FURNITUREBOX FOSSANO User manual

www.furniturebox.co.uk
Scan QR code for more tips,
advice and assembly video or visit
furniturebox.co.uk/club/fossano-wardrobe
SCAN ME
FOSSANO
WARDROBE
ASSEMBLY GUIDE

• Check you have all the components and
tools listed.
• Remove all ttings from the plastic bags
and separate them into their groups.
• We do not recommend the use of power
drills/drivers for inserting screws, as this
could damage the unit. Only use hand
screwdrivers and Allen keys.
• Keep children and animals away from the
work area, small parts could cause choking
if swallowed.
• Make sure you have enough space to
layout the parts before starting.
• Assemble the item as close to its nal
position (in the same room) as possible.
Important - Please read these instructions fully before starting assembly
SAFETY AND
CARE ADVICE
!
NO POWER TOOLS
Follow us on Instagram
@furniturebox_uk
• Do not overtighten the nuts
to avoid causing damage to
the threads.
•
• Only clean using a damp
cloth and mild detergent,
do no use bleach or
abrasive cleaners.
• From time to time check
that there are no loose
screws on this unit
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal
centre
IMPORTANT INFORMATION
SAFETY AND CARE ADVICE
TWO
PERSON
60 MINUTE
BUILD
MAXIMUM
CAPACITY 100Kg

www.furniturebox.co.uk
PLEASE CHECK CAREFULLY AND MAKE SURE YOU HAVE ALL
FITTINGS AND TOOLS LISTED BELOW BEFORE YOU START.
NOTE: The quantities above are the correct amount to complete the assembly. In
some cases more ttings may be supplied than are required.

Follow us on Instagram
@furniturebox_uk
STEP 2
Connect the right wardrobe side
support (11) and bottom board
(2) with wooden dowels (D), cam
lock nuts and cam screws.
STEP 1
Put the pieces on a soft at surface e.g.
a carpet to avoid scratching or ready to
bumping. Make the sure that you have all
pieces and components ready to build the
wardrobe.
Firstly use Screwdriver (L) to tighten the
Cam Screws (B) into the bottom board (2).
Once tightened the Cam Lock Nut (A) to
lock in the pieces and assemble the front
footboard (1) and back footboard (20) to the
bottom board (2).
Assemble the lower shelf (8) and upper
drawer support (9) together using cam
screws and lock nuts.
Add the cam screws onto the xing plate
(10) and then x the lower drawer support
(21) to this part using the cam lock nuts.

www.furniturebox.co.uk
STEP 3
Apply cam screws
and wooden dowels
onto the top board (5)
to the left wardrobe
side support (4), right
wardrobe side support
(11), wardrobe back (6).
Tighten using cam lock
nuts.
STEP 4
Assemble the left wardrobe side
board (3), bottom board (2), left
wardrobe side support (4) and top
board (5) together.
FULL ASSEMBLY INSTRUCTIONS
STEP 5
ATTENTION: Using 2 people
turn the cabinet 180 degrees,
then assemble upper shelf (7),
lower shelf (8), upper drawer (9),
xing plate (10) and lower drawer
support (21) with left wardrobe side
board (3)

Follow us on Instagram
@furniturebox_uk
STEP 7
Lift up the wardrobe with 2 people. Install
the clothes bar bracket (H) and put the
clothes rail (G) on.
Please note the height of the clothes bar
bracket is adjustable.
STEP 8
Assemble the left wardrobe door (18) and
right wardrobe door (19).
Then put the door handles (J) on.
STEP 6
Assemble the right
wardrobe side board (12).

www.furniturebox.co.uk
STEP 9
Assemble the drawer (13), (14), (15), (16), (17) with the
xings (A), (B), and screwdriver (L).
Please note the front drawer (17) must be xed last to
allow the drawer bottom (16) to slide in before hand.
To assemble the runners correctly, press and hold
the black plastic lever inside the slider (F) upward or
downward, and pull outwards. This will separate the
parent child parts of the slider (F), into two parts.
The child part (the runner with the black lever
attached) needs to be assembled to the side of the
drawer using the self tapping screw (E) to install the
child parts at the corresponding holes of (13) and (15).
Install the parent part at the corresponding holes of
(3), (12) which is on the inside of the wardrobe side,
with the black stopper on the parent runner at the
furthest back point.
Pull the parent runner out and then push the
drawer/child runner back onto the parent runner.
Once aligned the drawer should t straight in and
function normally.
ATTENTION: Be careful not to overload drawers
STEP 10
Using screwdriver (L) you can adjust the screw of the
hinge to make sure the door seam is consistent
ATTENTION: The Anti Tipping Kit MUST be used to
connect the cabinet to the wall to prevent tipping over.

www.furniturebox.co.uk

The cushions (foam inserts and
covers) are not covered by the guarantee.
