1000 SERIES DIGIFLEX
MADE IN THE USA
LINK ELECTRONICS, INC.
SDI TO ANALOG COMPOSITE & Y/C
DigiFlex 1159
FEATURES
10 Bit Processing
SDI Serial Component Digital Input
NTSC or PAL Input
Two NTSC/PAL Outputs
One Y/C (S-Video) Output
Composite Sync Output
The LINK 1159 converts SDI serial component
digital, 10 bit, to analog (NTSC/PAL) composite
video. The 1159 takes advantage of the latest
technology to provide high-performance
conversion from digital SDI to analog NTSC or
PAL composite video. The digital input is non-
loopingandoffersexcellentreturnloss.Error-free
transmission is provided for input cable lengths
exceeding 500ft. Serial digital input is confirmed
by a signal presence LED.
Two NTSC analog outputs are available on the
rear panel for distribution purposes. In addition,
thereisaY/CpairofBNC connectors forS-Video
distribution.
FEATURES
Color Bar Select
CCIR 601 Compliant
Set-up On/Off
Select NTSC/PAL
Fault Indication
Passes Line 21
ThreeswitchesonthefrontpanelselectColorBars,
Set-upOn/OffandNTSC/PAL.Line21ispreserved
forclosedcaption.TheDigiFlex1159isdesignedto
reside in LINK's 1000-Series frame. Thisframe can
house up to 11 modules of various types. A
redundant power supply is available for dual power
supply operation. A second power cord is a part of
the redundant power supply for separate AC circuit
breakers.
The family of DigiFlex 1000 series modules will
operate in the mounting frame in any configuration.
The specific rear cell matches the module and in
some cases the rear cell detects the desired output
signal.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]

REARCELL 1027
1159/110502
Rear Cell Outputs
0. Input
1. Sync
2. Composite
3. “Y”
4. “C”
5. Composite
DIGIFLEX 1159 SDI TO ANALOG COMPOSITE
SPECIFICATIONS
SERIAL DIGITAL VIDEO INPUT:
Standard: ..................................................... 270Mb/s, SMPTE 259M-C
Impedance: ..................................................................... 75Ω
ReturnLoss: .................................................................. >18dB
Signal Level ............................................................... 800mV±1%
CMR:..............................................................30Vp-p,upto60Hz
Equalization: ..................................................... Automaticupto>30dB
Connectors: .................................................................... BNC
ANALOG OUTPUTS:
Number of Video Outputs: ................................................ 2NTSCorPAL
........................................................ 1Y/C(TwoBNCConnectors)
CompositeSync:................................................... 0.3Vp-p,Terminated
Impedance: ..................................................................... 75Ω
ReturnLoss: ...........................................................>38dB to 5MHz
Signal Level: .................................................. 1.0Vp-p±10%,Adjustable
DC Offset: ...................................................................±100mV
Frequency Response: ................................................. >0.5dB@4.2MHz
DifferentialGain: ................................................................ 1.0%
DifferentialPhase:................................................................ 0.5°
Chroma-LumaDelay: ........................................................... ±10nS
Signal to Noise: .........................................................>65dB to 5MHz
FRONT CONTROLS & INDICATORS:
Power:................................................................... Green LED
No Signal: .................................................................. RedLED
Test: .............................................................. ColorBars,Select
Set-up:....................................................................... On/Off
Standard: ................................................................. NTSC/PAL
ENVIRONMENTAL:
Temperature:........................................................ 0°to50°CAmbient
Humidity:.................................................... 0%to90%non-condensing
Power:.....................................................................3.5Watts
MECHANICAL:
Height:......................................................................3.2Inch
Width: ...................................................................... 1.0Inch
Length ...................................................................... 10Inch
Weight: ..................................................................... 7.25Oz
LINK ELECTRONICS, INC.
2137 Rust Avenue
Cape Girardeau, MO 63703-7668
Phone: [phone]
FAX: [phone]
PROFESSIONAL SERIES--
modular system products--by LINK
