Mocka Hobart User manual

Phillips & Flathead screwdrivers and hammer required
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
X
Z
Y
W
safety
strap
x1
screw
x1
long
screw
x1
wall
anchor
x1
washer
x1
mocka.co.nz | mocka.com.au
B
ACDE
FGH
12 mm
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
WARNING: Any furniture that is not anchored to a wall has the potential
to tip over in certain circumstances, i.e. if a child attempts to climb up on
the furniture or in the event of an earthquake. Accordingly, we
recommend that all furniture is anchored to a wall. We supply a free
safety wall anchor with all furniture sold and we recommend these are
used to prevent your product tipping. The fixing device provided should
fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
WARNING: Never leave a child unattended on the change table.
bolt
x34
locking
nut x 34
dowel
x18
small
screw x20
I
L + R
slide rail
x4
L + R
slide rail
x4
medium
screw x 10
Hobart Change Table
40 mm
long
screw x 4
J
12 mm
small
screw x27
handle
x 2
30 mm

2
12
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
A
1
Insert 6 x bolts (A) into panels [1] and [2] .
Tighten with a screwdriver.
A
Attach 4 x dowels (C) into panels [1] and [2] with panel [3].
A
A
A
A
A
2
1
2
3
C
C
C
C

3
34
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
B
Tighten with a screwdriver.
Insert 6 x locking nuts (B) into panel [3] .
2
B
3
B
B
B
B
B
W
Y
Attach 1 x wall strap (W) to panel
[2] using 1x screw(Y).
E
E
E
E
E
E
A
A
A
A
AA
AAA
5
4
G
G
G
G
E
E
E
E
E
E
AA
A
A
A
A
A
A
A
Attach 2 x left slide rail (G) to panel [4] and secure with 6 x small screws (E).
Tighten with a screwdriver.
Attach 2 x right slide rail (G) to panel [5] and secure with 6 x small screws (E).
Insert 18 x bolts(A) into panel [4] and [5].

4
56
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
3
B
5
B
B
B
C
C
B
B
C
2
1
6
B
B
C
C
B
B
7
5
Insert 2 x dowels (C) into panel [7]. Attach panel [7] to panel [5] and secure
with 2 x locking nuts (B). Tighten with a screwdriver.
Insert 3 x dowels (C) into panel [5]. Attach panel [5] to panels [1] ,[2] , [3]
and [6]. Secure with 7 x locking nuts (B).

5
78
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
7
B
2
6
C
Insert 5 x dowels (C) into panel [4]. Attach panel [4] to panels [1], [2], [3], [6]
and [7]. Secure with 9 x locking nuts (B).
B
B
B
B
B
BBC
C
B
B4
4
5
9
C
D
DD
D
C
C
C
Insert 4 x dowels (C) into panel [4] and [5] .
Attach panels [9] to panel [4] and [5] .Secure with 4 x long screws(D).

6
910
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
9
8
8
8
8
JJ
J
JJJ
JJ
J
J
J
J
J
J
J
J
J
J
J
JJ
J
J
J
J
10
J
On the back side of the set, fit boards [10] and [17] into the grooves. Use
small 27x screws (J) all around to fasten boards to the change table unit.
Firmly screw 4 leg [8] to the base of panel [9].
17

7
11 12
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
Drawers (x2) Drawers (x2)
AA
B
B
B
B
AA
11
13
12
Tighten with a screwdriver.
Insert 8 xbolts (A) into panels [11] .Attach panels [12] and [13] to panels
[11] secure with 8 x locking nuts (B).
A
B
11
13
14
12
15
Insert 2 x bolts (A) into panels [11] .Slide panels [14] between the
Attach panels [15] to panels [11] and secure with 2 x locking nuts (B).
grooves on panels [12] and [13] to form the base of the drawer as shown.

8
13 14
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
Drawers (x2) Drawers (x2)
F
13
14
12
F
F
F
F
16
Tighten with a screwdriver.
Attach panels [16] to panels [12] and [13] .Secure with 10 x medium screws(F).
11
12
13
E
H
I
HE
E
Attach 4 x slide rails (H) to panels [12] and [13] and secure with 8 x small
screws (E). Insert 2 x handles (I) into panels [11] .
I

9
15
Hobart Change Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
X
Z
x1
wall
screw
wall
anchor
wall
screw
Washer
Strap
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (W). Fasten to wall
using wall anchor (X), washer (Z) and screw. Ensure the unit is balaced
and steady before use. You’re done, enjoy!
