Livoo DOC236 User manual

Instruction manual
WWW.LIVOO.COM
Reference : DOC236
Version : 1.5
Language: nglish
Double induction hob

Instruction manual
1
You have purchased a product LIVOO brand and we thank you. We take great care in design, ergonomics and ease of
use of our products. We hope that this product will give you complete satisfaction.
This instruction manual is available too on our website www.livoo.fr
General Instructions
PL AS , TAK TIM TO R AD W LL TH INSTRUCTIONS FOR US
PARTICULARLY B FOR TH FIRST US .
A misuse of the appliance can damage it or hurt the user. Assure
that you use the appliance for the use for which it is designed;
we refuse any responsibilities as for the damages by an incorrect
use or a bad manipulation.
1. The appliance is intended for household use. All other using
is forbidden. Don’t use outdoor.
2. Before plugging in check that the voltage of your wall outlet
correspond to the rated voltage manner.
3. This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
4. Children shall not play with the appliance.
5. Cleaning and use maintenance shall not be made by children
unless they are older than 8 year and supervised.
6. Keep the appliance and its cord out of reach of children less
than 8 years.

Instruction manual
2
7. Never leave the appliance unsupervised when in use.
8. Appliance inlet must be dried before the appliance is used
again.
9. Never used the appliance :
-If the power cord is damaged
-In case of bad operation
-It has been damaged in any manner
-It has been submerged in water
-If you dropped it
10. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
(*) in order to avoid a hazard.
11. Never immerse your appliance in water or any other liquid
for any reason whatsoever. Never place it into the
dishwasher.
12. To reduce the risk of electric shock, never operate this
product with wet hands.
13. Never unplug the appliance by pulling the cord.
14. Unwind the cord of its flat to avoid the superheating of the
appliance.
15. Do not place an appliance on or near a hot gas or on a heated
oven.
16. It is absolutely necessary to keep this appliance clean at all
times as it comes into direct contact with food.
17. Regarding the instruction for cleaning surfaces in contact
with food thanks to refer to the below paragraph
“cleaning” in manual.
18. The appliance is not intended to be operated by means of

Instruction manual
3
external timer or separate remote control system.
19. WARNING: Unattended cooking on a hob with fat or oil can
be dangerous and may result in fire
20. N V R try to extinguish a fire with water, but switch off the
appliance and then cover flame e,g, with a lid or a fire
blanket
21. CAUTION: The cooking process has to be supervised, a short
term cooking process has to be supervised continuously
22. WARNING: Danger of fire: do not store items on the cooking
surfaces
23. After use, switch off the hob element by its control and do
not rely on the pan detector
24. Metallic objects such as knives, forks, spoons and lids should
not be placed on the hob surface since they can get hot.
25. Warning: if the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
26. A steam cleaner is not be used.
27. This appliance is intended to be used in household and
similar applications such as:
•staff kitchen areas in shops, offices and other working
environments
•farm houses
•by clients in hotels, motels and other residential type
environments
•bed and breakfast type environments
(*)
Competent qualified electrician: after sales department of the producer or importer or any person who
is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any
case you should return the appliance to this electrician.

Instruction manual
4
WARNING: HOT SURFACE
Surfaces are liable to get hot during use.
WARNING: The appliance and its accessible parts become hot
during use. Care should be taken to avoid touching heating
elements. Children less than 8 years of age shall be kept away
DO NOT OP RAT this product near water sources or flammable
liquids.
DO NOT CL AN OR TOUCH this product when it is still hot.
T CHNICAL SP CIFICATIONS
Voltage: 220-240 ~50-60Hz
Power: 3500W


Table 5a
-
Information for
domestic electric hobs
Symbol Value Unit
Model identification
-
DOC236
-
Type of hob - Electric hob -
Number of cooking zones and/or areas - two cooking zones -
Heating technology (induction cooking
zones and cooking areas, radiant
cooking zones, solid plates)
- Induction cooking
zones
-
For circular cooking zones or area:
diameter of useful surface area per
electric heated cooking zone, rounded to
the nearest 5 mm
Ø Right zone:21.5
Left zone: 21.5
cm
For non-circular cooking zones or areas:
length and width of useful surface area
per electric heated cooking zone or area,
rounded to the nearest 5 mm
L
W
- cm

Instruction manual
5
Energy consumption per cooking zone or
area calculated per kg
EC
electric cooking
Right zone:183.7
Left zone: 184.2
Wh/kg
Energy consumption for the hob
calculated per kg
EC
electric hob
184.0 Wh/kg
D SCRIPTION
Control panel
After inserting the plug in the socket, a beep will emit, the display and all control lights are activated shortly.
Press on/off button L D display shows C.
Cooking mode:
Place your pot/pan on the plate, press setting button until display shows 1600W which is default power for
left burner and 1600W for right burner.
It can be adjusted by pressing “+” or “-“to set power you want, from 200 until 2000W for left burner, from
200 to 1500W for right burner.
To cancel this mode, press left button to switch to other cooking modes or on/off button to stop.
Temperature setting:
Press setting button until indicator of C° lights up, display will show 200°C for left burner and 180°C for right
burner (default power in degree) but it can be adjusted by pressing “+” or “-“to set power you want (from
60°C until 240°C), to cancel this mode, press setting button to switch to other cooking modes or on/off
button to stop.
Note: Do not touch the hot plate
Timer function:
Setting
button
Timer
To adjust power/temp/timer
Power
on/off
Keep warm
Display
Child lock
Power
on/off
Timer
Setting
button
Child lock
Symbol
temperature,
power
Symbol
temperature
power and timer

Instruction manual
6
Press the timer button, it lights up, display will show default time “10” and you can adjust time by pressing
“+” or “-“, with “+” you can adjust by 10 minutes and with “-“you can adjust by one minute (range from 1
to 180min), then you can press timer button to confirm or wait until display stops flashing.
When the time is up, appliance “beep” and stops to change for standby mode automatically.
To cancel this function you can press on/off button to return on standby mode or hold the timer to resume
the selected power or temperature.
Warning: after use, switch off the appliance. Don’t plug it out immediately, there's 1 minute pre-set for
the fan continuous working until the unit cool down. After the cooling fan stops operation, unplug the
appliance from the socket
Child lock function:
To prevent children from changing settings or turning appliance on, you can press '+' and '-' at the same
time, all keys would be locked.
Under 'lock' status, press '+' and '-' at the same time and hold for 3 sec., the setting is unlocked again.
Or you could press 'ON/OFF' key, it would change to standby mode, then you could set needed function
again.
Note: you can use steel, cast iron, enameled iron, stainless steel, flat-bottom pans/pots with bottom
diameter from 12cm to 26cm.
Do not pull out the power cord during operation.
CL ANING AND STORAG
Before cleaning, unplug and wait for the appliance to cool down.
•Wipe with a moistened cloth.
•Do not clean with any abrasive items or liquids, as this will damage the appliance.
•Do not immerse in water or any other liquid.

Instruction manual
7
Correct disposal of the unit
(Electrical and Electronic Equipment)
(Applicable in the uropean Union and the rest of urope that have adopted separate collection systems
countries)
The uropean Directive 2012/19/ U on Waste lectrical and lectronic quipment (W ), requires that old
household electrical appliances must not be disposed of in the normal household waste stream.

Instruction manual
8
Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain and
reduce the impact on human health and the environment.
The symbol of the crossed out dustbin is marked on all products to remind the obligations of separate collection.
Consumers should contact their local authority or retailer for information concerning the correct disposal of their product.
•Photo no contractual
•Worried about the quality of his products the manufacturer reserves the right to make modifications without advance
notice
