LOGICOM H.264 OnVif User manual

User Manual
H.264 OnVif IP Camera

1
Contents
Overview......................................................................................................................................................2
Safety Instructions.....................................................................................................................................3
Application Fields ......................................................................................................................................4
Product Features.......................................................................................................................................4
Device Installation and Connection.........................................................................................................5
Appearance Description............................................................................................................................5
Device Connection ....................................................................................................................................7
Device Search Tool..................................................................................................................................10
ActiveX Control Setup..............................................................................................................................14
Webpage Configuration of IP Camera..................................................................................................15
Live ..........................................................................................................................................................15
Parameter Setting ...................................................................................................................................17
Display .....................................................................................................................................................17
Network..............................................................................................................................................20
Alarm ..................................................................................................................................................28
Device.................................................................................................................................................30
System ...............................................................................................................................................31
Date/Time ..........................................................................................................................................32
Advanced...........................................................................................................................................34
Technical Parameters..............................................................................................................................38
Appendix 1Router Port Forwarding .......................................................................................................39
Appendix 2FAQ.........................................................................................................................................40

2
Overview
Thank you for using our IP camera product series, which are integrative products developed for
the network video surveillance. On the basis of the newest solutions of Hisilicon, the product series
develop a media processing platform by integrating the capture, compression and network
transmission of audio and video on one board.With standard H.264 encoding algorithm, the products
ensure clearer and smoother video transmission. The remote users may implement real-time
monitoring by inputting the IP address or domain name of IP Camera on web browser.
The products can be applied for small- and medium-sized enterprises, government projects,
large-scale shopping malls, chain supermarkets, intelligent buildings, hotels, hospitals, schools, and
any other places requiring remote network transmission and monitoring. The productsare easy to be
installed and operated.
Before installation, please check if your product accessories are complete. If some parts are lost,
please contact us immediately.
Note：
IP Camera refers to Internet Protocol Camera.
Single click：Click with the left mouse button.
Double click: Click twice with the left mouse button.
Default IP address of IP Camera：192.168.1.168
IP Camera default Username：admin（lower case）, Password：admin（lower case）
Default web port：80，Default media port：9988
Statement：
The contents in the manual may be different from your current version. If you encounter any unsolved
problem during operation, please contact our technical support department or product supplier. The
manual will be updated irregularly without prior notice.

3
Safety Instructions
To correctly use the product and avoid danger or property loss, please carefully read this manual
before operation and keep properly for later reference.
Use suitable power supply (attached or specified by the manufacturer). Do not use
unspecified power supply.
If the device is malfunctioned, please contact authorized dealer or service center. Do not
disassemble or fix the device without permission (any problems caused by unauthorized
change or repair are at your own risk).
Never let the device exposed in the rain or humid environment. Do not put the product in
a humid place. If water accidentally intrudes into the device, please unplug the power
supply and contact the local dealer immediately.
Do not put the device in a dusty place.
Before operating IP camera, please check the power supply.
Do not touch the optical components of image sensor. If necessary, use clean cloth and
alcohol to wipe away the dust. If IP camera is not in use, put on the dust-proof cover to
protect the image sensor.
During operation, avoid water or any kind of liquid to flow into the camera.
Do not focus against the strong light, such as lamplight or sunlight. Otherwise it will
cause excessive brightness and influence the service life of image sensor.
Check the service environment and make sure that the device is used in normal working
environment.
Improper replacement of batteries may cause malfunction of the product and accessories. It
is recommended for the users to change the batteries. If necessary, change with the same or
equivalent type of batteries.

4
Application Fields
IP camera is usually applied in large-scale shopping malls, supermarkets, schools, plants,
workshops, and other public places. As it has strong image processing capacity, IP camera can also
be used in the environment requiring high definition of image, such as bank and traffic intersection.
Refer to the following picture.
Product Features
Hisilicon media processor with high performance and strong functions.
Non-interlaced CMOS sensor
Optimized H.264 video compression algorithms; Multi-stream transmission ensures high
definition image transmission on both narrowband and wideband.
Support simultaneous connection of up to 5 video streaming.
With Build-in Web Server, user may use standard IE browser to conduct real-time monitoring,
setting and management on the site.
Support remote system upgrade.
Support LAN and Internet.
Support ONVIF protocol and GB28181 protocol.
Support multiple network protocols, such as
TCP/UDP,IP,HTTP,DHCP,RTP,RTSP,FTP,SMTP,DNS,DDNS,NTP,ICMP,IGMP,ARP
Support motion detection alarming function (user may set area and sensitivity)
Support block alarm.
Support privacy zone function.
POE power supply function（optical）
Support snapshot. Upload images by FTP or E-mail.
Support automatic recovery function. It can be automatically connected in case of network
interruption.
Note：The specifications of different products may be slightly varied.
Monitoring Center

5
Device Installation and Connection
Appearance Description
Model: EZ-IP7136IR
Items Descriptions
①Front cover It can prevent the IP camera from the irradiation of the sunlight.
②Rear cover It is fixed with the front cover.
③Set screw Fix the front cover and rear cover.
④Lens Lens of camera
⑤Infrared lamp Infrared LED lamp
⑥Ball and ball sleeve It is rotatable and used to adjust the angle of installation.
⑦Locknut Fix the ball sleeve and the base.
⑧Base Fix the device at the installation location.
⑨Fixing hole Fix with screws at the installation location.

6
Model: EZ-IP722812IR
Items Descriptions
①Front cover It can prevent the IP camera from the irradiation of the sunlight.
②Rear cover It is fixed with the front cover.
③Focusing lever Adjust the focal length of the camera.
④Lens Lens of camera
⑤Infrared lamp Infrared LED lamp
⑥Ball and ball sleeve It is rotatable and used to adjust the angle of installation.
⑦Locknut Fix the ball sleeve and the base.
⑧Base Fix the device at the installation location.
⑨Fixing hole Fix with screws at the installation location.

7
Model: EZ-IP642812IR
Items Descriptions
①Transparent cover Protect the hemisphere
②Infrared lamp Infrared LED lamp
③Lens Lens of camera
④Black inner cover Fix the hemisphere
⑤Adapter disc Connect tailing line and fix adjustment bracket
①
②
③
④
⑤

8
Model: EZ-IP6236IR
Items Descriptions
①Lens Lens of camera
②Infrared lamp Infrared LED lamp
③Hemisphere It is rotatable and used to adjust the installation angle
④Fixed guard Fix the position of the hemisphere.
⑤Base Fix the device at the installation location.
⑥Fixing hole Fix with screws at the installation location.
①
②
③
④
⑤
⑥

9
Device Connection
There are two types of connection：
1. Connect the device with PC
Connect IP camera with PC by network cable. The supply hub of IP camera is connected with
DC 12V power supply. Set the IP of PC and that of IP camera in the same network segment. If the
network is normal, wait for 1 minute after power on and IP camera will establish communictaion
with PC.
2. Connect the device with router or switchboard.
It the most commonly used way to connect IP camera to the Internet. Connect IP camera and PC to
Lan Port on the router or switchboard and set the gateway of IP camera as that of the router.

10
Device Search Tool
The software can detect the IP address of IP camera in the LAN.
Firstly, install .exe file (Device Search) in the included CD by the following procedures.：
1. Double click the .exe file
2. Click [Next] to continue.
3. Select installation folder and click [Next] to continue.

11
4. Click [Install] to begin the installation.

12
5. Click [Finish] to finish the installation.
Run the installed Device Search.exe software.
Click to run the software and it will automatically display the IP address, subnet
mask, gateway, port, version information and MAC address of the running IP camera in the current
LAN, as shown in the following picture：

13
If the searched IP address and PC IP address are not in the same network segment, user may
modify IP address, subnet mask, port number and other parameters of IP camera by using Device
Search software.
In the DeviceSearch software, select a device to modify IP address and then input new IP
address, subnet mask, gateway, port number and administrator password(default: admin). Click
【Modify】to change IP address of the device, as shown in the following picture：
Note：Default IP of IP camera is “192.168.1.168”, username is “admin”, password is “admin” , and

14
media port number is “9988”.
ActiveX Control Setup
If the user visits IP camera with Internet Explorer for the first time, he has to install the plug-ins.
For installing the plug-ins, it is necessary to set the browser security level. Enter menu
[Tools/Internet Options/Security/Custom Level] and change “ActiveX controls and plug-ins” as
“Enable” or “Prompt”, as shown in the following picture. For safety, after you view the image of IP
camera, please reset the security setting in IE browser to default level.
Installation method of plug-in：
Input IP address of IP camera in IE address bar to visit IP camera. The controls will be
automatically loaded on IP camera.：
The plug-in installation dialogue box will be popped up. Click “Install” and the installation will be
completed automatically.

15
Webpage Configuration of IP Camera
Live
Open Internet Explorer and input IP address of IP camera（http://192．168．1．168）. The login
dialog box will appear. See the following picture：
User may select stream types and fluent level in the login interface.
Input user name(default: admin) and password (default: admin) and click “Login” to enter the Live
interface, as shown in the following picture.

16
Other buttons on the Live interface：
：Enter the device setting menu and set customized parameters of the device；
：Snapshot, file type, storage path, etc.；
：Log out and return to the login interface；
：It shows preview control buttons. From the left to the right, the
names of buttons are play, stop, full screen, snapshot, start/stop recording, enable/disable talkback.
：Enable/disable sound; Open/close video setting.
Click “Local Setting” to pop up the following dialog box：
User may set Record Path, Download Path, Snapshot Path, File Type and Interval for manual
recording.

17
Parameter Setting
Display
Live
Click ，and enter the following interface（Live interface by default）：
Channel Name:Name of IP camera
Channel Display:Enable or disable. It may customize the display location.
Time Display：Enable or disable. It may customize the display location.
Flicker Control：50HZ, 60HZ or disable
Transparency：Set the transparency of OSD background color.

18
Image Control
Click【Display】→【Image Control】to enter the following interface.：
IRCUT Mode：4 modes: GPIOAuto, VideoAuto, Color Mode and Black & White Mode.
IR-CUT Delay：Set IRcut delay switching time
Image flip：Lens flip and angle flip
Back light：Enable or disable the Back light. When enabled, there are three levels: low, middle and
high.
Back light compensation can compensate the darkness of the subject caused by shooting against the
sunlight. In some application scenario, the field of view may contain a very bright background field,
such as the door and window against the light, while the observed subject is surrounded by the bright
field. In this case, the photo is gloomy and has no layering. The backlight compensation can be
applied to solve the problem.
3D Noise Reduction：Enable (auto or manual) or disable the video noise reduction function. Default
setting is Auto.
WDR：Enable or disable WDR function.
WDR is a technology that enables the camera to catch the image features with strong contrast.
In short, DR (dynamic range) is the details of the bright part and dark part of image. The larger
dynamic range shows richer layers and broader color space.

19
AGC：Adjust the level of AGC(low, middle and high)
White Balance：Auto, manual and indoor
Auto﹕Optimize according to the current lighting conditions and screen mode and calibrate
the video color of the camera.
Manual﹕Manually adjust red and blue gain of camera video
Indoor﹕Optimize according to the indoor environment and automatically calibrate the video
color of camera.
Shutter：It has auto mode and manual mode. Default mode is Auto.
Time exposure：Adjust exposure level of camera.
Privacy Zone
Click 【Display】→ 【Privacy Zone】to enter the following interface：
Set privacy zone:
1. Click to enable privacy zone.
2. Press and drag left mouse button to select privacy zone (4 zones at maximum).
3. Click Save to make the privacy zone effective.
