70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. i
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
INDEX
Pág.
1.- SYSTEM DESCRIPTION: CHARACTERISTICS………………………………………………………..............1
2.- SAFETY INSTRUCTIONS…………………………………………………………….........................................4
2.1.- GENERALS………………………………………………………………………… .......................................... 4
2.2.- HOISTING MACHINERY……………………………………………………………........................................ …4
2.3.- FCC RECOMMENDATIONS……………………………………………………………………………….............. 5
3.- INSTALLATION / SYSTEM ASSEMBLY………………………………………................................................5
3.1.- TRANSMITTER……………………………………………………….............................................…………....5
3.2.- RECEIVER………………………………………………………………………… ......................................... ..6
3.3.- STARTING UP………………………………………………………………................................................... ..7
4.- TRANSMITTERS..........…............................................................................................................................8
4.1.- TYPE OF TRANSMITTERS……………………………………………………… ........................................... …8
4.2.- MAINTENANCE /TROUBLESHOOTING………………………………………… ............................................ …9
5.- RECEIVERS…………………………….......................................................................................................10
5.1.- TYPE OF RECEIVERS………………………………………………………………………………………….. .. 10
5.2.- MAINTENANCE /TROUBLESHOOTING…………………………………………………………………………... 11
6.- RADIO REMOTE SYSTEM FUNCTIONALITIES…...…………………………………………………............12
6.1.- GENERALS……..………………………………………………………………………………………............. 12
6.2.- BATTERY LEVEL INDICATION…..……………………………………………………………………………...... 12
6.3.- BASE CHANNEL CHANGING (T70MG10;T70MH3D;T70MH3;T70MH2 TRANSMITTER MODELS)...……... . ...13
6.4.- ID RELEASING (T70MG10;T70MH3D;T70MH3;T70MH2 TRANSMITTER MODELS)…………………........ ..15
6.5.- AUTO TEACHING MODE (T70MG10;T70MH3D;T70MH3;T70MH2 TRANSMITTER MODELS)………..…... ... 15
6.6.- LOST TRANSMITTER SEARCHING MODE (T70MG10;T70MH3;T70MH2 TRANSMITTER MODELS)………... ... 17
6.7.- PROGRAMMING PARAMETERS(T70MG10;T70MH3;T70MH2 TRANSMITTER MODELS)………..……..….. ... 18
6.8.- PROGRAMATION (T70MH3D TRANSMITTER MODEL)……………….……………………..…………….…..... 20
6.8.1.- PROGRAMMING MODE BLOCK DIAGRAM…………….……………………………………………….... 21
6.8.2.- PROGRAMMABLE PARAMETERS…………………………………..……………………………....... ... 23
6.8.3.- OUTPUT PROGRAMMING MODE (TELE ALIGNED)…………………….……………………………... ... 24

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 1
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
1.- SYSTEM DESCRIPTION: CHARACTERISTICS
The systems are based on several handheld transmitter models (with the possibility of single step keypads
by function, known as generic transmitter, or double step keypads by function, known as hoisting transmitter) and
several receiver models, available with relays or static outputs –PWM outputs-.
The radio, integrated in the PCB of the transmitter and the receiver, is ready to work in different ISM bands,
according to different models.
The transmitter can be powered by alkaline batteries, type AA or rechargeable NiMH AA type batteries.
Applications are many and varied, depending on the emitter-receiver combination; basically the applications’
areas are as follows:
- Mobile applications (on board systems)
- Industrial hoisting applications (no EC)
- Other industrial hoisting applications (Chain hoists / Cat. 3 ;EN-954-1: EC)
- Other applications
SYSTEM CHARACTERISTICS
Transmitters: T70MG10-T70MH3-T70MG10D-T70MH3D Specifications
Available frequencies (ISM bands) 915MHz
870MHz/433MHz
419MHz
RF Power (ERP) < 1mW 915MHz
< 5mW 870 MHz; <10 mW 433MHz
< 10mW 419MHz
Modulation type FSK 4800 bps and 7.200 bps
Protection IP65
Channel bandwidth 25KHz
Number of IDs 64K per band
Response time < 150ms
Working channel selection Automatic at transmitters’ start-up
Display option (for Remote Tele-Alignment) 2 lines x 12 characters / line + icons
Antenna Printed circuit board integrated (standard)
Weight 250gr
Dimensions Length = 160mm / Wide = 75mm / Height = 45mm
Rechargeable batteries Alkaline type AA 1,5V 2600mAh (-10ºC / +50ºC)
Commercial Range
NiMH type AA 1,2V 1200mAh (-20ºC / +70ºC)
Industrial Range
Battery life >12h (100% duty cycle) Alkalines 2500mAh
>6h (100% duty cycle) NiMH 1200mAh
EEPROM Internal
Hoisting Safety Standards EN 954-1 Cat. 3 (hoisting models)
Active STOP (time) < 500ms (Cat.3 CE)
Passive STOP (time) < 2s (Cat.3 CE)
Operating temperature range -20ºC / +70ºC
Storage temperature range (24h) -25ºC / +75ºC
Storage temperature range –long periods- -25ºC / +55ºC
Signaling (transmitters without display) 1 bicoloured LED (RUN labeled)
Acoustic signaling Internal buzzer
T70MG10: Generic keypad transmitter (without display) 10 functions max. (1 step) + ON/OFF function
T70MH3: Hoisting keypad transmitter (without display) 6 functions max. (2 steps) + 2 AUX (1 step) + START
+ ON/STOP functions
T70MG10D: Generic keypad transmitter (with display) 10 functions max. (1 step) + ON/OFF function
T70MH3D: Hoisting keypad transmitter (with display)
6 functions max. (2 step) + START + ON/STOP
function

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 2
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
R70MP10: Receiver with PWM outputs (10 outputs) Specifications
Available frequencies (ISM bands) 915MHz
870MHz/433MHz
419MHz
Power supply 9-35V DC
Number of outputs 10 MOSFET (PWM)
Protection IP65
Antenna Printed circuit board integrated (standard)
Working channel selection Automatic at transmitters’ start-up
Weight 430 gr.
Dimensions Length = 151mm / Wide = 129mm (160mm with PG) /
Height = 61mm
EEPROM Internal
Status signaling MultiLED: 7 LED visible externally
Conexions Plug-In terminals: inputs/outputs with PG cable glands
1) PG11 model power supply cable gland
2) PG16 model outputs cable gland
Maximum current per output 5A
Maximum current output (total) 15A
PWM outputs frequency range 30 – 300Hz (5%+-95%)
Output accuracy 16 bits (power supply range)
Electrical input protection Fuse protected
Electrical output protections Polarity inversion / Shortcircuit
Operating temperature -20ºC / +70ºC
Storage temperature (24h) -25ºC / +75ºC
Storage temperature –long periods- -25ºC / +55ºC
Disconnecting security A MOSFET transistor connected with the positive value
of the power supply provides security functions.
R70MR11: Receiver with relays outputs (11 outputs) Specifications
Available frequencies (ISM bands) 915MHz
870MHz/433MHz
419MHz
Power supply (depending on the model) 24/48V AC 50/60Hz (+20% / -30% Vin)
115/230V AC 50/60Hz (+20% / -30% Vin)
Number of outputs 11 RELAYS MODEL (No valid for CE hoisting
applications) 11 relays outputs.
Protection IP65
Antenna Printed circuit board integrated (standard).
Working channel selection Automatic at transmitters’ start-up
Weight 980 grs.
Dimensions Length = 205mm / Wide = 156mm / Height = 62mm
EEPROM Internal
Status signaling MultiLED: 7 LED visible externally
Conexions Plug-In terminals. Inputs/outputs with PG 21 (25 poles
maximum) cable gland.
Maximum current over resistive load 8A
Operating temperature range -20ºC / +70ºC
Storage temperature (24h) -25ºC / +75ºC
Storage temperature –long periods- -25ºC / +55ºC

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 3
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
R70MR06: Receiver with output relays (6 outputs) Specifications
Available frequencies (ISM bands) 915MHz
870MHz/433MHz
419MHz
Power supply (depending on the model) 24V AC 50/60Hz (+20% / -30% Vin)
48V AC 50/60Hz (+20% / -30% Vin)
115V AC 50/60Hz (+20% / -30% Vin)
230V AC 50/60Hz (+20% / -30% Vin)
Number of outputs 06 RELAYS MODEL (CE hoisting applications / Cat.3
EN-954-1) 06 relays outputs (3 Hoist / 3 Travel)
Protection IP65
Antenna Printed circuit board integrated (standard).
Working channel selection Automatic at transmitters’ start-up
Weight 640 grs.
Dimensions Length = 151 mm / Wide = 129mm / Height = 61mm
EEPROM Internal
Status signaling MultiLED: 7 LED visible externally
Conexions Plug-In terminals: inputs/outputs with PG16 model
output cable gland.
Maximum current over resistive load 6A
Operating temperature range -20ºC / +70ºC
Storage temperature (24h) -25ºC / +75ºC
Storage temperature –long periods- -25ºC / +55ºC

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 4
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
2.- SAFETY INSTRUCTIONS
2.1.- GENERALS
These instructions must be read carefully. This will allow you to install, use and maintain
this device in a proper state, reducing the risk of incorrect use.
Do not install the equipment in machines for the elevation of people or in explosive
atmospheres.
Any failure to comply with that set out in this manual will create a hazard, for which
reason the following must be respected:
¾Ensure that the installation is carried out by trained, competent staff.
¾The safety rules of the work area and of all competent authorities must be respected every
time.
¾Ensure that this manual is permanently available to the operator and to the person in charge
of maintenance.
¾Keep the transmitter out of the reach of unauthorised people.
¾At the start of each day, check the correct working of the STOP button and the other safety
devices of the machine.
¾In the event of any anomaly, use the STOP button.
¾If there are several radio remote systems working in the same area, ensure that the used
transmitter corresponds to the machine that is being controlled. Identify the machine which
the transmitter corresponds to.
¾Carry out regular checks and preventive maintenance.
¾In the case of repairs, only use original spare parts.
¾Never modify the device without prior study and approval of the manufacturer.
¾Never use the device with a power supply other than the indicated.
¾Never allow the device to be used by unqualified people.
¾After being used, do not leave the transmitter in service without having pressed the STOP
button in order to prevent accidental operations.
¾Do not use the device without visibility.
¾Avoid knocking or dropping the set.
¾Do not use the set if failure is detected.
2.2.- HOISTING MACHINES
¾Ensure that the machine is fully halted throughout the estimated assembly time; clear the
work area and use safety clothing.
¾In the case of overhead cranes, park the crane and position stop-ends (if these are not
available use appropriate signs) at a suitable distance in order to prevent collision with other
cranes in the same area.
¾Verify the power supply and turn off the main contactor.
¾Remember that the receiver has at least, more than one circuit under voltage.
¾Even if the power supply is disconnected, there is still a risk of electrical discharges.
¾Never forget to connect the ground cable.
¾Use fireproof cables for the electrical connections.
¾Check that the input power supply corresponds to the right voltage of the receiver.
¾Be cautious: it may occur that the equipment has not been connected properly, which can
result in unforeseen movements during the start-up.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 5
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
2.3.- FCC RECOMMENDATIONS (only valid for equipment that works in 915MHz ISM band)
3.- INSTALATION / SYSTEM ASSEMBLY
3.1.-TRANSMITTER
Proceed to open the transmitter’s battery compartment and introduce the supplied batteries into the battery
housing (2 AA type 1,5V alkaline batteries) respecting the +/- polarity, indicated inside the battery housing.
1
2
3
Abrir
Open
Cerrar
Close
Abrir
Open
Cerrar
Close
Cerrar
Close
Abrir
Open
2
3
1 “Open” the safety lock: rotate in the direction
indicated by the arrow.
“Open” lock tab: press in the direction
indicated by the arrow.
“Open” battery housing cover: rotate in the
direction indicated by the arrow.
Procedure for o
p
enin
g
the mechanism of the batter
y
housin
g
:
“Close the safety lock”: rotate in the
direction indicated by the arrow.
1
“Close lock tab”: press in the direction
indicated by the arrow.
2
“Close” battery housing cover: rotate in the
direction indicated by the arrow.
3
Procedure for closing the mechanism of the
battery housing:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
To comply with FCC RF exposure compliance requirements, this device and its antenna must
not be co-located with, or operating in conjunction with, any other antenna or transmitter.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rul.
These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 6
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
3.2.-RECEIVER
Find an easy access location for the receiver, free from obstacles, in order to facilitate the reception of the
transmitter’s radio signal, and far away from elements which can produce intense electric disturbance.
R70MP10 and R70MR06 models receiver dimensions:
R70MR11 model receiver dimensions:

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 7
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
3.3.- STARTING UP.
RECEIVERS
Proceed to connect the power supply and the output connections. Use the plug-in terminals and the
connection block diagram provide in this manual (page 11).
Transmitters without display: RUN signalling LED in solid green colour. In transmitters with
LCD display: “WORKING OK”; if the transmitter is the owner of the receiver.
Turning on the T70MG10 transmitter model:
1- Insert the transmitter’s batteries (2 AA type batteries).
2- Press ON/OFF function. The transmitter remains powered.
3- Enter the key code: press simultaneously “7” + “8” functions.
4- Press “10” function. Equivalent to the START function.
5- Transmitter in ON state (solid green LED).
Turning on the T70MH3 / T70MH2 transmitter model:
1- Insert the transmitter’s batteries (2 AA type batteries).
2- Press ON/STOP function. The transmitter remains powered.
3- Enter the key code: press simultaneously ◄►functions.
4- Press START.
5- Transmitter in ON state (solid green LED).
Turning on the T70MH3D transmitter model:
1- Insert the transmitter’s batteries ( 2 AA type batteries).
2- Press ON/STOP function. LCD display message: “PLEASE WAIT”
3- Enter the key code: press simultaneously ◄►functions.
LCD display message: “PRESS START”
4- Press START.
5- Transmitter in ON state. LCD display message: “WORKING OK”
TRANSMITTERS:
LED’s si
g
nalin
g
in correct o
p
eratin
g
mode:
1) No radio link with the transmitter:
“Power”: solid green.
“Hard-OK”: solid green.
“Signal”: Blinking if there are transmitters near and
in the same band.
2) There is a radio link with the transmitter:
“Power”: solid green.
“Hard-OK”: solid green.
“Signal”: green blinking fast.
“Data”: green blinking fast.
“ID”: green blinking fast.
3) With STOP relay activated and active outputs:
“Power”: solid green.
“Hard-OK”: solid green.
“Signal”: green blinking fast.
“Data”: green blinking fast.
“ID”: green blinking fast.
“Relay”: solid green if the STOP relay is activated.
“Order”: green (variable intensity), if one or more PWM outputs are activated.
“Order”: green (fixed intensity), if at least one or more relay outputs are activated.
T70MG10
T70MH3
T70MH3D
T70MH2

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 8
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
4. – TRANSMITTERS
4.1. – Transmitters’ MODELS
The models with LCD dis
p
la
y
are alwa
y
sre
q
uired for Tele-
A
li
g
nment
p
ur
p
oses.
Generic: máx. 10 functions
(1 step) + ON/OFF (without
display)
Hoisting: máx. 6 functions
(2 steps) + 2 AUX: A1 and A2
(1 step) + START + ON/STOP
Hoisting: máx. 6 functions
(2 steps) + START +
ON/STOP (with display)
Hoisting (Cat. 3 EN-954-1): máx. 4
functions (2 steps) + START +
ON/STOP (without display)
T70MG10 T70MH3 T70MH3D T70MH2

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 9
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
4.2.- MAINTENANCE / TROUBLE SHOOTING GUIDELINE
TRANSMITTER’S LED SIGNALLING
Status
Correct operating
mode
Activated
function
Low battery
Lost transmitter
frame found
ERROR
LATENCY
Green flashing LED
Without signal
Switches to SWITCHED OFF
mode
Without signal
Red LED and buzzer
continuously activated.
SWITCHED ON:
TRANSMISSION
MODE (max. 1 min., it
only signalizes during
START action)
Without signal
Red LED + buzzer Red LED + buzzer.
Without signal
Red LED and buzzer
continuously activated. It
maintains after releasing
START
TRANSMISSION Green solid LED Without signal
Red LED + buzzer: switches
to SWITCHED OFF mode
after 4 minutes.
Without signal
Red LED and buzzer
continuously activated
LOST Without signal Without signal
Switches to SWITCHED OFF
mode
Buzzer bips during
1 minute
Red LED and buzzer
continuously activated
PASSWORD Orange solid LED Without signal
Switches to SWITCHED OFF
mode
Without signal
Red LED and buzzer
continuously activated.
AUTOID Orange LED Without signal
Switches to SWITCHED OFF
mode
Without signal
Red LED and buzzer
continuously activated.
LIBID Orange LED Without signal
Switches to SWITCHED OFF
mode
Without signal
Red LED and buzzer
continuously activated.
PROGRAMMING
Orange solid LED
Without signal
Red LED + buzzer
Without signal
Red LED and buzzer
continuously activated.
PARAM
Orange flashing LED Without signal Red LED + buzzer
Without signal
Red LED and buzzer
continuously activated.
TELE-ALIGNMENT Without signal Without signal Without signal Without signal
Buzzer continuously
activated
SEARCHING MODE
Orange LED
Without signal
Red LED + buzzer
Without signal
Red LED and buzzer
continuously activated.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 10
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
5.- RECEIVERS
5.1.- TYPE OF RECEIVERS: CONNECTIONS BLOCK DIAGRAMS
R70MP10: PWM OUTPUT RECEIVER (10 OUTPUTS).
R70MR11: RECEIVER WITH OUTPUT RELAYS (11 OUTPUTS).
R70MR06: RECEIVER WITH OUTPUT RELAYS (6 OUTPUTS).
The voltage DC of the power supply (from 9v to 35v
DC, is conducted to the common wiring of the 10 output
switches (OUT1 until OUT10), through a SAFETY
switch which guarantees the output disconnection in
case of breakdown of some of the outputs. The
“RELAY” (STOP) switches between 2 fixed positions
NO (normally opened) and NC (normally closed). An
“LIB ID” function, with ID release pushbutton is
available on the electronic board, and it can be used in
case of transmitter’s breakdown. The ID release can be
also performed from the transmitter with a special
function.
RL-1: Power supply plug in terminals (24,48,115
and 230 V AC). Please note –see table- the right
fuse values depending on the input voltage.
RL-2: Plug in identified connection terminals, 1st
and 2nd speed (K1….K11) and START relay.
RL-3: Plug in terminal for connecting the STOP
relay (NO Cat.3 EN-954-1)
LIB-ID: pushbutton to release the ID from the
receiver.
EP70: On board plug in connector to connect an
external EP70 (External EEPROM).
RL-1: Power supply plug in terminals (24,48,115 and 230
V AC). Please note –see table- the right fuse values
depending on the input voltage.
RL-2: Plug in identified connection terminals, 1st and 2nd
speed, HOISTING; TROLLEY TRAVELLING; SAFETY;
START: STOP (Cat.3 EN-954)
LIB-ID: pushbutton to release the ID from the receiver.
EP70: On board plug in connector to connect an external
EP70 (External EEPROM).
- Remember to connect the ground cable.
- Only use fireproof cables for connections.
- Select the appropriate voltage on the receiver, (230, 115 or 48 Vac). R70MR11 and R70MR06
models.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 11
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
5.2.- MAINTENANCE / TROUBLE SHOOTING GUIDELINES
RECEIVER’S LED SIGNALING
LED COLOUR STATUS REMARKS PROPOSED ACTION
POWER GREEN Switch On if powered Power supply OK Check the power supply
HARDOK GREEN Solid green LED if no error
detected Receiver hardware OK OK
Blinking during start up process Please wait to finish the start up
process
HARDOK
RED
Solid red LED if one of these errors
appears:
-Watchdog activated /
Oscillator breakdown / wrong
ROM checksum
-Reset activated
Electronic board hardware
breakdown Replace the electronic board
-Blinking fast : wrong
EEPROM checksum / Data
corrupted.
Reprogramme EEPROM
SIGNAL GREEN
LED Off if no radio signal detected
(Squelch)
- LED On and the transmitter
switched Off indicates
occupied radio channel
- LED On and DATA
switched Off indicates radio
channel occupied by a non
IKUSI system
Verify transmitter’s radio and
battery
DATA GREEN LED Off if a wrong frame is received
Blinking if receiving good frames
LED Off and SIGNAL LED
On: Radio breakdown
Replace radios
Switched Off and DATA LED
switched On: no valid ID
If the radio channel is not busy:
verify transmitter’s selected ID
or reset receiver ID
ID
GREEN Blinking if a correct ID is received SIGNAL; DATA and ID LED
On, indicates valid frames
from the transmitter. Correct
link.
OK
RELAY
GREEN STOP relay activated
ORDER
GREEN
Proportional lightning intensity
depending on the number of
activated outputs (PWM outputs); or
indicates that at least one output is
activated (RELAY outputs)

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 12
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
6.- RADIO REMOTE SYSTEM FUNCTIONALITIES
6.1.- GENERALS
6.2.- BATTERY LEVEL INDICATION
TRANSMITTER’S MODEL T70MH3D
Full battery: 3 black LED’s + frame. [▓▓▓]
Medium battery: 2 black LED’s + frame. [__▓▓]
Low battery: 1 black LED + frame. [___ ▓]
Empty battery: Blinking frame. [_____]
TRANSMITTER’S MODEL T70MH3 / T70MG10
Low battery state will be indicated with red LED blinking and intermittent buzzer’s sound (pulses of 0.1 sec. every
0.9 sec.: __/\_____________/\________).
The transmitter models without LCD display have restrictions with the access to the programation
parameters, due to the impossibility to show the Software Menu in Programation Mode.
The remote system receiver remembers the last ID used by the last current working transmitter.
This transmitter can be considered as the receiver’s owner. It means that if the receiver is going to
be used with another transmitter with a different ID, the receiver must released the current
transmitter’s ownership releasing the current ID code (LIB ID).This operation can be performed
from the current transmitter (performing LIB ID special function) or by pressing the LIB ID button
inside the receiver.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 13
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
6.3.- BASE CHANNEL CHANGHING (TRANSMITTER MODELS:T70MG10;T70MH3D;T70MH3;T70MH2)
T70MG10 TRANSMITTER MODEL
+ BASE CHANNEL CHANGING MODE (Press “5” and “10” functions
simultaneously) -> Wait until the orange LED lights continuously.
3) The current base channel information is displayed: Number of red pulses = Number of units of the
channel; Number of green pulses = Number in units of ten of the channel.
4) Once the orange LED lights continuously, proceed to change the base channel
Press function “1”, as many times as the number of units of ten of the new base channel.
Note: To programme channels from 1 to 9, do not press this function –equivalent to 0 value--
Press function “2”
,
as man
y
times as the number of units of the new base channel.
6) Updating and sending the new base channel data to the receiver (orange LED blinking).
7) Once the new base channel is recorded in the receiver the transmitter switches to OFF mode (Orange LED
stops blinking ).
5) To validate the new base channel, press “10” function.
The new updated base channel value will show with red and green
LED pulses:
Number of red pulses = Number of units of the channel.
Number of
g
reen
p
ulses = Number in units of ten of the channel.
2
)
Enterin
g
base channel chan
g
in
g
mode:
1
)
With the transmitter switched off
,
p
ress “ON/OFF”. Transmitter in stand-b
y
or LOW CONSUMPTION mode.
Note: Press “4” function to leave the process without updating the new base channel.
The transmitter switches to stand-b
y
or LOW CONSUMPTION mode.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 14
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
T70MH3D / T70MH3/ T70MH2 TRANSMITTER MODELS
+ BASE CHANNEL CHANGING MODE (Press “RIGHT” and “START” functions
simultaneously) -> Message in the LCD display: “FREQ CHANGE”
3) The current base channel information is displayed:
“Freq Change”
“Channel NN” -> (01,02,03……….MAXCAN) NN = 01,02,03,…………, MAXCAN
MAXCAN = 11 in 870 MHz
MAXCAN = 69 in 433MHz and 915MHz
4
)
Use “UP”and ”DOWN” functions to chan
g
e the base channel:
With “DOWN” function, choose the units of the new channel.
Nota: 0 to programme channels from 1 to 9.
With “UP”
,
function choose the number of units of ten of the new channel.
5
)
To validate the new channel
p
ress “START”
The new channel information will be displayed in the LCD:
“Freq Change”
“Channel __” -> (01,02,03……MAXCAN) NN = 01,02,03,…………, MAXCAN
MAXCAN = 11 in 870 MHz
MAXCAN = 69 in 433MHz and 915MHz
1
)
With the transmitter switched off
,
p
ress “ON/OFF”. Transmitter in stand-b
y
or LOW CONSUMPTION mode.
2
)
Enterin
g
in the base channel chan
g
in
g
mode:
6) Updating and sending the new base channel data to the receiver.(the message blinks in the LCD display).
7) Once the new base channel is recorded in the receiver the transmitter switches to OFF mode. (LCD
switched off).
Note1: To leave without updating the change, press “ESC” in
T70MH3 and T70MH3D models
Note2: To leave without u
p
datin
g
the chan
g
e
,
p
ress “RIGHT” in T70MH2 model.

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 15
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
6.4 ID RELEASING (LIB ID) (TRANSMITTER MODELS:T70MG10;T70MH3D;T70MH3;T70MH2)
6.5 AUTO TEACHING MODE (AUTO ID) (TRANSMITTER MODELS:T70MG10;T70MH3D;T70MH3;T70MH2)
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
DURING THE ID RELEASING PROCESS THE ORANGE LED BLINKS AND THE BUZZER IS ACTIVE. ID RELEASED PROCESS
FINISHED: LED OFF and BUZZER OFF.
T70MH3D / T70MH3 / T70MH2
It allows releasin
g
the receiver’s ownershi
p
of the
current
workin
g
transmitter.
1) With the transmitter switched off, press “ON/STOP”.
Transmitter in stand
-
by mode or LOW CONSUMPTION mode
2
)
To enter in LIB ID mode
,
p
ress simultaneousl
y
“UP” and “START” functions.
+
T70MG10 TRANSMITTER MODEL
It allows releasin
g
the receiver’s ownershi
p
of the workin
g
transmitter.
1
)
With the transmitter switched off
,
p
ress “ON/OFF”.
Transmitter in stand-b
y
or LOW CONSUMPTION mode.
2
)
To enter in LIB ID mode
,
p
ress simultaneousl
y
“4” and
“10” functions.
+
DURING THE ID RELEASING PROCESS THE ORANGE LED BLINKS AND THE BUZZER IS ACTIVE. ID RELEASED PROCESS
FINISHED: LED OFF and BUZZER OFF.
T70MG10 TRANSMITTER MODEL
The orange LED switches on-off when every password value is pressed.
At the validation process the orange LED blinks, indicating that the new values are being recorded into the receiver.
Once the operation has finished the orange LED switches off and the transmitter switches to stand-by or LOW CONSUMPTION mode.
It allows to re
g
ister in the receiver’s database a
new transmitter’s ID
(
maximum = 32 ID
)
+
1
)
With the transmitter switched off,
p
ress “ON/OFF”. Transmitter in stand-b
y
or LOW CONSUMPTION mode.
2
)
To enter in AUTO ID mode,
p
ress
“9” and “10” buttons simultaneousl
y
3
)
Introduce the “default
p
assword” : “8-8-8-8-8” -> “10” to
validate.
Keep pressed until the orange LED lights continuously.
PASSWORD
(
DEFAULT
)
►►►> VALIDATE

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 16
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
It allows to re
g
ister in the receiver’s database a
new transmitter’s ID
(
maximum = 32 ID
)
T70MH3 / T70MH2 TRANSMITTER MODEL
1) With the transmitter switched off, press “ON/STOP”.
Transmitter in stand-by or LOW CONSUMPTION mode.
2
)
To enter in AUTO ID mode
,
p
ress
“DOWN” and “START” buttons simultaneousl
y
3
)
Introduce the “default
p
assword” : “ENTER-ENTER-ENTER-ENTER” -> “START” to validate.
+Keep pressed until the orange LED lights continuously.
The orange LED switches on-off when every password value is pressed.
At the validation process the orange LED blinks, indicating that the new values are being recorded into the receiver.
Once the operation has finished the orange LED switches off and the transmitter switches to stand-by or
LOW CONSUMPTION mode.
PASSWORD
(
DEFAULT
)
►►► >VALIDATE
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
T70MH3D TRANSMITTER MODEL
It allows to re
g
ister in the receiver’s database a
new transmitter’s ID
(
maximum = 32 ID
)
1
)
With the transmitter switched off
,
p
ress “ON/STOP”. Transmitter in stand-b
y
or LOW CONSUMPTION mode.
2) To enter in AUTO ID mode, press “DOWN” and “START” buttons simultaneously; keep pressed this buttons
until the message is shown in the LCD display.
3
)
Introduce the “default
p
assword” : “ENTER-ENTER-ENTER-ENTER” -> “START” to validate.
****
+****
PASSWORD
(
DEFAULT
)
►►► >VALIDATE

70 MINI USER’S MANUAL
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI se reserva el derecho de modificar esta información sin previo aviso. 17
70-MINI V.01.00 (01/07) 120009-0B.pdf IKUSI reserves the right to modify this information without prior notification.
6.6 LOST TRANSMITTER SEARCHING MODE (TRANSMITTER MODELS: T70MG10;T70MH3;T70MH2)
T70MG10 TRANSMITTER MODEL
+
► ► SEARCH FUNCTION EXECUTING
O
RAN
G
E LED BLINK
S
PERMANENTLY
STAND BY or LOW CONSUMPTION MODE
1
)
With the transmitter switched off
,
p
ress “ON/OFF”. Transmitter is stand-b
y
or LOW CONSUMPTION mode.
2
)
To enter in SEARCH mode
,
p
ress simultaneousl
y
“7” and
“10” functions.
3
)
Enterin
g
“3”-“1”-“3” function’s se
q
uence, the SEARCH function will execute.
4
)
Pressin
g
“10”
function the transmitter switches to stand-b
y
or LOW CONSUMPTION mode.
It allows findin
g
one or more lost transmitters in the same workin
g
area.
Keep pressed until the orange LED lights continuously.
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
T70MH2 TRANSMITTER MODEL
SWITCHED OFF or LOW CONSUMPTION MODE
1
)
With the transmitter switched off,
p
ress “ON/STOP”. Transmitter in stand-b
y
or LOW CONSUMPTION mode.
2
)
To enter in SEARCH mode,
p
ress simultaneousl
y
“ENTER” and “START” functions.
3
)
Enterin
g
“ENTER-DOWN-ENTER” function’s se
q
uence, the SEARCH function will execute.
4
)
Pressin
g
“START” the transmitter switches to stand-b
y
or LOW CONSUMPTION mode.
It allows findin
g
one or more lost transmitters in the same workin
g
area.
Keep pressed until, the orange LED will light
+
EXECUTE SEARCH
►►
2
)
To enter in SEARCH mode
,
p
ress simultaneousl
y
“ENTER” and “START” functions.
3
)
Enterin
g
“ENTER-DOWN-ENTER” function’s se
q
uence
,
the SEARCH function will execute.
4
)
Pressin
g
“START” the transmitter switches to stand-b
y
or LOW CONSUMPTION mode.
T70MH3 TRANSMITTER MODEL
►►EXECUTE SEARCH
STAND-BY or LOW CONSUMPTION MODE
1
)
With the transmitter switched off
,
p
ress ON/STOP to switch on
(
stand-b
y
state
)
.
It allows findin
g
one or more lost transmitters in the same workin
g
area.
+ Keep pressed until the orange LED lights continuously.
Note: In two steps pushbutton keypads the special functions are activated pressing the first
step.
