Linksys WVC200 - Wireless-G PTZ Internet Camera User manual

Model No.
PTZ Internet Camera
Wireless-G
WVC200
User Guide
WIRELESS
GHz
2.4
802.11g
with Audio

Wireless-G PTZ Internet Camera with Audio
Copyright and Trademarks
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco
Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All
rights reserved. Other brands and product names are trademarks or registered trademarks of their respective
holders.
How to Use this Guide
This User Guide has been designed to make understanding networking with the Camera easier than ever. Look for
the following items when reading this guide:
In addition to these symbols, there are definitions for technical terms that are presented like this:
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like
this:
Figure numbers and descriptions can also be found in the “List of Figures” section in the “Table of Contents”.
This exclamation point means there is a Caution or warning and is
something that could damage your property or the Camera.
word: definition.
This checkmark means there is a Note of interest and is something
you should pay special attention to while using the Camera.
This question mark provides you with a reminder about something
you might need to do while using the Camera.
Figure 0-1: Sample Figure Description
WVC200-UG-60330NC BW

Wireless-G PTZ Internet Camera with Audio
TableofContents
Chapter 1: Planning Your Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ad-Hoc and Infrastructure Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Network Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2: Getting to Know the PTZ Internet Camera . . . . . . . . . . . . . . . . . . . . . . . . . 6
Camera LCD Screen and Built-in Microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Camera LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Camera Ports and Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 3: Connecting the PTZ Internet Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connection to a Wired Network for Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connection to a Wireless Ad-Hoc Network for Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Moving the Camera to a Different Network. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera . . . . . . . . . 11
Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Placement Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Audio Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 5: Installing and Using the Internet Camera Viewer & Recorder Utility. 19
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Installing the Viewer & Recorder Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using the Viewer & Recorder Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting Up the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Using File Finder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Chapter 6: Setting up the Linksys SoloLinktm DDNS Service. . . . . . . . . . . . . . . . . 30
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Setup Wizard for the SoloLink DDNS Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
SoloLink Registration of Additional Cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Chapter 7: Using the Wireless-G Internet Camera’s Web-based Utility . . . . . . . . 41
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
How to Access the Web-based Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Wireless-G PTZ Internet Camera with Audio
View Video. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Appendix A: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Appendix B: Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Security Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Security Threats Facing Wireless Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Appendix C: Upgrading Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Appendix D: Windows Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Appendix E: Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Appendix F: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Appendix G: Warranty Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Appendix H: Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Appendix I: Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Wireless-G PTZ Internet Camera with Audio
ListofFigures
Figure 2-1: Camera LEDS, LCD Screen and Built-in Microphone . . . . . . . . . . . . 6
Figure 2-2: Camera Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Figure 3-1: Connect the Ethernet Network Cable . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 3-2: Connect the Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Figure 4-1: Setup Wizard - Welcome Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 4-2: The End User License Agreement. . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 4-3: Connect Network Cable to Network . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4-4: Connect Network Cable to Camera. . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4-5: Connect Power to Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Figure 4-6: Check LEDs screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 4-7: Network Cameras Found Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 4-8: Wizard Login Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Figure 4-9: Basic Settings Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 4-10: Network Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 4-11: IP Settings Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 4-12: Mode Settings Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Figure 4-13: Wireless Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 4-14: Security Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 4-15: Review New Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4-16: Confirmation Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4-17: Congratulations Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 4-18: Stand Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 4-19: Camera Desktop Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Figure 5-1: Install Viewer & Recorder Utility Screen . . . . . . . . . . . . . . . . . . . . . 19
Figure 5-2: Choose Destination Location Screen . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 5-3: Select Program Folder Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 5-4: Setup Complete Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Figure 5-5: Viewer & Recorder Utility Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Wireless-G PTZ Internet Camera with Audio
Figure 5-6: Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 5-7: Selecting Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 5-8: Camera Selected. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 5-9: Set Preset Position Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 5-10: Camera Setup Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 5-11: Recording Schedule Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 5-12: Preferences Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 5-13: The File Finder Desktop Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 5-14: File Finder Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 6-1: SoloLink Welcome Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Figure 6-2: SoloLink for Dynamic IP Address Screen . . . . . . . . . . . . . . . . . . . . 31
Figure 6-3: SoloLink for Convenience Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figure 6-4: Check Connections Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 6-5: Cameras Found Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 6-6: Login Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 6-7: SoloLink DDNS Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Figure 6-8: Confirm Active Internet Connection Screen . . . . . . . . . . . . . . . . . . 33
Figure 6-9: Welcome to the SoloLink DDNS Service Screen . . . . . . . . . . . . . . . 34
Figure 6-10: Sign Up Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Figure 6-11: Confirmation of New Settings Screen. . . . . . . . . . . . . . . . . . . . . . 35
Figure 6-12: Select a Location ID Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 6-13: Confirm Your Location ID Screen . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 6-14: Payment Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 6-15: Verification Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Figure 6-16: Create Links Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 6-17: Successful Registration Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 6-18: Account Confirmation of Camera Screen . . . . . . . . . . . . . . . . . . . 38
Figure 6-19: Successful Setup Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 6-20: Port Forwarding Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 6-21: Web Utility Login Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Wireless-G PTZ Internet Camera with Audio
Figure 6-22: Web-based Utility Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 6-23: Find Available Port Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Figure 7-1: Camera’s Default IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 7-2: Web-based Utility Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 7-3: View Video Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 7-4: Security Warning Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Figure 7-5: Basic Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 7-6: Confirmation Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Figure 7-7: WEP Key Settings Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Figure 7-8: Image Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Figure 7-9: Maintenance Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Figure 7-10: Users Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Figure 7-11: DDNS Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Figure 7-12: FTP Upload Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Figure 7-13: Options Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Figure 7-14: Pan/Tilt Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Figure 7-15: Status Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Figure 7-16: Help Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Figure C-1: Upgrade Firmware Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

4
Chapter 1: Planning Your Wireless Network
Introduction
Wireless-G PTZ Internet Camera with Audio
Chapter1:PlanningYourWirelessNetwork
Introduction
A wireless local area network (WLAN) is exactly like a regular local area network (LAN), except that each
computer in the WLAN uses a wireless device to connect to the network. Computers and other devices, such as
peripherals, in a WLAN share the same frequency channel and SSID, which is an identification name for wireless
devices.
Ad-Hoc and Infrastructure Modes
Unlike wired networks, wireless networks have two different modes in which they may be set up: infrastructure
and ad-hoc. An infrastructure configuration is a WLAN and wired LAN communicating to each other through an
access point. An ad-hoc configuration is wireless-equipped computers communicating directly with each other.
Choosing between these two modes depends on whether or not the wireless network needs to share data or
peripherals with a wired network or not.
If the computers on the wireless network need to be accessed by a wired network or need to share a peripheral,
such as a printer, with the wired network computers, the wireless network should be set up in infrastructure
mode. The basis of infrastructure mode centers around an access point, which serves as the main point of
communications in a wireless network. (A wireless router can also be used because a wireless router
incorporates the capabilities of an access point.) Access points transmit data to PCs equipped with wireless
network cards, which can roam within a certain radial range of the access point. Multiple access points can be
arranged to work in succession to extend the roaming range, and can be set up to communicate with your
Ethernet (wired) hardware as well.
If the wireless network is relatively small and needs to share resources only with the other computers on the
wireless network, then the ad-hoc mode can be used. Ad-hoc mode allows computers equipped with wireless
transmitters and receivers to communicate directly with each other, eliminating the need for an access point.
The drawback of this mode is that, in Ad-Hoc mode, wireless-equipped computers are not able to communicate
with computers on a wired network. And, of course, communication between the wireless-equipped computers is
limited by the distance and interference directly between them.
Infrastructure: configuration in which
a wireless network is bridged to a
wired network via an access point.
LAN (Local Area Network): the
computers and networking products
that make up the network in your home
or office.
Ad-hoc: a group of wireless devices
communicating directly to each other
(peer-to-peer) without the use of an
access point.
WLAN (Wireless Local Area
Network): A group of computers and
associated devices that communicate
with each other wirelessly.

5
Chapter 1: Planning Your Wireless Network
Network Layout
Wireless-G PTZ Internet Camera with Audio
Network Layout
The PTZ Internet Camera is compatible with all 802.11g routers, such as model number WRT54G, as well as
access points, including model number WAP54G. The Camera will also communicate with network adapters,
such as the Wireless-G Notebook Adapter (model number WPC54G) for your laptop computers, Wireless-G PCI
Adapter (model numbers WMP54G) for your desktop PCs, and Wireless-G USB Adapter (model number WUSB54G)
for your computers when you want to enjoy USB connectivity.
With these, and many other Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com/international for more information about products that work with the PTZ Internet Camera.

6
Chapter 2: Getting to Know the PTZ Internet Camera
Camera LCD Screen and Built-in Microphone
Wireless-G PTZ Internet Camera with Audio
Chapter2:GettingtoKnowthePTZInternetCamera
Camera LCD Screen and Built-in Microphone
The Camera has a LCD screen that indicates the Camera’s current IP address and whether it is a fixed or dynamic
address. If the Camera uses a fixed IP address, then the screen will display the word “FIXED.” If the Camera uses
a dynamic IP address, then the screen will display the word “DHCP.”
The built-in microphone is located approximately one inch below the LCD screen, in the middle of the Camera’s
front panel. It has a range of approximately 9 feet (3 meters), depending on environmental conditions.
Camera LEDs
The Camera has four LEDs to let you know how the Camera is functioning.
POWER Amber. The POWER LED lights up when the Camera is powered on. It flashes for about 10-15
seconds while the Camera is initializing.
ACTIVITY Green. The ACTIVITY LED flashes when there is activity.
ETHERNET Green. The ETHERNETLED lights up when there is a connection to a wired network. It flashes
when data is transmitted to or received from the wired network.
WIRELESS Green. The WIRELESS LED lights up when there is a connection to a wireless network. It
flashes when data is transmitted to or received from the wireless network.
Figure 2-1: Camera LEDS, LCD Screen and
Built-in Microphone
Built-in
Microphone

7
Chapter 2: Getting to Know the PTZ Internet Camera
Camera Ports and Button
Wireless-G PTZ Internet Camera with Audio
Camera Ports and Button
The Camera features three ports and a Reset button on the bottom panel.
POWER The POWER port is where you will connect the power adapter.
MIC IN The MIC IN port is where you will connect the 3.5 mm input jack of your external microphone
(optional).
ETHERNET The ETHERNET port is where you will connect the Ethernet network cable.
RESET The RESET button is what you will press if you need to reset the Camera. Insert a paper clip
into the opening next to the Ethernet port. Then press the button and hold it in for five seconds.
Figure 2-2: Camera Ports
POWER RESETETHERNETMIC IN
IMPORTANT: Resetting the Camera will erase all of
your settings, such as encryption information, and
replace them with the factory defaults. Do not reset
the Camera if you want to retain these settings.

8
Chapter 3: Connecting the PTZ Internet Camera
Overview
Wireless-G PTZ Internet Camera with Audio
Chapter3:ConnectingthePTZInternetCamera
Overview
Before you set up the Camera, connect it to a wired or wireless network. Proceed to the appropriate section for
your setup.
If you need to move the Camera from a wired network to a wireless network, or vice versa, go to this section,
“Moving the Camera to a Different Network.”
Connection to a Wired Network for Setup
1. Attach the antenna.
2. Connect the Ethernet network cable to your network switch or router.
3. Connect the other end of the cable to the Ethernet port on the Camera.
4. Connect the power adapter to the Power port on the Camera.
5. Plug the power adapter into an electrical outlet.
The Camera’s Ready LED flashes while the Camera is initializing. The Camera is ready for use when the Ready
and Ethernet LEDs are solidly lit.
Proceed to “Chapter 5: Setting up and Mounting the Wireless-G Internet Camera.”
NOTE: You MUST connect the Camera to a PC, router, or switch using the Ethernet network
cable BEFORE powering on the Camera. Otherwise, the Camera will not function.
Figure 3-2: Connect the Power Adapter
Figure 3-1: Connect the Ethernet Network Cable

9
Chapter 3: Connecting the PTZ Internet Camera
Connection to a Wireless Ad-Hoc Network for Setup
Wireless-G PTZ Internet Camera with Audio
Connection to a Wireless Ad-Hoc Network for Setup
1. Make sure your computer has the following wireless settings:
• SSID - linksys
• Network Mode - Ad-Hoc
• Channel - 6
• WEP - Disabled
2. Attach the antenna.
3. Connect the power adapter to the Power port on the Camera.
4. Plug the power adapter into an electrical outlet.
The Camera’s Ready LED flashes while the Camera is initializing. The Camera is ready for use when the Ready
and Wireless LEDs are solidly lit.
Proceed to “Chapter 5: Setting up and Mounting the Wireless-G Internet Camera.”
Moving the Camera to a Different Network
When you move the Camera from a wired network to a wireless network, or vice versa, you must power off the
Camera before connecting to the new network. Proceed to the appropriate instructions.
To move the Camera from a wired network to a wireless network, follow these instructions:
1. Unplug the power adapter from the Camera.
2. Unplug the Ethernet network cable from the Camera.
3. Re-connect the power adapter to the Power port on the Camera.
The Camera’s Ready LED flashes while the Camera is initializing. The Camera is ready for use when the Ready
and Wireless LEDs are solidly lit.

10
Chapter 3: Connecting the PTZ Internet Camera
Moving the Camera to a Different Network
Wireless-G PTZ Internet Camera with Audio
To move the Camera from a wireless network to a wired network, follow these instructions:
1. Unplug the power adapter from the Camera.
2. Connect the Ethernet network cable to your PC, router, or switch.
3. Connect the other end of the cable to the Ethernet port on the Camera.
4. Re-connect the power adapter to the Power port on the Camera.
The Camera’s Ready LED flashes while the Camera is initializing. The Camera is ready for use when the Ready
and LAN LEDs are solidly lit.

11
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
Chapter4:SettingupandMountingtheWireless-G
InternetCamera
Setup Wizard
The Wireless-G Internet Camera Setup Wizard will guide you through the installation and configuration procedure.
1. Insert the Setup CD-ROM into your CD-ROM drive. The Setup Wizard should run automatically, and the
Welcome screen should appear. If it does not, click the Start button and choose Run. In the field provided,
enter D:\wvc200.exe (if “D” is the letter of your CD-ROM drive).
•Setup. Click the Click Here to Start button to begin the installation process.
•Install Viewer & Recorder Utility. Click this button to install the Camera’s Viewer & Recorder Utility on
your PC.
•Setup SoloLink DDNS Service. Click the Setup SoloLink DDNS Service button to configure and use
Linksys’s Dynamic Domain Name System (DDNS) service.
•User Guide. Click this button to open the PDF file of this User Guide.
•Exit. Click the Exit button to exit the Setup Wizard.
2. Click the Click Here to Start button to begin the installation process.
3. The next screen shows the End User License Agreement. Read through this and, if you accept the terms of the
Agreement, click Next to continue.
Figure 4-2: The End User License Agreement
Figure 4-1: Setup Wizard - Welcome Screen

12
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
4. The next three screens show how to connect the Camera to your network, starting with connecting a network
cable to your network’s router or switch. Once you have done this, click Next.
5. Next, connect that network cable to the Camera’s RJ-45 port, as shown. Once you have done this, click Next.
6. Once that is done, connect the Camera’s power cable to the Camera’s power port, as shown. Once you have
done this, click Next.
Figure 4-4: Connect Network Cable to Camera
Figure 4-3: Connect Network Cable to Network
Figure 4-5: Connect Power to Camera

13
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
7. Now, check the Camera’s LEDs to verify that they’re functioning properly. Then, click Next.
8. The Wizard will now display a list of Internet Cameras on your network, along with the status information for
the Camera whose name is highlighted. In the Selection box, click the name of the Camera you are currently
installing. Write down the IP address of the Camera, so you can use it to access the Web-based Utility later.
Click the Next button.
9. For increased network security, enter a name and password for administrator access to the Camera. In
lowercase letters, enter admin in the Administrator Name and Administrator Password fields. (You can
change these settings through the Camera’s Web-based Utility later.) Then, click the OK button.
Figure 4-6: Check LEDs screen
Figure 4-7: Network Cameras Found Screen
Figure 4-8: Wizard Login Screen

14
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
10. On the Basic Settings screen, you can alter the following settings:
•Camera Name. You can give the Camera a unique name. Memorable names are helpful, especially if you
are using multiple Cameras on the same network. It should have 15 characters or fewer.
•Description. You may enter additional information, such as location, in this field. It has a maximum length
of 32 characters.
•Time Zone. Select the time zone for the Camera’s location.
•Date. Enter today’s date in the fields provided.
•Time. Enter the current time in the fields provided.
When you have finished making your changes, click Next.
11. If you need to assign a static IP address to the Camera, select Static IP address. If your network has a DHCP
server, keep the default setting, Automatic Configuration-DHCP.
Then, click Next.
Figure 4-9: Basic Settings Screen
Figure 4-10: Network Settings Screen

15
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
12. If you selected Automatic Configuration-DHCP, proceed to the next step.
If you selected Static IP Address, the IP Settings screen will appear. Enter an IP Address, Subnet Mask, and
Default Gateway appropriate for your network. You must specify an IP Address and Subnet Mask on this
screen. If you are unsure about the Default Gateway, it is better to leave this field blank. Then complete the
Primary DNS and/or Secondary DNS fields. You must enter at least one DNS address, which can be obtained
from your ISP. Click Next to continue.
13. The Mode Setting screen will appear next. Click the Infrastructure radio button if you want the Camera to
communicate using an access point or wireless router. Click the Ad-Hoc radio button if you want the Camera
to communicate without using an access point or wireless router. After making your selection, click Next.
Figure 4-11: IP Settings Screen
Figure 4-12: Mode Settings Screen

16
Chapter 4: Setting up and Mounting the Wireless-G Internet Camera
Setup Wizard
Wireless-G PTZ Internet Camera with Audio
14. The Wireless Settings screen will appear, so you can change the wireless settings. Enter your wireless
network’s SSID or network name. If you chose Ad-Hoc mode, select the channel at which the network
broadcasts its wireless signal.
•SSID. The SSID must be identical for all devices in a wireless network. It is case-sensitive and should
have 32 alphanumeric characters or fewer. (You can use any keyboard character, but do not use any
spaces.)
•Channel. If you set the Camera to Ad-Hoc mode, select the appropriate channel from the drop-down
menu. All devices in your wireless ad-hoc network must use the same channel in order to function
correctly.
Then, click the Next button.
The Security Settings screen will appear. If your network has WEP encryption enabled, then select the level
of WEP encryption and enter a Passphrase. If you want to manually enter a WEP key, leave the Passphrase
field blank, and enter the WEP key in the Key 1 field. If your network has WPA-Personal encryption enabled,
enter a WPA Shared Key. If your network has WEP and WPA-Personal encryption disabled, keep the default
setting, Disabled.
•WEP. To enable WEP encryption, select 64-Bit Keys or 128-Bit Keys from the drop-down menu. Then
enter a Passphrase. If you want to manually enter a WEP key, leave the Passphrase field blank.
•Passphrase. If you enabled WEP encryption, you can enter a Passphrase, so a WEP key will be
automatically generated. If you want to manually enter a WEP key, leave the Passphrase field blank. The
Passphrase is case-sensitive and should have 16 alphanumeric characters or fewer. It must match the
passphrase of your wireless network and is compatible with Linksys wireless products only. (You will
have to enter the WEP key(s) manually on any non-Linksys wireless products.)
•Key 1. If you want to manually enter a WEP key, complete this field. If you are using 64-bit WEP
encryption, then the key must consist of exactly 10 hexadecimal characters. If you are using 128-bit WEP
encryption, then the key must consist of 26 hexadecimal characters. Valid hexadecimal characters are
“0” through “9” and “A” through “F”.
•WPA-Personal. To enable WPA-Personal encryption, enter a WPA Shared Key from 8 to 63 characters.
•WPA Shared Key. If you enabled WPA-Personal encryption, enter the WPA Shared Key that you’re using
on your wireless network.
Click the Next button.
Figure 4-13: Wireless Settings Screen
Figure 4-14: Security Settings Screen
