INSTRUCTION MANUAL
MODEL: CM5018D-GS

CONTENTS
Page
IMPORTANT SAFETY INSTRUCTIONS
2-3
PRODUCT OVERVIEW
4-5
HOW TO USE
5-10
CLEANING
10-12
TROUBLE SHOOTING 13
1

Before using the electrical appliance, the following basic precautions should always be
followed including the following:
•Read all instructions before use. Retain this guide for future reference.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
• When the appliance is not in use and before cleaning, unplug the appliance from the outlet
firstly.
• To protect against fire, electric shock and injury to persons do not immerse main parts of the
product, cord, plug, in water or other liquid.
• The appliance must not be immersed in liquid.
• Remove plug from wall outlet before cleaning and when not in use. Allow appliance to cool
down completely before removing/attaching components, or before cleaning.
• The use of accessory attachments not included with the appliance may result in fire, electric
shock or injury to persons.
• Place the appliance on a flat surface or table. Do not allow power cords to hang over the edge
of table or counter.
• Ensure that the power cord does not touch any hot surface of the appliance.
• Do not place the coffee maker on any hot surface or near heat sources in ordertoavoid
damage to the appliance.
• To disconnect, remove the plug from the wall outlet. Always hold the plug and never pull the
cord.
• Do not use the appliance for any purpose other than intended use. Place the unit in a dry
environment.
• Do not touch the hot surface of the appliance (such as the steam wand and the steel mesh).
Always use the handle or dials. Be careful not to get burned by the steam emitted from the
appliance.
2

•
• Never operate the coffee maker without water.
• DO NOT remove the metal funnel while brewing coffee. Only remove the metal funnel to make
additional coffee more than 10 seconds after brewing has finished. Cautionshouldalsobe
taken while removing the metal funnel since the metal parts will be hot. Makesuretoholditby
the handle and to use the filter retention clip to dispose of coffee grounds. Caution should be
taken when moving the unit with hot liquids inside.
• Connect the plug to a wall outlet before use, and turn any switches off beforetheplugis
removed from wall outlet.
• This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments.
- farm houses.
- by clients in hotels, motels and other residential type environments.
-bed and breakfast type environments.
• Do not use the appliance outdoors.
• WARNING: The filling aperture must not be opened during use.
• Warning: Potential injury from misuse. The heating element surface is subject to residual heat
after use.
• Cleaning and user maintenance shall not be made by children without supervision.
• Save these instructions for future reference.
3

COFFEE MAKER ANDACCESSORIES
Two cup filter
Portafilter
Control Panel
Steam Dial
Drip Plate
Water
Tank
Drip Tray
One cup filter Coffee Spoon/
Tamper
Steam Wand
(with removable tube）
CONTROL PANEL
ON/OFF button
Steam pressure
outlet control dial
Pump On/Off
control button
Temperature gauge
Coffee/steam
On/Off button
Coffee temperature
indicator light
Power indicator light
Steam temperature
indicator light
4

INSERTING THE FILTER INTO THE PORTAFILTER
1. To insert the selected filter (two cup or one cup) in the portafilter, makesuretoalignthenotch
on the filter with the groove inside the portafilter.
2. Turn the filter to the left or right to lock in place. This will help secure the filter in the
portafilter.
BEFORE THE FIRST USE
Before first use you should rinse the coffee maker with warm water as following:
1. Pull out the water tank of the coffee maker. Pour clean water into the tank, ensuring that the
water level should does not exceed the “MAX” mark and is no less than the “MIN”markonthe
side of the tank. When re-inserting the tank, angle forward slightly to allow the extraction tube to
fit into the tank, try to avoid direct pressure / stress onto the extraction tube from the sides of the
tank.
2. Insert the single or double cup filter into the Portafilter (see previous section), then position the
portafilter under the holder (see Fig.1) and turn it anticlockwise until it is fixed tightly (see Fig.2
and Fig.3).
Portafilter holder
Fig. 1
Fig. 2
Fig. 3
5

BEFORE THE FIRST USE (Continued)
3. Place an espresso cup on the drip plate. Make sure the steam dial is in the “0” position.
4. Connect the supply plug to a wall socket and press the ON/OFF button “ ”toturnthe
appliance on. The power indicator (red) will be illuminated.
5. Press down the pump on/off control button “”, the pump will activate and water will begin to
flow from the portafilter. Once water flows, push the pump on/off control button again to switch
off. The purpose of this step is to pump the water from the tank into the housing heating
chamber. the coffee temperature indicator light (green) will activate
6. Make sure the coffee/steam on/off button “ ” is in the off position (button not depressed so sits
higher) , the appliance will begin preheating until the coffee temperature indicator (green)
illuminates, indicating that the preheating process has completed (note, this will cycle on / off
during use). The temperature gauge will rise and then stabilise after around 30 seconds.
7. Press down the pump on/off control button“ ” again, and water will flow out.
8. After water has dispensed for approximately 1 minute, press the pump control button“”,
once more. Dispose of the water collected in the espresso cup, clean the cup and you can
now start brewing coffee.
Note: There may be a louder noise when pumping the water for the first time, this is normal, as the
appliance is releasing the air in the appliance. After about 20 seconds, the noise will disappear.
PREHEATING
It is recommended to preheat the appliance before making coffee, includingtheportafilter
and cup, so that the coffee flavour will not be influenced by the cold surfaces.
1. Pull out the water tank of the coffee maker. Pour clean water into the tank, ensuring that the
water level should does not exceed the “MAX” mark and is no less than the “MIN”markonthe
side of the tank. When re-inserting the tank, angle forward slightly to allow the extraction tube to
fit into the tank, try to avoid direct pressure / stress onto the extraction tube from the sides of the
tank.
2. Insert the filter into the Portafilter (see previous section), then position the portafilter under
the holder (see Fig.1) and turn it anticlockwise until it is fixed tightly (see Fig.2 and Fig.3).
3. Make sure the steam dial is set to “0” and place an espresso cup on the drip plate.
4. Connect the supply plug to a wall socket and press the ON/OFF button “ ”toturnthe
appliance on. The power indicator (red) will be illuminated.
5. Make sure the coffee/steam on/off button “ ” is in the off position (button not depressed so sits
higher).
6. Press down the pump on/off control button“, wait for a moment and water will begin flowing
out. When water is flowing out, immediately press the pump on/off control button again to
switch off. The purpose of the step is to pump the water from the tank into the housing heating
chamber.
6

MAKING ESPRESSO COFFEE
1. Connect the supply plug to a wall socket and press the ON/OFF button “ ”toturnthe
appliance on. The power indicator (red) will be illuminated.
2. Check that the water tank has sufficient water added and that the steam dial is set to “0”.
3. Insert the desired filter (single or double cup) into the Portafilter (see previous section),
then position the portafilter.
4. Add ground coffee to the filter with the measuring spoon (one level spoon should suffice for one
cup of coffee). Press the coffee powder down tightly with the tamper.
5. Position the portafilter under the holder (see Fig.1) and turn it anticlockwise until it is fixed tightly
(see Fig.2 and Fig.3).
6. Place an espresso cup under the portafilter and positioned on top of the drip tray.
7. Press the ON/OFF button to turn on the unit; the power indicator will illuminate red. Make sure
the coffee/steam on/off button “ ” is in the off position (button not depressed so sits higher)
and that the steam pressure dial is set to “0”).
8. Wait for the coffee temperature indicator light to switch on (green), then press down the pump
on/off control button“”, wait for a moment and coffee will begin flowing out. The temperature
gauge will rise and then stabilise after around 30 seconds.
9. Press the pump on/off control button “”to switch off manually when the desired coffee
quantity is obtained or if the colour of the coffee coming out starts to weaken.
10. After finishing making coffee, press the ON/OFF button, and the power indicator and coffee
temperature indicator will switch off.
11. Remove the portafilter by turning clockwise and tip out the coffee residue.
12. Let the components cool down completely, then rinse under running water.
WARNING: Do not leave the coffee maker unattended while in use.
NOTE: During coffee brewing or steaming, it is normal that the Coffee / Steam temperature
indicator light may go on/ off – this indicates that the heater is regulating the temperature to the
required level.
7

MAKING CAPPUCCINO
You can make a cup of cappuccino by topping a cup of espresso with frothing milk.
Note: During steaming, the portafilter must be assembled in position.
Method:
1. Prepare espresso first as per the instructions above, make sure that the steam dial is at the "0"
position.
2. Press the coffee/steam on/off button “
”, waiting until the steam temperature indicator
illuminates (green). The temperature gauge will rise higher (than that notedwhenmaking
espresso). This process will take around 1 minute.
3. Fill a small jug with about 100ml of milk for each cappuccino to be prepared. It is
recommended to use whole milk at a refrigerated temperature (not hot).
4. In order to achieve ideal milk foam consistency, it is recommended to keep the steam dial in the
open position for approximately 15 seconds, since the initial steam contains too much water,
then keep the dial at the “0” position and conduct next step.
5. Insert the steam wand into the milk (approx. two centimetres deep), then turn the steam dial
slowly anticlockwise. Steam will come out from the steam wand. Frothed milk is produced by
moving the vessel around and from up to down.
Note: To avoid burns, never directly touch the steam outlet during operation and take care to
avoid placing hand or fingers near the outlet when discharging steam.
Note: Never turn the steam dial rapidly, as the steam will accumulate rapidly in short time which
may increase the potential of the risk of steam bursts.
6. When the required amount of frothing is reached, you can turn the steam dial to the “0” position.
Then press the coffee/ steam on/off button.
7. To avoid the steam outlet being blocked after frothing milk each time, put an empty jug under
the steam wand, then turn on the steam dial and press the pump on/off control button. The
pump will begin operating. Once the water has been flowing for 30 seconds, press the pump
control on/off button to switch off.
8. Let the components cool down completely, then rinse under running water. Ensure the steam
wand / nozzle is thoroughly cleaned after each use. Remove the steam wand cover (tube) and
rinse, while cleaning the internal nozzle with a wet towel.
9. Press and release the ON/OFF button to power the unit off.
10. Pour the frothed milk into the espresso that was previously prepared. Sweeten if desired by
sprinkling the froth with a little cocoa powder.
Note: Please follow the instructions below if the steam outlet is blocked: turn the steam dial to “0”
position and let the coffee maker cool down for about half an hour. Poke the steam outlet several
times with a needle around 1mm in diameter. Finally, press the coffee/steam button and turn on the
steam dial to check if the appliance can produce steam normally when the steam indicator (green)
illuminates.
8

Note: After steaming, allow the coffee maker to cool down at least for 5 minutes before making
coffee again, otherwise a burnt odour may be noticeable in the prepared coffee. If you want to make
coffee immediately: press and release the coffee/ steam button and dip the steam wand into a cup.
Press the pump on/off control button down and turn on the steam control dial; water will flow out
from steam wand. After the ready temperature indicator, press and release the pump control button,
then turn the steam control dial to “0” position. When the ready indicator illuminates, the appliance
is prepared for making coffee once again.
FROTHING MILK / PRODUCING STEAM TO HEAT LIQUIDS
The steam wand can be used to froth milk and make hot beverages like drinking chocolate, water or
tea.
Method:
1. Remove the water tank and fill it with desired amount of water. The water level should be
between the “MAX” mark and the “MIN” mark in the tank. Re-insert the tank into the appliance
securely.
2. Connect the appliance to the wall socket.
3. Press the ON/OFF button “ ” to turn on the unit; the power indicator will illuminate in red.
4. Press down the pump on/off control button “ ”, the pump will activate and water will begin to
flow from the portafilter. Once water flows, push the pump on/off control button again to switch
off. The purpose of the step is to pump the water from the tank into the housingheating
chamber. the coffee temperature indicator light (green) will activate
5. Press down the coffee/steam on/off button “ ” , the appliance will begin preheating until the
coffee temperature indicator (green) illuminates, indicating that the preheating process has
completed.
6. Dip the steam wand into the liquid to be heated. If you want to froth milk, dip the steam wand
about 2 centimetres into the milk. Slowly turn the stand dial anti-clockwise to start making
steam.
7. When the required amount of frothing is reached, you can turn the steam dial to the “0” position.
8. To avoid the steam outlet being blocked after frothing milk each time, put an empty jug under
the steam wand, then turn on the steam dial and press the pump on/off control button “”.
The pump will begin operating. Once the water has been flowing for 30 seconds, press the
pump control on/off button “”to switch off.
9. Let the components cool down completely, then rinse under running water. Ensure the steam
wand / nozzle is thoroughly cleaned after each use. Remove the steam wand cover (tube) and
rinse, while cleaning the internal nozzle with a wet towel.
10. Press and release the ON/OFF button to power the unit off.
9

AUTOMATIC POWER OFF FUNCTION
The appliance will turn off automatically if no function is activated within 29 minutes.
DRIP TRAY FLOAT MECHANISM
The drip tray incorporates a red coloured plastic float mechanism that will raise above the drip
plate to indicate when the drip tray is full. In order to prevent overflow and spillage of liquids,
please empty when full.
CLEANING AND MAINTENANCE:
1. Turn off and unplug the appliance, then let the coffee maker cool down completely before
cleaning.
2. Clean housing of coffee maker with moisture-proof sponge often and clean water tank, drip tray
and removable shelf regularly then dry them.
Note: Do not clean the appliance with alcohol or solvents. Never immerse the housing in liquid for
cleaning.
3. Detach the portafilter by turning it clockwise, remove the filter and any coffee residue inside.
Clean it with a gentle detergent and rinse it under water. Do not wash these parts in a
dishwasher.
4. Clean all the attachments in the water and dry thoroughly.
5. Ensure the steam wand / nozzle are thoroughly cleaned after each use. Remove the nozzle
cover and rinse, while cleaning the internal nozzle with a wet towel.
Note: To maintain optimum operating performance, clean the appliance after every use.
10

CLEANING MINERAL DEPOSITS
To ensure your coffee maker operates efficiently, the internal piping should be cleaned every 1-2
months to guarantee optimal coffee flavour.
1. Fill the tank with water and descaler to the MAX level (the proportion of water and descaler is
4:1. Use a “household descaler” or citric acid at a ratio of 100: 3 (water to citric acid).
2. Follow the preheating process above (steps 2-6) to set the water temperature”.
3. When there is water flowing out, switch the pump on/off control again and wait for a moment f
or the appliance to reheat.
4. When the ready indicator illuminates green, press down the pump control button to the lower
position and “brew” two cups’ worth of water/descaler (about 60ml). Then close the pump and
wait for 5 seconds.
5. Press down the coffee/steam button, waiting until the green indicator is illuminated. Make steam
for 2 minutes and then turn the steam dial to the "0" position. Press the ON/OFF button to turn
off the unit immediately and let the descaler collect in the internal piping for at least 15 minutes.
6. Restart the unit and repeat steps 2-5 at least three times, then press and release the
coffee/steam button. When the green indicator is illuminated, press down the pump control
button to brew until no descaler is left.
7. Perform the brewing process (using no coffee powder) with tap water filled up to the MAX level
of the water tank. Repeat the steps of 2-5 for 3 times (it is not necessary to wait 15 minutes in
step
Note: Ensure you repeat step 7 at least three times to guarantee the piping is clean.
11

WATER TANK EXTRACTION HOSE
When removing and fitting the water tank into the recess slot, take care not to exert
pressure onto the extraction hose. Angle the water tank downwards when inserting and
manually place the hose into the tank. Try to limit the amount of bending and pressure
applied to the hose and ensure this sits vertically when the tank has been refitted.
The water tank extraction hose fits ontoahose socket on the upper section of the tank
recess housing. Should the hose be inadvertently detached from the socket, this can be
easily reattached by simply aligning the two parts and applying pressure. Firmly press the
hose onto the socket.
12

TROUBLE SHOOTING
Symptom
Cause
Corrections
The coffee maker will
not power on.
The power outlet is not
switched on or is faulty.
Ensure the plug of the power cord is
correctly fitted to the socket outlet, if the
appliance still does not work, try a different
socket outlet and use an alternative
appliance (for example a desk lamp) to
check it is functional.
Water leaks from the
bottom of coffee
maker.
There is excessive
water in the drip tray.
Please clean the drip tray.
Water leaks from the
outer side of the filter.
There is some coffee
powder on the filter
edge.
Ensure the filter is clean before use.
Acidic (vinegar) taste
noted in the coffee.
Appliance not cleaned
correctly after cleaning
mineral deposits.
Clean coffee maker as per “before the first
use” several times.
The coffee powder is
stored in a hot, wet
environment for a long
time. The coffee powder
has expired.
Please use fresh coffee powder and store
unused coffee powder in a cool, dry place.
After opening a packet of coffee powder,
reseal it tightly and store in a refrigerator to
maintain freshness.
Plastic taste noted in
the coffee.
Appliance in use for the
first time. Test run with
hot water strongly
recommended before
making any to drinks.
Upon first use, run the coffee machine with
just hot water to clean and prepare the
appliance. Do not drink the initial cycle of
water. Ensure water has been run for at least
one minute before making coffee to serve.
Burnt taste noted in
coffee.
Water flowing through
grinds too slowly,
leading to a bitter and
burnt tasting coffee.
Adjust your grinder for a coarser grind of the
beans.
The steam function will
not generate froth.
The steam ready
indicator is not
illuminated.
The unit is only ready for frothing once the
indicator is activated.
The container is too big
or poorly shaped for
frothing.
Useatallandnarrowcup.
Skim milk used for
frothing.
Use whole milk.
13

Warranty
We pride ourselves on producing a range of quality home
appliances that are both packed with features, and completely
reliable. We are so confident in our products, we back them up
with a 2 year warranty when accompanied with proof of
purchase. Now you too can relax knowing that you are
covered. Customer Helpline NZ: 0800 422 274
IM Version 1.0 – June, 2021
14
