1000 SERIES DIGIFLEX
MADE IN THE USA
LINK ELECTRONICS, INC.
SDI FRAME SYNCHRONIZER MODULE
DigiFlex 1190
FEATURES
10 Bit Processing
Digital Component Input
Digital Component Output
Analog Blackburst Reference
Infinite Window H & V Phasing
Freeze Last Good Frame/Field On Signal Loss
The LINK 1190 Frame Synchronizer represents
thestateoftheartindigitalsignalsynchronization.
It’s input is asynchronous component serial digital
video, which is de-serialized and written into the
on-board frame buffer.
The output is read from memory according to the
timebase of the analog blackburst reference
signal. Front panel horizontal and vertical phase
adjustments control the output timing relative to
the reference. When used in conjunction with our
A-to-D and D-to-A products, analog signals may
be synchronized to a house reference as well.
LED’s on the card edge provide monitoring of
Power, Video Presence Analog, Video Presence
Digital, NTSC/PAL, and H Lock Analog.
The 1190 can be used with the DigiFlex 1159,
1160, 1162, 1165, 1166, or 1167 to synchronize
composite or component analog signals to the
system.
The Link 1190 is used either ahead of the
conversion device or behind the conversion
device. This provides the user with a great deal of
system flexibility. There are over 24 system
configurations.
The 1190 provides for both PAL and NTSC
reference inputs. Timing for both Horizontal and
Vertical are controlled from the front panel. The
1190 operates in the 1000 series frame in any
module configuration. This is not a sub-module, it
is a full featured product.
When the input video is lost the output will either
be black or the last good frame of video, jumper
selectable. If the reference video is lost, the 1190
will use it’s own internal timebase with 2.5ppm
stability standard.
The 1190 has automatic NTSC/PAL digital
detectionontheinputsignal.Theanalogreference
input must match the input signal.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
Mounting Frame Options
1000 - Single Power Supply, Holds 11 Modules
1000/2 - Dual Power Supply, Holds 10 Modules
7200 - Mounting Frame, Holds 1 Module

1190030404 Model 1090
DIGIFLEX 1190
SDI FRAME SYNCHRONIZER MODULE
SPECIFICATIONS
INPUT
Number: ............................................................. ONE(1)
Standard: ...............................................SMPTE259M-C 270Mb/s
Configuration: ..................................................... Single-ended
Connector: ........................................................... 75ΩBNC
Impedance: ...........................................................75Ω±1%
Common Mode Rejection: ........................................ 30Vppupto60Hz
ReturnLoss: ............................................................>18dB
REFERENCE INPUT (Differential BNC Looping)
ReturnLoss: ........................................................... >35dB
Signal Level: ...................................................... 800mV±10%
Standard: ..........................................AnalogPALorNTSCComposite
OUTPUTS
Number: ............................................................ FOUR(4)
Standard: ........................................................ SameasInput
Connector: ........................................................... 75ΩBNC
Impedance: ...........................................................75Ω±1%
ReturnLoss: ............................................................>20dB
BitResolution:.......................................................... 10BIT
Signal Level ....................................................... 800mV±10%
Rise/FallTime ..................................................... 750ps±250ps
FRONT PANEL CONTROLS, INDICATORS
Power:.............................................................Green LED
H. Timing, Rotary Encoder: ..........................................InfiniteWindow
V. Timing, Rotary Encoder: ..........................................InfiniteWindow
Video Presence Analog,: ............................................. BiColorLED
Video Presence Digital .............................................. BiColorLED
NTSC/PAL: ....................................................... BiColorLED
H.Lock:.......................................................... BiColorLED
Free Run/Internal Frequency .......................................... 20TurnPot
ENVIRONMENTAL
Temperature:................................................. 0°to50°CAmbient
Humidity: .............................................10%to90%non-condensing
Power:.............................................................. 8.5Watts
MECHANICAL:
Height:............................................. 3.2Inches
Width: .................................................1Inch
Length: .............................................10Inches
Weight: .................................................8Oz
LINK ELECTRONICS, INC.
2137 Rust Ave.
Cape Girardeau, MO 63703
Phone: [phone]
FAX: [phone]
PROFESSIONAL SERIES--
modular system products--by LINK
Rear Cell I/O
IN. SDI Input
R1&2. Ref.In
1. SDI Out
2. SDI Out
3. SDI Out
4. SDI Out
