LOUDLINK LLK-266BLUE User manual

LLK-266BLUE
LLK-366BLUE
Bluetooth Handfree Car Kit
and multi format (Ogg
Vorbis P3 AAC W A FLAC
WAV) CD Changer Emulator
- SSD player
Installation Guide
Dear Customer!
Thank You for purchasing Loudlink products! We
hope You will be satisfied, since Your satisfaction is
our primary objective.
What you need for Loudlink installation:
Loudlink Bluetooth Handsfree Car Kit /
multi format (Ogg Vorbis P3 AAC W A
FLAC WAV) SSD player with icrophone
CD Changer cable – if not factory fitted
already
micro SD/SDHC card
ount the icrophone to the upper corner on
driver's side.
Connect the 3.5mm Jack plug of icrohpone to
Loudlink.
Connect CD Changer cable to Loudlink.
Be sure Head Unit is off, and please wait while LED
goes blank on Loudlink after connection!
The integrated charger operates when head unit is
on. For charging simply connect the USB charger
cable of Your mobile device to Loudlink.
Bluetooth device pairing
Switch head unit to “CD Changer”, than navigate to
CD2.
„Previous Track” (<<) button
disconnect the already connected mobile device.
“Next Track” (>>) button
disconnect the already connected mobile device,
and start pairing an another one.
Please be patient, within few seconds You'll see
„Loudlink CarKit” in Bluetooth devices list.
Pair with “2222” PIN code if asked, and switch head
unit back to CD1.
After succesful paring, you can manage your calls,
navigate within multimedia sources (audio, video,
online radio, etc.) using factory fitted steering wheel
remote control buttons (if have), and / or head unit
CD Changer control buttons.
During media playback the following functions are
available on CD1:
“Previous Track” (<<)
play the previous track
„Next Track” (>>)
play the next track

„Track Fast Rewind” (<<<)
call the last dialed phone number
“Track Fast Forward” (>>>)
call the last dialed phone number
During call the following functions are available on
CD1:
“Previous Track” (<<)
reject the incoming call or hang-up the current
call, or terminate the outgoing call
„Next Track” (>>)
answer to the incoming call
After call the media playing will continue from the
interrupted position!
Microphone volume
On CD3 selectable within range 1 ...63
Firmware upgrade
Simply copy fw.hex file to SD card. Insert the card
when LED is off. After few seconds of toggling LED
update will finish. Loudlink will go stand-by again.
or
Available through Bluetooth connection with
Bluetooth SPP profile.
Android: Supported with “Loudlink CarKit Tool”
Android application available in Google Play store for
free.
iOS: Not supported due to iOS limitations.
Windows obile: Not yet supported.
PC operating systems (Linux, OS-X, Windows):
Built-in or 3rd party serial port terminal emulator
program with xmodem file transfer features. Don't
forget PC must have Bluetooth interface with SPP
profile feature!
“Howto” video for Windows and Hyperterminal:
SD card Prepare
Copy music albums to the SD card
On CD5 the albums are selectable. First song will
play from each album.
On CD6 Loudlink will play the whole previously
selected album.
With this solution easy to organize 98 album x 98
songs.
Usually the supported audio files has AAC, 4a,
p3, Ogg, W A, WAV, FLAC extensions. Loudlink
try to decode all files located in folders, the
extensions are irrelevant.
Cable installation
If CD Changer cable is not installed already in Your
car, You need to remove the head unit. This process
requires special tools. We highly recommend you to
go to an authorized garage, where professionals can
remove the head unit and afterwards connect the
cable.
If You are able to remove head unit, just simply
connect the blue „ ini-ISO” connector to the socket
of the back side of the head unit.
You are finished! Enjoy the sound! Have great miles!
Loudlink Team
