Technical Specications

















do NOT submerge in water!!!
Quick Start Guide



This quick guide will get you started with the basic, most frequent operating functions.
Please refer to the overleaf instructions for MENU operation and available setup options.
You will nd downloads, certicates, manuals, and a knowledge-base onwww.linegrip.com/LS3
lineGrip Corporation Ltd.



















































NOTICE FOR PPE APPLICATION
Please fully read and understand the included PPE manual
before using the LineScale-3 for PPE application!









Technical Specications

















do NOT submerge in water!!!
Quick Start Guide



This quick guide will get you started with the basic, most frequent operating functions.
Please refer to the overleaf instructions for MENU operation and available setup options.
You will nd downloads, certicates, manuals, and a knowledge-base onwww.linegrip.com/LS3
lineGrip Corporation Ltd.



















































NOTICE FOR PPE APPLICATION
Please fully read and understand the included PPE manual
before using the LineScale-3 for PPE application!









LineScale-3 MENU Scheme v4 - Dec. 2021
When in Main-Menu, the top most row will display the date, firmware version, and time.
30.12.21 V2.520 16:45
Main Menu Sub Menu Item Buttons function for navigation and setting
(w. sample setting) (possible settings)
Log
Return
Date/Time Date format
Same button function as "edited per digit" above
Same button function as "edited per digit" above
Return
User Settings
Same button function as select value
Return
Service Reset abs zero
Set absolute zero
Simple calibration
Linear calibration
Same button function as "edited per digit" above
Same button function as "edited per digit" above
Factory reset
Return
Exit
Clear log memory
NO
Sure delete all logs?
NO
YES
When enter item, NO is highlighted, press  to
return without deleting. Select  YES and press
 to clear log memory and return to Sub-Menu
Onboard logging
ON
Onboard logging
ON
OFF
When enter item, current setting is highlited
Select  ON or OFF
press  to set and return to Sub-Menu
Overwrite oldest log
ON
Overwrite oldest log
ON
OFF
When enter item, current setting is highlited
Select  ON or OFF
press  to set and return to Sub-Menu
Capture start trigger
1.00 kN
Set start trigger
x.xx
00000 for none
When enter Item the current set value is edited per digit
press  to set value
first digit is highlited
change digit with  and  to set
next digit is highlited
change digit with  and  to set
repeat same for all digits
on last digit
press  to set value and return to Sub-Menu
Enter all zeroes (00000) for no triggers or recording
press  to set and return to Sub-Menu
press PWR to abort edit and return to Sub-Menu
____________________
When enter Scan Rate, current setting is highlited
Select  10, 40, 640, 1280Hz
press  to set and return to Sub-Menu
Max Log Rec, Min. Log Rec, Pre-Capture will show the
defined time setting for the respective selected Scan Rate
Capture end trigger
12.00 kN
Set end trigger
x.xx
00000 for none
Scan rate
40 Hz
Set scan rate
10 Hz, 40 Hz, 640 Hz, 1280 Hz
Max log rec time
180 sec.
Set max log rec time
xxxxx
Min log rec time
10 sec.
Set min log rec time
xxxxx
Pre-capture rec time
5 sec.
Set pre-capture time
xxxxx
00000 for none
Logging type
Continuous logging
Set logging type
Continuous logging
Single log
When enter item, current setting is highlited
Select  Continuous or Single
press  to set and return to Sub-Menu
Press  to exit Sub-Menu, and return to Main-Menu
Date format
dd.mm.yy
yy/mm/dd
When enter item, current setting is highlited
Select  to toggle date format
press  to set and return to Sub-Menu
Date
01.10.21
Set date
dd.mm.yy or yy/mm/dd
Time
16:45:00
Set time
hh:mm:ss
Press  to exit Sub-Menu, and return to Main-Menu
Auto power off
5 min.
Set auto power off
Off, 1, 3, 5, 10, 20, 30, 60
When enter item, current setting is highlited
Select  to toggle Minutes for Power Off
press  to set and return to Sub-Menu
Power save & lock
300 sec.
Set power save & lock
Off, 10, 30, 60, 100,
200, 300, 600
When enter item, current setting is highlited
Select  to toggle Seconds for Power Save & Lock
press  to set and return to Sub-Menu
Power save lock level
Max power save
Power save lock level
Min power save
Medium power save
Max power save
When enter item, current setting is highlited
Select  Min, Medium or Max for Power Save Level
press  to set and return to Sub-Menu
Auto zero tracking
1 div.
Set zero tracking
Off, 0.5, 1, 2, 3, 5, 10
Press  to exit Sub-Menu, and return to Main-Menu
Reset abs zero now?
NO
YES
When enter item, NO is highlited, press  to return
Select  YES
press  to cal abs. 0 and return to Sub-Menu
WARNING
Operate carefully in the
Service Menu!
Wrong settings can
render the LS3
inoperative!
Please note:
There is NO factory
reset option for the
CALIBRATION!
If the calibration process
is conducted with invalid
values or without a true
calibrated reference, the
LS3 wil no longer show
accurate loads.
A professional calibration
with a calibrated tensile
machine will be needed
to restore LS3 function.
Cal. abs. zero now?
NO
YES
When enter item, NO is highlited, press  to return
Select  YES
press  to cal abs. 0 and return to Sub-Menu
Start simple cal now?
NO
YES
When enter item, NO is highlited, press  to return
Select  YES
press  to start simple 2-point calibration
Start linear cal now?
NO
YES
When enter item, NO is highlited, press  to return
Select  YES
press  to start linear 3-point calibration
Calibrate acceler.
9.792 N/kg
Set cal. accel.
x.xxxx
User acceleration
9.807 N/kg
Set user accel.
x.xxx
Battery voltage
3.985 V
No setting,
value for information only.
Menu operation tip:
Press the PWR button at any time during item setting to
abort the setting operation, and return to the Sub-Menu
without saving any changes to the current item ;-)
From Sub-Menu press PWR to return to Main,
from Main-Menu press PWR to exit Menu.
AD internal code
3513
No setting,
value for information only.
Bluetooth MAC addr.
F0:F8:F2:6A:D1:8D
No setting,
value for information only.
Factory reset will delete ALL memory
and reset all log + user values!
Sure to continue?
NO
YES
When enter item, NO is highlited, press  to return
Select  YES
press  to reset the LS3 to factory defaults & erase memory.
NOTE: this will NOT reset the calibration values!!!
Press  to exit Sub-Menu, and return to Main-Menu
Press  to exit menu, and return to display screen
