DSE DX Series User manual

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 1 Page: 1
DSE SRL - ITALY - WWW.DSE.EU
Video recorders DX Series
AHD DVR cameras, analog, IP
CMS Program Manual
How to install and use the client program to the DVR

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 2 Page: 2
DSE SRL - ITALY - WWW.DSE.EU
Contents of this handbook
This manual describes how to install and use the CMS program that allows centralized management of multiple DVRs RX Series from a
single computer. The Windows program is included on the CD supplied with the DVR. Note that for remote access to a single DVR is not
necessary to use Viewclient, but you can also simply use Internet Explorer, as described in the installation manual.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 3 Page: 3
DSE SRL - ITALY - WWW.DSE.EU
Installing the program
The viewclient program is on the CD supplied with the DVR. To install it you must double-click on the icon and follow the installation
steps.
The program is not protected by security codes or keys. You can install it freely on as many computers as you want.
After installation, you can launch the program by double-clicking the program icon
LOG-IN
The program is password protected.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 4 Page: 4
DSE SRL - ITALY - WWW.DSE.EU
The default password is:
USERNAME: PASSWORD super: (leave
blank)
The main program window is divided into different areas of operation

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 5 Page: 5
DSE SRL - ITALY - WWW.DSE.EU
To maximize the viewing area is able to hide some sections clicking on the appropriate tabs.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 6 Page: 6
DSE SRL - ITALY - WWW.DSE.EU
Links to DVR
To use the program you must first provide the data for or to remote DVR you intend to manage.
ADD A NEW DVR
And 'possible to add a DVR in the first DEVICE MANAGEMENT section. Click DEVICE MANAGEMENT SYSTEM and the pushbutton
right of the screen.
The program is also designed to handle a large number of DVR. To be able to group together in a logical way it is possible to insert
AREAS, which could be geographical areas or any other logical reference. First click ADD AREA and enter the name of an area

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 7 Page: 7
DSE SRL - ITALY - WWW.DSE.EU
to taste. It will appear in the list. Select the area created and press ADD DEVICE
In this mask fit the data needed to make the connection to the DVR.
● SEARCH IP ADDRESS - DVR If you want to insert resides in the local network of the CMS PC can use this button to search for all DX
Series DVRs on the network. Then press the ADD DEVICE button to automatically load the DVR details below
● NAME - Identification name of the DVR to be freely assigned
● ACCESS - E 'can put a DVR in 4 different ways. By entering its IP ADDRESS (if operated over a local network or via the web with a
static IP and port mapping), by entering the name of a domain (if operated via web with DDNS and port mapping), inputting the serial ID
of the DVR (if made web without static IP and without port mapping, using cloud servers). The fourth ARSP mode is no longer used.
● IP ADDRESS / DOMAIN / SERIAL - Please select your DVR, depending on the type of access you have chosen.
● PORT NUMBER - Enter the connection port (default 34567). The figure is not required when connecting via the cloud
● USERNAME - The username to access the DVR, factory setting: admin
● PASSWORD - Password for access to the DVR, factory: Empty

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 8 Page: 8
DSE SRL - ITALY - WWW.DSE.EU
Other fields are not to be filled in
By clicking OK, the new DVR will appear in the list of devices on the left.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 9 Page: 9
DSE SRL - ITALY - WWW.DSE.EU
LIVE Vision camera
The program allows you to view on-screen real-time cameras organizing them flexibly.
START LIVE VIEWING
To view the DVR cameras just created, double click on the address of DVR. If the connection is successful they will show camera icons.
To start playback of a camera just drag it on the screen with the mouse in the desired position, or alternatively select the view pane and
then double-click the camera icon.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 10 Page: 10
DSE SRL - ITALY - WWW.DSE.EU
For more control on how to play, you can select the playback pane, and click the right button on the camera icon
This way you can choose to play the main video stream at full resolution or sub lighter stream.
And 'possible to click the right button on the camera to show the context menu

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 11 Page: 11
DSE SRL - ITALY - WWW.DSE.EU
● CLOSE - Closes the video stream active on the panel
● CLOSE ALL WINDOWS - Close all active streaming
● AUDIO - Turn on sound
● LOCAL RECORD - Starts recording the stream on a local HDD
● EXPAND - Inactive
● PHOTOS - Take a real-time photos
● START AUDIO - Enable / stop two-way audio to talk
● CONFIGURE DEVICE - Opens the remote configuration section of the DVR
● COLOR SETUP - Allows adjustment of image parameters
● FULL SCREEN - Take full screen program
In live view you can double-click on a camera to bring it to full screen. E 'can also move a camera in another pane by dragging it with the
mouse. And 'possible to mix on a cameras from different DVR screen.
BREAKDOWN OF THE VIDEO
Under the video frames are the buttons to decide the split screen mode 1,4,8,9,13,16,36 or 64 boxes.
The last button on the right serves to bring the program full-screen viewing of the sun

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 12 Page: 12
DSE SRL - ITALY - WWW.DSE.EU
cameras without the command frame.
AUDIO
To the right of the split screen commands there is the button to activate or inhibit the audio playback on the PC the camera selected,
followed by the volume control
MANAGING MULTIPLE SCREENS
The CMS program is able to manage the live video max.128 cameras. Since 128 cameras can be displayed simultaneously, live viewing
is composed of multiple pages. If you have chosen, for example, the screen subdivision into 16 panels we will have 8 different pages to
be able to contain all the cameras 128. E 'can move from one page to another with the buttons / OUT right.
PTZ CONTROL
If the camera attached allows the PTZ controls of movements and cases you can control them with the panel on the right which is
opened by pressing the PTZ button
ADJUSTING COLOR
In live view you can adjust the playback picture with the usual brightness control,

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 13 Page: 13
DSE SRL - ITALY - WWW.DSE.EU
Contrast, Saturation and Toni

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 14 Page: 14
DSE SRL - ITALY - WWW.DSE.EU
Recording live video
E 'can record local hard disk images that come from the remote DVR. Just bring in the camera frame, click the right mouse button and
choose LOCAL RECORDING
In the system settings (see below) you can set the storage folders. Files are saved in .264 format.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 15 Page: 15
DSE SRL - ITALY - WWW.DSE.EU
Playback
With the CMS program, you can also review the records stored in the remote DVR cos' like those stored local HDD. Press the PLAY
button on the right.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 16 Page: 16
DSE SRL - ITALY - WWW.DSE.EU
To play video files stored in the remote DVR choose the DVR, set the search criteria and start playback by selecting the file and pressing
the PLAY button
The calendar shows which appears highlighted in red on days that have recordings. Click a day to play recordings stored in the remote
DVR. In the below timeline they will appear green bars in the presence of continuous or manual recording or red in case of alarm
recording.
Similarly you can play back the recorded files on the local PC by choosing the tab PLAYBACK LOCAL
During playback available the usual playback controls

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 17 Page: 17
DSE SRL - ITALY - WWW.DSE.EU
Tele-programming of the DVR
With Viewcliet you can also make the entire programming of the DVR remotely. Click and select SYSTEM CONFIGURATION
REMOTE
Choose DVR for configuration from the left

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 18 Page: 18
DSE SRL - ITALY - WWW.DSE.EU
In this section you can configure, in comfortable tables, all programming options that are accessible through the local menu of the DVR.
In this manual you are not addressed these programming pages as described in detail in the configuration guide,

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 19 Page: 19
DSE SRL - ITALY - WWW.DSE.EU
Program settings
Pressing the SYSTEM CONFIGURATION LOCAL button and you can program some options related to the operation of the CMS
program on the local PC.
The configuration window consists of several folders.

VIEWCLIENT MANUAL
Video recorders DX Series
Page: 20 Page: 20
DSE SRL - ITALY - WWW.DSE.EU
BASIC CONFIGURATION
● KEEP LOG - Set the size in days of events in the program memory. Two settings for alarm events and user actions ..
● BRIEFCASE immagni - Defines the location where the snapshots are saved (photo) performed with the program.
● PHOTO FORMAT - defines the format in which the photos (uncompressed BMP or JPG are saved)
● REGISTRATION CARD - Defines the location where the recordings made with the program are saved.
● EXPAND AUTOMATICALLY AFTER THE CONNECTION - When selected, after
