Linsar WM800 User manual

WASHING MACHINE
WASHING MACHINE
User
Manual
User Manual
EN
WM800

4
CHAPTER-1: BEFORE USING THE APPLIANCE
•Correct usage 6-7
•  Generalwarnings 8-9-10-11
•  Safetywarnings   12-13-14-15-16-17
•  Packagingandtheenvironment  18
•  Savingsinformation   19
CHAPTER-2: OVERVIEW OF YOUR DEVICE
•  Generalappearance   20-21
•  Techincalspecications   22
CHAPTER-3: INSTALLATION
•  Removingtransportationsafetyscrews 23-24
•  Adjustingthefeet   25-26-27
•  Electricalconnection   28
•  Waterinlethoseconnection  29-30
•  Waterdischargeconnection  31
CHAPTER-4: INTRODUCTION OF CONTROL PANEL 32
•  Detergentdrawer   33-34-35
•  Programmeknob   36
•  Spinspeedselectorknob   36-37 
CONTENTS

5
CHAPTER-4: INTRODUCTION OF CONTROL PANEL
•  Electronicdisplay   38
CHAPTER-5: PRELIMINARY PREPARATION FOR LAUNDERING
•  Separatinglaundry   39-40
•  Puttinglaundryinthemachine  41
•  Addingdetergentintomachine  42
•  Operatingyourmachine   43-44-45
•  Auxiliaryfunctions   46-47-48-49
•  Childlock    50
•  Cancellingprogramme   51
•  Finishingprogramme   52
•  Warningsymbols   53-54
CHAPTER-6: PROGRAM TABLE   55-56-57-58-59-60-61-62-63
CHAPTER-7: MAINTENANCE AND CLEANING OF YOUR MACHINE
•  Warning    64
•  Waterinletlters    65
•  Pumplter    66-67
•  Detergentdrawer   68
CHAPTER-8: FLUSH STOPPER / BODY / DRUM 69
CHAPTER-9: TROUBLESHOOTING   70-71-72-73-74
CHAPTER-10: AUTOMATIC FAULT WARNINGS AND WHAT TO DO 75
CHAPTER-11: PRACTICAL INFORMATION 76-77-78-79
• Describingenergylabelandsavingenergy 80-81
• Disposalofyouroldmachine  82
CONTENTS

6
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
• Read the user’s manual.
• Your machine is designed to be used
domestically. Commercial use will cause
your warranty to be cancelled.
•Keepyourpetsawayfromyourmachine
•Pleasecheckthepackagingofyourmachine
beforeinstallation,andtheoutersurfaceaf-
terthepackageisopened.Donotoperate
damagedmachinesormachineswithopened
packaging.
•Haveyourmachineinstalledonlybyauthor-
izedservices.Anyinterferencetoyourma-
chinebyanyoneotherthanauthorizedservic-
esshallcauseyourwarrantytobevoid.
•Theapplianceisnotintendedforuseby
people(includingchildren)withreducedphys-
ical,sensoryormentalcapabilities,orlackof
experienceandknowledgeunlesstheyhave
beengivensupervisionorinstructionconcern-
inguseoftheappliancebyapersonresponsi-
blefortheirsafety.Childrenshouldbesuper-
visedtoensurethattheydonotplaywiththe
appliance.

7
CHAPTER -1: BEFORE USING THE APPLIANCE
(CORRECT USAGE)
•Useyourmachineonlyforlaundrythathave
beenspeciedassuitableforwashingbythe
manufacturer.
• Before operating the washing machine,
remove the 4 transportation screws and
rubber spacers from the back of the ma-
chine. If the screws are not removed, it
may cause heavy vibration, noise and
product malfunction, (voiding the guaran-
tee).
•Yourmachineisnotcoveredunderwarranty
forfaultscausedbyanykindofexternalfac-
tors(pesticides,re,etc.).
•Pleasedonotthrowawaythisusermanual;
keepitforfuturereference.Youorsomebody
elsemightneeditinthefuture.
Note:Machineryspecicationsmayvaryde-
pendingontheproductpurchased.

8
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
•Thenecessaryambienttemperatureforyour
machine’sidealoperationis15-25°.
•Frozenhosescantearandexplode.Inregions
wheretemperatureisbelowzero,ambienttem-
peraturemightendangerthesafeoperationof
electroniccard.
•Pleaseensurethattheclothesyouwillplace
inyourmachinedonotcontainanyforeignsub-
stances(nail,needle,coins,lighter,matches,clip
etc.)intheirpockets.Theseforeignsubstances
candamageyourmachine.
• It is recommended to perform the rst
washing operation in 90˚ Cotton programme
and without laundry by inserting ½ scale
of detergent in the 2nd compartment of the
detergent drawer.

9
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
•Asdetergentorsoftenerexposedtoairfora
longtimemaycauseresidues,onlyputyour
detergentorsoftenerinthedetergentdrawer
atthebeginningofeverywashing.
•Itisadvisedthatyouunplugyourmachine
andclosethewaterinlettapifyouwillnotuse
yourmachineforalongtime.
Also,leavingthedoorofyourmachineopen
willpreventtheformationofbadodorsdueto
humidity.
•Somewatermightbeleftinyourmachine
afterthetrialsandtestsconducteddueto
QualityControlprocedures.
Thiswillnotdamageyourmachine.
•Rememberthatpackagingmaterialsofyour
machinemaybedangerousforchildren.Keep
thepackagingmaterialsinaplacewhere
childrencannotreachordisposeofthem
appropriately.
•Keepthesmallpartsfoundinthedocument
partawayfromthereachofchildrenand
babies.
•Usepre-washprogramsonlyforverydirty
laundry.

1010
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
•Neveropenthedetergentcom-
partmentwhentheapplianceis
running.
•Incaseofanybreakdown,unplug
theappliancerstandthenturn
thetapoff.Donotattempttorepair
byyourself,alwayscontactforau-
thorizedserviceadvice.
•Theamountoflaundryyouputin
yourwashingmachineshouldnot
exceedthemaximumamountindi-
cated.
•Neverforcethedoortoopen
whenthemachineisrunning.
•Washingouryclothesinyour
machinedamagesthemachine.
Donotwashouryclothesinyour
machine.

11
CHAPTER -1: BEFORE USING THE APPLIANCE
(GENERAL WARNINGS)
•Pleaseadheretodetergent/fabriccondition-
ermanufacturers’adviceregardingtheuseof
fabricconditionerorsimilarproductsinyour
machine.
•Setupyourmachineinaplacewhereits
doorcanbecompletelyopened.(Donotset
upyourmachineinplaceswhereitsdoorcan-
notbefullyopened.)
•Setupyourmachineatlocationsthatcan
befullyventilatedandcouldhaveconstantair
circulation.

12
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
You must read these warnings. You can
thus protect yourself and your beloved
ones against fatal injuries and risks.
DANGER OF GETTING BURNT!
Donottouchdischarginghoseandwater
duringdischargingastheappliancemay
reachhightemperatureswhenrunning.

13
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
DEATH RISK DUE TO
ELECTRICAL CURRENT!
•Donotusemultiplereceptacles
orextensioncord.
•Donotplugindamagedortorn
plugs.
•Neverpullthecablewhenun-
plugging–alwaysgriptheplug
itself.
•Donotplug-inorouttheplug
fromthereceptaclewithwethands
topreventelectrocution!
•Nevertouchthemachinewithwet
handsorfeet.
•Callthenearestauthorizedser-
viceforareplacementifthepower
cordmalfunctions.

1414
Danger of Fire!
•Donotkeepinammableliquidsnearyour
machine.
•Thesulphurcontentofpaintremovers
mightcausecorrosion.Forthisreason,
neverusepaint-removingmaterialsinyour
machine.
•Neveruseproductsthatcontainsolvent
material(likewashinggas)inyourma-
chine.
•Removealltheobjectsinthepocketsof
yourlaundry(needle,paperclip,lighter,
matchesetc.)whenplacingtheminyour
machine.
Fire and Explosion risk may occur.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

15
Fall and injury hazard!
•Donotclimbonyourmachine.Theupperta-
bleofyourmachinemaybreakandyoumight
getinjured.
•Tidythehose,cableandpackagingofyour
machineduringinstallation.Youmighttrip
overandfall.
•Donotturnyourmachineupsidedown,or
onitsside.
•Donotliftyourmachinebyholdingitfrom
extrudingparts(detergentdrawer,door).
Thesepartsmightbreakandcauseyoutoget
injured.
•There’stheriskoftrippingandinjuryifthe
materialslikehoseandcablesarenotprop-
erlystoredafteryourmachineisinstalled. 
Machine must be carried by
2 people or more.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

16
Child safety!
•Donotleavechildrenunattendednearthe
machine.Childrenmightlockthemselvesup
intothemachineanddeathriskmightoccur.
•Doorglassandsurfacemightbe 
extremelyhotwhileyourmachine
operates.Thus,especiallytouchingthe
machinemightgivedamagetothe
skinsofchildren.
•Keeppackagingmaterialawayfromchildren.
•Poisoningmightoccurifthedetergentand
maintenancematerialsareconsumed,and
eyesortheskinmightbeirritatediftheycome
intocontactwiththeskin.Keepthecleaning
materialsawayfromthereachofchildren.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)

17
17
Removal of packaging materials
Packagingmaterialsprotectyourmachine
fromanydamagethatmightoccurduring
transportation.Packagingmaterialsareen-
vironmentallyfriendlyastheyarerecyclable.
Recyclingmaterialprovidesbothrawmate-
rialsavingsanddecreaseswasteproduc-
tion.
Disposal of old machine
Electricalorelectronicalolddevices
mightstillcontainsalvagableparts.
So,neverthrowawayyourolddevices
thatyoudonotuseintothewaste.
Ensurethatthepartsofyouroldelectronic
orelectricaldevicesarereusedbygiving
themtotherelatedauthorities.
Please ensure your old appliances are
kept in an appropriate place for the safe-
ty of children until they are taken outside
the house.
CHAPTER -1: BEFORE USING THE APPLIANCE
PACKAGING AND ENVIRONMENT

18
18
CHAPTER -1: BEFORE USING THE APPLIANCE
SAVINGS INFORMATION
Someimportantinformationtogetmoreef-
ciencyoutofyourmachine:
•Theamountoflaundryyouputinyourwash-
ingmachineshouldnotexceedthemaximum
amountindicated.
Thiswilloptimisetheefciencyofyourma-
chine.
•Notusingthepre-washfeatureforlittleand
normal-dirtylaundrywillsaveelectricityand
water.

19
19
CHAPTER -2: OVERVIEW OF YOUR DEVICE
GENERAL APPEARANCE
ProgramKnob
UpperTray
DetergentDrawer
Door
PumpFilterCover
ElectronicDisplay

20 20
CHAPTER -2: OVERVIEW OF YOUR DEVICE
GENERAL APPEARANCE
TransportationSafety
Screw
TransportationSafety
Screw
TransportationSafety
Screw
TransportationSafety
Screw
WaterInletValve
DischargingHose
PowerCable
