Lochinvar DVL 041 Application guide

DVN03-05
Replacement Parts List
RPL 7029
PARTS & SERVICE DEPARTMENT
Nashville, Tennessee
615-889-8900 • Fax: [phone]
www.Lochinvar.com
Residential Gas
Power-Vented Models
DVN & DVL 041 & 051
After Serial #TL *Before Serial #TK see page 2

Before Serial #TK

3
Please have model number and serial number when ordering parts
DV(N,L)041 DV(N,L)051
1 BLOWER (BEFORE SERIAL #TK) PVT1012 PVT1012
1 BLOWER (AFTER SERIAL #TL) PVT1014 PVT1014
2 BLOWER GASKET (BEFORE SERIAL #TK) GKT1030 GKT1030
2 BLOWER GASKET (AFTER SERIAL #TL) GKT1031 GKT1031
3 PRESSURE SWITCH (BEFORE SERIAL #TK) PRS1007 PRS1007
3 PRESSURE SWITCH (AFTER SERIAL #TL) PRS1011 PRS1011
4 BLOWER WIRE HARNESS (BEFORE SERIAL #TK) WRE1041 WRE1041
4 BLOWER WIRE HARNESS (AFTER SERIAL #TL) WRE1045 WRE1045
5 HI LIMIT (BEFORE SERIAL #TK) HLC1024 HLC1024
5 HI LIMIT (AFTER SERIAL #TL) HLC1026 HLC1026
6 THERMOSTAT TST1121 TST1121
7 IGNITION MODULE (ONLY BEFORE SERIAL #TK) RLY1033 RLY1033
8 GAS VALVE NAT (BEFORE SERIAL #TK) VAL1160 VAL1160
8 GAS VALVE NAT (AFTER SERIAL #TL) VAL1170 VAL1170
8 GAS VALVE LPG (BEFORE SERIAL #TK) VAL1161 VAL1161
8 GAS VALVE LPG (AFTER SERIAL #TL) VAL1171 VAL1171
9 BURNER ASSEMBLY NAT (BEFORE SERIAL # TK) BNR1078 BNR1075
9 BURNER ASSEMBLY NAT (AFTER SERIAL #TL) BNR1210 BNR1211
9 BURNER ASSEMBLY LPG (BEFORE SERIAL #TK) BNR1077 BNR1076
9 BURNER ASSEMBLY LPG (AFTER SERIAL #TL) BNR1220 BNR1221
10 PILOT ASSEMBLY NAT (BEFORE SERIAL #TK) PLT1043 PLT1043
10 PILOT ASSEMBLY NAT (AFTER SERIAL #TL) PLT1217 PLT1217
10 PILOT ASSEMBLY LPG (BEFORE SERIAL #TK) PLT1044 PLT1044
10 PILOT ASSEMBLY LPG (AFTER SERIAL #TL) PLT1210 PLT1210
11 TRANSFORMER (BEFORE SERIAL #TK) TRF1001 TRF1001
11 TRANSFORMER (AFTER SERIAL #TL) TRF1003 TRF1003
12 POWER CORD WRE1040 WRE1040
13 DRAIN VALVE DRV1007 DRV1007
14 T&P RELIEF VALVE RLV1001 RLV1001
15 ANODE, MAGNESIUM WTR1060 WTR1060
15 ANODE, ALUMINUM WTR1044 WTR1044
16 FLUE BAFFLE JKT1052 JKT1052
17 DIP TUBE WTR1063 WTR1063
18 VENT TERMINATION, 2" WITH SCREEN DRH1052 DRH1052
19 OUTER DOOR JKT1049 JKT1049
20 INNER DOOR JKT1109 JKT1109
ITEM NO. DESCRIPTION MODEL NO.

©-8/08-Printed in U.S.A.
