livn 5901540 User manual

EN ASH VACUUM CLEANER MULTIFUNCTIONAL
NL ASZUIGER MULTIFUNCTIONEEL
FR ASPIRATEUR A CENDRES MULTIFONCTIONNEL
DE ASCHESAUGER MULTIFUNKTIONAL
EN Instruction manual NL Handleiding FR Manuel d'instructions DE Bedienungsanleitung

EN INSTRUCTION MANUAL
Please retain manual for future reference.
DESCRIPTION
1. Handle
2. Power switch
3. Cover
4. Regular nozzle
5. Crevice nozzle
6. Soft hose
7. HEPA filter with metal mesh cover outside
8. Dust shake function
1
2
3
4
5
6
7
8
Fig. A1
Fig. A2
Brush
NO

ATTENTION: please read all instructions carefully before using this appliance.
IMPORTANT MATTERS
•Make sure that the voltage rating label of the appliance corresponds to your main voltage. If not
see your retailer and do not connect the appliance.
•When the appliance is not in operation, please remove plug from supply mains.
•The plug must be removed from the socket-outlet before cleaning or maintaining the appliance.
•Don't remove the plug by pulling the power cord.
•Never use the appliance unsupervised when in use. If you have to leave even for a short moment
please stop the appliance.
•This appliance can be used by children aged from 8 years and above and people with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children may not play with the appliance. Cleaning and user maintenance must
not be carried out by children without supervision.
•Don't press and roll the power cord using heavy objects.
•If the power cord is damaged, it must be repaired by the manufacturer, its authorised service centre
or a professional.
•Don't vacuum the following items: liquid, inflammable and explosive dangerous material, corrosive
material, burning ash, matches, and cigarettes.
•Do not use the appliance to vacuum dust which is harmful to health.
•Keep the appliance in a dry environment.
•Don't touch the live parts in the appliance.
•Appliance is only to be repaired by the manufacturer or its authorised service agent.
•Do not use the appliance for other uses than intended.
•Pay extra attention when cleaning the stairs.
•Use the accessories and spare parts only supplied by the manufacturer or its authorised service
agent.
•When using the appliance to vacuum fireplace ash, no ashes with a temperature of more than 40 °C
should be vacuumed, no ashes and other objects where the fire is not completely extinguished
should be vacuumed.
•Do not use the appliance if the filter is not installed! Do not use other filters except the ones (fire
prevention filter) attached to the appliance by the manufacturer.
•For hot and cold ash, “Cold Ash” is ash cooled down for a sufficient time without any pockets of
embers inside. This can be confirmed by scouring the ash for pockets of embers by using metal
tools before using the ash vacuum cleaner. Cold ash does not emit any recognisable heat. Hot ash
has a maximum temperature of 40 °C.
•Substance to be vacuumed - cold and hot ashes from fireplaces, wood/coal stoves, pellet stoves,
ashtrays, grills, barbecues.
•Empty and clean vacuum cleaner before and after vacuuming to avoid the collection of materials
that could pose a fire hazard in the vacuum cleaner.
•Do not use for the separation of health-hazardous dusts (dust classes M).
•Do not vacuum soot.
•Vacuum only ashes from acceptable fuels.
•Do not vacuum any burning or glowing objects.
•Do not vacuum any objects that are hotter than > 40 °C.
•Do not vacuum any flammable substances.

FUNCTION OF THE PARTS
• Aluminium pipes: used to vacuum ash in the fireplace (Fig. A1).
• Power switch: turn the appliance on or off.
• Dust shake function: tap the dust off the HEPA filter without opening the upper lid.
INSTALLATION
Vacuum cleaner:
•Take out the appliance and accessories from the box, check the accessories and whether the
appliance enclosure is well-found or not.
•Loosen the clasp, and remove the upper part from the container.
•Attach the filter to the bottom of upper part.
•Put the upper part back on the container and use the clasp to fix it.
•Attach one of the aluminium pipes to the soft tube, and the other end of the soft tube is inserted
into the air inlet.
Blowing function uses:
•As shown in the picture, put ①into the air outlet ④and tighten it to the left.
•Put aluminium tube ③into ②.
VACUUM ASH
•Only use with the HEPA filter with metal mesh cover.
•When the container is full or it feels difficult to vacuum more dust, the filter needs to be cleaned.
This can also be done by using the dust shake function. With the dust shake function you can tap
the dust off the filter without opening the upper lid. After this you can easily continue vacuuming.
•While vacuuming the fireplace ash, the ash temperature must be below 40 °C. Do not vacuum the
ash if the fire is not extinguished! (Fig. A1)
AFTER USE (Fig. A2)
•Press the switch to turn off the vacuum cleaner.
•Pull out the plug.
•Roll up the power cable.
•Disassemble the soft tube from the appliance.
•Take the upper part from the appliance.
•Empty the dust container and wash it.
•Use a rag to dry the container.
•Take out the filter, clean and wash it carefully, and air dry it before installing it back on the vacuum
cleaner. (Fig. A2)
②
③
short
④
①
long

MAINTENANCE (Fig. A2)
• The container and outer shell of the head part need to be cleaned frequently.
• The dirty container should be washed with clear water.
• The filter should be washed with clear water.
•If the appliance is working unsatisfactory, it usually results from a jam of the soft tube or
conjunction of pipes or accessories. In that case, please clean the parts concerned.
CORRECT DISPOSAL OF THE PRODUCT
Do not dispose of electrical appliances as unsorted municipal (household) waste; use separate
collection facilities (2021/19/EU). Contact your local government for information regarding the
available collection systems. If electrical appliances are disposed of in landfills or dumps, hazardous
substances can leak into the groundwater and enter the food chain, thus damaging your health and
well-being. When replacing old appliances with new ones, the retailer is legally obligated to take back
your old appliance for disposal free of charge.
WARRANTY INFORMATION
-Warranty of 2 years, starting from the date on which the appliance is sold to the end user.
-The warranty only covers defects in material or workmanship.
-The repairs under warranty may only be carried out by an authorised service centre. When making
a claim under the warranty, the original invoice (with purchase date) must be submitted.
-The warranty will not apply in cases of:
oNormal wear and tear;
oIncorrect use, e.g. overloading of the appliance, use of non-approved accessories;
oUse of force, damage caused by external influences;
oDamage caused by non-observance of the user manual, e.g. connection to an unsuitable
mains supply or non-compliance with the installation instructions;
oPartially or completely dismantled appliances.
TECHNICAL DATA
Model
Power
Voltage
Frequency
5901540
1,200 W
AC220 V
50 HZ
