Logik LCHOBTC16 User manual

Ceramic Hob
Instruction / Installation Manual
LCHOBTC16
LCHOBTC16_IB_RC_Final211019.indd 1LCHOBTC16_IB_RC_Final211019.indd 1 19/10/2021 4:28 PM19/10/2021 4:28 PM

LCHOBTC16_IB_RC_Final211019.indd 2LCHOBTC16_IB_RC_Final211019.indd 2 19/10/2021 4:28 PM19/10/2021 4:28 PM

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
Top View.......................................................................................................................................................................8
Control Panel..............................................................................................................................................................8
Before Using Your New Ceramic Hob .......................................................................................... 9
Choosing the Right Cookware..................................................................................................... 9
Using the Touch Controls ........................................................................................................... 10
Using Your Ceramic Hob............................................................................................................. 10
To Start Cooking ....................................................................................................................................................10
When You Have Finished Cooking ..................................................................................................................11
Locking the Controls............................................................................................................................................ 11
- To Lock the Controls..................................................................................................................................11
- To Unlock the Controls ............................................................................................................................. 11
Over-Temperature Protection ...........................................................................................................................12
Residual Heat Warning ........................................................................................................................................12
Auto Shutdown......................................................................................................................................................12
Using the Timer........................................................................................................................... 12
Timer Overview...................................................................................................................................................... 12
Using the Timer as a Minute Minder............................................................................................................... 12
Setting the Timer to Turn Cooking Zones O .............................................................................................13
Cooking Guidelines .................................................................................................................... 15
Cooking Tips............................................................................................................................................................ 15
- Simmering, Cooking Rice ........................................................................................................................15
- Searing Steak ...............................................................................................................................................15
- For Stir-Frying ..............................................................................................................................................15
Heat Settings........................................................................................................................................................... 16
Cleaning and Maintenance........................................................................................................ 17
Hints and Tips ............................................................................................................................. 18
Specication ............................................................................................................................... 18
Product Fiche .............................................................................................................................. 19
Installation .................................................................................................................................. 20
Preparing the Worktop........................................................................................................................................ 20
Ensuring Adequate Ventilation ........................................................................................................................20
Fastening the Fixing Brackets ...........................................................................................................................21
Connecting the Hob to the Mains Power Supply ...................................................................................... 22
LCHOBTC16_IB_RC_Final211019.indd 3LCHOBTC16_IB_RC_Final211019.indd 3 19/10/2021 4:28 PM19/10/2021 4:28 PM

4
Safety Warnings
Your safety is important to us.
Please read this information before
using your ceramic hob.
Installation
Electrical Shock Hazard
• Disconnect the appliance from
the mains electricity supply
before carrying out any
work or maintenance on it.
• Connection to a good earth
wiring system is essential and
mandatory.
• Alterations to the domestic
wiring system must only be
made by a qualied electrician.
• Failure to follow this advice may
result in electrical shock or death.
Important safety instructions
• Read these instructions carefully
before installing or using this
appliance.
• No combustible material or
products should be placed on
this appliance at any time.
• Please make this information
available to the person
responsible for installing the
appliance as it could reduce your
installation costs.
• In order to avoid a hazard, this
appliance must be installed
according to these instructions
for installation.
• This appliance must be installed
and earthed only by a suitably
qualied person.
• This appliance should be
connected to a circuit which
incorporates an isolating switch
providing full disconnection from
the mains power supply.
• Failure to install the appliance
correctly could invalidate any
warranty or liability claims.
Operation and Maintenance
Electrical Shock Hazard
• WARNING: Do not cook on
a broken or cracked ceramic
hob. If the ceramic hob surface
should break or crack, switch
the appliance o immediately
at the mains power supply (wall
switch) and contact a qualied
technician.
• Switch the ceramic hob o at
the socket before cleaning or
maintenance.
• Failure to follow this advice may
result in electrical shock or death.
Health Hazard
• This appliance complies
with electromagnetic safety
standards.
• Failure to follow this advice may
result in death.
LCHOBTC16_IB_RC_Final211019.indd 4LCHOBTC16_IB_RC_Final211019.indd 4 19/10/2021 4:28 PM19/10/2021 4:28 PM

5
Hot Surface Hazard
• WARNING: During use,
accessible parts of this appliance
will become hot enough to cause
burns.
• Do not let your body, clothing
or any item other than suitable
cookware contact the ceramic
glass until the surface is cool.
• Never leave metal objects (such
as kitchen utensils) or empty
pans on the ceramic hob as they
can become hot very quickly.
• Keep children away.
• Handles of saucepans may be
hot to touch. Check saucepan
handles do not overhang other
cooking zones that are on. Keep
handles out of the reach of
children.
• Failure to follow this advice could
result in burns and scalds.
Cut Hazard
• The razor-sharp blade of a
ceramic hob scraper is exposed
when the safety cover is
retracted. Use with extreme care
and always store safely and out
of reach of children.
• Failure to use caution could result
in injury or cuts.
Important safety instructions
• WARNING: Never leave the
appliance unattended when in
use. Boilover causes smoking and
greasy spillovers that may ignite.
• Never try to extinguish re with
water. Switch o the appliance
and cover the ame with a lid or
re blanket.
• WARNING: Danger of re. Never
use your appliance as a work or
storage surface.
• After use, always turn o the
cooking zones and the ceramic
hob as described in this manual
(i.e. by using the touch controls).
• Do not allow children to play
with the appliance or sit, stand,
or climb on it.
• Do not store items of interest to
children in cabinets above the
appliance. Children climbing
on the ceramic hob could be
seriously injured.
• Do not leave children alone or
unattended in the area where the
appliance is in use.
• Do not repair or replace any
part of the appliance unless
specically recommended in
the manual. All other servicing
should be done by a qualied
technician.
• Do not use a steam cleaner to
clean your ceramic hob.
• Do not place or drop heavy
objects on your ceramic hob.
LCHOBTC16_IB_RC_Final211019.indd 5LCHOBTC16_IB_RC_Final211019.indd 5 19/10/2021 4:28 PM19/10/2021 4:28 PM

6
• The hob must not be used to
warm the room, the heating
zones must only be switched
on after a pot or pan is placed
on top and switched o before
removing the pot or pan.
• Do not stand on your ceramic
hob.
• Do not use pans with jagged
edges or drag pans across the
ceramic glass surface as this can
scratch the glass.
• Do not use scourers or any other
harsh abrasive cleaning agents to
clean your ceramic hob, as these
can scratch the ceramic glass.
• If the mains cable is damaged, it
must be replaced by a qualied
technician.
• Do not operate your ceramic hob
by means of an external timer or
separate remote-control system.
• This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand
the hazards involved. Children
shall not play with the appliance.
Cleaning and user maintenance
shall not be made by children
without supervision.
• Children less than 8 years of
age shall be kept away unless
continuously supervised.
• Do not use a mains plug adapter,
extension cable or external timer.
It may overheat and cause a re.
LCHOBTC16_IB_RC_Final211019.indd 6LCHOBTC16_IB_RC_Final211019.indd 6 19/10/2021 4:28 PM19/10/2021 4:28 PM

7
Thank you for purchasing your new Ceramic Hob.
We recommend that you spend some time to read this manual in order to fully understand how
to install and operate it correctly.
Read all the safety warnigs carefully before use and keep this manual for future reference.
Main Unit
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Brackets × 4 GB818 / M4*10-PFH Screw × 4
for securing the bracket
Instruction / Installation
Manual
Instruction
Manual
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
LCHOBTC16_IB_RC_Final211019.indd 7LCHOBTC16_IB_RC_Final211019.indd 7 19/10/2021 4:28 PM19/10/2021 4:28 PM

8
Product Overview
Top View
1. Max. 1200 W Zone
2. Max. 1800 W Zone
3. Max. 1200 W Zone
4. Max. 1800 W Zone
5. Glass Plate
6. ON / OFF
7. Control Panel
Control Panel
1. On/Off Control
2. Power Regulating Controls
3. Keylock Control
4. Timer
6
3
7
5
4
1
2
3 12
4
LCHOBTC16_IB_RC_Final211019.indd 8LCHOBTC16_IB_RC_Final211019.indd 8 19/10/2021 4:28 PM19/10/2021 4:28 PM

9
Before Using Your New Ceramic Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your ceramic hob.
Choosing the Right Cookware
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking
zone. Always centre your pan on the cooking zone.
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
• Occasionally the heated areas may be seen to switch on and off when higher heat settings are
used. This is due to a safety device, which prevents the glass from overheating. Some switching on
and off when cooking at high temperatures, e.g. deep fat frying is quite normal, causes no damage
to the hob and little delay in cooking times. Excessive switching may however be caused by the
use of an unsuitable saucepan or a saucepan which is smaller than the heated area. If excessive
switching occurs, discontinue the use of the saucepan.
• To improve performance, and reduce energy, always use pans with close fitting lids.
LCHOBTC16_IB_RC_Final211019.indd 9LCHOBTC16_IB_RC_Final211019.indd 9 19/10/2021 4:28 PM19/10/2021 4:28 PM

10
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger.
• You will hear an audible tone each time a touch is registered.
• Make sure the controls are always clean, dry, and that there is no object (e.g. an utensil or a cloth) covering
them. Even a thin film of water may make the controls difficult to operate.
3. Select a heat setting by touching the or controls.
The unit will start from setting 5.
If you don’t choose a heat setting within 1 minute, the
ceramic hob will automatically switch back to standby
mode. You will need to start again at step 1.
You can modify the heat setting at any time during cooking.
Using Your Ceramic Hob
To Start Cooking
1. Touch the ON/OFF control.
After turning on, you will hear an available tone. All the
indicators light up then go out, indicating that the ceramic
hob has entered standby mode.
2. Place a suitable pan on the cooking zone that you wish to
use.
Make sure the bottom of the pan and the surface of the
cooking zone are clean and dry.
Do not place hot pans over the control panel
as this may cause damage.
LCHOBTC16_IB_RC_Final211019.indd 10LCHOBTC16_IB_RC_Final211019.indd 10 19/10/2021 4:28 PM19/10/2021 4:28 PM

11
2. Beware of hot surfaces
will display to show which cooking zone is hot to touch. It will
disappear when the surface has cooled down to a safe temperature.
It can also be used as an energy saving function if you want to heat
further pans, use the hotplate that is still hot.
Locking the Controls
• You can lock the controls to prevent unintended use (for example children accidentally turning the cooking
zones on).
• When the controls are locked, all the controls are disabled, but you can still turn off the unit.
To Lock the Controls
Touch the keylock control. The timer indicator will show “ “
To Unlock the Controls
Touch and hold the keylock control for a while.
Or, turn the whole cooktop off by touching the ON/OFF control.
When You Have Finished Cooking
1. Turn the cooking zone off by scrolling down to – or touching and controls together. Make sure
the display shows – .
OR
Do not lock the controls while a cooking zone is in use. In an emergency, you can always turn the
ceramic hob off with the ON/OFF control.
LCHOBTC16_IB_RC_Final211019.indd 11LCHOBTC16_IB_RC_Final211019.indd 11 19/10/2021 4:28 PM19/10/2021 4:28 PM

12
Using the Timer as a Minute Minder
1. Make sure the ceramic hob is turned ON.
Over-Temperature Protection
A temperature sensor monitors the temperature inside the ceramic hob.
When an excessive temperature is monitored, the ceramic hob will stop operation automatically.
Residual Heat Warning
When the hob has been operating for some time,there will be some residual heat. The letter “ ”appears to warn
you to keep away from it.
Auto Shutdown
Another safety feature of the hob is auto shutdown. This occurs whenever you forget to switch off
a cooking zone. The default shutdown times are shown in the table below:
Power Level 123456789
Default Working Timer (Hour) 888444222
Using the Timer
You can use the timer in two different ways:
• You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when
the set time is up.
• You can set it to turn one cooking zone off after the set time is up.
• You can set the timer for up to 99 minutes.
Timer Overview
Minute display
shows the number of minutes set/
remaining for:
• the cooking zone whose indicator
dot is ashing
LCHOBTC16_IB_RC_Final211019.indd 12LCHOBTC16_IB_RC_Final211019.indd 12 19/10/2021 4:28 PM19/10/2021 4:28 PM

13
2. Set the time by touching the or controls of the
timer.
• Touch the or controls of the timer
once to increase or decrease by 1 minute.
• Touch and hold the or control of the
timer to increase or decrease by 10 minute.
• If the setting time exceeds 99 minutes, the
timer will automatically return to – –.
3. Touching the or controls together, the timer is
cancelled, and the – – will show in the minute display.
5. When the set time has elapsed, an available tone will sound
for 30 seconds and – – will show in the display.
4. When the timer is set, it will begin to count down
immediately. The display will show the remaining time and
the timer indicator will flash for 5 seconds.
Setting the Timer to Turn Cooking Zones O
1. Touch the or controls of the corresponding
cooking zone you want to set the timer for.
The red light of the desired cooking zone will illuminate.
LCHOBTC16_IB_RC_Final211019.indd 13LCHOBTC16_IB_RC_Final211019.indd 13 19/10/2021 4:28 PM19/10/2021 4:28 PM

14
4. When the time is set, the timer will begin to count down
immediately.
The display will show the remaining time and the timer
indicator will flash for 5 seconds.
3. Touch the and controls together to cancel the
timer. – – will show in the minute display.
The red dot next to the power level indicator
will illuminate indicating that zone is selected.
5. When the set time has elapsed, the corresponding cooking
zone will switch off automatically.
• Other cooking zones will keep operating if
they are turned on.
• If you want to change the time after the timer
is set, you have to start from step 1.
2. While the power level indicator is flashing, set the time by
touching the or controls of the timer.
• Touch the or controls of the timer
once to increase or decrease by 1 minute.
• Touch and hold the or controls of the
timer to increase or decrease by 10 minutes.
• If the setting time exceeds 99 minutes, the
timer will automatically return to – –.
LCHOBTC16_IB_RC_Final211019.indd 14LCHOBTC16_IB_RC_Final211019.indd 14 19/10/2021 4:28 PM19/10/2021 4:28 PM

15
Cooking Guidelines
Cooking Tips
• When food comes to the boil, reduce the temperature setting.
• Using a lid will reduce cooking times and save energy by retaining the heat.
• Minimise the amount of liquid or fat to reduce cooking times.
• Start cooking on a high setting and reduce the setting when the food has heated through.
Simmering, Cooking Rice
• Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface
of the cooking liquid. It is the key to delicious soups and tender stews because the flavours develop without
overcooking the food. You should also cook egg-based and flour thickened sauces below boiling point.
• Some tasks, including cooking rice by the absorption method, may require a setting higher than the lowest
setting to ensure the food is cooked properly in the time recommended.
Searing Steak
To cook juicy flavoursome steaks:
1. Stand the meat at room temperature for about 20 minutes before cooking.
2. Heat up a heavy-based frying pan.
3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the meat
onto the hot pan.
4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak
and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the steak to gauge
how cooked it is – the firmer it feels the more ‘well done’ it will be.
5. Leave the steak to rest on a warm plate for a few minutes to allow it to relax and become tender before
serving.
For Stir-Frying
1. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook
the food in several smaller batches.
2. Preheat the pan briefly and add two tablespoons of oil.
3. Cook any meat first, put it aside and keep warm.
4. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the
meat to the pan and add your sauce.
5. Stir the ingredients gently to make sure they are heated through.
6. Serve immediately.
Take care when frying as oil and fat heat up very quickly. At extremely high temperatures oil and fat
will ignite spontaneously and this presents a serious fire risk.
LCHOBTC16_IB_RC_Final211019.indd 15LCHOBTC16_IB_RC_Final211019.indd 15 19/10/2021 4:28 PM19/10/2021 4:28 PM

16
Heat Settings
The settings below are guidelines only. The exact setting will depend on several factors, including your cookware
and the amount you are cooking. Experiment with the ceramic hob to find the settings that best suits you.
Heat setting Suitability
1 - 2 • delicate warming for small amounts of food
• melting chocolate, butter, and foods that burn quickly
• gentle simmering
• slow warming
3 - 4 • reheating
• rapid simmering
• cooking rice
5 - 6 • pancakes
7 - 8 • sautéing
• cooking pasta
9 • stir-frying
• searing
• bringing soup to the boil
• boiling water
LCHOBTC16_IB_RC_Final211019.indd 16LCHOBTC16_IB_RC_Final211019.indd 16 19/10/2021 4:28 PM19/10/2021 4:28 PM

17
Cleaning and Maintenance
What? How? Important!
Everyday soiling on
glass (fingerprints,
marks, stains left by
food or non-sugary
spillovers on the glass)
1. Switch the power to the ceramic
hob off.
2. Apply a ceramic hob cleaner while
the glass is still warm (but not hot!)
3. Rinse and wipe dry with a clean
cloth or paper towel.
• When the power to the ceramic hob
is switched off, there will be no ‘hot
surface’ indication but the cooking
zone may still be hot!
Take extreme care.
• Heavy-duty scourers, some nylon
scourers and harsh/abrasive cleaning
agents may scratch the glass. Always
read the label to check if your cleaner
or scourer is suitable.
• Never leave cleaning residue on the
ceramic hob: the glass may become
stained.
Boilovers, melts, and
hot sugary spills on the
glass
Remove these immediately with a fish
slice, palette knife or razor blade scraper
suitable for ceramic glass ceramic hobs,
but beware of hot cooking zone surfaces:
1. Switch the power to the ceramic
hob off.
2. Hold the blade or utensil at a 30°
angle and scrape the soiling or spill
to a cool area of the ceramic hob.
3. Clean the soiling or spill up with a
dish cloth or paper towel.
4. Follow steps 2 to 3 for ‘Everyday
soiling on glass’ above.
• Remove stains left by melts and
sugary food or spillovers as soon as
possible. If left to cool on the glass,
they may be difficult to remove or
even permanently damage the glass
surface.
• Cut hazard: when the safety cover
is retracted, the blade in a scraper is
razor-sharp. Use with extreme care and
always store safely and out of reach of
children.
Spillovers on the touch
controls
1. Switch the power to the ceramic
hob off.
2. Soak up the spill.
3. Wipe the touch control area with a
clean damp sponge or cloth.
4. Wipe the area completely dry with a
paper towel.
• The ceramic hob may make an
available tone or turn itself off, and the
touch controls may not function while
there is liquid on them. Make sure you
wipe the touch control area dry before
turning the ceramic hob back on.
LCHOBTC16_IB_RC_Final211019.indd 17LCHOBTC16_IB_RC_Final211019.indd 17 19/10/2021 4:28 PM19/10/2021 4:28 PM

18
Hints and Tips
Problem Possible Causes What To Do
The cooktop cannot be
turned on.
No power. Make sure the ceramic hob is
connected to the mains power
supply and that it is switched on.
Check whether there is a power
outage in your home or area. If
you’ve checked everything and the
problem persists, call a qualified
technician.
The touch controls are
unresponsive.
The controls are locked. Unlock the controls. See section
‘Using your ceramic hob’ for
instructions.
The touch controls are difficult
to operate.
There may be a slight film of
water over the controls or you
may be using the tip of your
finger when touching the
controls.
Make sure the touch control area is
dry and use the ball of your finger
when touching the controls.
The glass has been scratched. Rough-edged cookware.
Unsuitable, abrasive scourer or
cleaning products being used.
Use cookware with flat and
smooth bases. See ‘Choosing the
right cookware’.
See ‘Cleaning and Maintenance’.
Specication
Model LCHOBTC16
Rated Voltage 220 – 240V~
Rated Frequency 50 Hz
Overall Dimension (W x D X H) 590 × 520 × 55 (in mm)
Power Consumption 5500 – 6600 W
Features and specifications are subject to change without prior notice.
LCHOBTC16_IB_RC_Final211019.indd 18LCHOBTC16_IB_RC_Final211019.indd 18 19/10/2021 4:28 PM19/10/2021 4:28 PM

19
Product Fiche
Symbol Value Unit
Model -LCHOBTC16 -
Type of hob -Built-in hob -
Number of cooking zones and/or
areas -4 zones -
Heating technology (induction
cooking zones and cooking areas,
radiant cooking zones, solid plates)
-Radiant cooking
zones -
For circular cooking zones or areas:
diameter of useful surface area
per electric heated cooking zone,
rounded to the nearest 5 mm
Ø
Zone 1: 20.0
Zone 2:16.5
Zone 3: 20.0
Zone 4:16.5
cm
For non-circular cooking zones or
areas: length and width of useful
surface area per electric heated
cooking zone or area, rounded to
the nearest 5 mm
L
W-cm
Energy consumption per cooking
zone or area calculated per kg
ECelectric cooking
Zone 1: 180.7
Zone 2: 192.9
Zone 3: 180.7
Zone 4: 209.1
Wh/kg
Energy consumption for the hob
calculated per kg ECelectric hob 190.9 Wh/kg
Standby/o power Ps/Po 0.38 W
The values are tested and calculated according to the regulation EU66-2014.
LCHOBTC16_IB_RC_Final211019.indd 19LCHOBTC16_IB_RC_Final211019.indd 19 19/10/2021 4:28 PM19/10/2021 4:28 PM

20
56cm
49cm
5cm (min)
5cm (min)
5cm (min)
5cm (min)
Installation
Preparing the Worktop
Cut out the work surface following the dimensions shown in the drawing below.
For the purpose of installation and use, a minimum distance of 5cm space must be left around the cut out.
Be sure the thickness of the work surface is around 33mm. Use a heat-resistant work surface material to avoid
deformation caused by the heat from the hob. The minimum distance between the hob and the cupboard should
be at least 76cm.
Ensuring Adequate Ventilation
Always make sure the ceramic cooker hob is well ventilated and that the air inlet and outlet are not blocked.
This hob requires an adequate supply of fresh, cool air to fully function. The base of the hob must have direct
unrestricted ventilation to the room where the hob is installed. Follow the requirements below.
76 cm (min)
5mm
5cm
2 cm (min) Heat
Resistant
Board
There are ventilation holes around the outside of the hob. YOU MUST ensure that these holes are not
blocked by the worktop, when you put the hob into position.
LCHOBTC16_IB_RC_Final211019.indd 20LCHOBTC16_IB_RC_Final211019.indd 20 19/10/2021 4:28 PM19/10/2021 4:28 PM
