Logic DM800i User manual

PLEASE READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE OPERATING YOUR UNIT.
DM800i
INSTRUCTION MANUAL
• DVD/MP3/AM/FM/CD Receiver
• Flip Down/Full Detachable Front Panel
• DVD/DVD-R/DVD-RW/SVCD/VCD/MP4/MP3/WMA/
CD-R/CD-RW Compatible
• SD/MMC Card Input
• Front USB/AUX Input
• 3.2 Inch TFT-LCD Display
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
3(1-3) 3(4-6)
1 8 416 5 12 15 2610 117 92
RESET
25
23 17 24
AUX IN
18 19 20 21614 22 13 27
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
6201-DM800i-cover.indd 1 4/7/09 12:03:50 PM

DM800i
MP3-Compatible AM/FM DVD Receiver
INSTRUCTION MANUAL
SPECIFICATIONS
CD/MP3/WMA PLAYER SECTION
Signal to Noise Ratio > 60 dB
Channel Separation > 50 dB (1kHz)
Frequency Response 20Hz - 20 kHz
TUNER (FM)
Frequency range 87.5-107.9 MHz
Sensitivity 2.8 µV
Stereo separation 30 dB
Signal to noise ratio 50 dB
Channel step 200 kHz
TUNER (AM)
Frequency range 530-1710 KHz
Usable Sensitivity 32 dBµV
LINE-OUT
Output 5 V (max.)
Impedance 10k Ohm
GENERAL
Power Supply 12V DC (10.8-15.6V allowable)
Speaker impedance 4 or 8 Ohm
Output power 50W x 4CH
DM800i
MP3-Compatible AM/FM DVD Receiver
17
Introduction:
Congratulations! You have purchased the next generation in Car AM/FM
Multi Media Players. Our engineers have spent years to bring you the best
car stereo players available. This unit features next generation Advanced
“SMART USB” technology and “AUX IN” input to enhance your car audio
experience.
Included with this unit you will nd two iContact cables, IC-110 and IC-120.
IC-110 is used for direct connection of your portable media player such as
iPod* and other digital MP3 Players. IC-120 is used for next generation
MP3/cellular phones.
* iPod is a registered trademark of Apple Computers, Inc.
6201-DM800i-cover.indd 2 4/7/09 12:03:51 PM

1
CONTENTS
Before You Begin 2
Installation 3
Installation in the dashboard 3
Detaching and Attaching the front panel 3
Supporting the Unit 4
Wiring Connection 4-5
Operation 6
Locations of Parts (Main Unit) 66
Locations of Parts (Remote Control) 7
General Operations 8
Listening to Radio 9
Operations Common for CD/MP3/WMA/VCD/DVD/MP4 9-10
Listening to CD/MP3/WMA 10-11
Playing DVD/VIDEO CD/MP4 11-13
Customizing Audio/Video Settings 13
Setting Up the DVD Player 14
Troubleshooting 15
Problem During DVD/VCD Playback 16
Specications 17

2
BEFORE YOU BEGIN
PRECAUTIONS:
CAUTION:
USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE
HAZARD.
• Keep this manual handy as a reference for operating procedures and precautions.
• Always keep the volume low enough so you can hear sounds outside of the car.
• Protect this product from moisture.
• If the battery is disconnected or discharged, the preset memory will be erased and must be
reprogrammed.
FEATURES:
DVD video playback
This unit plays DVD video, DVD+-R, DVD+-RW and DVD+-DL.
Video CDs featuring PBC compatibility
This unit plays Video CDs featuring PBC (Playback Control).
CD playback
This unit plays Music CD/CD-R/CD-RW.
MP3/WMA le playback
This unit plays MP3/WMA les recorded on CD-ROM/CD-R/CD-RW.
MP4 le playback
This unit plays MP4 les.
PAL/NTSC compatibility
This unit is PAL/NTSC system compatible. When connecting other components to this unit,
be sure components are compatible with the same video system or else images will not be
correctly reproduced.
Multi-audio
You can switch between multiple audio systems recorded on a DVD as desired.
Multi-subtitle
You can switch between multiple subtitle languages recorded on a DVD as desired.
Multi-angle
You can switch between multiple viewing angles of a scene recorded on a DVD as desired.
When an operation is prohibited
When you are watching a DVD and attempt to perform an operation that is not permitted by the
programming on the disc a message appears on the screen.

3
INSTALLATION
PRECAUTIONS
• Choose the mounting location carefully so that the unit will not interfere with normal driving
functions.
• Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight
or hot air from the heater, or where it would be subject to dust, dirt or excessive vibration.
• Use only the supplied mounting hardware for a safe and secure installation.
• Be sure to remove the front panel before installing the unit.
NOTE: Inclination angle for car radio installation must not exceed 30˚ otherwise the front panel will
not open.
NOTE: Keep the release key in a safe place as you may need it in future to remove the unit from
the car.
Detaching and attaching the front panel
The front panel of this unit can be detached to prevent theft.
FOLDING DOWN AND DETACHING/ATTACHING THE FRONT PANEL
Before detaching the front panel, be sure to press the button (1) OFF rst.
Then press the button and detach the panel by pulling it towards you as illustrated.
Notes:
• Do not press the front panel hard against the unit when attaching it. It can be easily attached by
pressing it lightly against the unit.
• When you carry the front panel with you, put it in the supplied front panel case.
• Do not press hard or give excessive pressure to the display window of the front panel when
attaching it to the unit.
CLEANING THE CONNECTOR
The unit may not function properly if the connectors between
the unit and the front panel are contaminated with dirt. In
order to prevent this from happening, detach the front panel
by pressing the button and clean the connectors from
time to time.
Clean the connectors with a cotton swab and contact cleaner
as illustrated. Clean each pin carefully and make sure not to
damage the connecting points.
2
182mm
53mm
34
TAP
1
2
3
Bend these
claws, if necessary
Release screw and
bracket
1
2
1
Cotton Swab
Rear of
front panel
Main unit

4
INSTALLATION & WIRING CONNECTION
To rear camera video out
To reverse gear control switch
To Hand brake switch
ANTENNA
CONNECTOR
FRONT
REAR
AUDIO OUT CAMERA IN VIDEO IN
VIDEO OUT 1
VIDEO OUT 2
R
L
L R
L R
ISO CONNECTOR
B
A
1
2
3
4
5
6
7
8
4
5 7
8
REAR
O
UT CAMERA IN VIDEO IN
R
L
L R
10
7
1
2
3
4
4
4
5
5
6
6
8
9
1. UNIT
2. RELEASE CASE
3. DASH BOARD
4. HEX NUT
5. LOCK WASHER
6. PLAIN WASHER
7. CAR BODY
8. REAR SUPPORT STRAP
9. TAPPING SCREW
10. M5 X 15 HEX BOLT
Dashboard
WIRING CONNECTION
IN / OUT CONNECTOR
DVD Audio Out (GRAY) Rear : White (L) Red (R)
Connect this wire to rear seat A/V monitor system
Audio Out (Front): White (L) Red (R)
Audio Out (Rear): White (L) Red (R)
Subwoofer Output : Orange
CONTROL WIRE
Parking (Gray) : Connect this wire to the hand brake system
Tel mute (Black) :
This unit is equipped with a wire that will mute the audio output when a signal is received from a
cellular phone equipped with a muting output. When a cellular call is received, a signal sent from the
phone to the Tel Mute wire causes the unit to mute the audio output. When the call is over the audio
level is automatically restored. To use this feature, you must have a cellular phone handsfree kit with
a muting output that can be connected to the Tel Mute control wire.
• Please see the installation instructions for the cellular telephone to identify the correct connection
for the TEL MUTE wire.
Rear camera (Red) : Connect to back rear camera
In order to activate REAR camera, this wire should to be connected to high voltage (5V or 12V).
TO SUPPORT THE UNIT
2 Video Out: Yellow
Connect to external A/V system to display
Video In: Yellow
Connect to external Video equipment
Rear camera In: Blue
Connect to rear camera output
Steps:
1. Connect the gray wire to the hand brake system.
2. Check your hand brake switch and make sure it
is connected to car body chassis and properly
grounded.
DRIVING WITHOUT VIDEO DISPLAY
For localities where video display is prohibited while the vehicle is in motion, follow the instructions
below.
Note: Always follow your country’s laws regarding driving with video.

5
WIRING CONNECTION
To rear camera video out
To reverse gear control switch
To Hand brake switch
ANTENNA
CONNECTOR
FRONT
REAR
AUDIO OUT CAMERA IN VIDEO IN
VIDEO OUT 1
VIDEO OUT 2
R
L
L R
L R
ISO CONNECTOR
B
A
1
2
3
4
5
6
7
8
4
5 7
8
REAR
O
UT CAMERA IN VIDEO IN
R
L
L R
To rear camera video out
To reverse gear control switch
To Hand brake switch
ANTENNA
CONNECTOR
FRONT
REAR
AUDIO OUT CAMERA IN VIDEO IN
VIDEO OUT 1
VIDEO OUT 2
R
L
L R
L R
ISO CONNECTOR
B
A
1
2
3
4
5
6
7
8
4
5 7
8
REAR
O
UT CAMERA IN VIDEO IN
R
L
L R
CONNECTOR A
4. MEMORY +12V
5. AUTO ANTENNA OUTPUT
7. +12V (TO IGNITION KEY)
8. GROUND
NOTE: (connector A no. 7) must be connected by car ignition
key in order to avoid that car battery becomes weak when the
car will be not used for long period.
CONNECTOR B
1. REAR RIGHT SPEAKER (+)
2. REAR RIGHT SPEAKER (-)
3. FRONT RIGHT SPEAKER (+)
4. FRONT RIGHT SPEAKER (-)
5. FRONT LEFT SPEAKER (+)
6. FRONT LEFT SPEAKER (-)
7. REAR LEFT SPEAKER (+)
8. REAR LEFT SPEAKER (-)
Maintenance
FUSE REPLACEMENT
If the fuse blows, check the power connection and replace the fuse. If the fuse blows again after the
replacement, there may be an internal malfunction. In this case, consult your nearest repair center.
Warning
Use the specied amperage fuse for each lead. Use of a higher amperage fuse may cause serious damage.
B1 3 5 7
2 4 6 8
5 7
4 8
A
DRIVING WITH VIDEO DISPLAY
Follow the instructions below so video will display even when the vehicle is in motion.
Note: Always follow local laws regarding driving with video.
INSTALLING REAR CAMERA FOR REVERSE MOTION
Follow the instructions below to have the unit automatically switch to a read camera (not included) to
guide the driver when parking or moving in reverse.
Steps: Connect the GRAY wire to the WHITE wire.
Steps:
1. Connect the Rear Camera IN plug to the rear camera’s
video out plug.
2. Connect the RED wire to “REVERSE” gear control switch.
3. Check your gear control switch and make sure it is
connected to +12V.

6
OPERATION
LOCATIONS OF PARTS (MAIN UNIT)
1. POWER ON/OFF ( )
2. SELECT FUNCTION BUTTON
3. PRESET STATIONS (1,2,3,4,5,6)
4. EQUALIZER CONTROL (EQ)
5. DISPLAY BUTTON (DISP)
6. STEREO/MONO BUTTON (ST)
7. LOUDNESS BUTTON (LD)
8. MODE BUTTON (MODE)
9. BAND BUTTON (BD)
10. CD TRACK / SEARCH BUTTON
11. AUTO SEEK TUNING
12. MUTE BUTTON (MUT)
13. ‘SCAN’ AUTOMATIC TUNING CONTROL (SCN)
14. AUTO SEEK SEARCH TUNING (A/PS)
15. PANEL RELEASE BUTTON ( )
16. TFT-LCD DISPLAY
17. CD EJECT BUTTON ( )
18. PLAY/PAUSE BUTTON
19. INTRO BUTTON
20. REPEAT BUTTON
21. RANDOM BUTTON
22. 10 TRACK SEARCH DOWN/UP
23. RESET BUTTON
24. CD SLOT
25. SD/MMC CARD SLOT
26. USB PORT
27. FRONT AUX IN
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
3(1-3) 3(4-6)
1 8 416 5 12 15 2610 117 92
RESET
25
23 17 24
AUX IN
18 19 20 21614 22 13 27
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
3(1-3) 3(4-6)
1 8 416 5 12 15 2610 117 92
RESET
25
23 17 24
AUX IN
18 19 20 21614 22 13 27
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
3(1-3) 3(4-6)
1 8 416 5 12 15 2610 117 92
RESET
25
23 17 24
AUX IN
18 19 20 21614 22 13 27
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact
3(1-3) 3(4-6)
1 8 416 5 12 15 2610 117 92
RESET
25
23 17 24
AUX IN
18 19 20 21614 22 13 27
EQ
DISP
ST
3.2 inch
DVD/MPEG4/SVCD/VCD/CD/MP3/CD-R/CD-RW PLAYBACK DM800i
50
iContact

7
Use and care of the remote control
Installing the battery
Slide the tray out on the back of the remote control and insert the battery with
the (+) and minus (-) poles pointing in the proper direction.
• On rst use, pull out the lm protruding from the tray.
CAUTIONS
• Remove the battery if the remote control is not used for a month or longer.
• Do not recharge, disassemble, heat or dispose the battery on re.
• Do not store the battery with metallic materials.
• In the event of battery leakage, wipe the remote control completely clean and install a new
battery.
• When disposing of used batteries, please comply with government regulations or environmental
public institution’s rule that apply in your country/area.
• Always check carefully that you are loading the battery with plus (+) and minus (-) poles facing the
proper directions.
Using the remote control
Point the remote control in the direction of the front panel to operate.
IMPORTANT
• Do not store the remote control in high temperatures or direct sunlight.
• Do not let the remote control fall onto the oor, where it may become jammed under the brake or
accelerator pedal.
OPERATION
LOCATIONS OF PARTS (REMOTE CONTROL)
1. POWER ON/OFF
2. MODE
3. PLAY/PAUSE
4. TITLE
5. SELECT
6. SEEK+/SEEK- / CD TRACK/SEARCH
7. VOL +/VOL-
8. GOTO
9. AUDIO
10. ENTER
11. NAVIGATION
12. AUTO SEEK / PRESET SCAN / REPEAT
13. RANDOM / BAND / LOUDNESS
14. DUAL
15. INTRO / PROGRAM
16. SUBTITLE
17. SETUP
18. EQUALIZER / ANGLE
19. SLOW MOTION
20. ZOOM / A-B REPEAT
21. STEREO/MONO / STOP
22. CLOCK / ON SCREEN DISPLAY
23. MUTE
24. MAIN MENU / PLAYBACK CONTROL
25. STEP (FRAME BY FRAME PLAYBACK)
26. PAL / NTSC SYSTEM
27. 10 TRACK SEARCH DOWN/UP
28. TWO DIGIT TRACKS SEARCHS
29. KEYPAD
MODE
Goto Dual
Sub-T
EQ
Angle
Audio
Slow
CLK
OSD SEL INT
Prog
VOL- VOL+
SEEK-
Setup PBC
Menu
Step Title
SEEK+
ST
Stop
RPT
APS
RDM
BD/LD
A-B
Zoom
1 2
3 4
P/N
5
-10
6
+10
7
10+
8 9 0
ENTER
1
8 14 2517 4
24
2 3 23
VOL+/-
10
1118
16
9
19
22
13
28
5
20
26
21
12
15
29
27
7
6

8
OPERATION
GENERAL OPERATIONS
Turning the unit ON/OFF ( )
Press “ ” button to turn on unit. To turn off, press and hold the button again.
Selecting a source (MODE)
Press MODE repeatedly to switch between TUNER, CD/DVD, AUX IN, USB or SD/MMC mode.
Loading a Disc
1. Press to open the front panel
2. Insert a disc into the disc loading slot
Ejecting a Disc
Press button to eject disc
Adjusting Volume
• Head Unit: Rotate VOL knob right or left to increase or decrease volume.
• Remote Control: Press VOL+ or VOL- to increase or decrease volume.
Mute Button
• Head Unit: Press MUT button to mute the sound at once. Press again to return to previous volume
level.
• Remote Control: Press button.
Loud Button (LD)
Press and hold LD button to turn on/off LOUD feature.
Equalizer (EQ)
Press EQ to select between Flat – Class – Rock – Pop -- EQ– Class – Rock – Pop -- EQClass – Rock – Pop -- EQ– Rock – Pop -- EQRock – Pop -- EQ– Pop -- EQPop -- EQ equalizer modes.
CLOCK
1. Press and hold CLK button on remote control. Hour starts blinking.
2. Rotate VOL knob to set hour. Press CLK knob, minutes starts blinking.
3. Rotate VOL knob to set minutes. Press VOL knob to save.
DUAL SETTINGS
DUAL is a feature that lets user control the external AV device and the head unit. For example, driver can
listen to radio while the passenger at the back can watch DVD. This unit supports connection of external AV
device such as portable TV through the AUDIO OUT and VIDEO OUT port.
Controlling TUNER Controlling DISC
1. Connect the AUDIO OUT and VIDEO OUT port at the back of head unit to the LINE IN of external AV
device.
2. Press and hold MODE. DISC will display on top of screen.
3. Press DUAL key on remote control to select which mode you want to control.
T = TUNER, D = DISC
4. Refer to Radio and DVD sections on how to operate other features applicable to each mode.
Note: You will need to connect an external portable TV or monitor when using this feature.
When DUAL mode set to control DISC(D), volume control on head unit has no function. You can
control volume through the portable display device.
