Lode LA4D User manual

Lode Audio Servers
Technical Documentation & Installation Guide

TOC!
LA4$TECHNICAL$OVERVIEW$ 3!
DIMENSIONS$ 3!
POWER$AND$HEAT$ 3!
OUTPUTS$ 3!
LA4D$TECHNICAL$OVERVIEW$ 4!
DIMENSIONS$ 4!
POWER$AND$HEAT$ 4!
OUTPUTS$ 4!
LA1$TECHNICAL$OVERVIEW$ 5!
DIMENSIONS$ 5!
POWER$AND$HEAT$ 5!
OUTPUTS$ 5!
STREAMING$AND$LOCAL$MEDIA$ 6!
SUPPORTED$STREAMING$SERVICES$ 6!
SUPPORTED$FILE$FORMATS$ 6!
CONTROL$SYSTEM$INTEGRATIONS$ 6!
NATIVE$CONTROL$APPLICATIONS$ 6!
INSTALLATION$GUIDE$ 8!
WEB$CONFIGURATION$ 8!
CHANGE$NETWORK$SETTINGS$ 9!
LODENET$PROTOCOL$CONFIGURATION$ 9!
ENABLING$MUSIC$SERVICES$10!
INDEXING$A$NETWORK$SHARE$11!
PLAYER$SETTINGS$12!
AIRPLAY$CONFIGURATION$13!
PORTS$AND$ENCODING$14!
CHARACTER$ENCODING$14!
BROADCAST$DISCOVERY$14!
LODE$MESH$14!
LODENET$STREAMING$14!
PRODUCT$SUPPORT$15!
FACTORY$RESET$15!
REQUESTING$SUPPORT$15!

LA4!Te c h n i c a l ) O ve r v i e w !
Overview
1U rack mount 4 zone analogue output audio server.
Dimensions!
Weight: 5KG
Power&and&Heat!
Power Consumption: 35W
Current: 5amp
BTU/HR: 180(max)
120-230v IEC power supply
Outputs!
1 X Stereo RCA output per zone, 4 in total.

LA4D!Te c h n i c a l ) O ve r v i e w !
Overview
1U rack mount 4 zone analogue and digital output audio server.
Dimensions!
Weight: 4.6 KG
Power&and&Heat!
Power Consumption: 20W
Current: 5amp
BTU/HR: 80(max)
120-230v IEC power supply
Outputs!
1 X Stereo RCA, Optical and Coaxial output per zone.

LA1!Te c h n i c a l ) O ve r v i e w !
Overview
Half U 1 zone analogue output audio server.
Dimensions!
Weight: 1.4 KG
Power&and&Heat!
Power Consumption: 20W
Current: 5amp
BTU/HR: 80(max)
120-230v IEC power supply
Outputs!
1 X Stereo RCA output per zone, 4 in total.

Streaming*and*Local*Media!
Supported)Streaming)Services!
As of the 1st March 2017.
•TIDAL™
•Tunein™ Internet radio
•SoundCloud™
•Deezer™
•Napster™
•Local music library integration - multiple libraries
•iTunes playlists importing
•AirPlay per zone *includes extended functionality
•Spotify™ (Connect coming soon)
Supported)file)formats!
•Playback of MP3, M4P, M4A, Flac, WAV, AAC
Control'System'Integrations!
As of the 1st March 2017. Please check our website for updates to this guide and updated
integration list.
•Crestron - Media Player and Standard Driver
•AMX
•Control4
•RTI
•Command Fusion
•Elan
Native'Control'Applications!
•iOS
•Android
•Windows Desktop
•OSX Desktop

About&LODENET™!
All Lode Servers are powered by LODENET™.
Lode’s proprietary LODENET™ protocol enables synchronised, high-definition & low latency
audio-over-IP playback.
LODENET™ works as an audio matrix over the network, allowing users to group zones for
synchronized playback of content (party mode) and conveniently control volume for the main
and also individual zones, without the need of an external matrix.
Lode can be scaled up to 64 zones on a network without the need for a hardware audio
matrix. Synchonisation of playback is guaranteed; there can be no drift over time.

Installation)Guide!
Lode servers are machined from aluminium, which acts as the heat sink, eliminating noisy
fans and so increasing performance and reliability. This also means that the unit MUST HAVE
airflow both above and beneath for optimum cooling levels. Failure to provide may result in
the unit overheating and degrading performance.
On Boot, Lode severs will perform a number of checks over the internet to configure itself and
check for updates. Please allow a couple of minutes for unit/s to complete checks prior to
playing audio streams otherwise it may result in playback of multiple zones being out of sync.
Checklist
Internet access is required for all units to operate normally, even if only local is used.
Check “system maintenance” section of the web console and apply any pending updates to
the server/s.
Web$Configuration!
All Lode Server settings are configured via the Admin Web Console. To access the web
console, you will need to know the IP address of the Lode unit.
By default the unit ships with DHCP enabled.
Lode units can be discovered on the network using the Lode admin tool downloaded from
http://www.lodeaudio.com.
If you don’t have admin tool installed, you will need to ascertain it’s IP address via the DHCP
sever.
Click on listed sever to access the web console.
Example: http://192.168.10.100 where 192.168.10.100 is the address provided to the Lode
server.
It is recommended that each unit is set-up fully before adding others to the network

Change'Network'Settings!!
To change network settings, simply visit the “Network Settings” section of the web console.
Here you can set the unit’s IP address or confirm it’s configuration for DHCP.
If you are using a control system to control Lode, then you must either statically assign an IP
address to the unit or use IP allocation rules within the DHCP server to ensure that the unit
has a static IP address. This is required, as the set-up of the driver requires pointing the
module at the IP address of the Lode Server.
!
LODENET$Protocol$Configuration!
By default LODENET uses UDP Unicast for synchronizing audio streams, which will support
up to 64 zones on a network. This can be changed to UDP Multicast mode to enable support
for up to 256 zones.
Multicast filtering must be enabled on the VLAN for this to function correctly.
To change the LODENET Protocol, visit the “Network Settings” section of the web console.

System'Boot'Delay!
If this device is connected to switches that take a few minutes to boot in event of power
failure, you can set a boot delay for Lode within the “Network Settings” section of the web
console.
!
Enabling(Music(Services(!
From the ”Media Library” section of the web console, simply select to “enable” or “disable” a
service. If a service requires authentication, you will be asked for the Login and password.
Once successfully registered, the service will appear in controllers.
!

Indexing(a(Network(Share!
To index a local network share, you must first enable the Local Music service from the “Media
Library” area of the web console.
Once the Local Music service has been enabled, you will be presented with a new input area
to add the details of the network share you wish to index.
The Lode server requires an SMB share for mounting. Please ensure that any NAS or
computer share has SMB sharing enabled.
The share only needs read access.
Note. If using a NAS that has a network recycle bin, please ensure that all recycle bin
functionality is turned off as this can cause issues when deleting and adding new media.
To add the share to Lode, give the share a name, path and username / password if required.
Paths should be specified as //IP-ADDRESS/SHARE NAME
Once the share details have been added, click the “Add” button and you should receive a
message telling you that the share is now indexing.
The Lode server will re-index the share every 60 seconds.

Player!Settings!
To change the name of any of the players for the Lode server, visit the “Player Settings”
section of the web console.
Here you can give each player a unique name such as “Living Room’, or ”Kitchen”, for
example.
Within the Player Settings area, you can also choose to enable or disable zones as required.
Fixed Volume Settings
There are 3 volume options in Lode:
•Normal – Variable volume controllable by all apps.
•Fixed – The volume of the Lode zone is fixed (can be combined with volume trim).
The default fixes the volume to 100% and disables the volume control in apps.
•Passthrough – This fixes the Lode zone volume to 100% (can be combined with
volume trim). Only with pass through the volume control is not disabled in Lode apps
and Lode will pass the volume control feedback back to a control system. This option
could be used to control a local AVR volume that Lode is connected to.
Warning: Setting the volume to fixed or passthrough will set the volume at 100% on the Lode
Server. Please make sure that the pre-amp is turned down before changing this setting
Volume Trim
This feature really exists to protect any equipment after Lode in the audio chain. If the Lode
zone volume is trimmed to 60%, volume control within Lode will now be between 0% and
60%.

Airplay(Configuration(!
Lode servers have an Airplay per-zone capability. To set-up Airplay as a selectable source,
please access the “Media Library” section of the web console and enable Airplay.
If you want to have the ability for customers to play Airplay to any room at anytime, please
select the option for “Airplay interrupt” in the “Advanced Settings” section of the web console.
Please note that this option will enable any existing stream to be interrupted by another user.
An Airplay password can also be set for each player in the same section of the web console
by typing a password in each listed player section. Once the password is set, any user would
be prompted for this password via the iOS device before being allowed to play.

Ports&and&Encoding!
Character(Encoding(!
The Lode servers by default uses UTF-8 character encoding within its IP control API. This can
be changed, if required, when using a control system needing additional character support
you can use the following port options for communication:
•6667 UTF-8
•6668 UTF-16
•6669 ASCII
Broadcast)Discovery)!
Lode Desktop, iOS and Android apps use UDP broadcast for device discovery. As such, WiFi
attached devices must be in the same subnet as the Lode servers for discovery to work.
PORT = 44466
GROUP = 239.192.0.202
BROADCAST = 255.255.255.255
Lode%Mesh!
Lode provides it’s own mesh for inter unit communication. The mesh enables unit and zone
discovery between boxes as well as message broking for the API.
The mesh uses a simple multicast message for discovery communication:
GROUP = 224.2.2.3
PORT = 54327
LODENET!Streaming!
By default LODENET distributes audio between units using UDP unicast.
PORT = 41000
The port numbers will increments for each of zone.
LODENET relies on NTP for initial clock sychronisation, Please ensure NTP requests are
allowed out on the network which is UDP over port 123.

Product#Support!
Factory(Reset(!
The Lode server has a reset button located on the rear of the unit. To reset the unit, press and
hold this button for 10 seconds, the unit will then become unresponsive.
Now cycle the power on the unit (turn off the unit for at least 10 seconds before restarting)
and once the unit reboots, you will be back to factory default.
Be aware that resetting the unit will delete all playlists and favourites saved to date, so please
be sure that it really is a reset that you want. Ideally make a note of each of login credentials
BEFORE resetting the unit.
If you are running a cluster of Lode Servers, please follow these steps to reset all units in the
cluster:
1) Press and hold reset button for 10 seconds on each machine.
2) Power-off each machine.
3) Power-on each machine.
Unless this protocol is followed, the cluster could rebuild its data under certain conditions
meaning that no unit is properly reset.
Requesting*Support*!
To raise a support ticket, please e-mail [e-mail], a member of our dedicated
technical team will be in touch directly to assist.
When requesting support, you can also provide us with the logs of the platform. Please first
put the unit into debug mode via the “Diagnostics” area of the Web Console.
Once the unit is debug mode, you should try and re-create any issues you have experienced.
Once the issue has been replicated, you can send Lode the logs from the system by simply
going to the “System Maintenance” area of the web console and clicking the “Create Support
Package” button.
