Lippert WIFI ON-THE-GO User manual

Quick Start Guide
4G LTE
Wireless Hotspot
CCD-0001336

The WiFi On-the-Go™was designed and engineered
for the mobile lifestyle. The weatherproof, external
cellular antenna array increases your signal range
far beyond a simple “off-the-shelf” mobile hotspot.
WiFi On-the-Go utilizes Direct Link Technology specically
designed to go wherever you go. Direct Link Technology
provides the fastest 4G LTE connectivity available, up to
150Mbps per second, so you’re connected wherever the
road may take you.

Key Features:
• Direct Link Technology provides the fastest 4G LTE connectivity available,
up to 150Mbps
• Weatherproof externally mounted 4G antenna provides superior coverage
• Designed and engineered for the mobile lifestyle
• 2.4 GHz WiFi antennas designed to provide coverage at a longer range.
• More secure connection than open WiFi networks
• Dual power options; 120V AC/DC adapter or 12V DC/DC adapter
• Four additional Ethernet ports connecting additional devices
• MiMo technology for use with multiple devices
• Compatible with 4G LTE Bands 2, 4 and 12 (AT&T®and T-Mobile®)
The AT&T®and T-Mobile®trade names and logos are registered trademarks
of AT&T®and T-Mobile®US, Inc. respectively.

4
Additional Information Sources
WiFi On-the-Go is compatible with AT&T®and T-Mobile®cellular
service using LTE bands 2,4 & 12. In order to activate your
WiFi On-the-Go hotspot, the owner will need to purchase their
own AT&T®or T-Mobile®nano Sim card and data package.
Additional information about this product can be obtained from
lci1.com/support or by using the myLCI app. Replacement components
can be ordered from https://store.lci1.com/ or by using the myLCI app.
The myLCI app is available for free on iTunes®for iPhone®and iPad®
and also on Google Play™for Android™users. iTunes®, iPhone®and iPad®
are registered trademarks of Apple Inc. Google Play™and Android™are
trademarks of Google Inc.
Safety Information

5
Parts List
Letter Part# Description Qty
A 715645 Coax Cable, 10’ 2
B 722255 External Cellular Antenna 1
C 383635 #8 x 3/4” Stainless Steel Pan Head Screw 10
D 722251 2.4 GHz WiFi Antenna 2
E 722252 4.0G Cellular Antenna 2
F 716722 12V DC/DC In-line Power Supply 1
G 722250 Cellular Gateway 1
H 722253 120V AC/DC Adapter 1
B
DE
F
G
Fig.1
A
A
H
C

6
Introduction
The WiFi On-the-Go is a portable device but can be fastened
to a mounting surface if desired. If the external cellular antenna
is not a permanent mount there are a number of methods of temporary
mounting that can be utilized at the retail customer’s discretion, i.e. hook
and loop material, two-sided tape, etc. Use the method best suited for
the temporary mounting surface. If the external cellular antenna is not
permanently attached with all weather sealant, the antenna should not
be exposed to water.
The 12V DC/DC power adapter (Fig.1F) can be used to ensure a smooth
power supply to the cellular gateway when connected to various 12V
batteries or systems such as vehicle, solar power bank, etc. The user
will need to determine which connection type they will need to add to
the red/black wires, such as a cigarette lighter adapter or banana clips,
to suit their specic application.
Activation
Data package required to activate the WiFi On-the-Go. Before visiting
AT&T®or T-Mobile®, make sure to have the IMEI (International Mobile
Equipment Identity) number available. The IMEI number is printed on
the WiFi On-the-Go™label (Fig.2A).
The IMEI number is a unique 15-digit serial number given to every
device, which can then be used to check information such as the
device’s Country of Origin, the Manufacturer and its Model Number.
Whether currently an AT&T®or T-Mobile®Wireless customer or not,
contact AT&T®or T-Mobile®customer service or visit the nearest AT&T®
or T-Mobile®Wireless corporate store to purchase a nano SIM card.

7
Fig.2
A
.
Activation Using AT&T®or T-Mobile®SIM Card

8
Installation
For more comprehensive instructions, visit Lippert Components website
at https://www.lci1.com/assets/content/support/manuals/Electronics/
WiFi_On_the_Go____Aftermarket_Manual.pdf or for immediate use of
WiFi On-the-Go:
NOTE: Not all components will be needed for the initial set-up.
1. Attach the two, 4.0G cellular antennae (Fig.1E) to the corresponding
ports of the cellular gateway (Fig.1G).
2. Attach the two 2.4GHz WiFi antennae (Fig.1D) to the corresponding
ports of the cellular gateway (Fig.1G).
3. Locate the SIM card slot on the side of the cellular gateway (Fig.3B).
4. Gently push in on the edge of the nano SIM card adapter (Fig.3B)
and release, the SIM card adapter will pop out.
5. Position the SIM card adapter’s beveled edge on the top right hand
corner (Fig.4C), insert the nano SIM card (Fig.4B) purchased from AT&T
or T-Mobile at the same position into the nano SIM card adapter (Fig.4A).
System Requirements
• AT&T®or T-Mobile®nano SIM card
• Android, iOS smart device or personal computer
• Ethernet cable (optional)

9
NOTE: Take caution when inserting the SIM card adapter into the SIM
card slot opening to ensure that the adapter is NOT inserted below the
SIM card slot opening.
6. Insert the nano SIM card adapter with the nano SIM card into the SIM
card slot (Fig.3B) until a “click” sound is heard.
NOTE: The “click” sound means the SIM card is now securely latched
into the SIM slot.
7. After making sure the SIM card is rmly seated, connect the 120V
AC/DC adapter or the 12V DC/DC adapter to the cellular gateway (Fig.3A).
8. Plug the 120V AC/DC adapter into a wall outlet or connect the red and
black wires of the 12V DC/DC adapter to a 12V power source.
9. Verify power and connectivity with the Wi On-The-Go LEDs (Fig.3C).
Lights will ash when connected.
Fig.3
A
C
B
Fig.4
C
A
B

10
System Conguration
After successful activation of Wi On-The-Go, use a mobile device or an
Ethernet cable and personal computer to connect to the 4G LTE wireless
hotspot.
NOTE: For the best security, the settings should be congured with the
WiFi On-the-Go wired via Ethernet cable and a personal computer.
Connecting to Wi On-The-Go
1. From the device’s Wi-Fi settings, select Wi On_the_Go_xxxx, (xxxx
means the numbers at the end will vary.) The password will be blank.
2. To change the administrator password, rename the hotspot (ESSID)
and set the security settings with a login password:
A. Open a web browser.
B. Type 192.168.1.1 into the address bar.
C. When prompted, enter the following default username and password
(Fig.5A) and click Login (Fig.5B).
I. Username: root
II. Password: admin

11
3. At the top menu bar select “System” dropdown menu (Fig.6A).
Fig.5
A
B
Fig.6
A B
4. Click on “Administration” (Fig.6B).

12
5. Enter a new administrator password and conrm (Fig.7A and Fig.7B).
NOTE: For security purposes use a strong password. For easy retrieval
of a forgotten password, it is recommended to write down and store the new
password in a secure location or use a password management encrypted
database that may be located on your personal computer or mobile device.
Fig.7
A
B
Fig.8
A
6. Click “Save and Apply” at the bottom of the screen (Fig.8A).

13
A
B
7. At the top menu bar select “Network” dropdown menu (Fig.9A).
8. Click on “Wi” (Fig.9B).
A. Click on the Edit button under the “Wireless Overview” section
(Fig.10A), then scroll to the Interface Conguration at the bottom
of the page.
Fig.9
Fig.10
A

14
Fig.11
A
Fig.12
A
A
Fig.14Fig.13 A
B. If preferred, rename the hotspot (ESSID) here (Fig.11A).
C. Click on “Save” (Fig.12A).
D. Click on the “Wireless Security” tab (Fig.13A) to ensure Wi-Fi security.
I. From the menu, select the desired level of security. LCI recommends
WPA2-PSK (Fig.14A).
II. Enter a log in password in the “Key” eld (Fig.15A). The password
MUST be at least eight characters.
NOTE: For easy retrieval of a forgotten password, it is recommended to write
down and store the new password in a secure location or use a password
management encrypted database that may be located on your personal
computer or mobile device.
A

15
A
B
Fig.15
9. Click on “Save & Apply” button (Fig.15B).
NOTE: “Waiting for changes to be applied” may be visible until sign-in is
completed.
10. Sign into the hotspot again by selecting the hotspot from your mobile
device’s Wi-Fi settings.
NOTE: This will be the default hotspot name or the new name given in
step 8B.
11. If the security setting was changed and a security (log in) password
was added (step 8DII), enter the new password.
NOTE: Do not press “RESET” on the back of the cellular gateway unless
directed by Lippert Customer Service. Reset will take the device back to
factory settings and make the device inoperable.

16
FCC 15B statement:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
|limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Part 15 compliance statement:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.

17
IC User manual notice:
This device contains licence-exempt transmitter(s)/receiver(s) that com-
ply with Innovation, Science and Economic Development Canada’s
licence-exempt RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that
may cause undesired operation of the device.
Non-modication Warning
Any changes or modications to this device not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
RF Exposure Statement
This equipment complies with FCC/IC radiation exposure limits set forth
for an uncontrolled environment and meets the FCC radio frequency
(RF) Exposure Guidelines and RSS-102 of the IC radio frequency
(RF) Exposure rules. This equipment should be installed and operated
keeping the radiator at least 30cm or more away from person’s body.

18
Notes

19
Notes

Should you have any questions, please do not
hesitate to contact us at [phone] or by
email at [email protected].Self-help
tips, technical documents, product videos and a
training class schedule are available at lci1.com
or by downloading the MyLCI app.
Contact
Lippert Components Incorporated
part no. 722050
CCD-0001336Rev: 07.03.18
