LLK LLKPM20E User manual
Introduction
Thank you for purchasing a Linda Lewis Kitchens Ltd product. In this booklet you will
find instructions for safe operation so please read carefully and retain for future
reference. The planetary mixers have a stirring hook that rotates. They have three
speed settingsand use a combination transmission composed of a locking band,
triangle belt and chains.
Warnings and Precautions
The following warnings and precautions are important and must be observed:
•Never immerse the mixer in water. If the mixer does become completelywet, it
must be dried and checked by a qualified specialistbefore it is used again.
•The mixer cannot be used if the protective cover switch is not functioning.
•Prior to installation, pleaseread the instructions fully.
•Do not put your hand or other items into the bowl when the machine is in
operation.
•Whenever a speed change is made, the main switch must be turned off
beforehand and then the slow or fast button must be pressed. This ensures a
long service life of the mixer.
•Do not leave the mixer unattended when it is in operation.
•Please unplug the electrical cord when the mixer is not in use.
Disclaimer: The manufacturer will acceptno liability for any injury or damage caused
by incorrect usage of the mixer.
Technical Data
Specifications:
LLKPM20
Motor Power
1.1kW
Width
500mm
Depth
600mm
Height
780mm
Weight
107kg
Specificationsare subject to change. Please checkthe rating label on the back of the
machine.
2
0161 696 0052
Operating Instructions
1. The machine must be placed on a dry, level surface to ensure the mixer is
stable.
2. Check the power voltage of the socket matches the mixer’s required voltage
and ensure it is properly earthed before plugging in the mixer.
3. Slide the guard across and pour the ingredients into the bowl.
4. Close the guard and set the stirring speed.
5. Switch on the mixer using slowspeed at first, thenswitch to fast speed to
ensure uniform dough is produced.
6. If the machine is stopped during the mixing process, be sure to return to the
lowest speed when starting the machine up again.
Maintenance
Cleaning
Spilled food should be removed immediatelyfrom all exterior surfaces. Also, it is
important to clean the mixer afteruse. To remove dirt or marks from the mixer, it is
best to wipe with a soft damp cloth. The stainlesssteel is washable.The mixer must
not be cleaned using a high-pressure jet.
Please note that attachmentsand machine are not suitable for cleaning in the
dishwasher due to causticsoda contained within the chemicals. They should be
cleaned with soapywater.
Problems and Solutions
1. The mixer will not start – the power is not properly connected or the guard is
not fittedcorrectly
2. The guard switch is not operating correctly – open the guard and check to see if
the micro-switch is connected properly. Check the power supply.
3. The mixer has overheated – this can occur if the mixer is operated for too long,
with excessive load. Overheating can also come from electricleakage.
4. The mixer is operating with lowefficiency– check to see if the drive system is
worn, whether the motor is in good condition, whether the belt is loose or
damaged. Remove the top cover and the rear ventilating plate,adjust the belt,
tighten the wheel or the chains, thus the belt and the chains can be re-
tightened.
4
0161 696 0052
Ser.
No.
Part No.
Part Name
Ser.
No.
Part No.
Part Name
1
P01.053
Wire Whip
42
P01.166
Circlips for shaft 12
2
PM20.HOOK
Spiral Dough Hook
43
P01.198
Taper Gear Wheel
3
PM20.BEATER
Flat Beater
44
P01.200
Gear
4
P01.052
Safety Guard
45
P01.197
Bushing
5
P01.291
Bowl Assembly
46
P01.205
Sleeve
6
P01.201
Plunger-Shifter
Yoke
47
P01.204
Claw Type Gear
Wheel
7
P01.202
Spring
48
P01.203
Ring
8
P01.266
Pin Shaft
49
P01.183
Bearing 6205
9
P01.181
Shifting Yoke
50
P01.196
Bushing
10
P01.100
Cam-Gear Shifter
51
P01.179
Oil Seal 30x52x10
11
P01.101
Plate-ShifterIndex
52
P01.145
Press board
12
P01.049
Handle-Shifter
Cover
53
P01.194
Support
13
P01.050
Handle-Shifter
54
P01.195
Case
14
P01.089
Speed Handle
55
P01.131
Nut
15
P01.096
Plug
56
P01.187
Bearing
16
P01.261
Attachment Hub
57
P01.058
Mid-gear wheel
17
P01.226
Tighten Handle
58
P01.057
Key 4*14
18
P01.173
Ring
59
P01.167
Circlips for shaft 18
19
P01.199
Taper Gear Wheel
60
P01.189
Gear
20
P01.069
Top Cover
61
P01.191
Bushing
21
P01.157
Nut
62
P01.193
Gear
22
P01.168
Pressing Plate
63
P01.192
Plug Cover
23
P01.102
Plug Cover
64
P01.177
Worm Pole
24
P01.178
Super Machine
Parts
65
P01.180
Oil Seal
25
P01260
Declutch Shift
Shaft
66
P01.044
Green Button
26
P01.132
Spring Washer 10
67
P01.045
Red Button
27
P01.262
Nut M10
68
P01.209
Brand
28
P01.188
Main Shaft
69
P01.210
Motor Box
29
P01.206
Gear Box
70
P01.190
Key 5*14
30
P01.214
Internal Gear
71
P01.176
Shaft Worm Gear
31
P01.263
Gear
72
P01.174
Worm Wheel
32
P01.213
Operating Shalf
73
P01.080
Motor
33
P01.265
Bearing
74
P01.068
Back Housing
34
P01.067
Oil Seal 28x47x10
75
P01.025
Back Cover
35
P01.059
Working shaft
76
P01.184
Handle-Shifter
36
PM20.PIN
Retainer-pin 8x35
77
P01.185
Crank Lever
37
P01.207
Spring washer 14
78
P01.186
Connecting Rod
38
P01.264
Pressing plate
79
P01.208
Stud
39
P01.216
Transmissionshaft
support
80
P01.212
Clamp Plate
40
P01.094
Bearing 6203
81
P01.161
Clamp Plate
41
P01.217
Spacer-lower
82
P01.211
Spring
6
0161 696 0052
Service@linda-lewis.co.uk –2 – 0161 696 0052
Introduction
Thank you for purchasing a Linda Lewis Kitchens Ltd product. In this booklet
you will find instructions for safe operation so please read carefully and retain
for future reference. The planetary mixers have a stirring hook that rotates.
They have three speed settings and use a combination transmission
composed of a locking band, triangle belt and chains.
Warnings and Precautions
The following warnings and precautions are important and must be observed:
•Never immerse the mixer in water. If the mixer does become
completely wet, it must be dried and checked by a qualified specialist
before it is used again.
•The mixer cannot be used if the protective cover switch is not
functioning.
•Prior to installation, please read the instructions fully.
•Do not put your hand or other items into the bowl when the machine is
in operation.
•Whenever a speed change is made, the main switch must be turned off
beforehand and then the slow or fast button must be pressed. This
ensures a long service life of the mixer.
•Do not leave the mixer unattended when it is in operation.
•Please unplug the electrical cord when the mixer is not in use.
Disclaimer: The manufacturer will accept no liability for any injury or damage
caused by incorrect usage of the mixer.
Technical Data
Specifications:
LLKPM10
Motor Power
0.5 kW
Width
485mm
Depth
410mm
Height
635mm
Weight
75kg
Specifications are subject to change. Please check the rating label on the back of
the machine.
Service@linda-lewis.co.uk –4 – 0161 696 0052
Operating Instructions
1. The machine must be placed on a dry, level surface to ensure the mixer
is stable.
2. Check the power voltage of the socket matches the mixer’s required
voltage and ensure it is properly earthed before plugging in the mixer.
3. Slide the guard across and pour the ingredients into the bowl.
4. Close the guard and set the stirring speed.
5. Switch on the mixer using slow speed at first, then switch to fast speed
to ensure uniform dough is produced.
6. If the machine is stopped during the mixing process, be sure to return
to the lowest speed when starting the machine up again.
Maintenance
Cleaning
Spilled food should be removed immediately from all exterior surfaces. Also, it
is important to clean the mixer after use. To remove dirt or marks from the
mixer, it is best to wipe with a soft damp cloth. The stainless steel is washable.
The mixer must not be cleaned using a high-pressure jet.
Please note that attachments and machine are not suitable for cleaning in the
dishwasher due to caustic soda contained within the chemicals. They should
be cleaned with soapy water.
Problems and Solutions
1. The mixer will not start – the power is not properly connected, or the
guard is not fitted correctly
2. The guard switch is not operating correctly – open the guard and check
to see if the micro-switch is connected properly. Check the power
supply.
3. The mixer has overheated – this can occur if the mixer is operated for
too long, with excessive load. Overheating can also come from electric
leakage.
4. The mixer is operating with low efficiency – check to see if the drive
system is worn, whether the motor is in good condition, whether the
belt is loose or damaged. Remove the top cover and the rear
ventilating plate, adjust the belt, tighten the wheel or the chains, thus
the belt and the chains can be re-tightened.
Service@linda-lewis.co.uk –6 – 0161 696 0052
PM10 PARTS
Ser.
No.
Part No.
Part Name
Ser.
No.
Part No.
Part Name
1
PM10.WHISK
Wire-Whip
42
P01.119
Super Machine Parts
2
PM10.HOOK
Spiral Dough Hook
43
P01.123
Taper Gear
3
P01.115
Spring
44
P01.090
Motor
4
P01.149
Pin Shaft
45
P01.125
Combination of Gear
5
P01.153
Shifter Yoke
46
P01.028
Bushing
6
PM10.BEATER
Flat Beater
47
P01.165
Claw-Type Clutch
7
P01.126
Main Shaft
48
P01.154
Inner Gear
8
P01.127
Nut
49
P01.147
Gear Box
9
P01.151
Lining Ring
50
P01.164
Support
10
P01.247
Bearing 6204
51
P01.182
Base
11
P01.089
Speed Handle
52
P01.155
Retainer-Spring
12
P01.117
Handle Shaft
53
P01.131
Nut
13
P01.152
Lining Ring
54
P01.132
Spring Washer 10
14
P01.150
Oil Seal
55
P01.136
Gear Shaft
15
P01281
Locking Bolt
56
P01.137
Key 4x12
16
P01.118
Block Handle
57
P01.166
Circlips for Shaft 12
17
P01.049
Block Handle Cover
58
P01.138
Gear
18
P01.096
Plug
59
P01.093
Lining Ring
19
P01.121
Cam-Gear Wheel
60
P01.139
Gear
20
P01.120
Attachment Hub
61
P01.140
Ring
21
P01.124
Taper Gear Wheel
62
P01.141
Bearing 6001
22
P01.159
Circlips for Shaft
63
P01.142
Shaft Worn Gear
23
P01.144
Planet Gear
64
P01.167
Circlips for Shaft
24
P01.236
Bearing 6202
65
P01.143
Worm Gear
25
P01.128
Operating Shelf
66
P01.141
Bearing 6001
26
PM10.001
Safety Guard
67
P01.170
Nausea Cover
27
P01.134
Working Shaft
68
P01.141
Back Guard
28
P01.094
Bearing 6203
69
P01.162
Worm Pole
29
P01.113
Oil Seal 20x40x7
70
P01.011
Back Cover
30
P01.293
Bowl
71
P01.133
Motor Box
31
P01.099
Cover
72
P01.122
Crank Lever
32
P01.282
Plug
73
PM10.HANDLE
Handle
33
P01.157
Nut
74
P01.148
Connecting Rod
34
P01.158
Control Nut
75
P01.171
Stud
35
P01.129
Declutch Shift Shaft
76
P01.116
Spring
36
P01.130
Spring Washer 8
77
P01.161
Clamp Plate
37
P01.169
Gear
78
P01.156
Nut M10
38
P01.163
Spring Washer 14
79
P01.145
Press Board
39
P01.164
Support
80
P01.146
Brand
40
P01.160
Bearing 6003
82
41
P01.125
Spindle Boring Cover
P01.045 Stop Switch
Introduction
Thank you for purchasing a Linda Lewis Kitchens Ltd product. In this booklet you will
find instructions for safe operation so please read carefully and retain for future
reference. The planetary mixers have a stirring hook that rotates. They have three
speed settingsand use a combination transmission composed of a locking band,
triangle belt and chains.
Warnings and Precautions
The following warnings and precautions are important and must be observed:
•Never immerse the mixer in water. If the mixer does become completelywet, it
must be dried and checked by a qualified specialistbefore it is used again.
•The mixer cannot be used if the protective cover switch is not functioning.
•Prior to installation, pleaseread the instructions fully.
•Do not put your hand or other items into the bowl when the machine is in
operation.
•Whenever a speed change is made, the main switch must be turned off
beforehand and then the slow or fast button must be pressed. This ensures a
long service life of the mixer.
•Do not leave the mixer unattended when it is in operation.
•Please unplug the electrical cord when the mixer is not in use.
Disclaimer: The manufacturer will acceptno liability for any injury or damage caused
by incorrect usage of the mixer.
Technical Data
Specifications:
LLKPM20
Motor Power
1.1kW
Width
500mm
Depth
600mm
Height
780mm
Weight
107kg
Specificationsare subject to change. Please checkthe rating label on the back of the
machine.
2
0161 696 0052
Operating Instructions
1. The machine must be placed on a dry, level surface to ensure the mixer is
stable.
2. Check the power voltage of the socket matches the mixer’s required voltage
and ensure it is properly earthed before plugging in the mixer.
3. Slide the guard across and pour the ingredients into the bowl.
4. Close the guard and set the stirring speed.
5. Switch on the mixer using slowspeed at first, thenswitch to fast speed to
ensure uniform dough is produced.
6. If the machine is stopped during the mixing process, be sure to return to the
lowest speed when starting the machine up again.
Maintenance
Cleaning
Spilled food should be removed immediatelyfrom all exterior surfaces. Also, it is
important to clean the mixer afteruse. To remove dirt or marks from the mixer, it is
best to wipe with a soft damp cloth. The stainlesssteel is washable.The mixer must
not be cleaned using a high-pressure jet.
Please note that attachmentsand machine are not suitable for cleaning in the
dishwasher due to causticsoda contained within the chemicals. They should be
cleaned with soapywater.
Problems and Solutions
1. The mixer will not start – the power is not properly connected or the guard is
not fittedcorrectly
2. The guard switch is not operating correctly – open the guard and check to see if
the micro-switch is connected properly. Check the power supply.
3. The mixer has overheated – this can occur if the mixer is operated for too long,
with excessive load. Overheating can also come from electricleakage.
4. The mixer is operating with lowefficiency– check to see if the drive system is
worn, whether the motor is in good condition, whether the belt is loose or
damaged. Remove the top cover and the rear ventilating plate,adjust the belt,
tighten the wheel or the chains, thus the belt and the chains can be re-
tightened.
4
0161 696 0052
Ser.
No.
Part No.
Part Name
Ser.
No.
Part No.
Part Name
1
P01.053
Wire Whip
42
P01.166
Circlips for shaft 12
2
PM20.HOOK
Spiral Dough Hook
43
P01.198
Taper Gear Wheel
3
PM20.BEATER
Flat Beater
44
P01.200
Gear
4
P01.052
Safety Guard
45
P01.197
Bushing
5
P01.291
Bowl Assembly
46
P01.205
Sleeve
6
P01.201
Plunger-Shifter
Yoke
47
P01.204
Claw Type Gear
Wheel
7
P01.202
Spring
48
P01.203
Ring
8
P01.266
Pin Shaft
49
P01.183
Bearing 6205
9
P01.181
Shifting Yoke
50
P01.196
Bushing
10
P01.100
Cam-Gear Shifter
51
P01.179
Oil Seal 30x52x10
11
P01.101
Plate-ShifterIndex
52
P01.145
Press board
12
P01.049
Handle-Shifter
Cover
53
P01.194
Support
13
P01.050
Handle-Shifter
54
P01.195
Case
14
P01.089
Speed Handle
55
P01.131
Nut
15
P01.096
Plug
56
P01.187
Bearing
16
P01.261
Attachment Hub
57
P01.058
Mid-gear wheel
17
P01.226
Tighten Handle
58
P01.057
Key 4*14
18
P01.173
Ring
59
P01.167
Circlips for shaft 18
19
P01.199
Taper Gear Wheel
60
P01.189
Gear
20
P01.069
Top Cover
61
P01.191
Bushing
21
P01.157
Nut
62
P01.193
Gear
22
P01.168
Pressing Plate
63
P01.192
Plug Cover
23
P01.102
Plug Cover
64
P01.177
Worm Pole
24
P01.178
Super Machine
Parts
65
P01.180
Oil Seal
25
P01260
Declutch Shift
Shaft
66
P01.044
Green Button
26
P01.132
Spring Washer 10
67
P01.045
Red Button
27
P01.262
Nut M10
68
P01.209
Brand
28
P01.188
Main Shaft
69
P01.210
Motor Box
29
P01.206
Gear Box
70
P01.190
Key 5*14
30
P01.214
Internal Gear
71
P01.176
Shaft Worm Gear
31
P01.263
Gear
72
P01.174
Worm Wheel
32
P01.213
Operating Shalf
73
P01.080
Motor
33
P01.265
Bearing
74
P01.068
Back Housing
34
P01.067
Oil Seal 28x47x10
75
P01.025
Back Cover
35
P01.059
Working shaft
76
P01.184
Handle-Shifter
36
PM20.PIN
Retainer-pin 8x35
77
P01.185
Crank Lever
37
P01.207
Spring washer 14
78
P01.186
Connecting Rod
38
P01.264
Pressing plate
79
P01.208
Stud
39
P01.216
Transmissionshaft
support
80
P01.212
Clamp Plate
40
P01.094
Bearing 6203
81
P01.161
Clamp Plate
41
P01.217
Spacer-lower
82
P01.211
Spring
6
0161 696 0052
Table of contents
Other LLK Mixer manuals
