Living & Co SRO8321 User manual

Induction Cooker
INSTRUCTION MANUAL
MODEL: SRO8321

...................................................................... 1
................................................................................ 9
.................................................................................... 7
................................................................................12
.........................................................................12
.........................................................................................13
............................................................................14
IMPORTANT SAFEGUARDS
Operation Instructions
Product Introduction
Compatible Cookware
Cleaning And Maintenance
Troubleshooting
Environmental protection

1
Symbols: Forbidden Mandatory Warning Attention
IMPORTANT SAFEGUARDS
For safety reasons and to avoid damage to the appliance or
injuries to people, please abide by all the safety instructions
below.
Ignoring safety warnings may result in injuries.
This appliance does not take into consideration the following
situations:
- use by children or disabled people without supervision;
- children treating it as a toy.
Never heat foods in sealed
containers, such as compressed
products, cans, or coffee pots, to
avoid explosion caused by heat
expansion.
To avoid affecting product
performance and to prevent injury, do
not heat empty pots. When in use, do
not leave the appliance without
supervision for a long time. When
leaving the appliance without
supervision, make sure there is
enough water in the pot.
Do not heat iron items on the
induction cooker heating plate to
avoid danger caused by high
temperatures.
To avoid accidents, do not place the
induction cooker, when in use, on a
gas stove (the magnetic lines can
heat the metal parts of the gas
stove).
Do not directly rinse this induction
cooker under water. Do not spill
water or soup into the internal parts
of the induction cooker.

2
The utensils provided for the
induction cooker can only be used
for cooking with it. These cooking
utensils cannot be used on both
induction cooker and gas stove.
To avoid injuries such as scalding, do
not let children operate the appliance
alone.
To avoid danger, do not insert any
foreign object, such as iron wire, nor
block the air ventilation opening or
air entry port.
To avoid danger, do not place paper,
aluminium foil, cloth or other
unsuitable articles onto the induction
cooker heating plate for indirect
heating.
When using the induction cooker, do
not put it on any metal platform (such
as iron, stainless steel, aluminium),
or place a non-metal pad less than
10cm thick on the heating plate.
Unplug the power cord from the
outlet after use to avoid fire and/or
damaging the electronic
components, caused by prolonged
electrical connection.
People with heart pacemakers
should consult a doctor. Only use the
appliance after confirming that it
does not affect the pacemaker.
IMPORTANT SAFEGUARDS

3
To avoid damage, avoid causing
impacts on the heating plate. If the
surface is cracked, switch off the
appliance to avoid the possibility of
electric shock.
To avoid danger, if the power cord is
damaged, have it replaced by agents
of the manufacturer, its maintenance
department or specialized personnel
from a similar department.
Do not touch the cooker plate with
sharp Tools, to avoid cracking or
damaging the plate. If the surface is
cracked, switch off the appliance to
avoid the possibility of electric shock.
The cooker cannot be overloaded.
Overloading the plate may damage
the plastic cover and cooker plate.
Do not use the induction cooker near
a gas stove, kerosene stove, gas
cooker or in any space with an open
fire or an environment with high
temperature.
When using the induction cooker,
place it horizontally and allow at least
10cm of free space between the sides
and back of the induction cooker and
the wall. Do not use the induction
cooker in narrow spaces. To avoid
hindering release of heat, do not
cover the ventilation opening.
IMPORTANT SAFEGUARDS

4
IMPORTANT SAFEGUARDS
Please use a dedicated and high
quality power outlet, with high power
rating, equal to or above 10A. Do not
use poor quality outlets. Do not
share the power outlet with electrical
appliances with high power ratings,
such as air conditioners, electrical
stoves etc. to avoid fires caused by
overburdening the outlet.
When using the induction cooker or
after use, please keep it clean.
Protect the induction cooker from
bugs, dust and humidity. Avoid letting
cockroaches etc. fall into the internal
parts of the induction cooker and
causing a short circuit of the electrical
board. When not in use for a long
period, please clean it and put it into
a plastic bag to store it.
Do not use the induction cooker by
putting it onto a carpet, tablecloth or
thin paper to avoid blocking the air
inlet opening or air outlet opening,
which results in influencing heat
emission.
Metal objects, such as knives, forks,
spoons and lids, should not be put
on the surface of the cooking area,
since they can become heated.

5
Always clean the induction cooker to
prevent mess from getting into the
fan, which could influence the normal
operation of the appliance.
When operating the appliance or
after moving the pot, the cooking
area will remain hot for a period of
time. Do not touch it, be careful of
scalding caused by the high
temperature.
Danger of
scalding
This appliance is intended to be used in household and
similar applications such as:
-Staff kitchen areas in shops, office and other working
environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
Mandatory
This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Never have the induction cooker to work without food
inside, otherwise its
operational performance may be affected and danger may
happen.
IMPORTANT SAFEGUARDS

6
This appliance is for household use only. Do not use
outdoors.
Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use.
We suggest that you should periodically check that there
are no object (glass, paper, etc.) that could obstruct the
inlet under your induction cooker.
Warning
Keep electrical appliance out of reach from children or
inform person. Do not let them use the appliances without
supervision.
Children should be supervised to ensure that they do not
play with the appliance.
The instructions shall state that appliances are not
intended to be operated by means of an external timer or
separate remote-control system.
IMPORTANT SAFEGUARDS

7
The induction cooker is able to meet various kinds of cooking demands by
electromagnetic heating, high thermal efficiency, is safe and reliable, easy to
clean.
Technical Data of the Product
Product Introduction
Product Fiche
It is recommended to select power setting level 2 to achieve maximum energy
eciency.
The energy consumption of a domestic electric hob (EC electric hob) is measured in
Wh per kg of water heated in a normalised measurement (Wh/kg) considering all
cookware pieces under standardised test conditions and rounded to the first decimal
place. Standard EN 60350-2:2013 was used as reference for the measurement and
calculation.
220-240V~ 50/60Hz
Model No. Rated voltage Dimension Weight
350X280X68 mm 2.8 kg
Rated power
2000W
Symbol
Model
Freestanding
Induction
cooking zone
1
19.5 cm
Wh/kg
Wh/kg
Ø
EC electric
cooking
EC electric
hob
199.5
199.5
Type of hob
Number of cooking zones and/or areas
Value Unit
Heating technology(induction cooking zones
and cooking areas, radiant cooking zones,
solid plates)
Energy consumption per cooking zone or
area calculated per kg
Energy consumption for the hob calculated
per kg
For circular cooking zones or area:
diameter of useful surface area per electric
heated cooking zone, rounded to the
nearest 5 mm
SRO8321
SRO8321

8
B
Temp.
Level
Product Introduction
Product Sketch Map
Power cord
Air vent
Ceramic plate
Cooking zone
indicator
Control panel
Air entry
Control Panel
2.
4.
Keep warmTimer
1.
3.
5.
ON/STANDBY
Lock Function
Boost
34
21
6 5
6.
B
Temp.
Level

9
Operation Instructions
Product Introduction
Before using New Induction cooker
● Read this guide, taking special note of the "Safety Warnings" section.
● Remove any protective film that may still be on your ceramic plate.
Using the Touch Controls
● The controls respond to touch, so you don't need to apply any pressure.
● Use the ball of your finger, not its tip.
● You will hear a beep each time a touch is registered.
● Make sure the controls are always clean, dry, and that there is no object (e.g. a
utensil or a cloth) covering them.
Even a thin film of water may make the controls difficult to operate.
Put the pot on the ceramic plate
● Make sure the air vents are not blocked and keep utensils away from the
immediate surrounds of the ceramic plate.
● Make sure the cookware which has food or liquid is placed in the center of
ceramic plate.
Plug in
● After the power supply is connected, a beep will be heard. The display shows
“L”, indicating that the induction cooker is in standby mode.

10
Operation Instructions
Timer
● Press the “Timer” button to enter the timer mode. When the timer indicator
lights up and the numbers blink on the display, press the “+” or “-” button to
adjust the time duration. Adjustable timer from 1 minute to 3 hours.
● When the adjustment is finished, the number on the display will be shown
after blinking for several seconds. The induction cooker starts counting down.
● When the counting down is over, the induction cooker automatically stops
heating and switches off.
● The induction cooker will shut down when the default timer is reached unless
the user sets the timer himself.
Function
● After switching on the induction cooker, press “Function” button to enter the
temperature or level mode.
● You can adjust the power level by pressing “+” or “-” button.
You can adjust the temperature by pressing “+” or “-” button.
Turn on
● After pressing the “ON/STANDBY” button, the induction cooker is ready for
heating. Press the “Function” button, the induction cooker enters heating
mode.
● After pressing the “ON/STANDBY” button, if no function button is pressed for
10 seconds, the induction cooker will switch off automatically.
● After pressing the function button, if there is no proper pot on the ceramic
plate, the induction cooker will not heat up and the alarm will sound to indicate
that a pot is required. One minute later, it will switch off automatically.

11
Operation Instructions
Keep Warm
● Press the “Keep warm” button to maintain warmth. Under this mode, the
induction cooker heats the ingredients with gentle power to maintain a certain
temperature inside the pot.
Boost
● The Boost button allows obtaining directly the highest power level. By pressing
again the Boost button the appliance will go back to the power of origin.
How To Lock
● Press the “+”and “-” button to start lock function. The lock indicator lights up.
Now only the “ON/STANDBY” button can be used to switch off the induction
cooker, all the other operations are forbidden.
● Press the “+”and “-” button for 3 seconds to quit the lock function. The lock
indicator turns off.
Switch Off
● When the operating time is over, the induction cooker switches off
automatically.
● Press the “ON/STANDBY” button to turn off the appliance.
Under this mode, the power cannot be adjusted.
Note:
Note:
Do not touch the surface of the ceramic while “H” is displayed, it means
the temperature high. While “L” is displayed, it means the temperature low.

12
Compatible Cookware
Cleaning And Maintenance
Iron oil frying
pan
Stainless
steel por Iron pan Iron kettle
Enamel stainless
steel kettle
Enamel cooking
utensil Iron plate
● Requirement for pot materials: containing magnetic inducting materials.
● Shape requirement: plat bottom, with the diameter more than 15 cm and less
than 20 cm.
● After the first use, some white spots would appear at the bottom of the pot.
This is normal.
● Please pour some vinegar into the pot, heat it at about 60-80 ℃, then wipe
the spots away with brush.
● Incompatible pots material: glass, ceramic, aluminium, copper and other non
magnetic material.
● lf the pot removed, the induction cooker will stop heating immediately. After
the buzzer sounds for 1 minute, it will go into standby mode automatically.
● Before cleaning, please switch off the appliance first and then disconnect the
power plug from the power outlet. Wait till the cooker plate of the induction
cooker is not hot and start cleaning.
● After using the induction cooker for a long time, the opening of air inlet/air
outlet will pile up with dust or other dirt, please wipe it with a soft dry cloth.
Dust in the air inlet and outlet can be cleaned by using a soft brush or a mini
vacuum cleaner.
Please do not rinse it with water.
Note:

13
Cleaning And Maintenance
Troubleshooting
● For oil spots on the cooker plate, wipe the cooker plate by using a soft moist
cloth with a little tooth paste or mild detergent. And then use a soft moist cloth to
wipe it until no stain remains.
● When not using it for a long time, please disconnect the power plug from the
power outlet and protect the induction cooker from any dust or bugs.
The “ON/STANDBY” indicator lights
up and the display works normally,
but heating does not start.
After plugging in the power cord and
pressing the e “ON/STANDBY” button,
the indicator and display do not light up.
Abnormalities Key checking points and trouble shooting
Is the power plug properly connected?
Is the switch, power outlet, fuse or power cord
damaged?
Is the pot material proper?
Is the appliance in a “Preset” working status?
For other causes, please take the appliance to a
repairing and maintenance site to be fixed.
Please contact the special maintenance
department.
Wait a moment and press the “ON/STANDBY”
button when the temperature of the hotplate
becomes normal, the induction hotplate will
operate as usual.
Turn off the hotplate, when the voltage becomes
normal, and then turn on the hotplate, it will
operate as usual.
Heating suddenly stops during the
process.
Code of failure
Is the temperature of the oil too high when
frying dishes?
Is the temperature of the surroundings very
high?
Is the air inlet or air outlet of the induction
cooker blocked?
Is the default heating time of the induction
cooker over?
The self-safety protection of the induction
cooker starts, wait for several minutes and
connect power to use it.
E1 E2 E4
E5 Eb
E3 E6
E7 E8
During using, if there are some abnormal cases, please unplug
immediately and disconnect power.
For any failure of the product, please contact the special maintenance
department or the customer service center.
Emergency

14
Environmental protection
Responsible Disposal
At the end of its working life, do not throw this product out with your
household rubbish. Electrical and electronic products contain substances
that can have a detrimental effect on the environment and human health if
disposed of inappropriately. Observe any local regulations regarding the
disposal of electrical consumer goods and dispose of it appropriately for
recycling. Contact your local authorities for advice on recycling facilities in
your area.
Please keep the original packaging carton and materials in a safe place. It
will help to prevent any damage if the product needs to be transported in
the future. In the event it is to be disposed of, please recycle all packaging
material where possible.

Warranty
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and completely reliable. We are so confident in our products,
we back them up with a 3 year warranty.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
This Product is covered by 3 year warranty when
accompanied by proof of purchase.
