Linon 6220SF-01-KD User manual

PAGE 4
F
G
D
D
E
STEP 2)
2.1. FIX (01) METAL KNOB (E)TO TABLE TOP #1 USING (02) SCREWS (D), (01) SCREW (F),
(01) WASHER (G), A PHILLIPS HEAD SCREWDRIVER (NOT PROVIDED) AND THE PRE-
DRILLED HOLES AS GUIDE,AS SHOWN ON DRAWING.
30 1/2”
49 3/4”
25 3/4”
PAGE 1
ASSEMBLY INSTRUCTIONS
DESK
MODEL # 6220SF-01-KD
WE ARE HERE TO HELP!
LINON HOME DECOR PRODUCTS, INC.
TOLL FREE NUMBER 1.800.262.1852
TEL: [phone]
FAX: [phone]
E-mail: [email protected]
WE TRY TO INSURE THAT YOUR FURNITURE ARRIVES IN EXCELLENT CONDITION. OUR SERVICE
REPRESENTATIVES ARE READY TO HELPYOU WITH QUICK SERVICE. PLEASE CALL IFA PART IS DAMAGED OR
MISSING. PLEASE CALL OUR CUSTOMER SERVICE PRIOR TO RETURNING THE ITEM TO THE STORE. OUR
OFFICE IS OPEN MONDAY-FRIDAY 9AM TO 5 PM EASTERN STANDARD TIME.
IMPORTANT:
PLEASE READ ALL INSTRUCTIONS IN THIS BOOKLET BEFORE STARTING ASSEMBLY.
MADE IN BRAZIL
FOR LINON HOME DECOR PRODUCTS, INC.
05/03

A
08SCREW 2 3/8"
ALLEN WRENCH
ADHESIVE FELT
01
04
B
C
PAGE 3PAGE 2
OPEN HARDWARE PACKAGE ON A FLAT SURFACE COVERED WITH NEWSPAPER.
COUNT EACH PIECE OF HARDWARE AND MATCH THE QUANTITY TO THE
HARDWARE LIST COLUMN. CALL CUSTOMER SERVICE IF ANY PARTS ARE MISSING.
FOLLOW THE LETTER IDENTIFICATION WHEN READING THE ASSEMBLY DRAWING
“A" THROUGH "G”.
HARDWARE PACKAGE COUNT.
HARDWARE IDENTIFICATION
IMPORTANT:
USE ALL THE HARDWARE MENTIONED ABOVE TO
ASSURE THE STABILITYAND SAFETY OF THE DESK.
TOOLS REQUIRED
AN ALLEN WRENCH (PROVIDED “B”) ANDA PHILLIPS
HEAD SCREWDRIVER (NOT PROVIDED) ARE REQUIRED
TO ASSEMBLE THIS UNIT.
ATTENTION NOTE:
BEFORE USING THIS UNIT, ATTACH (04) ADHESIVE FELTS (C) TO THE BOTTOM OF EACH LEG #02
IN ORDER TO AVOID DAMAGES TO FLOOR.
1 - TABLE TOP
2 - LEG (4x)
PARTS IDENTIFICATION
STEP 1)
1.1. FIX LEG #2 (4x) TO TABLE TOP #1 USING (08) SCREWS (A), AN ALLEN WRENCH
(PROVIDED-”B”) AND THE PRE-DRILLED HOLESAS GUIDE, AS SHOWN ON DRAWING.
ATTENTION:
ASSEMBLE DESK FACING DOWN ON A CLEAN SURFACE (CARPET,
CARTON, ETC...) TO AVOID SCRATCHING THE SURFACE.
SCREW 5/8 02
D
METAL KNOB 01
E
SCREW 3/4 01
F
WASHER 01
G
C
2
2
2
2
1
C
C
C
C
A
B
1
2
2
2
2
A
