Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Table of Contents
Introduction ............................................ 1
Safety Information ..................................... 1
Parts List ................................................ 2
Resources Required ................................... 3
Prior to Installation ..................................... 3
Installation .............................................. 3
Fixed Faucet ........................................... 3
Pull Down Faucet ...................................... 4
Operation ............................................... 5
Fixed Faucet ........................................... 5
Pull Down Faucet ...................................... 6
Troubleshooting Chart ................................. 7
Maintenance ............................................ 7
Notes .................................................... 8
Flow MaxTM
Faucets
Installation and
Owner’s Manual
(For Aftermarket Applications)
Introduction
Add a splash of modern to your kitchen or bath with a
Flow Max Faucet by Lippert. Available in a variety of spout
constructions, including coiled spring and high-arched,
we are challenging how the world feels about faucets.
Constructed with quality stainless steel or black matte
nish, these sleek faucets are designed for maximum
lifespan and durability.
Safety Information
MOVING PARTS CAN PINCH, CRUSH OR CUT.
KEEP CLEAR AND USE CAUTION.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR PROPERTY
DAMAGE IF NOT SAFELY ADHERED TO AND WITHIN
THE PARAMETERS SET FORTH IN THIS MANUAL

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Parts List
Part #Part # DescriptionDescription
Stainless Steel Finish
719323 Spring Faucet, Single Hole
719324 Curved Gooseneck Faucet, Single Hole
719325 Square Gooseneck Faucet, Single Hole
719333 Bullet Pull Down Faucet, Single Hole
729396 Waterfall Bathroom Faucet, Single Hole
692179 Luminary Lavatory Faucet, Single Hole
Black Matte Finish
2021090598 Spring Faucet, Single Hole
2021090601 Curved Gooseneck Faucet, Single Hole
2021090597 Square Gooseneck Faucet, Single Hole
2021090600 Bullet Pull Down Faucet, Single Hole
2021090599 Waterfall Bathroom Faucet, Single Hole
2021090602 Pulldown Faucet, Single Hole
719323 - Spring Faucet
Pull Down Installation
Black matte - 20212090598
719324 - Curved Gooseneck
Fixed Installation
Black matte - 20212090601
719325 - Square Gooseneck
Fixed Installation
Black matte - 20212090597
719333 - Bullet Pull Down
Pull Down Installation
Black matte - 20212090600
729396 - Waterfall Bathroom
Fixed Installation
Black matte - 20212090599
692179 - Luminary Lavatory
Fixed Installation
2021090602 - Black Matte
Pull Down Faucet

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Resources Required
• Phillips screw driver
• Adjustable wrenches
• Bucket
• Flashlight
• Safety glasses
Prior to Installation
1. Shut o󰀨 the hot and cold water outlet supply valves for
the existing faucet, typically located below the sink.
2. Relieve any pressure from the existing faucet by turning
the existing faucet on and o󰀨.
3. Place a bucket under the sink, under the supply lines’
supply valves to catch any excess water.
4. Using an adjustable wrench, disconnect the supply lines
from the outlet water supply valves. Place the supply lines
into the bucket to drain any excess water.
5. Under the sink, disconnect the mounting hardware for
the existing faucet and remove the faucet from the deck.
6. Make sure the deck around the mounting hole area is
clean, dry and free from any debris.
Installation
Fixed Faucet
1. Unscrew the metal collar with the two screws from the
faucet base and set aside (Fig.1A).
2. Remove the metal washer (Fig.1B) from the base and
set aside.
NOTE: Leave black rubber washer (Fig.1C) on faucet.
3. Place the faucet supply lines through the mounting
hole on the deck, making sure the black rubber washer
and faucet base are seated rmly on the deck of the sink
(Fig.2A).
4. Position the faucet base so the handle is to the right side
of the faucet base (Fig.2B).
NOTE: The handle can be positioned to the left of the
faucet base but is typically placed to the right. Placing the
handle in the middle may cause severe burns depending
on where the faucet neck is located when turning
on the water.
5. Under the sink, slide the metal washer (Fig. 1B) over
the supply lines onto the base of the faucet. Make sure
the metal washer is ush against the underside of the sink
deck and covering the mounting hole (Fig.3A).
A
B
Fig.1
C
A
B
Fig.2
Fig.3 A
sink deck
faucet base

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
6. Make sure the two screws on the collar are evenly
inserted and are ushed with the top of the collar (Fig.4A).
7. Screw the collar onto the faucet base all the way up to
the metal washer (Fig.5A).
NOTE: Make sure the handle of the faucet is placed in the
desired position.
8. Using a Phillips screwdriver, tighten the two screws
(Fig.5B) on the collar to hold the collar into place.
NOTE: The red-marked supply line is for hot water and the
blue-marked supply line is for the cold water.
9. Thread the nut on the hot water supply line onto the hot
water outlet supply valve and tighten with an adjustable
wrench. Do not over tighten.
10. Thread the nut on the cold water supply line onto
the cold water outlet supply valve and tighten with an
adjustable wrench. Do not over tighten.
11. Turn the hot and cold water outlet supply valves back on
and check for any leaks.
Pull Down Faucet
1. Unscrew the black plastic coupler from the faucet base
and slide o󰀨 from the faucet assembly.
NOTE: Wiggle the plastic collar o󰀨 the supply lines one line
at a time.
2. Slide the clear plastic washer o󰀨 the faucet assembly.
3. Place the faucet supply lines through the mounting
hole on the deck, making sure the black rubber washer
and faucet base are seated rmly on the deck of the sink
(Fig.6A).
4. Under the sink, slide the clear plastic washer over the
supply lines up to the underside of the sink deck and
covering the mounting hole (Fig.7A).
A
A
B
A
Fig.4
Fig.5
Fig.6
Fig.7 A

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Operation
Fixed Faucet
1. Pull the lever away from the faucet to turn it on (Fig.9A).
5. Slide the black plastic collar back onto the supply lines,
inserting one supply line at a time.
NOTE: Make sure the inside threads of the black plastic
coupler are at the top.
6. Screw the black plastic collar all the way up the faucet
base until it will no longer turn (Fig.8A).
NOTE: The red marked supply line is for hot water and the
blue marked supply line is for the cold water.
7. Thread the nut on the hot water supply line onto the hot
water outlet supply valve and tighten with an adjustable
wrench. Do not over tighten.
8. Thread the nut on the cold water supply line onto
the cold water outlet supply valve and tighten with an
adjustable wrench. Do not over tighten.
9. Turn the hot and cold water outlet supply valves back on
and check for any leaks.
2. Move the lever towards you for hot water (Fig. 10) and
away from you for cold water (Fig. 11).
NOTE: Located on the front of the lever is a “H” for hot
water and a “C” for cold water. Move the lever in the
direction of the desired temperature.
A
right profile
view
right profile
view
A
Fig.8 Fig.9
Fig.10 Fig.11

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
3. Push the lever in towards the faucet to shut the water o󰀨
(Fig.12A).
Pull Down Faucet
1. Pull the lever away from the faucet to turn it on (Fig.13A).
A
2. Move the lever towards you for hot water (Fig.14) and
away from you for cold water (Fig.15).
NOTE: Located on the front of the lever is a “H” for hot
water and a “C” for cold water. Move the lever in the
direction of the desired temperature.
A
right profile
view
right profile
view
3. To use the spray wand pull down and out on the faucet
head.
4. Press and release the button in on the lower portion
of the faucet head (Fig.16A) for spray mode. Press and
release the button again for stream mode.
5. Replace the faucet head by gently guiding the hose back
into the faucet neck and insert into clip, if applicable.
A
Fig.12
Fig.13
Fig.14 Fig.15
Fig.16

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Troubleshooting Chart
Vibration caused by driving or transporting can loosen plumbing and hardware. Check for loose system components.
Many symptoms can be resolved by tightening hardware. Use care not to over-tighten. Refer to the chart for
troubleshooting tips.
Maintenance
Clean the faucet periodically with a soft cloth. Avoid
abrasive cleaners, steel wool and harsh chemicals as
these will dull the nish and void the warranty.
6. To shut the water o󰀨 push the lever in towards the faucet
(Fig.17).
A
What is happening?What is happening? Why?Why? What should be done?What should be done?
Irregular Flow
Blockage at the aerator. For further instructions:
Reference: CCD-0004351
Cartridge is clogged. For further instructions:
Reference: CCD-0004317
There is a leak from the aerator
when the faucet is on.
The aerator does not fit correctly on the
faucet.
Remove aerator and re-install.
The aerator has irregular or
reduced water flow. The aerator is dirty. Remove aerator and clear debris.
Fig.17

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 09.23.21
Flow MaxTM Faucets
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0001241
Manual information may be distributed as a complete
document only, unless Lippert Components provides
explicit consent to distribute individual parts.
All manual information is subject to change without notice.
Revised editions will be available for free download at
lippert.com. Manual information is considered factual until
made obsolete by a revised version.
Please recycle all obsolete materials and contact
Lippert Components with concerns or questions.
Notes
