LK CubicSecure User manual

1 (9)
TABLE OF CONTENTS
Design 1
System description 1
Preparing for installation 2
Installation 2
Startup 3
Pairing 5
Functions 6
Summary of LEDs 6
Start-up and function check 6
Operation 8
Maintenance 8
Technical data 9
Comment 9
Environment 9
Guarantee 9
CE approval 9
Design
LK CubicSecure is a water safety system that pro-
tects against leakage by continuously measuring
water consumption, water pressure and tempera-
ture. The unit emits alarms for both micro-leaks
and larger leaks. When the water safety system
detects a leak, it automatically shuts off the water
ow.
System description
LK CubicSecure is a small unit that is easy to
install in conned spaces. The unit is easily in-
stalled on incoming water pipes for a house or
apartment. The water safety system is equipped
with a switch for manual shut-off in the event of
power failure or emergency.
NOTE!
Two water safety systems can be paired in
order to avoid scalding in apartments. Pairing
provides a synchronised automatic shut-o󰀨
between the hot and cold water pipes.
With the LK app and Wi-Fi connectivity, you can
remotely control the unit to shut the water off or
on, acknowledge alarms and monitor your water
consumption, for example.
The LK app
The login page for the LK app.
LK CubicSecure - An intelligent water safety system
EN.40.C.12.2021-12-06
Installation instructions | LK CubicSecure

2 (9)
Installation
1. Install the water safety system on the in-
coming water pipe directly after the water
meter isolation valve and any check valve.
2. Tighten the couplings without damaging
the plastic casing on the water safety sys-
tem.
The water safety system and the incoming water pipe.
TIP! The water safety system is equipped with a
counterhold on the underside. Use an adjustable
wrench on the counterhold. It is also possible to
use a screwdriver in the slot to create a counter-
hold.
The counterhold on the underside of the water safety
system.
The water safety system installed in the cabinet.
Preparing for installation
The water safety system must be installed by a
plumber according to the Safe Water Installation
industry regulations.
TIP! The water safety system is equipped with
a G20 EuroCone external thread which is to be
installed with an LK PressPex press connection
coupling or LK Pusht AX connection coupling.
When using a at gasket, LK Plain Adapter is
supplied
(RKS-187 06 78) with the product.
NOTE!
Safety systems such as residential sprinklers
and emergency cooling of solid fuel boilers or
similar must be connected before the water
safety system. If they are installed after-
wards, they risk being left without a water
supply.
NOTE!
Install the water safety system after supplying
safety systems that require water.
NOTE!
Water lters that are backwashed should
also be connected before [word missing] to
avoid interfering with its function. The system
prevents water damage that may occur after
the position of the water safety system.
Correct installation of the water safety system.
The arrows show the direction of water ow.
EN.40.C.12.2021-12-06
Installation instructions | LK CubicSecure

3 (9)
Connecting to Wi-Fi
Remote monitoring of the unit's measurements
and alarms via a smartphone requires an app and
a connection to a Wi-Fi network.
1. Check that the CONNECT LED is ashing
WHITE.
2. If the LED does not ash WHITE, press the
CONNECT button.
White ashing light - CONNECT.
Connecting with the LK app
1. Download and install the LK app from the
App Store or Google Play Store.
2. Launch the LK app and log in.
The login page in the LK app.
Startup
1. Connect power to the unit using the micro-
USB power adapter included.
The water safety system connected to the power source.
2. Check that the STATUS LED is WHITE.
White light indicates that the unit is work-
ing normally. If no LEDs are lit, check that
the wall socket or power adapter is func-
tional.
White light - the unit is working normally.
EN.40.C.12.2021-12-06

4 (9)
7. Connect to the wireless
access point of the water safety system.
Conrm that the connection is working.
Press CONNECTED.
Connecting to the wireless access point of the water safety
system. This is called CubicSecure_XXXX.
8. Select the name of the wireless network and
enter the password.
9. Conrm your selection by pressing FLASH-
ES WHITE.
Selecting a wireless network.
3. Check that the STATUS LED is WHITE.
4. Conrm by pressing GLOWS WHITE.
White light - the unit is working normally.
5. Press the CONNECT button and check that
it starts ashing WHITE.
6. Conrm by pressing FLASHES WHITE.
White ashing light - CONNECT.
EN.40.C.12.2021-12-06

5 (9)
Manual connection
1. Use a smartphone or computer to connect to
the wireless access point of the water safety
system. This is named CubicSecure_XXXX.
2. Open a web browser and go to
cubicsecure.net (or 10.123.45.1)
3. Select your wireless network and enter the
password in the box displayed.
4. Press ADD followed by CONFIRM, then
wait until the CONNECT LED shines solid
WHITE.
PAIRING
Example cabinet with pairing
NOTE!
In the event of apartment installation, units
should be installed on hot and cold water
pipes to protect against any leakage and
avoid possible scalding.
Manual pairing
1. Install and start the units. One for hot water
and one for cold water.
2. Hold down the CONNECT button for ve
seconds on the unit installed for cold water.
The CONNECT LED starts ashing YEL-
LOW and BLUE.
3. Hold down the CONNECT button for ve
seconds on the unit installed for hot water.
The CONNECT LED starts ashing YEL-
LOW and RED.
10. Give the water safety system a name and
select the correct setting for the water.
Conrm your selection by pressing ADD
DEVICE.
Selecting the name and add-on for the unit.
The LK app
All installed units are displayed in the LK app.
Summary screen - DEVICES.
EN.40.C.12.2021-12-06

6 (9)
Summary of LEDs
STATUS LED Meaning
WHITE The unit is switched on and
active, and no errors or
alarms are indicated.
Dark/O󰀨 The unit is not powered.
Make sure the unit is con-
nected to a power source.
Check that the power source
is working properly.
YELLOW Leak detection is deactivated.
Press the WATER ON/OFF
button to activate the func-
tion.
YELLOW
Flashing
Detected leakage.
WHITE
Flashing
The unit is being updated and
other functions are temporar-
ily disabled. Do not discon-
nect the power source.
GREEN
Flashing
The unit is collecting data on
the water pressure and has
closed the valve in the mean-
time. Data collection con-
tinues for up to one minute,
after which the unit opens the
valve again.
RED The unit is not working/is not
working properly. Contact
technical support.
WATER ON/
OFF LED
Meaning
WHITE The valve is open. The water
supply/ow is on.
Dark/O󰀨 The valve is open. The water
supply/ow is o󰀨.
WHITE
Flashing
Indicates that there is an
ongoing water ow.
YELLOW The position of the valve has
been changed using the man-
ual switch. Press the WATER
ON/OFF button to turn o󰀨 the
warning/alarm function.
RED The water pressure is very
low or there is no water in the
pipe. Check that the water
system is working properly.
CONNECT
LED
Meaning
WHITE Wi-Fi congured and con-
nected.
4. Make sure that the CONNECT LEDs on
both units ash GREEN rapidly for about a
second.
5. If pairing was not completed,
redo process steps 2 to 4.
Pairing via the LK app
Pairing can also be done via the LK app if the
units are connected to Wi-Fi and added to the
same account. Follow the instructions in the LK
app.
functions
1. Valve switch.
2. Reset button (factory setting)
3. CONNECT LED for pairing.
4. CONNECT button for pairing.
5. STATUS LED (red, green, white and yel-
low).
6. ON/OFF button for water.
7. ON/OFF LED for water.
EN.40.C.12.2021-12-06

7 (9)
• If the pressure sensor manages to nd a
leak
, the STATUS LED starts ashing YEL-
LOW.
If the pressure sensor does not nd a leak,
redo the steps with a slightly larger leak.
3. Close the tap and press the WATER ON/
OFF button to open the valve again.
Leakage control with flow
1. Open a tap with the valve in the open posi-
tion.
2. Leave the valve at full ow on the tap for at
least 40 minutes.
3. Check that the unit emits an alarm after 30
minutes and switches off the ow after 40
minutes.
4. Then close the tap and reset the unit.
Alarm
Small leak
• The unit will emit an alarm after micro-leak-
age for at least
48 hours and shut off the water after 24
hours.
Medium-sized leak
• The unit will emit an alarm and shut off the
water after a leak with continuous ow for at
least 45 minutes.
Large leak
• The unit will emit an alarm when the ow
is continuous for at least 45 seconds and the
ow is above 1500 l/h.
Acknowledge alarm
Press the WATER ON/OFF button once to ac-
knowledge the alarm.
Factory reset of the unit
Firstly, insert a paper clip into the hole on the re-
set button while plugging in the power cable.
CONNECT
LED
Meaning
Dark/O󰀨 Wi-Fi congured and con-
nected.
WHITE
Flashing
The unit is in hotspot mode
for Wi-Fi conguration.
RED
Flashing
No Internet contact with the
Wi-Fi network.
YELLOW
Flashing
Ongoing pairing
establishment between two
water safety system units,
one for cold water and one for
hot water.
YELLOW/
BLUE
Flashing
Pairing completed
between the hot and cold
water units. The connection
is made from the cold water
unit which ashes YELLOW/
BLUE.
YELLOW/
RED
Flashing
Pairing completed between
the hot and cold water units.
The connection is made from
the hot
water unit which ashes
YELLOW/RED.
GREEN
Flashing
Pairing has been successful
and is completed.
Start-up and function check
Check that the ball valve is working
1. Press the WATER ON/OFF button.
The LED starts ashing RED. The LED
shines solid RED when the ball valve has
completely shut off the water ow.
2. Open a tap. Check that
no water comes out of the tap.
3. Press the WATER ON/OFF button.
The LED goes off when the valve is fully
open. Check that water is now coming out
of the open tap.
Check that the pressure sensor is working
1. Open a tap to simulate a very small leak. A
dripping stream of water will sufce.
2. Press the WATER ON/OFF button to close
the valve.
• When the valve is closed, the STATUS
LED will ash GREEN while the pressure
sensor scans for small leaks for about 45
seconds.
EN.40.C.12.2021-12-06

8 (9)
The LK app
This function is also available in the LK app,
where you can also change the time.
Changing the time for stopped leak detection
Maintenance
Check the opening and closing function of the
valve
1. Press the WATER ON/OFF button.
• The button shines WHITE when the valve
is open.
• The LED is off and dark when the valve is
closed.
• The switch at the top of the unit must
rotate and break the line when closed and
follow the line when open.
The picture on the left shows an open valve, a closed valve
is shown on the right.
Operation
Follow the unit’s measurements via the LK app.
Various data such as temperature, volume, water
pressure, valve position and no leakage detected
are displayed for each unit. When LK CubicSe-
cure is in operation, it performs automatic leak-
age tests. If a fault occurs during operation, the
water safety system will emit an alarm and close
the valve.
Measured values from the water safety system are shown in
the LK app.
Use of large amounts of water
The abnormal ow alarm function can be deac-
tivated if a larger amount of water is needed to
ll a pool or for irrigation. The preset time is 24
hours.
Manual
1. To deactivate the alarm function, press and
hold down the Water ON/OFF button
for at least ve seconds.
WATER ON/OFF button and yellow LED for the function.
EN.40.C.12.2021-12-06

9 (9)
LK Systems AB, Box 66, 161 26 Bromma, Sweden | www.lksystems.se
Technical data
Water temperature 0.1 °C … 70 °C (T70)
Press PN10
Environment Indoors
Climate/Environment 5 °C … 30 °C in the event
of condensation/a damp
environment
Storage -25 °C … 55 °C
Wireless frequency 2.4 GHz
Nominal ow rate (Q3) 4,000 l/h
Micro-leakage detected >0.5 bar pressure loss for
two consecutive days (48
h).
Leakage detected. >5 l/h for at least 45 min-
utes
Leakage detected, large >1500 l/h for 45 seconds
Weight 720 grams
Dimensions 71 mm height: 85 mm
width, length 110 mm
Comment
Completely interference-free operation cannot always
be guaranteed with the technology available today,
which allows free use of the frequency band.
Every installation should therefore be tested indi-
vidually. LK CubicSecure always works indepen-
dently. The water safety system will still work if
the unit loses contact with the Internet. The unit is
still in operation and emits an alarm when a leak
is detected. The contact with the LK app is tem-
porarily interrupted, and it then does not receive
notications or alarms until contact is established
with the Internet
Environment
LK Systems is afliated with El-Kretsen for col-
lecting and recycling electronics and batteries.
Used batteries should be sorted as batteries or
small batteries and deposited for battery recy-
cling. When the system has reached the end of
its life, it should be sorted as electronics or other
electronics and deposited with a recycling centre.
Guarantee
LK Systems AB is responsible for faults in prod-
ucts that appear within two years from the deliv-
ery of the product to the buyer. If LK is responsi-
ble for the fault in the product, LK has the right to
replace the product with either a new or repaired
product. The liability period for replacement or
repair of a product or spare part does not exceed
the liability period for the original product. The
seller is not responsible for faults resulting from
accidents, incorrect installation, incorrect instal-
lation, incorrect care, abuse or other irregular use.
LK Systems AB is not responsible for any loss or
damage caused by a non-functioning product.
Its responsibility is strictly limited to the replace-
ment of the product.
CE approval
LK Systems hereby declares that radio equip-
ment type CubicSecure - LTCS01 is in compliance
with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available by con-
tacting [email protected].
EN.40.C.12.2021-12-06
