Litheli U1BR27103 User manual

Readthis material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
40V BATTERY POWERED
LEAF BLOWER
U1BR27103
Visit our website at: http://www.litheli.com
Operator's Manual
Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Save This Manual
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please contact us: WWW.LITHELI.COM.
Copyright 2020 Litheli. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Litheli.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
©

All visitors should
be kept at adistance from work area.
Watch what you are doing. Use
common sense. Do not operate appliance when
you are tired.
When not in use,
appliances should bestored indoors indry, and
high or locked-up place - out of reach of children.
Page 2
Table of Contents
Safety ............................................................... 2
Specifications ............................................... 5
Setup................................................................. 6
Operation ....................................................... 9
Maintenance ................................................. 11
Parts List and Diagram..............................12
Warranty ......................................................... 14
When using electric gardening appliances, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and personal injury, including the following:
READ ALL INSTRUCTIONS
1. Avoid Dangerous Environment -
Do not use appliances indamp orwet locations.
2. Do Not Use In Rain.
3. Keep Children Away -
4. Dress Properly -Do not wear loose clothing or
jewelry. They can be caught inmoving parts.
Use of rubber gloves and substantial footwear
is recommended when working outdoors.
Wear protective hair covering to contain long hair.
5. Wear ANSI-approved safety goggles,
hard hat and heavy-duty rubberwork
gloves. Useface or dust mask if
operation is dusty.
6. Use Right Applianc - Do not use appliance
for any job except that for which it is intended.
7. Avoid Unintentional Starting - Do not carry
appliance with finger on switch.
8. Do Not Force Appliance - It will dothe job
better and withless likelihood of injury at the rate
for which it was designed.
9. Do not Overreach - Keep proper footing and
balance at all times.
10. Stay Alert -
11. Store Idle Appliances Indoors -
12.
Maintain Appliance With Care - Keep cutting edge
sharp and clean forbest performance and to
reduce the risk of injury. Follow instructions for
lubricating and changing accessories. Keep
handles dry, clean, and free from oil and grease.
WWW.LITHELI.COM
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
WARNING SYMBOLS AND DEFINITIONS
Important Safety Instructions
Gardening Appliance Safety
U1BR27103

Page 3
13. Check Damaged Parts - Before furtheruse of the
appliance, a guard or other part that is damaged
should be carefully checked todeterminethat it will
operate properly and perform its intended function.
Check for alignment of moving parts,binding of
moving parts,breakage of parts,mounting, and any
other condition that may affect its operation. Aguard
or other part that is damaged should beproperly
repaired or replaced by aqualified technician unless
indicated elsewhere inthis manual.
14. Wear full eye protection and protective clothing.
15. If electrolyte contacts the skin, wash it off
immediately with water.
16. If electrolyte contacts the eyes, flush thoroughly
and immediately with water. Seek medical attention.
Blower Safety
1. Do not put any object into openings.Do not use
with any opening blocked; keep free of dust,lint,
hair, and anything that may reduce air flow.
2. Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
3. Use extra care when cleaning on stairs.
4. Do not use to pick up flammable or
combustible liquids, such as gasoline, or
use in areas where they may be present.
5. Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or hot
ashes.
6. Remove all hard objects from work area. Do
not blow debris in the direction of people,
animals or property.
7. Use only accessories provided. Keep guards in
place and in working order.
8. Maintain labels and nameplates on the
appliance. These carry important safety
information. If unreadable or missing, contact
Litheli for a replacement.
9. The battery Charger gets hot during
use. The Charger’s heat can build up to
unsafe levels and create a fire hazard if
it does not receive adequate ventilation,
due to an electrical fault, or if it is used in a hot
environment.
Do not place the Charger on a flammablesurface.
Do not obstruct any vents on theCharger.
Especially avoid placing the Charger on carpets
also obstruct vents under the Charger.
Place the Charger on a stable,solid,nonflammable
surface (such as a stable metal workbench or
concrete floor) at least 1 foot away from all
flammable objects,such as drapes or walls. Keep a
fire extinguisher and asmoke detector inthe area.
Frequently monitor theCharger and
Battery Pack while charging.
10. People withpacemakers should consult their
physician(s) before use.Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemakerfailure.
11. The warnings,precautions, and instructions
discussed inthis instruction manual cannot cover
all possible conditions and situations that may
occur.
It must be understood by the operator that
common sense and caution are factors which
cannot bebuilt intothis product, but must be
supplied by the operator.
U1BR27103 WWW.LITHELI.COM
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE
A LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE IF MISTREATED:
1. Keep Battery Pack dry.
2. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
a. Open,
b. Drop,
c. Short-circuit,
d. Puncture,
e. Incinerate,
f. Expose totemperatures greaterthan 104°F.
3. Charge Battery Pack only according to its
Charger’s instructions.
4. Inspect Battery Pack before every use;
do not use or charge if damaged.

Page 4
Battery Charger Safety
1. SAVE THESE INSTRUCTIONS - This manual
contains important safety and operating instruction
for battery charger Model U1BR27103.
2. Before using battery charger, read all instructions
and cautionary markings on battery charger,
battery, and product using battery.
3. CAUTION - To reduce risk of injury, charge only
li-ion type rechargeable batteries. Other types of
batteries may burst causing personal injury and
damage.
4. Do not charge or use appliance in rain, or in wet
locations.
5. Do not use battery-operated appliance in rain.
6. Remove or disconnect battery after use, before
servicing, cleaning or removing material from
the gardening appliance.
7. Do not dispose of battery in a fire. The cell may
explode. Check with local codes for possible
disposal instructions.
8. Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxicif swallowed.
9. Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings,bracelets, and keys. The battery
or conductor may overheat and cause burns.
Vibration Safety
This tool vibrates during use.
Repeated or long-term exposure to vibration may cause
temporary or permanent physical injury, particularly to
the hands, arms and shoulders. To reduce the risk of
vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-ups to
ensure medical problems are not being caused or
worsened from use. Pregnant women or people
who have impaired blood circulation to the hand,
past hand injuries, nervous system disorders,
diabetes, or Raynaud’s Disease should not use this
tool. If you feel any symptoms related to vibration
(such as tingling, numbness, and white or blue
fingers), seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces the
blood supply to the hands and fingers, increasing
the risk of vibration-related injury.
3. Wear suitable gloves to reduce the vibration
effects on the user.
4.
5. Include vibration-freeperiods each day of work.
6. Grip tool as lightly as possible (while still keeping
safe control of it). Let the tool do the work.
7. To reducevibration,maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
SAVE THESE INSTRUCTIONS
U1BR27103
WWW.LITHELI.COM
Specifications
Charger Input Rating 100-120VAC / 50-60Hz
Charger Output Rating 36VDC / 3.0A
Battery Rating 40VDC / 2.5Ah / 90Wh
Battery Type 40V Li-Ion
Sound Rating Highest Speed - 96dB @ 1.5'
Use tools with the lowest vibration when there is
a choice.
Litheli

Page 5
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING:
grounded.Do not modify the power cord plug provided with the charger. Do not use the charger
if the power cordor plug is damaged. If damaged, have it repairedby a service facility before
U1BR27103 WWW.LITHELI.COM
Extension Cords
NOTE : Extension cords must not be used with this item’s Charger..
Symbology
Never throw the rechargeable
battery into water.
Rechargeable battery contains
lithium! Do not dispose of in trash bin!
- Discharge the rechargeable battery
by operating the tool at idle until the
motor stops.
- Take the rechargeable battery out
of the tool.
Double Insulated
VVolts
~Alternating Current
AAmperes
n0 xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
Do not throw the batteries in the
household waste, fire or water.
Do not expose the battery to sunlight
for a long time and do not place it on
radiators (max. 45 ° C).
Dispose of the batteries at a collection point
for old batteries, from where they are taken
to environmentally friendly recycling.
Charge level indication.
Indication of the noise
level LWA in dB.
Charge level indication.

Page 6
U1BR27103
WWW.LITHELI.COM
Trigger
Blower
Tube
Handle
Variable
Speed
Dial
Turbo Speed
Button
Trigger
Safety
Lock
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Functions

Page 7
U1BR27103 WWW.LITHELI.COM
Charging the Battery Pack
NOTE : The Battery Pack comes partly charged.
Charge the Battery Pack prior to first use, ideally atleast 60minutes.
Rapid Battery Charger
Power Cord
with Plug
Battery
Pack
Connector
Charging
Status
LED – Red
Charging
Status
LED – Green
Alwayspull out the Power Plug of the Charger
from the mainsbefore removing or connecting the Battery Pack to the charger.
Never charge the Battery Pack when the ambient temperature isbelow 10 °C or above 40 °C.
Rest the Charger for atleast 15 minutes between successive charging sessions.
If no Battery Pack isinserted into the Chargerand the
chargeris connected to mains, the Charging Status LED flashes green.
1 .
2.
3.
4.
Align the Battery Pack to the rails of the
Charger and slide it in. Ensure it clicks
noticeably in place.
Connect the Power Plug of the Charger with
the mains. The Charging Status LED lights
up red. The continuously lit green
Charging Status LED indicates
that the charging process is complete.
Disconnect the Power Plug of the
Charger from the mains and remove the
Battery Pack from the charger.
Attach the Battery Pack back to the
product (see “Installing and Removing
Battery Pack”).
Charging status LEDs
Green LED flashes
without battery pack Charger ready
Green LED lights up
with battery pack
Battery pack fully
charged
Red LED lights up with
battery pack Battery pack charging
Red and green LEDs
flashing Battery pack defect
Red and green LEDs
continuously lit
Battery pack too cold
or warm

Page 8
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Release Trigger of the appliance and remove battery pack before performing any procedure in this section.
Attaching Blower Tube
1. 2. Rotate Blower Tube clockwisetolock inplace.
U1BR27103
WWW.LITHELI.COM
Blower
Outlet
Blower
Tube
Tab
Slot
SlideBlower Tube over Blower Outlet,lining
up. Blower Tube's Slot over Blower Outlet's Tab.
Battery Pack
Release
Button
Battery Level
Indication Lights
Battery
Level Button
Checking the Battery Charging Level
Press the Battery Level Button
to check the charging level of the Battery Pack. The charging level
will be shown on the Battery Level Indication Lights.
Charge the Battery Pack before
operation when it is at 25% or low battery charging level.
NOTE :
Charging level
Charging level too low
Between 5% and 50%.
Between 50% and 80%.
More than 80%.
LED status

While charging, Battery Pack and Charger
may become warm tothetouch and the Chargers
fan may come on. This is normal.
Afully discharged Battery Pack will take
about 1 hour tofully charge.
Page 9
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM FLYING DEBRIS:
Wear long pants, long sleevesand protective footwear. Wear ANSI-approved
safety goggles, dust mask,hearing protectors,and gloves.
Charging Battery Pack
1. Place Battery Chargeron a dry, flat, fireproof
surface indoors.
NOTE : Allowbattery to cool completely before charging.
2. ExamineBattery Pack. Do not charge a cracked,
open, or leaking Battery Pack, or charge a
non-recommended type of Battery Pack.
3. Battery Pack is designed to fit this Charger
specifically.If Battery Pack does not fit Charger
properly,do not try to insert it. Do not force
Battery Pack into the Charger.
4. Plug Charger into agrounded,120VAC, 60Hz
receptacle. Green LEDwill blink, showing that power
is supplied tothe charger.
5. Slide Battery Pack onto Charger. Red LED
will light continuously while charging.
NOTE :
NOTE :
6. Green LED will light continuously when
Battery Pack is charged. Unplug Charger and
remove Battery Pack when finished.
7. Allow Battery Pack to cool completely before use.
Installing and Removing Battery Pack
1. To install: SlideBattery Pack intoslot on
back of Blower until it clicks into place.
2. To remove: Press bothBattery Pack Release
Buttons and pull Battery Pack out of slot.
U1BR27103 WWW.LITHELI.COM
Battery
Pack
Battery Pack
Release
Buttons

Page 10
Operation
TO AVOID SERIOUSINJURYAND PROPERTY DAMAGE:
Inspect the area before using the Blower. Remove all hard objects from work area.
Do not blow debris in the direction of people, animals or property.
Use both hands when operating Blower.
1. Assemble Blower according to.
Assembly Instructions on page 8.
NOTE : Rake or sweep toloosen debris if necessary.
2. Hold Blower with both hands, with the
Tube several inches off the ground.
3. Press Trigger Safety Lock, then press Trigger.
Adjust Variable Speed Dial as necessary.
4. Press Turbo Speed button to increase air
speed. Release button when done.
5. Sweep from side to side.
6. Release Trigger when done.
7. When finished, to prevent accidents:
• Remove battery pack.
• Wipe external surfaces of the appliance
with clean cloth. Store in an indoor
dry area out of reach of children.
U1BR27103
WWW.LITHELI.COM
Trigger
Handle
Variable
Speed
Dial
Turbo Speed
Button
Trigger
Safety
Lock

wipe external surfaces of the
appliance with clean cloth. Store inanindoor
dry area out of reach of children.
inspect the
generalcondition of theappliance. Check for:
Page 11
User-Maintenance and Storage
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Release Triggerof the appliance and remove battery packbefore performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM APPLIANCE FAILURE:
Do notuse damaged equipment. If abnormal noise orvibration
occurs, have the problem corrected before furtheruse.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE,
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other conditionthat may affect its safe
operation.
2. AFTER USE,
3. Li-Ion BATTERY MUST BERECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.
4. All parts are permanently lubricated.
Donot use additional lubrication.
U1BR27103 WWW.LITHELI.COM

Page 12
NANC E
U1BR27103
WWW.LITHELI.COM
Record Product’s Serial Number Here:
NOTE : If product has no serial number, record month and year of purchase instead.
NOTE : Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THEPRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT.IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSEDTECHNICIANS, ANDNOT BY THEBUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HISOR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO,OR ARISING OUT OF HIS OR HER INSTALLATIONOF REPLACEMENT PARTS THERETO.
Parts List and Diagram
Parts List
Part Description Qty
1 Left Casing 1
2 Platten 1
3Inner plum pan head tapping screw 22
4Internal wire 1
5 Connection piece 1
6 Anti-static metal wire 1
7 Inner plum pan head tapping screw 1
8 Charger insert holder 1
9 Insert 3
10 Upper trigger 1
11 Inching switch 1
12 3
13
Trigger spring
1
14
Lower trigger
Part Description Qty
15 Rocker switch 1
16
17
Button
Air outlet pipe lock spring
1
1
18 Air duct sleeve 1
19 Flat round head semi-tubular rivet 2
20 Small air duct 1
21 Big air duct 1
22 Air outlet housing 1
23 Upwind pipe 1
24 Brushless motor 1
25 Air duct 1
26 Cross recessed triple screw 3
27
Cross recessed pan head
tapping screw
40V Battery pack
1
28 1
29
30
31
32
33
34
Quick button
Fan blade (with insert)
Locknut hexagon nut with flange
Rear cover
Right Casing
1
1
1
1
1
1
1
Controller assembly
Crimp terminal

Page 13 U1BR27103 WWW.LITHELI.COM
Assembly Diagram

Warranty
90-Day Money Back
You May Return Your Product for A Full Refund Within The First 90 Days of Your Purchase.
3-Year Battery and Charger Warranty
Against Defects in Workmanship and Materials.
Battery and Charger Must Be Used and Maintained in Accordance with The Manual of The
Operator's Instructions and Regulations.
5-Year Tool Warranty
Against Defects in Materials, Parts or Workmanship.
Litheli at Its Own Discretion Will Repair or Replace Any and All Parts Found To Be Defective.
All Units Must Be Used and Maintained in Accordance with The Directions and Regulations in The
Operator's Manual.
Returning The Product
Contact Us at www.litheli.com for The Return Address, We Will Issue Replace/Refund Upon Receiving
Your Return.
Need An Extra Copy of The Operator's Manual? Visit www.litheli.com to Download it.
Follow @Litheli Global
Customer Service E-mail：[e-mail]
