Rice Cooker
INSTRUCTION MANUAL
MODEL: SRO8318

Table of Contents
....................................................................... 1
..................................................................................................... 4
IMPORTANT SAFEGUARDS
Part Names
Product Specifications
Operating
Cleaning & Maintenance
Troubleshooting
Circuit diagram
................................................................................... 4
...................................................................................................... 5
............................................................................... 6
............................................................................................ 7
............................................................................................. 7
Environmental protection ........................................................................... 8

1
IMPORTANT SAFEGUARDS
Caution
For safety reasons and to avoid damage to the appliance
or injuries to people, please follow by all the safety
instructions below. Ignoring safety warnings may result in
injuries.
This appliance does not take into consideration the
following situations:
— Use by children or disabled people without supervision;
— children treating it as a toy.
1. Read all instructions.
2. This appliance is for household use only. Do not use
outdoors.
3. This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
4. Unplug from outlet when not in use and before cleaning.
Allow to cool before cleaning.
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
6. Children should be supervised to ensure that they do not
play with the appliance
7. The use of accessory attachments not recommended by
the appliance manufacturer may cause injury.
8. Please turn off and unplug the appliance before cleaning,
maintenance or relocation and whenever it is not in use.
9. Do not let cord hang over edge of table or counter, or
touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in
a heated oven.

2
IMPORTANT SAFEGUARDS
noituaC noituaC noituaC noituaC
11. Extreme caution must be used when moving an
appliance containing hot food, water or other hot liquids.
12. Do not use the appliance for other than intended use.
13 .Lift and open cover carefully to avoid scalding, and allow
water to drip into unit.
14. To disconnect turn the control to OFF, then remove plug
from wall outlet.
15. Containers are designed for use with this appliance only.
They must never be used on a range top. Do not set a
hot container on a wet or cold surface. Do not use a
cracked container.
16. Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
17. Do not immerse the appliance in water or any other
liquid.
18. This appliance is intended to be used in household and
similar applications such as: -staff kitchen areas in
shops, offices and other working environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments.
19. Children shall not play with the appliance. The surfaces
of the appliance are liable to get hot during use.
20. To protect against electrical shock, do not immerse cord,
plug or appliance in water or other liquid.
21. The heating element surface is subject to residual heat
after use, do not touch.

3
IMPORTANT SAFEGUARDS
Caution
Never use this appliance to cook any food that may jam
the steam valve: such as Foliaceous food (e.g. liver,
Chinese cabbage) or strip food (e.g. kelp) and
fragmentary foods (e.g. corn grit), as these may cause
accidents or damage to the rice cooker.
During operation, never put your face or hands close to
the steam valve in order to avoid scald.
Use an individual earthed socket of 10A rated current.
To avoid any malfunction or damage, do not tiltthe
appliance whilst in use.
Therice cookermust operate with theprovided inner pot
only.
When in use, do not touch theinner pot to avoid scalding
by high-temperatures.
Wipe away waterfrom outside theinner pot before
cooking to avoid any fault.
Please clean away waterdrops and rice grains between
theinner pot and heating plate before cooking to avoid
overheating.
22. Warning: Misuse may cause potential injury
23. Do not touch hot surfaces. Use handles or knobs. Use
potholders when removing cover or handling hot
containers.
24. Do not place on or near a hot gas or electric burner, or in
a heated oven.

4
Part Name
Cover
Cover Handle
Steamer
Cooker Body
Control Box
Cooking Button
Base
WARM Indicator
Electric Heating
tray (Inside)
Inner Pot
Cooker Handle
Cooking Indicator
Magnetic Steel
Temperature
Limiter (Inside)
Product Specifications
SRO8318 6.5L 325×325×300 630-750W
Metal Steam Basket
220-240V~ 50/60Hz
Model No.
Capacity
Rated voltage
Rated
frequency
Rated power Cooking
method
LXWXH(mm)
Direct
heating
Accessories
Spoon Measuring Cup

5
Do not immerse the cooker body in water.
NOTE: One cup of rice is about 0.18L (about 150g).
CAUTION: Do not directly wash rice in the inner pot to avoid scratching or
distorting the inner pot.
CAUTION: Use the plastic accessory scoop when serving the rice.
DO NOT use metal spoons or utensils to avoid damaging the inner pot.
STEAMING
When steaming food, use the correct amount of water in the inner pot, then put
the food into the steamer, operate according to above step 4, 5 and 6. After
steaming, lift the cooking button.
When steaming food, ensure a correct amount of water is used to avoid
overflowing the steamer when the water is boiling.
•Do not use the WARM function for longer than 5 hours to avoid affecting the
flavor.
•Do not cook hard foods with bones, to avoid scratching and damaging the
inner pot.
•When cleaning the inner pot,do not scrub it with a metal pad or stiff tools to
avoiding scratching it.
•After use, please dry the parts, and then store it in the safe and dry place.
1. Add the cleaned rice into the inner pot, select the suitable water level mark
according to the amount of rice measured.
2. The scale mark on the inner pot is the scale mark for the cups of rice and
water. For example: when cooking 2 cups of rice, put the clean rice into
the inner pot, and then add water to the scale mark “2”.
3. The water mark of the inner pot is the standard cooking water mark,
please adjust the water amount according to personal taste.
4. Do not exceed the max scale mark of the corresponding function,
otherwise, it may cause an overflow or short circuit.
5. Dry the external surface of the inner pot, place it in the cooker and make
the rice even in the bottom of inner pot, carefully rotate the inner pot left to
right to make a good contact with the heating element.
6. Insert the power plug into the socket, press down the “Cooking” button,
the rice cooker will start.
7. After cooking, the Cooking button will automatically disconnect, and the
electric rice cooker enters into the automatic Keep Warm state.
8. If possible, leave the rice for about 15min and then open the cover to
serve.

6
1. Before cleaning, first switch off the appliance and then disconnect the power
plug from the power outlet.
2. Wash the Inner pot and Steamer tray in warm and soapy water using a sponge
or cloth and rinse throughly. Wipe dry. Do not clean with any abrasive brushes
to avoid damaging the non-stick coating.
3. Occasionally rice grains or other residue may stick onto the heating plate.
Ensure a proper contact is made with the Inner pot and rub the grains/residues
away from the heating plate and then wipe clean.

7
WARM
Indicator Resistor
Resistor
Cooking
Indicator
Insulation Board
Micro Switch
Magnetic Steel Temperature Limiter
Temperature Fuse Electric Heating Tray
Circuit diagram
Indicator
doesn’t
light on
Indicator
lights on
Electric
heating tray
doesn’t heat
The circuit of the electric rice
cooker is not connected with
the power supply
Check the switch, plug, socket and
power cord, ensure the plug is tightly
inserted into the socket
Electric
heating
tray heats
1. Indicator wire is loose
2. Indicator is damaged
1. Middle wire is loose
2. Electric heating tube element is
damaged
3. Temperature limiter is damaged
Electric
heating tray
doesn’t heat
Rice is not well
cook , or the
cooking time is
too long
The rice is burnt
The cooker can’t
automatically
WARM
The wires of the insulation board
is loose or the heating element
of the insulation board is damaged
time is not
adequate
Electric heating tray is
distorted
Inner pot is not in the middle
of the cooker
There’s foreign object between
the inner pot and electric
heating tray
Inner pot is distorted
The surface of the magnetic
steel temperature limiter is
dirt
The cooking button and
lever mechanism is no
Magnetic steel temperature
limiter is fault
the rice according to the
requirement
Rotate the inner pot to keep it at
the middle of the cooker
Remove the foreign object
Clean the surface with 320# sand
paper
S/N Possible Cause Check and Solutions
Troubleshooting

8
Environmental protection
Responsible Disposal
At the end of its working life, do not throw this product out with your
household rubbish. Electrical and electronic products contain substances
that can have a detrimental effect on the environment and human health if
disposed of inappropriately. Observe any local regulations regarding the
disposal of electrical consumer goods and dispose of it appropriately for
recycling. Contact your local authorities for advice on recycling facilities in
your area.
Please keep the original packaging carton and materials in a safe place. It
will help to prevent any damage if the product needs to be transported in
the future. In the event it is to be disposed of, please recycle all packaging
material where possible.

Warranty
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and completely reliable. We are so confident in our products,
we back them up with a 3 year warranty.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
This Product is covered by 3 year warranty when
accompanied by proof of purchase.
