Link2Home RF201R-UL User manual

Instruction Manual
Remote control
Item no. Receiver RF201R-UL and Transmitter RF201T1
A. Functions
1. Learning code system
2. Manual button on each receiver for ON/OFF control.
3. All ON/All OFF control
4. Countdown function with 1, 2, 3, 4 hours
5. Random function for security use
B. Diagram
No.
Description
Function
1
ALL ON
ALL OFF
Switch ON/OFF all the paired receivers
2
ON OFF
Switch ON/OFF the paired receiver
3
Countdown
Press the button from 1-4 hours, the paired receivers will switch
off after the set countdown time
4
Random
Press the button, the paired receivers will enter the random
mode, switch ON/OFF randomly
5
Manual
Button
Switch ON/OFF the receiver;
press over 3 seconds on transmitter to pair with selected receiver
or delete paired transmitters.
6
LED indicator
LED ON/OFF indicates receiver power ON/OFF; LED flashes
means receiver is under pairing mode; indicator countdown hours
1
2
3
4
6
5

C. Instruction
1. Pairing
a) Plug the receiver into an outlet, the LED indicator flashes (under pairing mode), press the ON or
OFF button on the transmitter (select one from 1-5, number means different channels).
If the LED is not under pairing mode, press the manual button over 3 seconds to turn the
receiver into pairing mode.
b) LED stop flashing, pairing success.
c) Pairing mode can last for 15 seconds, if no operation on transmitter after 15 seconds, the
receiver will exist the pairing mode, LED stops flashing.
2. Control
a) Press ON/OFF button on the transmitter to switch the related channel's receiver ON/OFF
b) Press the manual button on the receiver to switch this receiver status.
c) Press ALL ON/OFF button on the transmitter to switch all the paired receivers' status
d) Press the button from 1-4 hours, the paired receivers will switch off after the set countdown time,
for example, user set a 3 hour countdown, the first two quarter LED will turn on, and the third
quarter LED will flash
e) Press the button, the paired receivers will enter the random mode, switch ON/OFF randomly
D. Caution
1. Do follow product parameter for functionally use
2. Product is non-waterproof, require using in dry environment
3. When the battery of transmitter is in low voltage, it influences product transmitting distance
E. Specification
Receiver battery: 125VAC, 60Hz
Transmitter battery: CR2032L DC3V
Receiver maximum capacity load: 1875W (Resistive), 1250W (Tungsten)
Frequency: 433 MHz
Distance: Up to 30 meters in open area
FCC CAUTION:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.

—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
IC WARNING:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit
pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003.
Cetappareilnumérique de la classe B estconformeà la norme NMB-003 du Canada.
Les communications effectuées au moyen de cet appareil ne sont pas nécessairement protégées des
indiscrétions.
the device is compliance with RF exposure guidelines, user can obtain Canadian information on RF
exposure and compliance.
Le présentappareilestconforme
Après examen de ce materiel aux conformitéou aux limitesd'intensitè de champ RF,
Les utilisateurspeuventsurl'exposition aux radiofréquenceset la conformité and compliance d'acquérir.
Manufacturer :
Manufacturer: Ningbo EverFlourish Smart Technology Corp. Ltd.
Adress: 77 Wuxiang East Road, Yinzhou, Ningbo, 315111, P.R.China
