Introduction
Thank you for purchasing the LM Technologies Wireless Wi-Fi N+3G Wi-Fi Router. Before
use, please read this manual carefully. This manual will help you to complete the
installation and also help you in using the product to its full potential. You can then enjoy
the fun of surfing wirelessly anytime and anywhere on any network.
Product Overview
The LM009 from LM Technologies is a wireless access point and Ethernet router, capable of
connecting to a existing cable / xDSL Broadband modem and also featuring a USB port for
use with a 3G HSPA modems, enabling both wired and wireless Internet access from
connected clients via fixed-line and cellular service, all in one pocket-sized portable device.
The LM009 incorporates a number of feature-rich networking services providing all the
functionality a small office or temporary field site may require, including:
Firewall•
Advanced wireless encryption support•
Port Forwarding•
Port Filtering•
IP Filtering•
URL Filtering•
MAC filtering•
DMZ•
VLAN•
Virtual Server•
Route management•
QoS•
The unit’s USB port can also be used with a USB storage device to provide shared file
server access to connected clients (both local and remote), via FTP or network file sharing
protocols. The unit also features a Dynamic DNS client for use with the DynDNS service,
ideal for temporary or mobile locations requiring inbound access.
Product Specification
OS Compatibility:
• Windows XP 32bit & 64bit, Vista 32bit & 64bit, Windows 7 32bit & 64bit, Mac OS 10.4
&10.5, Linux Ubuntu
2
Data Rate:1
• Up to 150 Mbps
• 802.11b: 11, 5.5, 2 & 1 Mbps
• 802.11g: 90, 60, 54, 48, 36, 30, 24, 22, 18, 12, 11, & 6Mbps
• 802.11n: 300, 270, 240, 180 and 120Mbps
• Compatibility: IEEE 802.11b / IEEE 802.11g and IEEE 802.11n
Security:
• Encryption: 64-bit / 128-bit WEP, WPA, WPA2, WPS, TKIP, AES
Physical Specification:
• Chipset: Realtek RTL8196B
• Antenna: On board chip antenna
• LED: Power, WLAN, WAN/LAN (Link/Act)
• Interface: LAN - One 10/100 BaseT with RJ45 port
WAN - One 10/100 BaseT with RJ45 port
USB - One USB 2.0 port
• Height: 23mm (0.905 in)
• Length: 100mm (3.937 in)
• Width: 67mm (2.638 in)
• Weight: 99 grams
Environmental Specifications:
• Transmission Class: Class 1 - up to 300 meters
• Operating Temperature: 0ºC to +50ºC
• Operating Range:2 Indoors: Up to 100m (328 feet),
Outdoors: Up to 280m (919 feet)
Power Consumption:
• Power Adapter: 5V DC
• Transmit: <380 mA
• Receive: <250 mA
• Transmitter Power: 17 dBm at 11b,15dBm at 11g,13dBm at 11n
• Receive Sensitivity: 11Mbps: -80dBm@8% FER
• Modulation Method: BPSK / QPSK / 16-QAM / 64-QAM
Notes:
1 Maximum wireless data rate derived from IEEE standard 802.11b, 802.11g and 802.11n specifications.
Actual throughput will vary. Network conditions and environment factors, including volume of network
traffic, building materials and construction, and network overhead lower actual data throughput rate.
2 Environmental conditions may affect wireless signal range.
