LORD T2 User manual

User manual
Návod kobsluze
Návod na obsluhu
Tumble Dryer
Sušička
Sušička
T2

3
CONTENTS
SAFETY INSTRUCTIONS
Safety Instructions .................................................4
INSTALLATION
Product Description .............................................10
Installation ........................................................10
OPERATIONS
Quick Start ........................................................12
Before Each Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control Panel .....................................................15
Option.............................................................16
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Programmes ......................................................18
Drying Programmes Table ......................................20
Consumption Data...............................................21
MAINTENANCE
Cleaning And Care ...............................................22
Trouble Shooting.................................................25
Technical Specifications .........................................27
Product Fiches....................................................28

4
SAFETY INSTRUCTIONS
Safety Instructions
yThis product belongs to Category electrical appliances, and
only for drying textiles which have been washed with water in
the household. Please pay attention to the safety of power use
during the operation!
yThe power source with reliable earthing must be used. Its
earth wire must be buried under the ground and shall not be
connected with the public utilities such as city water pipe or
gas pipe etc. The earth wire and null wire shall be distinguished
and shall not be connected together.
yThe power wire shall be met IEC and must be able to withstand
the current above 16 A. To ensure your and your family’ssafety,
please make improvement immediately if any power use at
your home does not meet the above-mentioned requirements.
yDo not put more load than recommended. Obey the maximum
load volume. See the related chapter in the user manual.
yThat the tumble dryer is not to be used if industrial chemicals
have been used for cleaning.
yDo not dry unwashed items in the tumble dryer.
yItems that have been soiled with substances such as cooking
oil, acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes and wax removers should be washed in hot
water with an extra amount of detergent before being dried in
the tumble dryer.
Warning!
To prevent any damages to your and others‘ life or property,
you have to follow the safety notes.
SAFETY INSTRUCTIONS

5
SAFETY INSTRUCTIONS
yItems such as foam rubber (latex foam), shower caps,
waterproof textiles, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the
tumble dryer.
yFabric softeners, or similar products, should be used as
specified by the fabric softener instructions.
yThe final part of atumble dryer cycle occurs without heat (cool
down cycle) to ensure that the items are left at atemperature
that ensures that the items will not be damaged.
yThe lint trap has to be cleaned frequently.
yThe lint must not to be allowed to accumulate around the
tumble dryer.
yAdequate ventilation has to be provided to avoid the back flow
of gases into the room from appliance burning other fuels,
including open fires.
yThe exhaust air must not be discharged into aflue which is
used for exhausting fumes from appliance burning gas or other
fuels.
yThe appliance must not be install behind alockable door,
asliding door or adoor with ahinge on the opposite side to
that of the tumble dryer. In such away that afull opening of
the tumble dryer door is restricted.
yOil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in atumble dryer.
The items become warm, causing an oxidation reaction in the
oil. Oxidation creates heat. If the heat cannot escape, the items
can become hot enough to catch fire. Piling, stacking or storing
oil-affected items can prevent heat from escaping and so
create afire hazard.

6
SAFETY INSTRUCTIONS
yIf it is unavoidable that fabrics that contain vegetable or
cooking oil or have been contaminated by hair care products
be placed in atumble dryer they should first be washed in hot
water with extra detergent-this will reduce, but not eliminate,
the hazard.
yThe appliance should not be overturned during normal use or
maintenance.
yRemove all objects from pockets such as lighters and matches.
yThis appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in asafe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervision. (This warning is only for EUROPEAN market)
yThe appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by aperson responsible for their safety.
yChildren should be supervised to ensure that they do not play
with the appliance. (This warning is not for EUROPEAN market)

7
SAFETY INSTRUCTIONS
yIf the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid ahazard.
yThis appliance is for indoor use only.
yThe openings must not be obstructed by acarpet.
yChildren of less than 3 years should be kept away unless
continuously supervised.
yIf the appliance appear high temperature abnormally, please
draw the mail plug immediately.
yRemove all packages before using the appliance. Otherwise,
serious damage may result.
yThe appliance contains an environmentally friendly but
flammable R290 refrigerant.
yKeep away from open flame and other sources of ignition.
CAUTION: RISK OF FIRE!
Warning!
yNever stop atumble dryer before the end of the drying
cycle otherwise too much heat will diffuse and may
cause harm.
yThe appliance must not be supplied through an external
switching device, such as atimer, or connected to
acircuit that is regularly switched on and off by autility.
yIn the appliance enclosure or in the built in structure,
keep ventilation openings clear of obstruction.
yDo not damage the refrigerant circuit.

8
SAFETY INSTRUCTIONS
Correct Disposal of this product:
This marking indicates that this product should
not be disposed with other household wastes
throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To
return your used device, please use the return and
collection systems or contact the retailer where the
product was purchased. They can take this product
for environmental safe recycling.

9
SAFETY INSTRUCTIONS
Electric shock hazard
yDo not pull the power cord forcefully. Please disconnect the
mains plug instead.
yPlease do not plug/draw the mains plug with wet hands.
yDo not damage the power cord and the power plug.
Injury danger
yDo not disassemble or install the dryer without any instruction
or supervision.
yDo not stack this dryer on washing machine without stacking
kits.(if you want to stack this dryer on washing machine, please
purchase the independent parts and it must be installed by the
manufacturer, its service agent or similarly qualifiedpersons to
avoid any hazards.)
yDo not lean on the opened door of the dryer.
yDo not put any pyrotoxin on the dryer, such as the candle,
electric cooker.
Damage danger
yDo not dry over the rated capacity.
yDo not operate the dryer without the filter door and filter base.
yDo not dry the clothes before being spun.
yDo not expose the dryer directly under the sun, indoor use
only.
yDo not install the dryer in humid and drenching environment.
yWhile cleaning and maintenance, please do remember to pull
out the power plug and do not directly wash the dryer with
water.
Explosion danger
Please do not dry the clothes with any flammable substances
such as coal oil or alcohol. Otherwise, there may be explosion.

10
INSTALLATION
Product Description
Note: Please see the products you purchased in kind prevail.
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and them as per the instruction below.
Installation
Control panel
Door
Air inlet
Filter base
Maintenance cover
Top board
Container
Drum
Filter
Remove the drain
hose from the
housing drawer.
Insert the drain
hose and the
external drainage
hose into the
connector.
Put the hose holder on the
washing basin or any other sink.
Max120cm
200cm
x
x
INSTALLATION

11
INSTALLATION
Transport
Move cautiously. Do not grasp any salient parts of machine. The machine door can not be
used as the handle for delivery. If the dryer can’t be transported erectly, the dryer could be
slant to right less than 30°.
Level Adjusting
Once in its permanent operating position, check that the dryer is absolutely level with the
aid of aspirit level. If it is not, adjust the feet with atool.
Power Supply Connection
1. It is recommended that, for your convenience, the machine is positioned close to your
washing machine.
2. The tumble dryer must be installed in aclean place, where dirt does not build up. Air
must be able to circulate freely all round the appliance. Do not obstruct the front air inlet
or the air intake grilles at the back of the machine.
3. To keep vibration and noise within minimum level when the dryer is in use, it placed on
afirm and level surface.
4. The feet must never be removed. Do not restrict the floor clearance through deep pile
carpets, strips of wood or similar. This might cause heat built-up which would interfere
with the operation of the appliance.
Level Adjusting
Once in its permanent operating position, check that the dryer
is absolutely level with the aid of aspirit level. If it is not, adjust
the feet with atool.
Power Supply Connection
1. Make sure that the voltage of the power supply is the same
as the electric specification of the dryer.
2. Do not connect the dryer with the power connection board, the universal plug or socket,
do not use multi-plug adapters and extension cables.

12
OPERATIONS
Quick Start
Drying
After Drying
Buzzer beep or„0:00“on display.
Note!
Before using, please make sure it’sinstalled properly.
 
close doorloadplug in
startselect programon select function
or default
    
pour out
condensate
water
pull out the
container
open the door
and take out
laundry
clean the filter power off
Note!
yIf the socket with aswitch is used, please press the switch to turn off the power
directly.
OPERATIONS

13
OPERATIONS
Before Each Drying
1. Before drying, thoroughly spin the laundry in washing machine. High spin speed can
reduce the drying time and save energy consumption.
2. For uniform drying result, sort the laundry according to fabric type and drying
programme.
3. Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4. Do not over dry the clothes, because over dried clothes can easily get creases.
5. Do not dry the articles containing rubber or similar elastic materials.
6. Keep the area around the tumble dryer clean while it is running. If there is coal dust or
flour around, it may cause an explosion.
7. The door can be opened only after the programme of the drying machine finishes to
prevent human skin from being scalded by hot steam or over heated drying machine.
8. Clean the lint filter and empty container after each use to avoid extension of drying time
and energy consumption.
9. Do not dry these clothes after dry-clean process.
10. Please choose the related programme when dealing with wool material clothes, to make
the cloth more fresh and fluffy.
The reference weight of dry clothes (each)
Mixed-fabric clothes
(about 800 g)
Jacket (about
800 g cotton
Jeans (about
800 g)
Towel quilt
(about 900 g
cotton)
Single bedsheet
(about 600 g cotton)
Work clothes
(about 1120 g)
Sleepwear
(about 200 g)
Long sleeve
shirt (about
300 g cotton)
Short sleeve shirt
(about 180 g cotton
Short pants (about
70 g cotton)
Socks (about
50 g mixed-
weave)
Note!
yLeave it to stand for 2 hours after transporting. Before first use, please use the soft
fabric to clean the inside drum.
1. Put some clean rags into the drum.
2. Plug the power, press On/Off .
3. Select the Refresh Programme, press Start/Pause button.
4. After finishing this programme, please follow the“cleaning and care”(refer to
page 21) to clean the filter door.
yDuring drying, the compressor and the water will generate some noise which is
entirely normal.

14
OPERATIONS
Please pay attention to use the drying machine if the materials of your clothes can not be
dried by it or contain the symbols as follows:
Dry Normal Not tumble dry normal Do not dry
Line dry / hang to dry Drip dry Dry flat In the shade
Dry clean Do not dry clean Dry clean normal cycle with
any solvent
Dry clean normal cycle
petroleum solvent only
Note!
yNever overload.
yNot for textile with dropping water. The dryer could be damaged, even fire.

15
OPERATIONS
Control Panel
2
1
3
5
3
4
Delay
Drying Time
Dry Level
Light
Anticrease
Signal
aOn/Off
Product is switched on or off.
bStart/Pause
Press the button to start or pause
the drying cycle.
cOption
These buttons are used for setting
additional functions.
dDisplay
This display shows the setting,
estimated remaining time and
status messages of your dryer.
eProgrammes
Different Dryer cycle can be
selected according to the
user’sneeds to ensure the clothes
drying results are more effective.

16
OPERATIONS
Option
(depends on model)
Delay Delay
This function is used for delaying clothes drying time. Max delaying time is 24
hours. The delay time means the programme will start after x hours. When the
delay programme starts, the time starts to countdown on the display and the
delay icon blinks.
Steps in details:
1. Load your laundry and make sure the machine door is closed.
2. Press the On/Off button, then to turn the programme selector knob and
select adesired programme.
3. You can select the Anti-Crease or Signal functions according to your
need
4. Press the Delay button.
5. Continue to press the Delay to select the delay time.
6. After the Start/Pause button is pressed, the Dryer is at the running
condition.
The drying procedure will be automatically performed when the delay time
is over.
7. If you press the Start/Pause button again, the delay function will be
paused.
8. If you want to cancel the“Delay” function, please press the On/Off
button.
Drying Time Drying Time
When the warm or cool or refresh programme is selected, the Drying Time
button can be used to adjust the drying time in 10 min. steps.
Dry Level Dry Level
Use for adjusting the dryness level of the laundry.
The level has four grades. a
The drying time of the four grades increases 3 minutes in every grade.
1. The intensity function can be activated only before the programme starts.
2. Press the Dry Level button repeatedly to select the drying time.
3. Except the Cotton Iron Delicate Wool Warm Cool
Refresh , all the other programmes can be set with the Dry Level
function.
Light Light
The lamp inside the drum will be on for lighting about 3 minutes when the
button is pressed or 1 minute when the door is open.

17
OPERATIONS
Signal Signal
Set the buzzer on or off. In general condition, the buzzer is on. Please touch it if
needed.
When the buzzer is on:
1. The dryer will make the leading sound if press the extra function buttons.
2. If the programme knob is rotated when the dryer is running, the dryer will
remind the operator that it is an invalid programme selection.
3. When the drying programme is done, the buzzer will beep to remind the
user.
Anti-Crease
Anti-Crease
At the end of the drying cycle, the time of the anti-crease for 60 minutes or 90
minutes can be selected; 120 minutes can be selected alternatively.
This function prevents the laundry from creases. The laundry can be removed
during the anti-crease phase. Except Cool , Wool and Refresh , all the
other programmes have this function.
My Cycle My Cycle
Used to define and save your favorite programmes that are used frequently.
1.Use the programme knob to select the required programme and other drying
functions.
2.Press and hold the button with for 3 seconds until the beep and the
required programme has been saved.
3.Turn the programme selector to the My Cycle position, then you can start
your favorite programmes.
If you want to change the My Cycle settings, repeat the steps (1) and (2).
Child Lock Child Lock
1. This machine incorporates aspecial child safety lock, which can prevent
children from carelessly pressing buttons or making the faulty operation.
2. When the dryer is at the operation status, press the Anti-Crease and
Signal buttons or Anti-Crease or Silence and Dry Level button at
the same time for over 3 seconds to start child lock function. When child
lock function is set, the display will show Child lock icon and no key can
have an effect on the dryer except On/Off button.
To activate the child lock function, the Anti-Crease and Signal or
Silence and Dry Level buttons shall be pressed at the same time for
over 3 seconds.
Silence Silence
Rotate speed of the drum will drop down to reduce the noise of the dryer, but
the drying time will extend.

18
OPERATIONS
Display
//
Delay start
/
Drying Time
//
Child lock
Remaining Drying Time indicator/Error message
Cycle phase status
Filter
/ /
Clean filters (warning)
//
Full Empty water container (warning)
Dry Level or Dry level (four grades)
Drum lamp indicator
Signal indicator
Anti-Crease mode
My Cycle
Iron
Silence
The wool drying cycle of this machine has been approved by
The Woolmark Company for the drying of machine dryable wool
products provided that the products are dried according to
the instructions on the garment label and those issued by the
manufacturer of this tumble dryer. M1716

19
OPERATIONS
Programmes
Programme selector
1. Press the On/ Off button. When the LED display screen brightens up, rotate the
programme knob to select the desired programme.
2. Select the Delay , Drying Time , Dry Level , Anti-Crease or Signal
functions for additional options.
3. Press the Start/Pause button.
Programme start
The drum will keep rotating after the programme starts. The status light in the
display area will flash in sequence, and the displayed remaining time will change
automatically.
Programme end
1. The drum will stop running after the programme ends. The display will show„
„, also the status light of„End“ and related light will illuminate. The dryer will start
Anti-Crease function if user doesn’t remove the load in time (refer to page 15).
Please press On/Off key to cut off power and pull the plug out.
2. Deal with the problems according to“Malfunction display and solutions, if there is an
unexpected stop during the drying procedure and the dryer shows information (refer to
page 23).

20
OPERATIONS
Drying Programmes Table
Programme Weight
(max)
Application/Properties Delay Drying
Time
8.0 kg
Cotton For cottons and coloureds made of cotton or linen.
Cupboard dry +
8.0 kg To dry cotton pieces of clothing. Drying level: extra dry. Y N
Cupboard dry To dry cotton pieces of clothing. Drying level: cupboard dry.
Iron dry To dry cotton pieces of clothing. Drying level: applicable to iron. Y N
Delicates Delicates 1.0 kg To dry delicate laundry that is suitable for drying or laundry which is advised to be hand-
washed at alower temperature.
Y N
Mix Mix 3.5 kg If you can not determine what the clothing’smaterial is, please choose Mix. Y N Easy Care For non-iron washing made of synthetic and blended fabrics, cotton.
Cupboard dry+ 3.5 kg To dry thick or multi-layered synthetic fabrics. Drying level: extra dry. Y N
Cupboard dry To dry thin synthetic fabrics which are not ironed, such as easy care shirts. table linen, baby
clothes, socks.
Wool Wool finish 1.0 kg To dry afew machine washable clothing. Y Y
Special Jeans 4.0 kg To dry jeans or leisure clothes that are spun at high speeds in the washing machine Y N
Bed Linen 4.0 kg To dry sheets or other large sized textiles. Y N
Sport 3.0 kg To dry sportswear, thin fabrics, polyester, which are not ironed. Y Y Shirts 1.0 kg For easy care clothes such shirts and blouses with anti-crease mechanism for minimum
ironing effort. Place clothes loosely in the dryer. Once dried. hang it on aclothes hange
Y N
My Cycle My Cycle — Define and save your favorite programme. Y — Drying Time Warm —To warm clothes from minimum 10 min. to maximum 120/180 min. (in 10 min. steps). Y Y
Cold — T oair clothes without heating from minimum 10 min. to maximum 30 min. (in 10 min.
steps).
Refresh 1.0 kg To refresh the clothes that have been kept at closed environments for along time from
minimum 20 min. to maximum 150 min.
