Living & Co LHC25B User manual

INSTRUCTION MANUAL
HAIR CUTTING SET 25 PIECE
5.5W
LHC25B
Important: Read all instructions carefully before using this
appliance. Retain those instructions for further reference.

2
03 IMPORTANT SAFEGUARDS
05 PRODUCT FEATURES
06 HOW TO USE
07 GETTING STARTED
10 MAINTENANCE & STORAGE
Contents

3
When using an electrical appliance,basic precautions should
always be
observed,including the following.
■To avoid danger of electrocution,do not store or leave the clipper in a
position where it might fall into a bath-tub,basin or other vessel
containing water,even the clipper switch is in the off positon.
■Do not reach for an appliance that has fallen into water.Unplug it
immediately.
■Do not use while bathing or in the shower.
■Always unplug this appliance from the electrical outlet immediately
after using.
■Unplug this appliance before cleaning it.
■The clipper is not washable.Do not try to clean the clipper
under a water tap.
■Keep the clipper dry.Never operate the appliance with wet hands.
■This appliance is for household use only.
■An appliance should never be left unattended when it’s plugged in.
■Close supervision is necessary when this appliance is used by,on,or
near children or persons with special needs.
■Use this appliance only for its intended use as described in this
manual.
■Keep the cord away from heated surfaces.
IMPORTANT SAFEGUARDS
DANGER
To reduce the risk of electric shock:
WARNING
To reduce the risk of burns, fire, electric shock or injury to persons:

4
■Never operate this appliance if it has a damaged cord or plug,if it is
not workingproperly,if it has been dropped ordamaged,or if it has been
dropped into water.If any of these things happen,return the appliance to
an authorized service center for examination and repair.
■Never drop or insert any object into any of the appliance’s openings.
■Do not use outdoors or operate where aerosol (spray)products are
being used,or where oxygen is being administered.
■Always store this appliance and cord in a moisture-free area.
■Do not store it in temperatures exceeding 140°F(60°C).
■Do not plug or unplug this appliance when your hands are wet.
■Do not use an extension cord or a voltage converter with this
appliance.
■Always attach the plug to the appliance,then to the outlet.To
disconnect,
turn all controls to OFF,then remove plug from outlet.
Detach removable power cords from appliances for storage.
■Do not place this appliance on any surface while operating.
■This power unit is intended to be correctly oriented in a vertical or
floor mount position.
■Do not wrap the cord around the appliance.
■This appliance is not intended foruse by persons(includingchildren)
with reduced physical,sensory or mental capabilities,or lack of
experience and knowledge,unless they have been given
supervision or instruction concerning use of theappliance byaperson
responsible for their safety.
■Children should be supervised to ensure that they do not play with
the appliance.
■If the supply cord is damaged,it must be replaced by the
manufacturer, its
service agent or similarly qualified persons in
order to avoid a hazard.
IMPORTANT SAFEGUARDS(Cont.)

5
For best cutting performance we recommend you read these
instructions thoroughly and keep them in a safe place.
1.Hair Clipper 2.1”(25mm)Guide Comb 3.7/8”(22mm)Guide Comb
4.3/4”(18mm)Guide Comb 5.5/8” (16mm)Guide Comb
6.1/2”(12mm)Guide Comb 7.3/8”(9mm)Guide Comb
8.1/4”(6mm)Guide Comb 9.1/8”(3mm)Guide Comb
10.Right Ear Taper Guide Comb 11.Left Ear Taper Guide Comb
12.Blade Guard 13.Barber Scissors 14.Neck Brush
15.Styling Comb 16.Cleaning Brush 17.Sectioning Clip
18.Sectioning Clip 19.Sectioning Clip 20.Sectioning Clip
21.Sectioning Clip 22.Sectioning Clip 23.Cape
24.Storage Case 25.Lubricating Oil
PRODUCT FEATURES

6
We have pre-lubricated and aligned the blades on your hair clipper.
Before cuttinghair,make sure the sufficient lubrication and good
alignment of the blade.
They are essential for effective cutting.
The blade can be lubricated and/orre-aligned by following steps:
1.Add a few drops of oil to the blades,turn the clipper on for a few
moments;
2.Turn off the clipper and unplug from power mains;
3.Loosen the two screws slightly and manually adjust the bottom
blade until it is aligned .Re-tighten(butdo not over-tighten)the
screws.
4.Run the clipper again,check that the blade is running smoothly with
no fractions.
HOW TO USE
Before cutting hair

7
1.To insert plug,grasp it firmly and guide it into outlet.
2.To disconnect the appliance,grasp the plug and remove it from outlet.
Do not pull or yank on the cord or appliance.Do not wrap the cord
around the appliance.
3.Make sure your hair clipper is running smoothly with a slight vibration.
4.Place the cape around the neck of the person whose hair is being
trimmed or cut.
5.This person should be seated so that the top of their head is at your
eye level.
6.Comb the hair as it is normally styled.
7.Comb out all knots and tangles.
8.Ensure the hair is dry.Hair clippers perform best with dry hair,
making it easier to see how much hair is being cut.
9.Hold the hair clipper in the palm of one hand with your thumb
resting firmly on the top of the hair clipper.This grip
provides comfortable cutting control.Although the hair
clipper may be used with the left or right hand,using it
right-handedallows you to access the taper lever
more easily.
1.Select the trimming guide that matches the length you want the hair
to be after the cut.The trimming guides are numbered and marked
with1/8”
(3mm),1/4” (6mm),3/8”(9mm),1/2”(12mm),5/8”(16mm),
3/4”(18mm),7/8”(22mm),and 1” (25mm).
2.While the clipper is off,hold the trimming guide with the teeth up.
Slide the trimming guide onto the blades until it locks into place.
GETTING STARTED
To Attach Trimming Guides

8
Giving a Comfortable,Even Cut
Allow the clipper to cut through the hair without moving it too
quickly.Moving the clipper too quickly may create a pulling
sensation.
Use short strokes when cutting,and initially use the longest
trimming guide.You can always use a closer trimming guide later if you
want a closer cut.
How To Give a Haircut
1.Startat the back of the head.Holding the clipper as shown,lightly
stroke upward making sure you are taking off the desired amount of
hair.Work your way up to the crown of the head in layers.
When completed,comb the area to remove any loose hair and
to determine whether you need any further cutting.
2.Repeat the same procedure for each side of the head.Make sure
the length of the hair is trimmed to the same length on both sides of the
head.
3.To cut the hair at the top of the head,hold the hair between
your fingers and cut a small amount at a time.Cut from the
front to the back.
4.Remove the trimming guide and replace with either the left or right
ear guide.
The shorter guideteeth are designedto be toward
the ear.Move the clipper from the back of the head to the
front.This creates a tapered effect around the ears and
back of the neck.
5.The final trim can be made with the hair clipper or the included
scissors.
Make sure to check over the entire head for any uneven areas.
For styled hair or giving quick trims,you may prefer using your hair
clipper without the trimming guide.
HOW TO USE (Cont.)

9
6.The adjustable taper control lever allows you to gradually change the
closeness of your cut,either with or without a trimming guide.When the
lever is fully forward the blades will give you the closest cut.Moving the
lever gradually backward increases the cut length.
1.Using the 1/2”(12mm)trimming guide,hold the comb flat against the
head and move the hair clipper from the back of the neck to the crown
of the head.
2.Cut in a similar manner from the side to the top of the
head.
Then cut from the front to the crown of the head.
3.If a “Flat Top”style is desired,remove the trimming
guide and use the barber’s comb.Trim a little at a time until
a flat look is achieved.
1.Comb your beard in the direction it grows.
2.Determine the length you want the beard to remain,and fit the
appropriate trimming guide.Remember the 1/8”(3mm)guide will
give you the shortest beard while the 1”
(25mm)will give you the
longest.
If you want a longer beard you can use the styling comb as a
trimming guide.
3.Start trimming under your chin and work toward your ear and beard
line.
Cut in different directions for a uniform trim.
4.Lightly stroke the edge of your mustache in a downward
movement.
HOW TO USE (Cont.)
Very short styles
Trimming Beards & Mustaches

10
1.Lubrication:The blades on your hair clipper should be lubricated
before every haircut.Use only the light grade oil supplied or a suitable
alternative like sewing machine oil.Blades will wear prematurely and
not cut properly if they are not sufficiently lubricated.There may also
be a pulling sensation on the hair.
2.Cleaning:The blades should be cleaned after each haircut.Use the
supplied cleaning brush to clean the blades.If necessary,remove the
bottom blade and clean the hair between the two blades.
Warning:The clipper is not washable.Do not try to clean the clipper
under a water tap.
3.Service:This appliance does not contain any user-serviceable parts.
Bring this appliance to an authorized service representative for service.
When not in use,unplug it and store out of reach of children in a safe,
dry location.Never wrap the cord around the appliance as this will
cause the cord to wear prematurely and break.Handle the cord
carefully for long life,and avoid jerking,twisting or straining especially
at plug connections.
MAINTENANCE
STORAGE

completely reliable.We are so confident in our products,
we back them up with a 1 year warranty.
you too can relax knowing that you are covered.
Customer Helpline NZ:0800 422 274
This Product is covered by 1 year warranty when
accompanied by proof of purchase.
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and
Now
Warranty
