Lotus LIBR.ISTR.PCIDX User manual

Translation of the original instructions
Installation and operating instructions
ELECTRIC INDUCTION HOBS FOR
PROFESSIONAL USE
PCID-64ETX PCID-68ETX PCIWD-64ETX
PCID-64ETDX PCID-68ETDX PCIWD-64ETDX
PCID-44ETX PCID-44ETDX
PCID-84ETX PCID-84ETDX
PCID-88ETX PCID-88ETDX
Model LIBR.ISTR.PCIDX
Code 5630272A0
Review 1
Edition date 22/04/2020
Language English
LOTUS S.p.A.
Via Calmaor, 46
31020 San Vendemiano
[phone]
[phone]

Contents
Translation of the original instructions
2
Contents
1 INTRODUCTION......................................................................................................................... 5
1.1 Installation drawing...................................................................................................................... 5
1.2 Connections ................................................................................................................................ 17
2 GENERAL INFORMATION......................................................................................................... 18
2.1 Declaration of compliance............................................................................................................ 18
2.2 User information, RAEE Directive on waste electrical and electronic equipment ........................ 19
2.3 Technical data table..................................................................................................................... 19
3 INSTALLATION........................................................................................................................... 21
3.1 Delivery checks ............................................................................................................................ 21
3.2 Removing the packaging ............................................................................................................. 21
3.3 Mechanical installation ................................................................................................................. 21
3.4 Electrical/gas connections ........................................................................................................... 21
4 INSTRUCTIONS FOR USE......................................................................................................... 24
4.1 General information ..................................................................................................................... 24
4.2 Induction cooker hobs .................................................................................................................. 24
4.2.1 Induction generator ...................................................................................................................... 25
4.3 Lighting and adjusting the open rings.......................................................................................... 26
4.3.1 Pans ............................................................................................................................................. 26
4.3.2 Function checks .......................................................................................................................... 28
4.3.3 Shut-off ........................................................................................................................................ 28
4.3.4 Lin Knob ....................................................................................................................................... 28
4.3.5 Flex touch .................................................................................................................................... 31
4.3.6 Normal mode ............................................................................................................................... 31
4.3.7 Function keys ............................................................................................................................... 31
4.3.8 Pot detection ............................................................................................................................... 32
4.3.9 Parameter table ........................................................................................................................... 32
4.3.10Residual heat symbol h................................................................................................................ 32
4.3.11 Troubleshooting ........................................................................................................................... 33
4.3.12Error signals ................................................................................................................................. 33
4.3.13Lin knob error messages ............................................................................................................ 34
5 MAINTENANCE.......................................................................................................................... 37
5.1 Routine......................................................................................................................................... 37
5.2 Spare parts .................................................................................................................................. 38
6 CLEANING.................................................................................................................................. 39
6.1 Routine cleaning.......................................................................................................................... 39
6.2 Cleaning the glass ....................................................................................................................... 39
6.3 Maintenance suggestions............................................................................................................ 40

Contents
Translation of the original instructions
3
6.4 How to achieve a brilliant result in three simple steps:................................................................ 41
6.5 How to your SCHOTT CERAN® hob bright and shining for a long time...................................... 42

Contents
Translation of the original instructions
4

INTRODUCTION
Translation of the original instructions
5
1 INTRODUCTION
1.1 Installation drawing
FIG. 1 PCID-6... (ANALOGIC)

INTRODUCTION
Translation of the original instructions
6
B Electrical connection
C Air inlet
D Air outlet

MODEL A (mm) C D
PCID-64ET 400 ≥100 cm² ≥150 cm²
PCID-68ET 800 ≥165 cm² ≥200 cm²

INTRODUCTION
Translation of the original instructions
7
FIG. 2 PCID-6...D (FLEX TOUCH)

INTRODUCTION
Translation of the original instructions
8
B Electrical connection
C Air inlet
D Air outlet

MODEL A (mm) C D
PCID-64ETD 400 ≥100 cm² ≥150 cm²
PCID-68ETD 800 ≥165 cm² ≥200 cm²


INTRODUCTION
Translation of the original instructions
9
FIG. 3 PCIWD-64ET (ANALOGIC)
B Electrical connection
C Air inlet
D Air outlet

INTRODUCTION
Translation of the original instructions
10
FIG. 4 PCIWD-64ETD (FLEX TOUCH)
B Electrical connection
C Air inlet
D Air outlet

INTRODUCTION
Translation of the original instructions
11
FIG. 5 PCID-44ET (ANALOGIC)
B Electrical connection
C Air inlet
D Air outlet

INTRODUCTION
Translation of the original instructions
12
FIG. 6 PCID-44ETD (FLEX TOUCH)
B Electrical connection
C Air inlet
D Air outlet

INTRODUCTION
Translation of the original instructions
13
FIG. 7 PCID-8…ET (ANALOGIC)

INTRODUCTION
Translation of the original instructions
14
B Electrical connection
C Air inlet
D Air outlet

MODEL A (mm) C D
PCID-84ET 400 ≥100 cm² ≥150 cm²
PCID-88ET 800 ≥165 cm² ≥200 cm²


INTRODUCTION
Translation of the original instructions
15
FIG. 8 PCID-84ETD (FLEX TOUCH)

INTRODUCTION
Translation of the original instructions
16
B Electrical connection
C Air inlet
D Air outlet

MODELL C D
PCID-84ETD ≥100 cm² ≥150 cm²


INTRODUCTION
Translation of the original instructions
17
1.2 Connections
Warning

In this type of luminaire NEUTRAL is not present

GENERAL INFORMATION
Translation of the original instructions
18
2 GENERAL INFORMATION
2.1 Declaration of compliance
The manufacturer declares that the appliances comply with the requirements of the regulation GAR
2016/426 for the gas part and directive 2014/30/EU,2014/35/EU for the electrical part. Installation must be
performed in compliance with current regulations, especially with regard to ventilation of the premises and
the exhaust gas evacuation system.
·Read the warnings in this manual carefully. They provide important information about safe installation,
use and maintenance.
·The instruction manual must be kept for the entire duration of the equipment and made available to users
for every possible consultation. The manual should be consulted for any information concerning
installation, use and maintenance of the appliance.
·After removing the packaging, check the integrity of the equipment.
·All packaging materials (plastic bags, polystyrene, staples, etc.) must be disposed of in compliance with
current regulations.
·Before connecting the appliance, make sure that the information on the data plate matches the electricity
and gas mains where the appliance is installed. The manufacturer accepts no liability if the
equipment is not connected in accordance with current regulations.
·Always keep all parts of the equipment clean to avoid the risk of oxidation/rust and/or aggression by
chemical agents.
·The equipment must only be used by personnel trained for the purpose.
·The installation must be implemented by professionally qualified personnel in accordance with
the manufacturer's instructions and current reference standards.
·The electrical safety of this equipment is only ensured when it is correctly connected to an effective
ground/earth system as required by current electrical safety standards. The manufacturer cannot be held
liable for any damage caused if the system is not connected to ground/earth.
·Before carrying out any cleaning or maintenance tasks on the equipment, unplug it from the electricity
mains. In the event of faults or malfunctions, always deactivate the appliance.
·Repair work of any kind must only be performed by qualified personnel.
·This appliance must only be used for its expressly intended purpose for cooking or heating food. Any
other use is considered improper.
·The appliance is intended for professional use and must be used by trained personnel.
·The installation and possible transformation to another power supply voltage (if envisaged), or
transformation for operation with another type of gas, must be implemented exclusively by qualified and
authorised professional personnel.
·Before using the appliance, carefully clean all surfaces intended to come into contact with food.
·The manufacturer declines any and all liability for any direct or indirect damage resulting from improper
use of the equipment. The manufacturer declines any and all liability for damage caused by incorrect
installation, tampering, poor maintenance and unskilled use. Moreover, the manufacturer declines any
liability for possible inaccuracies that may be contained in this booklet attributable to errors in
transcription or printing and equally reserves the right to make any changes to the product it deems
useful and/or necessary without compromising its essential characteristics.
·The manufacturer cannot be held liable for any damage caused by failure to comply with these
basic standards and all other use and maintenance standards contained in this booklet.

GENERAL INFORMATION
Translation of the original instructions
19
2.2 User information, RAEE Directive on waste electrical and
electronic equipment
With regard to the regulatory framework of reference of the European Community, we remind the user of the
following:

·Used AAE (Electrical and Electronic Equipment) products must be collected separately
·The user can carry out this collection in the RAEE collection systems and return the equipment to the
distributor when purchasing a new one
·Plus being RoHS compatible, (in accordance with Directive 2011/65/EU on the restriction of the use of
certain hazardous substances in electrical and electronic equipment) the potential effects on the
environment and human health may be due to the misuse of the same equipment or parts of it
·The symbol next to the rating plate indicates the obligation of separate collection
·The penalties provided for in the event of improper disposal of RAEE (Waste Electrical and Electronic
Equipment) are those provided for by the national transpositions of European Directives 2012/19/EU
2.3 Technical data table
Technical data table PCIDX
MODEL POWER SUPPLY MAXIMUM INPUT (A) MAXIMUM POWER
(kW)
Silicon POWER
SUPPLY CABLE
PCID-64ETX 400V~3 50/60 Hz 14,43 10 4 x 1,5 mm²
PCID-64ETX 440V~3 60 Hz 13,12 10 4 x 1,5 mm²
PCID-68ETX 400V~3 50/60 Hz 28,87 20 4 x 4 mm²
PCID-68ETX 440V~3 60 Hz 26,24 20 4 x 4 mm²
PCIWD-64ETX 400V~3 50/60 Hz 7,22 5 4 x 1,5 mm²
PCIWD-64ETX 440V~3 60 Hz 6,56 5 4 x 1,5 mm²
PCID-64ETDX 400V~3 50/60 Hz 14,43 10 4 x 1,5 mm²
PCID-64ETDX 440V~3 60 Hz 13,12 10 4 x 1,5 mm²
PCID-68ETDX 400V~3 50/60 Hz 28,87 20 4 x 4 mm²
PCID-68ETDX 440V~3 60 Hz 26,24 20 4 x 4 mm²
PCIWD-64ETDX 400V~3 50/60 Hz 7,22 5 4 x 1,5 mm²
PCIWD-64ETDX 440V~3 60 Hz 6,56 5 4 x 1,5 mm²
PCID-44ETX 400V~3 50/60 Hz 7,22 5 4 x 1,5 mm²
PCID-44ETX 440V~3 60 Hz 6,56 5 4 x 1,5 mm²
PCID-44ETDX 400V~3 50/60 Hz 7,22 5 4 x 1,5 mm²
PCID-44ETDX 440V~3 60 Hz 6,56 5 4 x 1,5 mm²
PCID-84ETX 400V~3 50/60 Hz 14,43 10 4 x 1,5 mm²
PCID-84ETX 440V~3 60 Hz 13,12 10 4 x 1,5 mm²
PCID-84ETDX 400V~3 50/60 Hz 14,43 10 4 x 1,5 mm²
PCID-84ETDX 440V~3 60 Hz 13,12 10 4 x 1,5 mm²
PCID-88ETX 400V~3 50/60 Hz 28,87 20 4 x 4 mm²
PCID-88ETX 440V~3 60 Hz 26,24 20 4 x 4 mm²
PCID-88ETDX 400V~3 50/60 Hz 28,87 20 4 x 4 mm²
PCID-88ETDX 440V~3 60 Hz 26,24 20 4 x 4 mm²


GENERAL INFORMATION
Translation of the original instructions
20
Caution

The ambient temperature of the generator housing must not exceed 35°C

General technical data for induction hobs
Minimum pot diameter: 120 mm

Relative humidity: 10% ÷ 90% no condensation

Temperature in work area: 0°C ÷ 40°C

Power Supply Voltage Tolerance: -10% ÷ +6%
Power Supply Frequency: 50 – 60 Hz
