Lite-Puter DP-E6B User manual

ISO 9001 CERTIFIED www.liteputer.com.tw
DP-E6B
Ethernet to DMX Interface
【User Manual】
Lite Puter Enterprise Co., Ltd.
Website：www.liteputer.com.tw
Email：[e-mail]
Lite-Puter
DP-E6B [EUM-A]

ISO 9001 CERTIFIED www.liteputer.com.tw
Index
CHAPTER ONE INTRODUCTION....................................................................................................................2
1-1 FEATURE .......................................................................................................................................................2
1-2 SPECIFICATION..............................................................................................................................................2
1-3 DIMENSION ...................................................................................................................................................2
1-4 FUNCTION .....................................................................................................................................................3
1-5 SYSTEM DIAGRAM.........................................................................................................................................4
CHAPTER TWO OPERATION..........................................................................................................................5
2-1 SOFTWARE VERSION CHECK ..........................................................................................................................5
2-2 CHANNEL EDIT..............................................................................................................................................5
2-3 SCENE EDIT.................................................................................................................................................11
2-4 DMX IN MONITOR........................................................................................................................................14
2-5 DMX OUT MONITOR.....................................................................................................................................15
2-6 DMX IN CONFIG...........................................................................................................................................16
2-7 ASTRO TIMER ..............................................................................................................................................17
2-8 CALENDAR TIMER .......................................................................................................................................21
2-9 TIMER ON/OFF.............................................................................................................................................24
2-10 SYSTEM CLOCK ........................................................................................................................................25
2-11 PATCH EDITING ..........................................................................................................................................28
2-12 SD CARD SETTING .....................................................................................................................................31
2-13 IPADDRESS SETTING .................................................................................................................................34
2-14 MAC ADDRESS SETTING.............................................................................................................................35
2-15 LCD BACK LIGHTING SETTING ...................................................................................................................37
2-16 MEMORY INITIALIZATION ..........................................................................................................................38
2-17 CONNECTION WITH HOME LIGHTING SOFTWARE........................................................................................39
2-18 CONNECT PC BY USB PORT.........................................................................................................................40
GUARANTEE.....................................................................................................................................................41
Lite-Puter
DP-E6B[EUM-A]
1

ISO 9001 CERTIFIED www.liteputer.com.tw
Chapter One Introduction
1-1 Feature
zIt accepts/outputs DMX-512 signal and controls 512 channels. It can monitor
DMX-512 signal status from DMX OUT/IN MONITOR function.
zIt accepts ECP series control panel and CP-2B/CP-3B control panel’s control.
zIt can save/recall 896 scenes and each scene can control up to 512 channels.
zIt can set each scene’s fade in/fade out time.
zIt can set accept/refuse DMX input.
zIt can set 128 zones.
zIt has LCD display and easy to operate.
zIt has timer function and can set astronomical timer and calendar timer.
zIts memory is 8M and it can be expanded to 16G by SD card; it also can accept
SDHC.
zIt can work with Lite-Puter’s home lighting software.
zThe data can be saved to memory or SD card, or be coped to PC from USB port.
zIts data (device settin
updated by SD card
g, scene setting, timer setting and patch setting) can be
or other flash memory.
1-2 Specification
zPower supply: AC 90 – 240V, 45-63 Hz
zSignal input: DMX-512, EDX
zSignal output: DMX-512
zSignal connector: 4PIN green terminal, PHONE JACK（RJ11）, XLR 5-PIN
zDimension: 482( W ) X 88 ( H ) X 112( D ) mm
zWeight: 2Kg
1-3 Dimension
Lite-Puter
DP-E6B[EUM-A]
2

ISO 9001 CERTIFIED www.liteputer.com.tw
1-4Function
10 9 8 7
1
23456
1 LCD display 2 DMX signal output terminal
3 DMX/EDX signal input terminal 4 Ethernet port
5 Power supply: AC 90 – 240V 6 Power on/off
7 DMX signal output terminal 8 SD card port
9 USB port 10 Number/function key
Lite-Puter
DP-E6B[EUM-A]
3

ISO 9001 CERTIFIED www.liteputer.com.tw
1-5 System Diagram
Lite-Puter
DP-E6B[EUM-A]
4
（data upload/download）
（DMX-512）
（CP-3B EDX）
（EDX）
（DMX-512）
……

ISO 9001 CERTIFIED www.liteputer.com.tw
Chapter Two Operation
2-1 Software Version Check
After turning on the device and LCD shows,
进入主界面，LCD 显示如下：
It will shift to main page after 3 seconds and LCD shows,
Version 1.0
LITE-PUTER
DP-E6B
www.liteputer.com.tw
Version no.：V1.0.
Lite-Puter
DP-E6B[EUM-A]
5
2-2 Channel Edit
Lite-Puter 17 : 47
CP001 SCOF
D:192.168.003.234
L:Disconnect
Channel group: a group that include several contious/discontious channels is called a
channel group.
On usual , user only can edit one channel at one time but with channel group function ,
user can edit several channels at one time.
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-2 Press【▲】or【▼】to select F1 and LCD shows,
STEP-3 Press【ENT】to check the channel and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Press【▲】or【▼】to check all 512 channel’s dimming value.
CH +/-:mul-sel 17:47
C001 NC 00 01 05 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
Channel’s dimming value.
Channel no.
NC means the channel is useless and FL means the dimming value is 100%.
CH +/-:mul-sel 17:47
C511 NC NC %
Notice: On the main page , press【CH】can enter channel edit directly.
STEP-4 Press【ENT】to enter channel edit and LCD shows,
Lite-Puter
DP-E6B[EUM-A]
6

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-5 Press【▲】,【▼】or the number keys on the front panel to adjust the
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
CH 17:47
C001 _ _ 00 01 05 82 %
Blink.
dimming value; press【◀】or【▶】select the channel.
Press【▲】or【▼】once to increase or discrease 1% dimming value at one time ;hold
【▲】or【▼】to adjust the value quickly. Press【+】to adjust the value to FL directly，
press【-】to adjust the value to NC directly.
STEP-6 After setting, press to【ENT】save.
CH 17:47
C001 NC 00 01 88 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
Blink.
CH+/-:mul-sel 17:47
C001 NC 00 01 88 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
Stop blinking.
Please follow the steps below to create the channel group.
STEP.1: On the channel check page , press【+】and LCD shows,
Lite-Puter
DP-E6B[EUM-A]
7

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP.2: Press【▲】or【▼】,or the number keys on the front panel to enter a channel
no. that need to add in the channel group.
STEP.3: Press【ENT】to save the channel to the channel group.
STEP.4: Repeat STEP.1~STEP.3 to add other channels to the channel group.
Lite-Puter
DP-E6B[EUM-A]
8
+CH001 17 : 47
C001 NC 00 01 05 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
Blink.
+CH032 17 : 47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC
Blink.
CH +/-:mul-sel 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC
CH +/-:mul-sel 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC

ISO 9001 CERTIFIED www.liteputer.com.tw
Please follow the steps below to delete channel from the channel group.
STEP.1: On the channel check page , press【-】and LCD shows,
STEP.2: Press【▲】,【▼】or the number keys on the front panel to enter a channel
no. that need to delete from the channel group.
STEP.3: Press【ENT】to delete the channel.
-CH001 17 : 47
C001 NC 00 01 05 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82
C016 NC 00 01 05 82
C021 NC 00 01 05 82
C026 NC 00 01 05 82
Blink.
-CH032 17 : 47
C031 NC NC NC NC NC %
Blink.
C056 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C036 NC NC NC NC NC
STEP.4: Repeat STEP.1~STEP.3 to delete other channels from the channel group.
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC
CH +/-:mul-sel 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
Lite-Puter
DP-E6B[EUM-A]
9

ISO 9001 CERTIFIED www.liteputer.com.tw
After creating the channel group, Please follow the steps below to set their dimming
value.
STEP-1 On the channel check page ,press【ALT】to edit the channel group and LCD
shows,
STEP-2 Press【▲】,【▼】or the number keys on the front panel to adjust the
dimmingvalue of the channel group.
Press【▲】or【▼】once to increase or discrease 1% dimming value at one time ;hold
【▲】or【▼】to adjust the value quickly.Press【+】to adjust the value to FL directly，
press【-】to adjust the value to NC directly.
STEP-3 After setting, press【ENT】to save.
CH 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC
Blink.
CH 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC 13 NC
C051 NC NC NC 13 NC
C056 NC NC 13 NC NC
Blink.
C041 NC NC NC NC NC
C046 NC NC NC NC NC
C051 NC NC NC NC NC
C056 NC NC NC NC NC
CH +/-:mul-sel 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
Lite-Puter
DP-E6B[EUM-A]
10

ISO 9001 CERTIFIED www.liteputer.com.tw
CH +/-:mul-sel 17:47
C031 NC NC NC NC NC %
C036 NC NC NC NC NC
C041 NC NC NC NC NC
C046 NC NC NC 13 NC
C051 NC NC NC 13 NC
C056 NC NC 13 NC NC
2-3SceneEdit
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
STEP-2 Press【▲】or【▼】to select F2 and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Notice: On the main page , press【SEQ】can enter scene edit directly.
Lite-Puter 17 : 47
F1 : CHANNEL EDIT
▶F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
STEP-3 Press【ENT】to enter scene edit and LCD shows,
]
Lite-Puter
DP-E6B[EUM-A]
11

ISO 9001 CERTIFIED www.liteputer.com.tw
Notice: It will show the scene off of zone 1’s editing page automatically.
CP001 SCOF 17 : 47
C001 NC NC NC NC NC %
C006 NC NC NC NC NC
C011 NC NC NC NC NC
C016 NC NC NC NC NC
C021 NC NC NC NC NC
C026 NC NC NC NC NC
CP001 means zone 1.
SCOF means scene off.
Press【▲】or【▼】to check all 512 channel’s dimming value.
STEP-4 Press【ENT】to edit scene and LCD shows,
CP001 SCOF 17 : 47
C511 NC NC %
SC FADE：0.1 S
STEP-5 Press【▲】,【▼】or the number keys on the front panel to adjust the
CP001 SCOF 17 : 47
C001 _ _ NC NC NC NC %
C006 NC NC NC NC NC
C011 NC NC NC NC NC
C016 NC NC NC NC NC
C021 NC NC NC NC NC
C026 NC NC NC NC NC
Blink.
dimming value; press【◀】or【▶】select the channel.
C021 NC 00 01 05 82
C026 NC 00 01 05 82
C016 NC 00 01 05 82
CH 17:47
C001 NC 00 01 88 82 %
C006 99 FL NC 00 01
C011 NC 00 01 05 82 Lite-Puter
DP-E6B[EUM-A]
12

ISO 9001 CERTIFIED www.liteputer.com.tw
Press【▲】or【▼】once to increase or discrease 1% dimming value at one time ;hold
【▲】or【▼】to adjust the value quickly.Press【+】to adjust the value to FL directly，
press【-】to adjust the value to NC directly.
CP001 SCOF 17 : 47
C511 00 00 %
SC FADE：0.1 S
Blink.
SC FADE is the scene fade time , press【▲】or【▼】once to increase or discrease 0.1
at one time ; hold【▲】or【▼】to adjust the value quickly. It’s range from 0 second to
99 minutes.
STEP-6 After setting, press【ENT】to save.
Notice: User can press【◀】or【▶】shift to edit other scene, it will show the 7 scenes
of 128 zones in order; hold 【◀】or【▶】to shift the scene no. quickly.
CP001 SCOF 17 : 47
C511 00 00 %
SC FADE：0.1 S
Stop blinking.
CP001 scene off CP002 scene off CP003 scene off
CP001 scene 1 CP002 scene 1 CP003 scene 1
CP001 scene 2 CP002 scene 2 CP003 scene 2
CP001 scene 3 CP002 scene 3 CP003 scene 3
CP001 scene 4 CP002 scene 4 CP003 scene 4
CP001 scene 5 CP002 scene 5 CP003 scene 5
CP001 scene 6 CP002 scene 6 CP003 scene 6
Lite-Puter
DP-E6B[EUM-A]
13

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-7 Press【◀】or【▶】shift to another scene and repeat STEP4 ~STEP6 to do
the setting.
When editing the channel, press【SEQ】can save the channel setting to a scene and
it will show,
Lite-Puter
DP-E6B[EUM-A]
14
Press【▲】,【▼】and【◀】,【▶】to adjust the zone no. and scene no.
MESSAGE 17 : 47
SAVE TO SCENE
CP:001 SC:OF
ENT’ENTER FCN’EXIT
/▲▼ SELECT
After setting, press【ENT】to save or press【FCN】to exit.
2-4DMXINMONITOR
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
STEP-2 Press【▲】or【▼】to select F3 and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Lite-Puter 17 : 47
F1 : CHANNEL EDIT
F2 : SCENE EDIT
▶F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-3 Press【ENT】to enter DMX IN monitor and LCD shows,
STEP-4 Press【▲】or【▼】to check all 512 channels.
DMX IN 17 : 47
C001 00 00 01 05 82 %
C006 99 FL 00 00 01
C011 00 00 01 05 82
C016 00 00 01 05 82
C021 00 00 01 05 82
C026 00 00 01 05 82
Channel 1 to 5’s dimming value
is 0, 0, 1%, 5%, 82%.
2-5DMXOUTMONITOR
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
STEP-2 Press【▲】or【▼】to select F4 and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
STEP-3 Press【ENT】to enter DMX OUT monitor and LCD shows,
Lite-Puter 17 : 47
F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
▶F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Lite-Puter
DP-E6B[EUM-A]
15

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-4 Press【▲】or【▼】to check all 512 channels.
DMX OUT 17 : 47
C001 90 00 00 00 FL %
C006 00 00 00 00 00
C011 00 00 00 00 00
C016 00 00 00 00 00
C021 00 00 00 00 00
C026 00 00 00 00 00
Channel 1 to 5’s dimming value is
90%, 0, 0, 0, and 100%.
DMX OUT 17 : 47
C511 80 00 %
2-6DMXINCONFIG
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
STEP-2 Press【▲】or【▼】to select F5 and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Lite-Puter 17 : 47
F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
▶F5 : DMX IN CONFIG
F6 : ASTRO TIMER
Lite-Puter
DP-E6B[EUM-A]
16

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-3 Press【ENT】to enter DMX IN configration and LCD shows,
STEP-4 Press【▲】,【▼】or【◀】,【▶】to select the setting.
DMX IN CONFIG 17 : 47
DMX IN OFF
DMX IN ON
TO DMX OUT
ENT’ENTER FCN’EXIT
/▲▼ SELECT
DMX IN OFF —— refuse DMX signal.
DMX IN CONFIG 17 : 47
DMX IN OFF
DMX IN ON
TO DMX OUT
ENT’ENTER FCN’EXIT
/▲▼ SELECT
DMX IN ON —— accept DMX signal and monitor DMX IN signal in DMX IN
MONITOR function.
TO DMX OUT —— accept DMX signal and monitor DMX OUT signal in DMX OUT
MONITOR function.
STEP-5 After setting, press【ENT】to save or press【FCN】to exit.
2-7ASTROTIMER
STEP-1 On the main page, press【FCN】to enter function menu and LCD shows,
Lite-Puter 17 : 47
▶F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
F6 : ASTRO TIMER Lite-Puter
DP-E6B[EUM-A]
17

ISO 9001 CERTIFIED www.liteputer.com.tw
STEP-2 Press【▲】or【▼】to select F6 and LCD shows,
STEP-3 Press to【ENT】enter astronomical timer and LCD shows,
Lite-Puter 17 : 47
F1 : CHANNEL EDIT
F2 : SCENE EDIT
F3 : DMX IN MONITOR
F4 : DMX OUT MONITOR
F5 : DMX IN CONFIG
▶F6 : ASTRO TIMER
If there has astronomical timer and LCD will show the first timer.
TIMER 17 : 47
NO ASTRO-TIMER
1 DEL 2 ADD 3 EDIT
REVIEW/SEL ▲▼ ADJ
It will show info alternatively as
below,
No astronomical timer.
STEP-4 Press【◀】or【▶】to check other timer.
TIMER 00117 : 47
SUNRISE+ 01:00
CP:002 SC:01
FD:0.1S
1 DEL 2 ADD 3 EDIT
REVIEW/SEL ▲▼ ADJ
Add timer
STEP.1: Enter astronomical timer function , press【2】to add a timer and LCD shows,
Lite-Puter
DP-E6B[EUM-A]
18

ISO 9001 CERTIFIED www.liteputer.com.tw
Lite-Puter
DP-E6B[EUM-A]
19
STEP.2 : Press【▲】or【▼】to select sunrise or sunset .
TIMER 17:47
SUNRISE+ 01:00
Blink.
STEP.3 Press【▶】to select + or -;press【▼】to change+to -.
STEP.4 Press【▶】to set the time value; press【▲】or【▼】to adjust value.
CP:001 SC:OF
FD:0.1S
1 DEL 2 ADD 3 EDIT
REVIEW/SEL ▲▼ ADJ
It will show info alternatively as
below,
TIMER 17:47
SUNSET + 01:00
CP:001 SC:OF
FD:0.1S
1 DEL 2 ADD 3 EDIT
REVIEW/SEL ▲▼ ADJ
Blink.
TIMER 17:47
SUNSET - 01:00
CP:001 SC:OF
FD:0.1S
1 DEL 2 ADD 3 EDIT
REVIEW/SEL ▲▼ ADJ
Blink.
+: after sunrise time/sunset time
-：before sunrise time/sunset time
“Sunset +01:00” means 1 hour after
sunset time 17:13, it’s 18:13.
TIMER 17:47
SUNSET - 02:00
CP:001 SC:OF
FD:0.1S
“Sunset -01:00” means 1 hour
before sunset time 17:13, it’s 16:13.
SUNRISE 06:42
SUNSET 17:13
“Sunset -02:00” means 2 hour
before sunset time 17:13, it’s 15:13.
