Living & Co LMW720W User manual

INSTRUCTION MANUAL
0800 422 274
NZ
20L MICROWAVE OVEN
700W
LMW720W

Specifications
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
440x330x259mm
Approx.10.23kg
Model:
Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions:
Net Weight:
20 L
255 mm
230-240V 50Hz
surface could be degraded and affect the lifespan of the apparatus and
lead to a dangerous situation.
(d) If the apparatus is not maintained in a good state of cleanliness, its
1100-1150 W
650-700 W
MW720W
AC,
2
0800 422 274
NZ
L

IMPORTANT SAFETY INSTRUCTIONS
WARNING To reduce the risk of fire, electric shock, injury to persons
or exposure to excessive microwave oven energy when
using your appliance, follow basic precautions, including
the following:
1. Warning: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
2. Warning: It is hazardous for anyone other
than a competent person to carry out any
service or repair operation that involves
the removal of a cover which gives
protection against exposure to microwave
energy.
3. Warning: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the
child is able to use the oven in a safe way
and understand the hazards of improper
use.
4. Warning: When the appliance is operated
in the combination mode, children should
only use the oven under adult supervision
due to the temperatures generated.
(only for grill series)
5. Only use utensils suitable for use in
microwave ovens.
6. The oven should be cleaned regularly and
any food deposits should be removed.
7. Read and follow the specific:"PRECAU-
TIONS TOAVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper
containers, keep an eye on the oven due
to the possibility of ignition.
9. If smoke is observed, switch off or unplug
the appliance and keep the door closed
in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage
purposes. Do not store items,
such as bread, cookies, etc. inside the
oven.
12. Remove wire twist-ties and metal handles
from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only in
accordance with the installation
instructions provided.
14. Eggs in the shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even
after microwave heating has ended.
15. Use this appliance only for its intended
uses as described in manual. Do not
use corrosive chemicals or vapors
in this appliance. This oven is especially
designed to heat. It is not designed for
industrial or laboratory use.
16. If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance
outdoors.
18. Do not use this oven near water, in a
wet basement or near a swimming
pool.
19. The temperature of accessible surfaces
may be high when the appliance is
operating. The surfaces are liable to
get hot during use.Keep cord away
from heated surface, and do not cover
any vents on the oven.
20. Do not let cord hang over edge of table
or counter.
21. Failure to maintain the oven in a clean
condition could lead to deterioration
of the surface that could adversely
affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles and
baby food jars shall be stirred or shaken
and the temperature checked before
consumption, in order to avoid burns.
23. Microwave heating of beverages can
result in delayed eruptive boiling,
therefore care must be taken when
handling the container.
24.The appliance is not intended for use by
persons (including children) with reduced
physical , sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for their
safety.
25.Children should be supervised to ensure
that they do not play with the appliance.
3
0800 422 274
NZ

27.Appliances are not intended to be operated by means of an external timer or separate
remote-control system.
26.The microwave oven shall not be placed in a cabinet unless it has been tested in
a cabinet.
29.The rear surface of appliance shall be placed against a wall.
28.The door or the outer surface may get hot when the appliance is operating.
4
30. Never operate the appliance with wet hands.
It is recommended to have a residual current device (safety switch)
installed by qualified electrician to provide additional safety
protection when using all electrical appliances.
31.
0800 422 274
NZ

5
To Reduce the Risk of Injury to Persons
DANGER:Electric Shock Hazard!
Touching some of the internal components can cause
serious personal injury or death. Do not disassemble this
appliance.
WARNING: Electric Shock Hazard!
Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly installed
and grounded.
CAUTION: Personal Injury Hazard!
It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the
removal of a cover which gives
protection against exposure to microwave energy.
Grounding Installation
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding
wire with a grounding plug. The plug must be plugged into
an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood or if
doubt exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord:
1. The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
2. The extension cord must be a grounding-type 3-wire cord.
3. A short power-supply cord is preferred to reduce the risks
resulting from becoming entangled in or tripping over.
4. If a long cord set or extension cord is used, the long cord
should be arranged so that it will not drape over the counter
top or tabletop where it can be pulled on by children or
tripped over unintentionally.
0800 422 274
NZ

6
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly
damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that
the food cooked can touch: Place half a lemon in a bowl,
add 300ml (1/2 pint) water and heat on 100% microwave
power for 10 minutes. Wipe the oven clean using a soft, dry
cloth.
UTENSILS
See the instructions on "Materials you can use in microwave
oven or to be avoided in microwave oven." There may be
certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do
not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
0800 422 274
NZ

Materials you can use in microwave oven
Utensils
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking.Arcing can occur if foil is too
close to oven walls.The foil should be at least 2.5cm away from oven
walls.
Follow manufacturer’s instructions. The bottom of browning dish must
be at least 5mm above the turntable. Incorrect usage may causethe
turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metalic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Remarks
7
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
0800 422 274
NZ

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
8
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
0800 422 274
NZ

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
Select a level surface that provide
enough open space for the intake
and/or outlet vents.
(3) Blocking the intake and/or outlet openings
can damage the oven.
(4) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
1.
A minimum clearance of 3.0 inches
(7.5cm) is required between the oven and
any adjacent walls. One side must be open.
(1) Leave a minimum clearance of 12
inches (30cm) above the oven.
(2) Do not remove the legs from the
bottom of the oven.
3.0 inch(7.5cm)
3.0 inch(7.5cm)
12 inch(30cm)
OPEN
9
0800 422 274
NZ

Function/Power
Low
Med. Low (Defrost)
Med.
Med. High
High
Timer
Power
Control Panel and Features
OPERATION
Operation Instructions
Output
17% micro.
33% micro.
55% micro.
77% micro.
100% micro.
Application
Soften ice cream
Soup stew, soften butter or defrost
Stew, fish
Rice, fish, chicken, ground meat
Reheat, milk, boil water, vegetables, beverage
Notice: When removing food from the oven, please ensure that the oven
power is switched off by turning the timer switch to 0 (zero).
Failure to do so, and operating the microwave oven without food in
it, can result in overheating and damage to the magnetron.
1.Set the cooking power by turning the
power knob to desired level.
2.Set the time by cooking by turning
the timer knob to desired time per
your food cooking guide.
3.The microwave oven will
automatically start cooking after
power level and time are set.
4.After the cooking time is up, the unit
will " Dong " to stop.
5.If the unit is not in use, always set
time to " 0 " .
10
0800 422 274
NZ

Trouble shooting
It is forbidden to run the unit without any food inside.
It is very dangerous.
Radio and TV reception may be interfered when
microwave oven operating. It is similar to the
interference of small electrical appliances, like
mixer, vacuum cleaner, and electric fan.
It is normal.
In low power microwave cooking, oven light may
become dim. It is normal.
In cooking, steam may come out of food. Most will
get out from vents. But some may accumulate on
cool place like oven door. It is normal.
Microwave oven interfering
TV reception.
Dim oven light.
Steam accumulating on
door, hot air out of vens.
Oven started accidentally
with no food in.
Oven can not
be started.
Oven does not heat.
Glass turntable
makes noise when
microwave oven
operates.
(1) Power cord not
plugged in tightly.
(2) Fuse blowing or
circuit breaker works.
(3) Trouble with outlet.
(5) Dirty roller rest and
oven bottom.
Unplug. Then plug again after
10 seconds.
Replace fuse or reset circuit
breaker(repaired by professional
personnel of our company).
Test outlet with other electrical
appliances.
Refer to "Cleanning " to clean
dirty parts.
(4) Door not closed well. Close door well.
Trouble Possible Cause Remedy
Normal
CUSTOMER SERVICE NUMBER-0800 422 274
11
0800 422 274
NZ

Your product has been inspected and tested and is guaranteed subject to the
following for a period of 12 months from the date of purchase against defects
in workmanship and materials. During this period, such defects will be rectified by repair
or replacement of the product purchased. Your product contains no user
serviceable components and this warranty becomes invalid if in our opinion the
product has been misused, abused, incorrectly installed, tampered with, connected to an
electrical supply not corresponding with the name plate specification, or subjected to
power surges. The warranty does not include any labour or other associated expense
that may be involved in removal or installation of the product. Normal wear and tear is
expressly excluded.
If your product fails to operate satisfactorily, please return it to the retailer from
whom it was purchased. To obtain a repair or replacement product under this warranty,
you will need to produce satisfactory evidence of date of purchase. The completed warranty
and purchase receipt must be presented with the product. The warranty should be filled
out at the time of purchase. It is in your interest to make sure this is done.
If the product is to be replaced (cannot be repaired) then that replacement will be of
the faulty product or accessory excluding packaging, instruction card etc. Where a
replacement product is supplied, this shall be guaranteed for the balance of the original
warranty period. Any model that is no longer available will be replaced by a model of a
value and with such features as we consider appropriate in the circumstances.
is not responsible for freight forwarding charges, losses or damage in transit.
If service is required after the warranty period has expired, the product should be
returned to a qualified electrical technician. Service outside of the warranty period will
be at your cost.
Consumers Guarantee Act (1993).
In accordance with the above act consumers are advised that: The manufacturer does
not undertake that repair facilities and parts are necessarily available for this product.
If any of the provisions of the foregoing are contrary to any relevant legislation, then
that provision shall be deemed to be excluded from the warranty and the rest of the
provisions will continue to apply.
12 MONTH WARRANTY
IMPORTANT: PLEASE RETAIN THIS WARRANTY CARD
NAME: .
ADDRESS: .
PURCHASED FROM: .
SUBURB: .
DATE OF PURCHASE: .
NAME OF PRODUCT: .
MODEL No: .
Made In China. Marketed By:The Warehouse,26 The Warehouse Way, Northcote,
Auckland 0627, 0800 422 274
Living&Co
Living&Co
Living&Co

Warranty
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and completely reliable. We are so confident in our products,
we back them up with a 1 year warranty.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
This Product is covered by 1 year warranty when
accompanied by proof of purchase.
0800 422 274
NZ
