Koden MDC-1810P User manual

0735
04
OPERATION MANUAL
KODEN ELECTRONICS CO.,LTD.
13-24, TAMAGAWA 2-CHOME, OHTA-KU
TOKYO 146-0095 JAPAN
TEL : [phone]
FAX : [phone]
http://www.koden-electronics.co.jp/
COLOR RADAR
MDC-1810P/1820P
PRINTED IN JAPAN 93142112-06

AMENDMENT HISTORY
MDC-1810P/1820P Series OPERATION MANUAL
Doc No: 93142112
No. Document No & Rev No. Date(D/M/Y) Amendments
0 93142112-00 10/12/03 First issue
1 93142112-01 14/01/04 Chapter 3, para 3.6: Entered the compass safe
distance for Display and Operation unit.
Chapter 5, para 5.2: Deleted “MAP” from the key
switch, which was mistakenly printed.
2 93142112-02 25/02/04 Preface: Added “Operation of AIS.” Chapter 1, 2, 4:
Amended the power cable type name. Chapter 3:
Added AIS spec. Chapter 6: Added the descriptions
for AIS display, operation, etc. Chapter 4: Reedited
4.6.4 by adding 4.6.4.1 and 4.6.4.2 for Display
installation methods. Reedited Para. 4.7.3 to add
more details for GAIN/STC settings. Chapter 10:
Added the AIS sentence.
3 93142112-03 01/04/04 Chapter 2, 4: Added Ferrite Core.
4 93142112-04 01/06/04 Chapter 4 Added "Auto Tune Adjustment".;Cover
Address
5 93142112-05 25/08/04 Cover
6 93142112-06 08/09/04 Chapter6.4.1.7SERIAL…Chapter10.4.5 pinNO
7
8
9
10
Amendment policy
When any change is applied in the document, only the document number of the relevant sheet(s) and
cover sheet are modified and the rest of the sheets are not changed. The document number is shown in
the footer area, right or left bottom of each sheet.
○
c2003 2004 Koden Electronics Co.,Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, translated in any form by any means without
the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in this
publication are subject to change without notice. KODEN assumes no responsibility for any errors,
incidentals or consequential damages caused by misinterpretation of the descriptions contained in this
publication.

MDC-1810P/1820P Series Preface
Operation Manual
Preface
Safety Notices
OPERATOR SAFETY
Watch for the rotating antenna:
The radar antenna will start to rotate without notice. For your safety, keep away from
the area in the vicinity of the radar antenna.
Be aware of RF Radiation Hazard:
The active radar antenna radiates powerful RF energy. Continuous exposure to RF
energy may cause harmful effects to the human body. It also causes Cardiac
Pacemaker to malfunction. A person who uses a Cardiac Pacemaker should under no
circumstances be exposed to RF radiation.
Most countries accept that RF power density levels below 100 W/m2cause no
significant RF hazard.
Distance vs. specified RF Power Density Level
Power / antenna length 100 W/m210 W/m2
12KW / 4 ft Aerial 1.55 m 4.89 m
12 KW / 6 ft Aerial 1.84 m 5.81 m
25KW / 4 ft Aerial 2.45 m 7.73 m
25 KW / 6 ft Aerial 2.82 m 8.91 m
Dangerous HIGH voltage inside:
Life threatening high voltage is present in the antenna and display units. This high
voltage may be present even after the power switch has been turned off. The high
voltage circuits are provided with protection covers and warning labels to avoid
unintentional contact with these sections. For safety reasons, switch the power off
before accessing the internal circuitry and discharge any residual voltages in
capacitors by an appropriate method. Only qualified personnel should attempt these
maintenance procedures.
93142112-02 (1)

Preface MDC-1810P/1820P Series
Operation Manual
MAINTENANCE SAFETY
Beware of residual high voltages:
High voltages may remain in the capacitors and the anode cap on the Cathode Ray
Tube several minutes after you have turned the power switch off. Wait at least five
minutes or discharge them to ground before starting your inspection.
Make sure the main power supply is OFF:
To prevent an electrical injury due to erroneous power switching, make sure that the
main power supply and the system power switch are both OFF. Also attach a safety
label showing that service is in progress.
Avoid inhaling dust:
The dust could be a temporary health hazard. When cleaning inside of the equipment,
avoid inhaling the dust.
Avoid static electricity:
Take care not to damage the ESDs (Electrostatic Sensitive Devices) due to static
electricity from carpet and cloths.
(2) 93142112-02

MDC-1810P/1820P Series Preface
Operation Manual
Various symbols used in this manual
The following symbols are used in this manual. You are requested to be fully aware of the meaning
of each symbol before carrying out inspection and maintenance on this radar system
Warning mark
To handle the equipment ignoring this sign may lead to fatal
damage or injury to human body.
Warning
Alarm mark To handle the equipment ignoring this sign may lead to injury to
human body or damage to the equipment.
Alarm
Caution mark To handle the equipment ignoring this sign may lead to a
malfunction of the equipment.
Caution
Warning High Voltage mark
To handle the equipment ignoring this sign may lead to electrical
shock to human body.
Prohibition mark
This sign indicates that a specified action is prohibited. The
prohibited action will be shown in the vicinity of the mark.
93142112-02 (3)

Preface MDC-1810P/1820P Series
Operation Manual
HOW TO USE THIS MANUAL
Scope of this manual
This manual provides necessary information for installation, operation and
maintenance of MDC-1810P/1820P radar systems.
Organization of this manual
This manual is divided into chapters for quick and easy finding of the information you
require. The titles and contents of each chapter are as follows:
Chapter 1: GENERAL DESCRIPTIONS
- Outline of the equipment
- Equipment category
- EMC compliance statement
- System configuration
- Software type name used
Chapter 2: EQUIPMENT SUPPLIED
- Standard equipment list
- Spare parts list
- Installation material list
- Optional items
Chapter 3: TECHNICAL SPECIFICATIONS
- Antenna specification
- Display specification
- ATA Specification
- Serial data and sentence used
- Power supply
- Compass Safe Distance
- Environmental specification
- Mechanical specification
(4) 93142112-02

MDC-1810P/1820P Series Preface
Operation Manual
Chapter 4: INSTALLATION
- Installation considerations
- Unpacking each component of the system
- Inspection of each component unit and accessories
- Setting the units
- Cable routing and connections
- Installation procedure
- Setting up after installation
- Setting up option
Chapter 5: BASIC OPERATION
- Introduction
- Control panel layout
- Operating controls
- Getting started
- Basic radar operations
Chapter 6: USING THE MENU
- RADAR MENU
- DISP MENU
- ADJUST MENU
- SYSTEM MENU
- MAINTENANCE MENU
- Operation of EPA
- Operation of ATA
- Operation of AIS
Chapter 7: GRAPHIC DISPLAYS
- Entering Graphic Mode
- Selecting the Graphic Display/DISPLAY ITEM SELECT MENU
- Registering or modifying the NAVLINE data / NAVLINE DATA INPUT
MENU
93142112-02 (5)

Preface MDC-1810P/1820P Series
Operation Manual
Chapter 8: TROUBLE SHOOTING AND ON BOARD SERVICING
- Information required for service
- Self diagnosis functions provided
- Trouble shooting
- On board servicing
Chapter 9: MAINTENANCE
- Periodic inspection and cleaning
Chapter 10: TECHNICAL REFERENCES
- Serial input data sentence detail
- Tracking data output sentence detail
- Radar output sentence detail
- Interface requirements
(6) 93142112-02

MDC-1810P/1820P Series Chapter 1
Operation Manual General Descriptions
Chapter 1
General Descriptions
Contents
Page No.
1.1 Outline of the equipment ....................................................... 1-1
1.2 Equipment category ............................................................... 1-1
1.3 EMC compliance statement ................................................... 1-1
1.4 System configuration............................................................. 1-2
1.5 Software type name used ...................................................... 1-2
93142112-02 Contents

MDC-1810P/1820P Series Chapter 1
Operation Manual General Descriptions
Chapter 1 General Descriptions
1.1 Outline of the equipment
The MDC-1810P/1820P series of radar is designed and manufactured to meet the
carriage requirement of the latest IMO/SOLAS regulations and its harmonized IEC
technical standards, shown below.
 IEC 60945 4th Edition 2002, General
 IEC 60936-1: Ship borne Radar
 IEC 60872-2 and 3: EPA and ATA
 IEC 61162-1: Digital Interface
The equipment is composed of two units, the antenna and the display. The antenna
unit comprises a 4 ft or 6 ft aerial, which is mounted on the transceiver unit of either 12
kW (For MDC-1810P) or 25 kW (For MDC-1820P) type. The 4 foot and 6 foot aerials
are encapsulated in a water-sealed, durable plastic case. The transceiver unit is
contained in a waterproof aluminum case. The display unit has a drip-proof cabinet
made of aluminum, and has a 250 mm diameter effective screen shown on the high
resolution 18-inch diagonal color LCD.
1.2 Equipment category
The MDC-1810P/MDC-1820P series of radar is composed of the component units in
the following categories, specified in the IEC 60945 4th edition, Para 4.4.
Antenna Unit (Type RW701A-04/06 + RB718AP/719AP):
Exposed to the weather (formerly Class X)
Display Unit (Type MRD-100P):
Protected from the weather (formerly Class B)
Operation Unit (Type MRO-100):
Protected from the weather (formerly Class B)
1.3 EMC compliance statement
This series of equipment has been tested and verified by the CETCOM Germany,
according to the IEC 60945 4th Edition, in terms of Electro Magnetic Compatibility and
atmospheric durability against the maritime environment.
93142112-02 1-1

Chapter 1 MDC-1810P/1820P Series
General Descriptions Operation Manual
1.4 System configuration
The MDC-1810P and MDC-1820P radar sets are configured as follows:
Refer to Figure 1 for the system configuration of this series.
MDC-1810P
Component Unit Sub-unit Type name
Antenna Unit Not assigned
Aerial, 4-foot RW701A-04
Aerial, 6-foot RW701A-06
Transceiver RB718AP (12 kW)
Display Unit MRD-100P
Operation Unit MRO-100
MDC-1820P
Component Unit Sub-unit Type name
Antenna Unit Not assigned
Aerial, 4-foot RW701A-04
Aerial, 6-foot RW701A-06
Transceiver RB719AP (25 kW)
Display Unit MRD-100P
Operation Unit MRO-100
1.5 Software type name used
The MDC-1810P series of radar uses the following type of software:
Software Type Application
KM-D56C Radar logic board
KM-D62A Gyro/Log Interface
KM-D07C ATA (Option: MRE-300)
KM-D63A AIS Interface(Option: AIS-100)
1-2 93142112-02

MDC-1810P/1820P Series Chapter 1
Operation Manual General Descriptions
A
NTENNA UNIT
A
ERIAL Type RW701A-04 (4ft) or RW701A-06 (6ft)
TRANSCEIVER Unit
Type RB718AP (12 kW) or RB719AP (25 kW)
DISPLAY UNIT
Type MRD-100P
Serial Data IN/OUT
DC mains
21.6 – 41.6 VDC
A
C mains
100/115/200/230 VAC
This section is built into the Display unit
Data 1 (TX/RX)
Data 2 (RX)
Data 3 (RX)
Gyro/Log Interface
Type KSA-08A
DC Power cable
Type
CW-256-2M
Length: 2 m
A
C Power Cable
Type: VV2D8-3M
Length: 3 m
A
IS Interface
Type AIS-100
(Option)
ATA Type MRE-300
(Option)
OPERATION UNIT
Type MRO-100
AC/DC Rectifier
Type PS-010
Connecting Cable
Type
242J159098B-15M
Length: 15 m
A
IS Transponde
r
(Option)
Bearing Signal
LOG Signal
Gyro Power Supply
(11-40 VDC)
Figure 1.1 System configuration of MDC-1810P / MDC-1820P series of radar
93142112-02 1-3

MDC-1810P/1820P Series Chapter 2
Operation Manual Equipment Supplied
Chapter 2
Equipment Supplied
CONTENTS
Page No.
2.1 Standard equipment list......................................................... 2-1
2.2 Spare parts list ........................................................................ 2-2
2.3 Installation material list.......................................................... 2-2
2.4 Optional items......................................................................... 2-2
93142112-02 Contents

MDC-1810P/1820P SERIES Chapter 2
Operation Manual Equipment Supplied
Chapter 2 Equipment Supplied
2.1 Standard equipment list
MDC-1810P
No. Item name Type name Remark Weight/length Q’ty
1 Aerial RW701A-04/06 4 ft / 6 ft 6 kg / 8 kg 1
2 Transceiver unit RB718AP 12 kW 17 kg 1
3 Display unit MRD-100P 12 kg 1
4 Operation unit MRO-100 2 kg 1
5 Hood MRH-180 Not specified 1
6 Gyro/Log Interface KSA-08A Built into the display unit 1
7 Connecting cable 242J159098B-15M With connectors attached
on both ends 15 m 1
8 Power cable CW-256-2M Cable with 5-pin connector
on one end and fly leads on
the other end
2 m 1
RF725A/MRD-100.SP
9 Spare parts
RF725A/MRD-100.KIT
See spare parts list Not specified 1 set
10 Installation materials M12-BOLT.KIT See installation material list Not specified 1 set
11 Documents MDC-1800PSER.OM.E Operation manual Not specified 1
MDC-1820P
No. Item name Type name Remark Weight/length Q’ty
1 Aerial RW701A-04/06 4 ft / 6 ft 6 kg / 8 kg 1
2 Transceiver unit RB719AP 25 kW 21 kg 1
3 Display unit MRD-100P 12 kg 1
4 Operation unit MRO-100 2 kg 1
5 Hood MRH-180 Not specified 1
6 Gyro/Log Interface KSA-08A Built into the display unit 1
7 Connecting cable 242J159098B-15M With connectors attached
on both ends 15 m 1
8 Power cable CW-256-2M Cable with 5-pin connector
on one end and fly leads on
the other end
2 m 1
RF725A/MRD-100.SP
9 Spare parts
RF725A/MRD-100.KIT
See spare parts list Not specified 1 set
10 Installation materials M12-BOLT.KIT See installation material list Not specified 1 set
11 Documents MDC-1800PSER.OM.E Operation manual Not specified 1
93142112-03 2-1

Chapter 2 MDC-1810P/1820P Series
Equipment Supplied Operation Manual
2.2 Spare parts list
MDC-1810P/1820P (Common use)
No Description Rating Remark Shape (Dimensions) Q’ty Use
1 Fuse 15A Normal blow Tubular (
φ 6.3 x 32) 1 Main power supply
2 Fuse 5A Normal blow Tubular (
φ 5 x 25) 1 Motor power supply
3 Fuse 0.3A Normal blow Tubular (
φ 5 x 25) 1 High voltage power supply
4 Motor brush 24Z125209B Not specified Not specified 1 set Antenna motor
2.3 Installation material list
MDC-1810P/1820P (Common use)
No Description Rating Q’ty Use
1 Hexagonal bolt B12X55U 4 Antenna unit
2 Nut N12U 8 Antenna unit
3 Plain washer 2W12U 8 Antenna unit
4 Spring washer SW12U 4 Antenna unit
5 Ferrite core E04RA400270150 1 Display unit
2.4 Optional items
MDC-1810P/1820P (Common use)
No. Description Rating Remark Weight/length/Q’ty
1 ATA MRE-300 Built into the display unit Not specified
2 AIS Interface AIS-100 Built into the display unit Not specified
CW-387-5M For AIS I/F. One end with
8-pin connector and flying
leads on the other end
5 m
CW-376-5M For Navigator. One end with
a 6-pin connector and flying
leads on the other end
5 m
CW-561-10M For Remote Display. With
12-pin connector on both
ends
10 m
3 Connecting cable
CW-560-2M With D-sub connector on
both ends 2 m
4 Rectifier PS-010 For Remote Display. With
12-pin connector on both
ends
3.5 kg
5 AC power cable VV-2D8-3M With D-sub connector on
both ends 3 m
242J159098C-20M Connectors attached on
both ends 20 m
242J159098D-30M 30 m
6 Connecting cable
in extra length
242J159098E-60M
Connectors attached on
both ends Length customer
specified: 60 m max.
2-2 93142112-03

MDC-1810P/1820P Series Chapter 3
Operation Manual Technical Specification
Chapter 3
Technical Specification
Contents
Page No.
3.1 Antenna specification ............................................................ 3-1
3.2 Display specification.............................................................. 3-1
3.3 ATA specification (Option) ..................................................... 3-2
3.4 AIS specification..................................................................... 3-3
3.5 Serial data and sentence used .............................................. 3-3
3.6 Power supply .......................................................................... 3-3
3.7 Compass safe distance.......................................................... 3-3
3.8 Environmental specification.................................................. 3-4
3.9 Mechanical specification ....................................................... 3-4
93142112-02 Contents

MDC-1810P/1820P Series Chapter 3
Operation Manual Technical Specifications
Chapter 3 Technical Specifications
3.1 Antenna specification
Aerial length 4 feet / 6 feet
Peak power output 12 kW (For MDC-1810P) / 25 kW (for MDC-1820P)
Frequency 9410 +/- 30 MHz
Beam width Horizontal 1.8o/ 1.2o
Vertical 22
o
Side lobes Within +/- 10oBetter than –23dB
Outside+/-10
oBetter than –30 dB
Rotation 24 r.p.m.
Transmission pulse width 12 kW 25 kW
S (Short pulse) 0.08 µs / 2000 Hz 0.08 µs / 2000 Hz
M1 (Medium 1 pulse) 0.25 µs / 1500 Hz 0.3 µs / 1300 Hz
M2 (Medium 2 pulse) 0.5 µs / 1000 Hz 0.6 µs / 800 Hz
L (Long pulse) 1.0 µs / 500 Hz 1.2 µs / 500 Hz, 400Hz(96NM)
IF center frequency 60 MHz
IF bandwidth 15 MHz (S, M1) / 3 MHz (M2, L)
Noise figure Better than 6 dB
Operation in wind 100 knots as relative
Water proofing grade IPX6 (IEC60529)
3.2 Display specification
Picture tube 18 inch high resolution color LCD
Effective diameter 269 mm
Resolution 1280 x 1024 pixels
Video level 8 levels
Presentation mode Head-up, north-up, course-up and true motion
Range scale (NM) 1/8 1/4 1/2 3/4 1.5 3 6 12 24 48 64 72 (12 kW) 96 (25kW)
Rings interval (NM) 1/16 1/16 1/8 1/4 1/2 1 2 4 8 16 12 (12 kW) 16 (25kW)
Off-centering Sweep origin can be moved to any point within 2/3 of the screen
radius.
Trail display interval Every scan, 15 sec, 30 sec, 1 min, 3 min, 6 min, 12 min and OFF
Alarm Entry alarm [alarm range (Minimum 0.5 NM), depth and bearing
can be varied]
EPA Up to 10 targets can be plotted, 5 points for one target each
93142112-02 3-1

Chapter 3 MDC-1810P/1820P Series
Technical Specifications Operation Manual
(Display specification)
ATA (Option) Display of acquire/track data of up to 10 targets and
Guard Zone are available. Display of guard zone is
also available (any alarm range, width and bearing can
be set).
AIS (Option) Display of AIS data of up to 20+20 targets.
Data available for EPA and ATA Speed, course, CPA, TCPA, distance, bearing and age
(time elapsed since the first plot, applicable to EPA
only).
Minimum detectable range 20 meters at 1/8 nm range
Range resolution 20 meters at 1/8 nm range
Range data accuracy 70 meters or 1% of the range scale selected,
whichever is the greater.
Bearing data accuracy +/-1omaximum
Navigation data display Data of own ship’s position (latitude/longitude)
3.3 ATA specification (Option)
Acquisition Manual
Tracking Automatic
Number of targets tracked Up to 10 targets
Numerical data output Distance, bearing, speed, course, CPA and TCPA
Alarm Collision alarm and lost alarm
On screen display Symbols (acquired target, tracked target, target with
data display and lost target), target number and
vectors.
Display mode Relative and True
Tracking distance range Up to 40.0 nm
ATA data output To be taken via the DATA 1 connector on the display
rear panel.
Signal level: RS422
Data format: IEC1162-1
3-2 93142112-02

MDC-1810P/1820P Series Chapter 3
Operation Manual Technical Specifications
3.4 AIS specification (Option)
Number of targets displayed Up to 20 activated targets and 20 sleeping targets
Numerical data indication MMSI, CPA, TCPA, CSE/COG, STW/SOG
On screen display Symbols, target number and vectors.
Indication limit range 1.0 to 6.5 nm
AIS data input To be taken via the AIS connector on the display rear panel.
Signal level: RS422
Data format: IEC 61162-2
Formatter: ALR, VDO, VDM
3.5 Serial data and sentence used
Serial data: IEC 61162-1
Sentence: BWC, GGA, GLC, GLL, HDT, RMB, RTE, VBW, VDR, VHW, VTG,
WPL
3.6 Power supply
Mains Input Voltage: 24 VDC / 32 VDC
Input Voltage Tolerance: 21.6 VDC – 41.6 VDC (24 V/32 V, -10%, +30%)
Input Power: 170 W nominal at 24 VDC
Transient Protection:
To the requirements of IEC 60945 4th Edition.
Reversed polarity protection: Protected by the Main Fuse.
AC Operation
Rectifier Unit Type PS-010 is required.
Input voltage range: 115/230 VAC
Input voltage tolerance: +/- 10%
Input voltage frequency range: 47 to 63 Hz
Input Power: 220 W
3.7 Compass safe distance
Component Unit Type Name Standard Steering
Antenna RB718AP/RW701A-04 1.40 m 0.95 m
RB718AP/RW701A-06 1.40 m 0.95 m
RB719AP/RW701A-04 1.40 m 0.95 m
RB719AP/RW701A-06 1.40 m 0.95 m
Display MRD-100P 1.60 m 1.15 m
Operation MRO-100 0.60 m 0.40 m
93142112-02 3-3

Chapter 3 MDC-1810P/1820P Series
Technical Specifications Operation Manual
3.8 Environmental specification
To the requirements of IEC 60945 3rd Edition. The measure environmental
specifications are as follows:
(1) Temperature and humidity
Operating temperature Storage temperature Humidity
Antenna -25oC - +55oC +70oC 93%+/-3% at +40oC
Display -15oC - +55oC +55oC 93%+/-3% at +40oC
(2) Vibration
2-5Hz up to 13.2 Hz: Amplitude +/-1mm +/-10% (Maximum acceleration 7m/s2at
13.2Hz)
13.2 Hz up to 100Hz: Maximum acceleration 7 m/s2constant
3.9 Mechanical specifications
Dimensions: W (Width) x Depth x Height, Unit in mm
Weight: Unit in kg
Antenna unit:
RB718AP: 325 x 390 x 450, 23 kg (for 4ft system), 25 kg (for 6ft system)
RB719AP: 325 x 470 x 450, 27 kg (for 4ft system), 29 kg (for 6ft system)
Aerial Swing circle: 1346 for 4 ft, 1970 for 6 ft
Display unit: 450 x 390 x 366, 12 kg
Operation unit: 354 x 130 x 49, 2 kg
3-4 93142112-02
