Lowrance Radar Operation User manual

Pub. 988-0161-012
www.lowrance.com
Radar Operation
Instruction Manual

Copyright © 2007 Lowrance Electronics, Inc.
All rights reserved.
No part of this manual may be copied, reproduced, republished, trans-
mitted or distributed for any purpose, without prior written consent of
Lowrance Electronics. Any unauthorized commercial distribution
of this manual is strictly prohibited.
Lowrance®is a registered trademark of Lowrance Electronics, Inc.
NMEA 2000®is a registered trademark of the National Marine Elec-
tronics Association.
Lowrance Electronics may find it necessary to change or end our poli-
cies, regulations and special offers at any time. We reserve the right to
do so without notice. All features and specifications subject to change
without notice.
For free owner's manuals and the most current information on
this product, its operation and accessories,
visit our web site:
www.lowrance.com
Lowrance Electronics Inc.
12000 E. Skelly Dr.
Tulsa, OK USA 74128-2486
Printed in USA.

i
Table of Contents
Warnings and Cautions .......................................................... iii
Section 1: Introduction............................................................. 1
Models Covered ............................................................................. 1
Update Display Unit Software (2006 Units only) ....................... 2
Checking Software Version....................................................... 2
Installing Software Update ...................................................... 2
How to use this manual: typographical conventions .................. 3
Section 2: Radar Setup ............................................................. 7
Getting Started.............................................................................. 7
Auto Power-On .............................................................................. 9
Turning on/off Auto Power-On: ............................................ 9
Radar Setup ................................................................................... 9
Trigger Delay Preparation...................................................... 10
Range.................................................................................... 10
Gain ...................................................................................... 10
Anti-Sea Clutter .................................................................. 10
Anti-Rain Clutter ................................................................ 10
Main Bang Suppression ...................................................... 11
Trigger Delay ....................................................................... 11
Adjust Trigger Delay............................................................... 11
Adjust Main Bang Suppression.............................................. 13
Adjust Heading Line ............................................................... 14
Adjust Transmit Off Zone ....................................................... 15
Adjust Tune ............................................................................. 16
Section 3: Basic Operation .................................................... 17
Pages ............................................................................................ 17
Radar Only............................................................................... 18
Digital Data ............................................................................. 18
Radar with Map....................................................................... 18
Radar with Sonar .................................................................... 18
Radar with Gauges.................................................................. 18
Radar, Map and Sonar ............................................................ 19
Radar Menu ................................................................................. 20
Gain .......................................................................................... 20
Anti-Sea Clutter (STC):........................................................... 21
Anti-Rain Clutter (FTC).......................................................... 21
Interference Rejection ............................................................. 22
Radar Range ............................................................................ 22
Radar Echo Expansion............................................................ 23
Echo Trail Interval .................................................................. 23
Clear Radar Trails................................................................... 24

ii
Adjust Radar PPI Offset ......................................................... 24
Recenter Radar PPI................................................................. 24
Log Radar Data ....................................................................... 25
Radar Setup ............................................................................. 29
Radar Orientation ................................................................... 29
Radar Color Scheme................................................................ 29
Adjust Antenna Park .............................................................. 29
Radar Information................................................................... 31
Radar Power ............................................................................ 31
Turns the radar on and off...................................................... 31
Radar Simulator ...................................................................... 31
Radar Overlay ............................................................................. 32
Radar Options menu ............................................................... 33
Overlay Options menu ............................................................ 34
Section 4: Advanced Operation ............................................ 37
Reading the Display .................................................................... 37
Gain .......................................................................................... 37
Range Rings ............................................................................. 37
Anti-Sea Clutter (STC)............................................................ 38
Anti-Rain Clutter (FTC).......................................................... 38
Electronic Bearing Line (EBL) ............................................... 38
Variable Range Markers......................................................... 38
Radar Cursor ........................................................................... 38
Section 5: Radar Interpretation........................................... 43
Anti-Rain Clutter (FTC or Fast Time Constant)....................... 43
Echo Trails................................................................................... 46
Typical Small Boat Targets ........................................................ 48
Shoreline Images......................................................................... 50
Recommended Reading ............................................................... 52
Appendix I: Glossary............................................................... 53
FCC Compliance ...................................................................... 58

iii
Warnings and Cautions
Caution:
Use this radar at your own risk. This radar was designed for
use as a navigation aid. It should not be used for purposes that
require precise measurements of direction, distance, topography
or location. Always compare the navigation information received
from your radar with data from other navigation aids and
sources. When a conflict arises between the navigation data from
your radar and data from other navigation aids, make sure you
resolve the conflict before proceeding with navigation. A CARE-
FUL NAVIGATOR NEVER RELIES ON ONLY ONE
METHOD TO OBTAIN NAVIGATION INFORMATION.
Caution:
International Regulations for Preventing Collisions at Sea man-
date that when radar is on a vessel, the radar must be used at
all times, regardless of weather conditions or visibility. Numer-
ous court decisions have not only ruled the radar must be used,
but that the radar operator must be knowledgeable in all opera-
tional aspects of radar performance or otherwise face a greater
risk of liability if an accident occurs.
Caution:
If you purchased an open array radar antenna, make sure it is
installed in an area free of hardware obstructions and free of po-
tential obstructions like sails, lines or other vessel components
that could intermittently intrude or be caught up in the array
antenna's rotation path.
WARNING: High Voltage Hazard
Dangerously high voltages are present within the radar
scanner unit. The unit contains no user-serviceable
parts. The cover should be removed only by a qualified
radar service technician. Technicians must exercise ex-
treme care when working inside the unit. ALWAYS re-
move power before removing the cover. Some capacitors
may take several minutes to discharge, even after
switching off the radar. Before touching the magnetron
or any high voltage components, ground them with a
clip lead. There are no internal connections or adjust-
ments necessary for installation or operation.
