Link LKW300-21A3 User manual

LKW300-21A3
User Manual
V1.0

i
Contents
1Introduction ........................................................................................................ 1
1.1 Packing List ........................................................................................... 1
1.2 Safety Precautions ................................................................................ 1
1.3 LEDs and Interfaces .............................................................................. 2
1.4 System Requirements ........................................................................... 4
1.5 Features ................................................................................................ 5
2Hardware Installation ......................................................................................... 7
3About the Web Configuration ........................................................................... 10
3.1 Access the Router ............................................................................... 10
3.2 Wizard ................................................................................................. 11
3.3 Status................................................................................................... 25
3.3.1 System...................................................................................... 26
3.3.2 LAN........................................................................................... 26
3.3.3 WLAN ....................................................................................... 26
3.3.4 WAN ......................................................................................... 27
3.3.5 Port Mapping ............................................................................ 27
3.3.6 Statistics.................................................................................... 28
3.3.7 ARP .......................................................................................... 29
3.4 Network ............................................................................................... 30
3.4.1 LAN........................................................................................... 30
3.4.2 WAN ......................................................................................... 39
3.4.3 WLAN ....................................................................................... 47
3.5 Service................................................................................................. 60
3.5.1 DNS .......................................................................................... 60
3.5.2 Firewall ..................................................................................... 63
3.5.3 UPnP ........................................................................................ 67
3.5.4 IGMP Proxy .............................................................................. 68
3.5.5 TR-069...................................................................................... 70
3.5.6 ACL........................................................................................... 72
3.6 Advance............................................................................................... 73
3.6.1 Routing ..................................................................................... 73
3.6.2 NAT........................................................................................... 76
3.6.3 Port Mapping ............................................................................ 83

ii
3.6.4 IP QoS ...................................................................................... 84
3.6.5 SNMP ....................................................................................... 86
3.6.6 Others ....................................................................................... 88
3.7 Admin .................................................................................................. 89
3.7.1 Commit/Reboot......................................................................... 89
3.7.2 Update ...................................................................................... 90
3.7.3 System Log............................................................................... 92
3.7.4 Password .................................................................................. 92
3.7.5 Time.......................................................................................... 93
3.7.6 Logout....................................................................................... 94
3.8 Diagnostic............................................................................................ 95
3.8.1 Ping Diagnosis.......................................................................... 95
3.8.2 Traceroute Diagnosis................................................................ 96
3.8.3 OAM Loopback ......................................................................... 97
3.8.4 ADSL Statistics ......................................................................... 97
3.8.5 Diag-Test................................................................................... 98

1
1 Introduction
The LKW300-21A3 is an ADSL access device that supports multiple line modes. The
device provides high-speed ADSL broadband connection to the Internet or Intranet
for high-end users, such as net cafes and office users. The device provides high
performance access to the Internet, downlink up to 24 Mbps and uplink up to 1 Mbps.
The device supports WLAN access. It can connect to the Internet through a WLAN
AP or WLAN device. It complies with IEEE 802.11, 802.11b/g/n specifications, WEP,
WPA, and WPA2 security specifications.
1.1 Packing List
Wireless router x1
Power adapter (DC) x1
ADSL splitter x 1
Quick installation guide x1
RJ45 Cable x1
RJ11 Cable x1
CD (user manual) x1
Warranty card X1
1.2 Safety Precautions
Follow the following instructions to prevent the device from risks and damage caused
by fire or electric power:
Use volume labels to mark the type of power.
Use the power adapter packed within the device package.
Pay attention to the power load of the outlet or prolonged lines. An
overburden power outlet or damaged lines and plugs may cause electric
shock or fire accident. Check the power cords regularly. If you find any
damage, replace it at once.
Proper space left for heat dissipation is necessary to avoid damage caused
by overheating to the device. The long and thin holes on the device are

2
designed for heat dissipation to ensure that the device works normally. Do
not cover these heat dissipation holes.
Do not put this device close to a place where a heat source exists or high
temperature occurs. Avoid the device from direct sunshine.
Do not put this device close to a place where it is over damp or watery. Do
not spill any fluid on this device.
Do not connect this device to any PCs or electronic products, unless our
customer engineer or your broadband provider instructs you to do this,
because any wrong connection may cause power or fire risk.
Do not place this device on an unstable surface or support.
1.3 LEDs and Interfaces
Front Panel
Figure 1 Front Panel
The following table describes the LEDs of the device.
LEDs Color Status Description
On The initialization of the device is
successful.
Power Green
Off The device is powered off.
On
Connection between the device and
the physical layer of the office end is
established.
Blinks
slowly No signal is being detected.
ADSL Green
Blinks
quickly
The device is handshaking with the
physical layer of the office end.

3
LEDs Color Status Description
On
The Internet connection is normal in
the routing mode (for example, PPP
dial-up is successful), and no Internet
data is being transmitted.
Blinks Internet data is being transmitted in
the routing mode.
Green
Off The device is in the bridge mode.
Internet
Red On
The Internet connection fails after
successful synchronization in the
routing mode (for example, PPP
dial-up is failed).
On The LAN connection is normal and
activated.
Blinks
Data is being transmitted in the LAN
or Internet data is being transmitted
in the bridge mode.
LAN 4/3/2/1 Green
Off The LAN interface is not connected.
On The WLAN connection has been
activated.
Blinks Data is being transmitted in the
WLAN.
WLAN Green
Off The WLAN connection is not
activated.
Blinks WPS is enabled, and is waiting for
client to negotiate.
WPS Green
Off WPS is disabled.

4
Rear Panel
Figure 2 Rear panel
The following table describes the interfaces of the device.
Interface Description
WPS/WLAN
Press the button and hold it for less than 1 second to enable
WLAN.
If WLAN is enabled, press the button for more than 3
seconds, to initialize WPS negotiation.
ADSL RJ-11 interface, for connecting to the ADSL interface or a
splitter through a telephone cable.
LAN1/2/3/4 RJ-45 interface, for connecting to the Ethernet interface of a
computer or the Ethernet devices through an Ethernet cable.
Power Power interface, for connecting to the power adapter
Reset
This button is used to restore the factory default settings of
router. Keep the device powered on, and insert a needle into
the hole for more than 3 seconds, then release it. The device
restores the factory default settings of router.
1.4 System Requirements
Recommended system requirements are as follows:
A 10/100 base-T Ethernet card is installed on your PC
A hub or Switch. (connected to several PCs through one of Ethernet
interfaces on the device)

5
Operating system: Windows 98SE, Windows 2000, Windows ME, Windows
XP
Internet Explorer V5.0 or higher, Netscape V4.0 or higher, or Firefox 1.5 or
higher
1.5 Features
The device supports the following features:
Various line modes
External PPPoE dial-up access
Internal PPPoE/PPPoA dial-up access
1483Briged/1483Routed/MER/IPoA access
Multiple PVCs (up to eight) and these PVCs can be isolated from each other
A single PVC with multiple sessions
Multiple PVCs with multiple sessions
802.1Q and 802.1P protocol
DHCP server
NAPT
Static route
Firmware upgrading through Web, TFTP, or FTP
Resetting to the factory defaults through Reset button or Web
DNS
Virtual server
DMZ
Two-level passwords and usernames
Web interface
Telnet CLI
System status display
PPP session PAP/CHAP
IP filter
IP quality of service (QoS)
Remote access control
Line connection status test
Remote managing through Telnet or HTTP
Backup and restoration of configuration file

6
Ethernet interface supporting crossover detection, auto-correction, and
polarity correction
Universal plug and play (UPnP)

7
2 Hardware Installation
To connect the device, do as follows:
Step 1 Connect the ADSL interface of the device and the Modem interface of
the splitter through a telephone cable. Connect the phone to the Phone
interface of the splitter through a cable. Connect the incoming line to the
Line interface of the splitter.
The splitter has three interfaces:
Line: Connect to a wall phone jack (RJ-11 jack).
Modem: Connect to the ADSL jack of the device.
Phone: Connect to a telephone set.
Step 2 Connect the LAN interface of the device to the network card of the PC
through an Ethernet cable (MDI/MDIX).
INote:
Use the twisted-pair cables to connect with the hub or switch.
Step 3 Plug one end of the power adapter to the wall outlet and connect the
other end to the Power interface of the device.
Connection 1
Figure 3 shows the application diagram for the connection of the router, PC, splitter
and the telephone sets, when no telephone set is placed before the splitter.

8
Figure 3 Connection diagram (Without connecting telephone sets before the splitter)
Connection 2
Figure 4 shows the connection when the splitter is installed close to the router.
Figure 4 Connection diagram (Connecting a telephone set before the splitter)
Note:
When connection 2 is used, the filter must be installed close to the telephone
cable. See Figure 4. Do not use the splitter to replace the filter.

9
Installing a telephone directly before the splitter may lead to failure of connection
between the device and the central office, or failure of Internet access, or slow
connection speed. If you really need to add a telephone set before the splitter, you
must add a microfilter before a telephone set. Do not connect several telephones
before the splitter or connect several telephones with the microfilter.

10
3 About the Web Configuration
This chapter describes how to configure the router by using the Web-based
configuration utility.
3.1 Access the Router
The following is the detailed description of accessing the router for the first time.
Step 1 Open the Internet Explorer (IE) browser and enter http://192.168.1.1.
Step 2 In the Login page that is displayed, enter the username and password.
Figure 5 Login window
Note:
The username and password of the super user are admin and admin.
The username and password of the common user are user and user.
If you log in as a super user, you can check, configure and modify all the settings.

11
If you log in as a common user, you can check the status of the router, but can not
configure the most of the settings.
Note:
In the Web configuration page, you can click Apply Changes to save the
settings temporarily. If you want to save the settings of this page permanently,
click save of Attention that appears on the left pane of the Web page after the
configuration.
3.2 Wizard
When subscribing to a broadband service, you should be aware of the method by
which you are connected to the Internet. Your physical WAN device can be either PPP,
ADSL, or both. The technical information about the properties of your Internet
connection is provided by your Internet Service Provider (ISP). For example, your ISP
should inform you whether you are connected to the Internet using a static or dynamic
IP address, and the protocol that you use to communicate on the Internet.
The Wizard page guides fast and accurate configuration of the Internet connection
and other important parameters. The following sections describe these various
configuration parameters. Whether you configure these parameters or use the default
ones, click Next to enable your Internet connection. In the navigation bar, choose
Wizard. The page shown in the following figure appears.

12
Figure 6 Web account setup
Enter the correct password and then click Next. The page shown in the following
figure appears. In this page, you can set the system time and Network Time Protocol
(NTP) server.
Figure 7 Time zone setup
The following table describes the parameters in this page.
Field Description
State
You can disable or enable NTP function. You have to
enable it if you want to configure the parameters in this
page.
NTP Server Enter the IP address of the specified time server manually.
Interval
Set the interval that the router obtains the time from the
time server. That is, the interval that the router verifies the
time with the server.
Time Zone Choose the time zone of your country.
GMT time Display the Greenwich mean time.
After finishing the settings, click Next. The page shown in the following figure
appears.

13
Figure 8 WAN interface setup
The router provides 6 types of WAN connection protocols. They are PPPoE, PPPoA,
1483 MER:DHCP, 1483 MER:Static IP,1483 Bridged, and.1483 Routed. The
following wizard settings will vary depending on the protocol you select.
PPPoE/PPPoA
If you select the PPPOE protocol, the page shown in the following figure appears.

14
Figure 9 WAN interface setup (PPPoE)
The following table describes the parameters in this page:
Field Description
Country Select the country from the drop-down list of Country.
ISP
Select the ISP according to the country from the drop-down list. If
you do not find the ISP that matches the country, you can select
Others.
Protocol Select PPPoE.
Connection
Type
You can select VC-Mux or LLC.
VPI Virtual path between two points in an ATM network. Its valid value
range is from 0 to 255.
VCI
The virtual channel between two points in an ATM network, ranging
from 32 to 65535 (0 to 31 is reserved for local management of ATM
traffic).
User name The correct user name that your ISP provides to you.
Password The correct password that your ISP provides to you.
Confirm
Password
Enter the password again.
After finishing the settings, click Next. The page shown in the following figure
appears.
Figure 10 WLAN interface setup (PPPoE)

15
The following table describes the parameters in this page.
Field Description
WLAN
Interface
You can choose Enable or Disable. By default, WAN
interface is enabled.
You need to enable WAN interface, and then you can
set the parameters in this page.
Band Choose the working mode of the router.
SSID
The service set identification (SSID) is a unique name to
identify the router in the wireless LAN. Wireless stations
associating to the router must have the same SSID.
Enter a descriptive name that is used when the wireless
client connecting to the router.
Encryption
Configure the wireless encryption mode. You can
choose None,WEP,WPA (TKIP), WPA (AES), WPA2
(AES), WPA2 (TKIP), or WPA2 Mixed.
Wired equivalent privacy (WEP) encrypts data
frames before transmitting over the wireless
network.
Wi-Fi protected access (WPA) is a subset of the
IEEE802.11i security specification draft.
WPA2 Mixed is the collection of WPA and WPA2
encryption modes. The wireless client establishes
the connection between the router through WPA or
WPA2.
Key differences between WPA and WEP are user
authentication and improved data encryption.
After finishing the settings, click Next. The page shown in the following figure
appears.

16
Figure 11 Configuration summary (PPPoE)
In this page, click Finish to complete the wizard configuration of PPPoE. You can
modify the settings by clicking the < Back button if necessary. Click Reset to cancel
the settings.
Note:
If the WAN connection protocol is set to PPPoA, the configuration steps are
similar to that of PPPoE. For the parameters in these pages, refer to the
parameter description of PPPoE.
1483 MER: DHCP
If you select the 1483 MER: DHCP protocol, the page shown in the following figure
appears.

17
Figure 12 WAN interface setup (1483 MER:DHCP)
The following table describes the parameters in this page.
Field Description
Country Select the country from the drop-down list of Country.
ISP
Select the ISP according to the country from the
drop-down list. If you do not find the ISP that matches
the country, you can select Others.
Protocol Select 1483 MER: DHCP.
Connection
Type
You can select LLC or VC-Mux.
VPI Virtual path between two points in an ATM network. Its
valid value range is from 0 to 255.
VCI
The virtual channel between two points in an ATM
network, ranging from 32 to 65535 (0 to 31 is reserved
for local management of ATM traffic).
After finishing the settings, click Next. The page shown in the following figure
appears.
