations.
* Medical devices, such as a heart pacemaker and hearing aid.
* Automatic control devices, such as automatic door and re alarm.
* Microwave, high-level electronics, TV, or radio.
* Microwave, high-level electronics, TV, or radio.
* Wireless station for mobile communications or a specied low
power radio station.
*Do not remove the label of batteries or damage them.
It may cause leaking, generation of heat, and explosion.
* Remove the batteries from the line monitor before throwing it
away.
* Stick adhesive tape on the terminals of batteries before
throwing or keeping them.

-4-
Warning
* Attention for using the USB charger.
It may cause the generation of heat, burn, electric shock and
malfunction.
*Do not use it above the specication of input.
* Do not use the broken one.
* Do not twist the cable or insert it upside down.
* Do not use it near the heater. Do not heat it itself.
* Do not disassemble or damage it.
* Remove the USB cable from the charger after using it.
* Do not put many loads on one electrical outlet.
* Insert it well to the electrical outlet.
* Remove the dust on the AC plug.
* Unplug the charger if you do not use it.
* Do not pull the cable when you unplug it.

-5-
CONTENTS
Introduction
Safety Information ......................................................................1
Chapter 1 Before Using the Product ...........................................8
1.1 Guide to This Manual ................................................................... 8
1.2 Unpacking..................................................................................... 9
1.3 Major Functions and Features .................................................... 10
1.4 Explanation of Each Part ............................................................ 11
1.5 Power and Battery ......................................................................12
Chapter 2 Basic Operation and Set-Up.....................................14
2.1 Power Source ON ....................................................................... 14
2.2 Operation.................................................................................... 14
2.3 Data Display window ................................................................. 15
2.4 Languages (Japanese / English) ................................................. 16
2.5 Date and Time Setting................................................................ 16
2.6 Settings for Charging Batteries.................................................. 17
2.7 Adjust LCD Back Light.............................................................. 18
2.8 Power saving Mode .................................................................... 18
Chapter 3 Basic Settings...........................................................19
3.1 Setting Menu............................................................................... 19
3.2 Functions .................................................................................... 20
3.3 CAN Conguration .................................................................... 21
3.4 LIN Conguration ...................................................................... 22
3.5 Capture Memory ........................................................................24
3.6 Auto Backup ............................................................................... 25
Chapter 4 Connect to the Target Devices .................................26

-6-
4.1 Connect to CAN interface.......................................................... 26
4.2 Connect to LIN interface ...........................................................26
Chapter 5 Monitor Function .....................................................28
5.1 Overview..................................................................................... 28
5.2 Start and Stop Monitoring.......................................................... 28
5.3 Scroll........................................................................................... 31
5.4 Retrieval Function ...................................................................... 31
5.5 LED display ................................................................................ 33
5.6 Save a Screen Image................................................................... 33
Chapter 6 Simulation Function .................................................34
6.1 Overview ....................................................................................34
6.2 Registration of Transmission Data............................................. 34
6.3 Sweep setting.............................................................................. 36
6.4 Start and stop of simulation........................................................ 37
Chapter 7 Trigger Function......................................................39
7.1 Trigger Function ......................................................................... 39
7.2 External trigger input / output.................................................... 39
7.3 Trigger setting.............................................................................40
7.4 Timer / Counter function............................................................44
Chapter 8 Data Save and Read.................................................46
8.1 File Management Function.........................................................46
8.2 Save.............................................................................................46
8.3 Filter Function ............................................................................ 47
8.4 Reload (Read).............................................................................48
8.5 Delete..........................................................................................48
Chapter 9 Documents ..............................................................49
9.1 Specication................................................................................ 49
9.2 Option .........................................................................................50

-7-
9.3 USB Driver Installation..............................................................50
Chapter 10 After Support and Maintenance............................52
10.1 How to make it back to default state......................................... 52
10.2 How to Update the Firmware ................................................... 52
10.3 Troubleshooting ........................................................................54
10.4 Warranty and After Service ..................................................... 56

-8-
Chapter 1 Before Using the Product
1.1 Guide to This Manual
Screen Display Representation

Printed representation of screen displays in this manual may not be
■
the same as that actually displayed concerning the font andspecial
symbols.
Descriptions of parts of the screen being displayed are enclosed in
■
double quotation marks “ ”.
Flashing of the cursor or the like is not represented in this manual.
■
Representation of the Operating Procedure

Keys and touch panels are indicated in [ ].
■
e.g. Press →Press [Menu]
Successive key operation is represented by putting their symbols
■
one after another.
e.g. : Press [Menu], then press [System] to make a selection.
→ Press [Menu][System]
Pressing two keys at the same time is expressed by combining their
■
symbols with “+”.
e.g. : Press [A] and [B] at the same time. → Press [A]+[B].
Touch screen is described as “Touch”.
■
Touch screen and slide the nger is described as “Swipe”.
■
Some details might be omitted if it is not necessary.
■

-9-
1.2 Unpacking
When you unpack the product, make sure of the

following:
Product has not been damaged during transport.
■
You have received all the standard accessories listed below.
■
・Line Monitor (LE -170SA) 1
・Dsub 9pin Mouitor Cable (LE-009M2) 1
・10pin External Input / Outoput Cable (LE-10ES1) 1
・Micro USB Cable 1
・AA-sized NiMH batteries 2
・Utility CD 1
・Carrying Bag ( LEB-02) 1
・Instruction manual 1
・Warranty, Registration Card 1
Please let us know if you nd any damage to the product or accessories
lacking.
Utility CD
■
This CD contains the following:
Manual folder : Instruction manual in PDF format.
Utility folder : Transferring software for rmware.
Driver folder : USB driver for line monitor to connect with PC.

-10-
1.3 Major Functions and Features
LE-170SA is the handheld data monitor which is useful to develop,
test and analyze CAN / LIN communications.
Functions

◆Monitor
Monitors communication protocol or data to check for existence of
hindrance in the line, or to monitor the communications.
◆Simulate
Executes operating transmission of data as communication partner for
tested devices / equipment.
Features

* Display communication data in real time in the 4.3 inch TFT color
display.
* The capacitive touch screen offers easy control by soft touch and
swipe.
* Support 20Kbps to 1Mbps of CAN communications (ISO 11898
conformity).
* Support 400bps to 26Kbps of LIN communications (ISO 9141
conformity).
* High resolution of time stamp and idle time are useful for
analyzing data.
* Record the analog value of 4 external inputs, along with
communication data.
* Measured data and conguration can be saved in a USB ash
drive.
* Light-weight (about 300g) handheld body is easy to carry around.
* Able to select a power supply - USB bus power, Ni-MH batteries,
or AA alkaline batteries.

-11-
1.4 Explanation of Each Part
[LE-170SA]
N a m e F u n c t i o n
1) Power Switch Turn on / off the power.
2) [ Run ] key Start monitoring / simulating.
3) [ Stop ] key Stop monitoring / simulating.
4) [ Menu ] key Display the top menu.
5) [ Esc ] key Return to the previous display.
6) LCD 4.3 inch color LCD with touch panel.
7) Line State LED Light in red when signal is active.
8) Power LED
Light in green when turning on the power.
Light in red: battery full charged. Blink in red:
Stillcharging the battery.
9) Battery Cover Open to change the batteries.
10) USB Device Port
Micro-USB connector.
Connect to the USB port of PC or USB battery
charger.
11) USB Host Port Standard A USB connector. Connect to the USB
ash drive.
12) CAN port Measurement port for CAN.
13) LIN / External signal port LIN port, External signal input / output port.
9)
13) 10)12)
4)
7)
5) 3) 2)
11)
8)
1)
6)

-12-
1.5 Power and Battery
USB Bus Power

Supply power from a PC, or USB charger (option).
Connect attached micro USB cable to the USB device port of line monitor.
Attention:
Do not use the USB charger which outputs 9V or 12V. (use 5V only)
Batteries inserted in the line monitor are used when USB bus power is OFF.
However, do not remove the batteries from the line monitor while using
with USB bus power.
Battery Drive

The line monitor is able to run for about 5 hours with attached Ni-
HM batteries. For temporary use, it is able to use AA-size Alkali
batteries (LR6) and run for about 2 hours.
The running time is just a standard time. It might be different if using batteries

of different manufactures.
＜Attention for Alkali batteries ＞
Please follow the instruction. It may cause leaking and damaging the
batteries.
* Use Alkali batteries for temporary use. Put back the Ni-HM batteries for
normal use.
* Do not use old and new batteries together at the same time. Do not use the
batteries of different manufactures.
* Change the batteries immediately if remaining quantity of batteries is
low.
* Do not charge the Alkali batteries.
* Do not touch the liquid of batteries directly. Please go to see your doctor
when having it on your body.
Micro USB cable
USBport
USB battery charger (not included)
Micro USBcable

-13-
To insert the batteries
■
1) Pull up the battery cover.
2) Insert two batteries. Positive pole of battery has to be inserted to the
side where it is labeled.
3) Put back the battery cover.
Charge Ni-HM Batteries

As a factory setting, the line monitor cannot charge Ni-HM batteries
to prevent charging Alkali batteries by mistake. You can charge them
using the Ni-HM battery charger for AA-size.
LINEEYE confirms the performance of Ni-HM battery chargers:
“BQCC23” and “BQCC55” of Panasonic. “TNHC-34SMC” and
“TNHC- 34HBC” of Toshiba.
Charge Ni-HM batteries by the line monitor
■
Change the settings of line monitor to charge Ni-HM batteries.
→ 2.6 Settings for Charging Batteries
There is a natural discharge on the batteries. If you do not use the line monitor

for a while, remove the batteries from the line monitor. We recommend
charging the batteries one in a year.
LINEEYE and our distributors are able to supply spare batteries.

We do not warrant the batteries.

+
+

-14-
Chapter 2 Basic Operation and Set-Up
2.1 Power Source ON
Press the power switch and following screens will be displayed.
If “Self Check NG” is displayed, it is necessary t o have a repairing.

Press the power switch for a while to turn off the power.

After a few seconds, data screen window will be displayed.
Or press [Esc] to go to the data screen window.

2.2 Operation
There are 5 keys and touch panels to control the line monitor.
Touch panels enable to select settings by soft touch or to scroll the display by
swipe.
Pressing two (three) keys at the same time has a special function.

e.g. : [Menu]+[Esc] → 5.6 Save a Screen Image
[Esc]+turn on the power → 10.1 How to make it back to default state
[Stop]+[Run]+turn on the power → 10.2 Update Firmware

-15-
2.3 Data Display window
1) Measuring [ ] , Pause [ ]
2) Position of data / all data. Able to input the position of data.
3) Other status.
4)
Selected Mode
[CAN / LIN] : Monitor CAN / LIN
[CAN sim] : Simulate CAN
[LIN master] : LIN master simulation
[LIN slave] : LIN slave simulation
5) Status of USB device mode (Green: Connected)
6) Status of Host port (Green: Connected)(*1)
7) Level of remained battery. [ ] indicates “bus power”
8) Display more items.
9) Change display mode of measured data.
Data display -> Analog display of external input.
10) Stop updating data on the display while measuring.
Save data or read les.
11) Selected data code. Change data code.
12) [ ▲ ] : Search earlier data. [ ▼ ] : Search later data.
13) Read the data table for simulation.
14) Other operations.
* 1 : It becomes in red while accessing to the USB ash drive.
3)2) 4) 5) 6) 7)
8) 9) 10) 11) 12) 13)
1)
14)

-16-
2.5 Date and Time Setting
Set date & time in the line monitor correctly. Timestamp information
will be used for the measured data and saved le names.
Touch the display of date and time.
(e.g. : 2018-09-10 09:07:31) from the
opening screen to set the date and
time.
You can also the display of data and
time from pressing [Menu] key.
Use [0]-[9] keys and [→][←] keys to set the time and touch[ ] to apply it.
Batteries and inner condenser keep the time information. If your remove
the batteries from the line monitor for a while, the time information will
go back to “2018/01/01” as an initial setting.
2.4 Languages (Japanese / English)
It is able to select a language (Japanese / English).
Select a language from openingscreen.

-17-
2.6 Settings for Charging Batteries
As a factory setting, the line monitor cannot charge Ni-HM batteries
to prevent charging Alkali batteries by mistake. Change the settings
of line monitor to charge Ni-HM batteries.
Supply the USB bus power to the
line monitor and then press [Menu]
→ [System Settings] and select
[Charging type]
Not charge : Do not charge anything. Set this if using Alkali batteries.
Normal
charge
: Charge 70-90% of Ni-HM batteries in about 12 hours.
Set this if charging from USB port of PC.
Fast charge : Charge 70-90% of Ni-HM batteries in about 4 hours (turn
off the power of line monitor). Set this if charging from
optional USB charger. If turn on the power of line monitor,
it works almost same as “Normal Charge”.
→ 1.5 Power and Battery
The line monitor cannot charge 100% of Ni-HM batteries. To charge them full,

you need to use the Ni-HM battery charge for AA-size.
LINEEYE confirms the performance of Ni-HM battery chargers:
“BQCC23” and “BQCC55” of Panasonic. “TNHC-34SMC” and
“TNHC- 34HBC” of Toshiba.
--- Attention before charging Ni-HM batteries ---
* Do not insert any Alkali batteries in the line monitor when selecting
“Normal Charge” and “Fast Charge”.
*“Fast Charge” exceeds the ability of USB bus power of USB 2.0 port.
Therefore, do not connect to the USB port of PC while selecting “Fast
Charge”.

-18-
2.7 Adjust LCD Back Light
It is able to adjust the brightness of LCD back light.
Press [Menu] → [System setting] →
[Backlight brightness] and adjust the
brightness using [▼] [▲] keys.
While holding down [Menu], press [Run] to make the screen lighter or press

[Stop] to make the screen darker. Make sure you press two keys at the same
time, otherwise measurement will be started or stopped.
Brighter the screen consumes more electricity.

→ 2.8 Power saving Mode
2.8 Power saving Mode
Using power saving mode extends the battery running time of line
monitor.
P r e s s [ M e n u ] → [ S y s t e m
Settings] → set [Backlight auto
saving] and [Auto power off].
Backlight auto saving
■
The LED backlight will be darker after the setting time to save power
consumption.
Press any button to go back to the normal brightness. Initial setting is one
minute.
Auto power off
■
Turn off the power of line monitor automatically if there is not any
operation on the line monitor. Selection are Off (initial setting), 5, 10, 30
or 60 minutes.
This setting will not be work while measuring communications.

