Lucas BBQ GPC2700JD-Grey User manual

GPC2700JD-Grey
Owner’s Manual 0
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC
fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, PLEASE CALL 1-877-630-5396
(TOLL-FREE), 10:00 A.M. – 19:00 P.M. (EST),
MONDAY-FRIDAY.
WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or
property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
Service Center: 1-877-630-5396
TG 1201 2502
NG 510957
The Deck Grill

GPC2700JD-Grey
Owner’s Manual 1
Grill Operation 1-2-3
Before Grilling
Step 1 Keep your grill a safe distance away from your property.
Step 2 Always perform a leak test on all connections and hoses.
Step 3 Keep children away from the grill.
During Grilling
(To avoid tripping safety valves, please follow these instructions carefully!)
Step 1 First open lid and turn gas tank on slowly.
Step 2 Turn only one knob on at a time when lighting up the grill.
Step 3 Use protective gloves when grill gets hot.
Step 4 Never leave a lit grill unattended.
After Grilling
Step 1 Always burn grill for 10-15 minutes to burn off food residues after use.
Step 2 Wait until the grill is completely cooled before closing lid.
Step 3 Clean up grease build-up to avoid grease fire and cover your grill to prevent rust.
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to
use this gas barbecue grill to prevent possible bodily injury or property damage.
NOTE : This grill must be used with propane gas only (propane gas cylinder not included).
Installer
: Leave this manual with the consumer.
Consumer : Retain this manual for future reference.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapor in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vi cinity of this or any
other appliance.
DANGER:
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.

GPC2700JD-Grey
Owner’s Manual 2
Table of Contents
For Your Safety.................................................................................................................3
Package Contents.............................................................................................................5
Hardware Contents ...........................................................................................................6
Assembly Instructions .....................................................................................................7
Operating Your Grill .......................................................................................................12
Connecting & Disconnecting The Gas Cylinder ..........................................................13
Checking for Leaks ........................................................................................................13
Lighting Your Grill .........................................................................................................14
Excess Flow Safety Valve Reset Procedure ................................................................15
Care and Maintenance ...................................................................................................16
Troubleshooting ............................................................................................................17
Warranty Program ..........................................................................................................18

GPC2700JD-Grey
Owner’s Manual 3
For Your Safety
Dear Valued Customer,
Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly
instructions, suggestions for
grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of
your grill. Our expert staff strives to provide you with an easy-to-assemble product. Should you have any questions or
problems with this product, please call
our customer service department at 1-877-630-5396
10:00 am –
7:00 pm (EST), Monday through Friday.
NOTE: The use and installation of this product must conform to local codes. In the absence of local codes, use the
National Fuel Gas Code, ANSI Z223.1/ NFPA54. Reference to Natural Gas and Propane Installation code CSA B149.1 or
Propane Storage and Handling code B149.2
IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE.
Safety First!
Read and understand all warnings and precautions prior to operating your grill.
WARNING:
1.
This grill is for outside use only. It should not be used in a building, garage or any other enclosed area.
2. The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or
safely
operate this appliance.
3. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.
4. Always place your grill on a hard and level surface far away from combustible materials and structures. An asphalt or
blacktop surface may not be acceptable for this purpose.
5. Do not leave a lit grill unattended.
6. Keep children and pets away from the grill at all times.
7. This is not a tabletop grill. Do not place this grill on any type of tabletop surface.
8. Do not use the grill in high winds.
9. This grill must be used with propane gas only (propane gas cylinder not included).
10. Do not attempt to attach this grill to the self-contained propane system of a camper , trailer, motor home or house.
11. Do not use charcoal or lighter fluid.
12. Do not use gasoline, kerosene or alcohol for lighting. The LP-gas supply cylinder must be constructed and
marked
in accordance with the specifications for propane gas cylinders of the U.S. Department of Transportation
(DOT) CFR
49 or National Standard of Canada, CAN/CSA B339.
13. This outdoor gas appliance is not intended to be installed in or on recreation vehicles and / or boats.
14. Do not attempt to move the grill while it is lit.
15. Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
16. Keep combustible items and surfaces at least 50 inches away from the grill at all times. DO NOT use this gas grill
or any
gas product under any overhead enclosure or near any unprotected combustible constructions.
17. Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
18. Do not attempt to use or assemble with missing or damaged parts. Contact customer service for replacement parts.
CAUTION-Prevention of Burns
1.
To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or unless
you
are wearing protective gear such as pot holders, protective gloves or mittens.
2.
Do not alter the grill in any manner.
3.
Clean and inspect the hose before each use. If there is evidence of abrasion, wear, cuts or leaks, the hose must be
replaced prior to
operation. The replacement hose assembly should be in accordance with the manufacturer’s
specifications.
4.
Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
5.
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could
open
the relief valve and allow gas to escape.
Safe Locations For Use Of This Outdoor Grill
DANGER:
Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational
vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation.

GPC2700JD-Grey
Owner’s Manual 4
WARNING:
Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or
gazeboes).
Always confirm that this grill is not positioned under the overhang of a house, a garage or other structure before lighting it. An
overhang will serve to deflect flare-ups and radiated heat into the structure itself, which could result in a fire.
Always confirm that this grill is positioned more than 50 inches (127cm) away from any
building or combustible materials or surface before lighting it, and that no gasoline
or other volatile substances are stored in the vicinity of this grill.
(See diagram to right). The temperature of a grease fire or of the radiated heat
might otherwise be sufficient to ignite nearby combustible or volatile substances.
Always locate this grill where there will be ample combustion and ventilation air,
but never position it in the direct path of a strong wind.
Never allow the grill to operate while unattended to prevent uncontrolled grease fires
from erupting.
Never attempt to move this grill while it is in operation or while it is still hot to prevent possible personal injury.
Never store or use gasoline or other flammable or volatile substances in the vicinity of this grill or in the vicinity of any other
heat-generating appliance because of the danger of starting a fire.
Always confirm that the installation of this grill conforms with the requirements of all local codes or, in the absence of
applicable local codes, with either the National Fuel Gas Code, ANSI Z223. NFPA 54 or CAN/CGA-B149.2.
DANGER – Gas Safety
Liquefied propane (LP) gas is flammable and hazardous if handled improperly. Become aware of its characteristics before
using any propane product.
 Propane Characteristics: Flammable, explosive under pressure, heavier than air and settles in pools in low areas.
 In its natural state, propane has no odor. For your safety, an odorant has been added.
 Contact with propane could burn to the skin.
 This grill is shipped from the factory for propane gas use only.
 Never use a propane cylinder with a damaged body, valve, collar or footing.
 Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier.
CAUTION:
 It is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
 Inspect the grill before each use .
Step 1. Inspect all hoses and connections and make certain they are secure.
Step 2. Check and clean the burner venturi tubes for insects and insect nests by removing the burner and inserting a bottle
brush cleaner into each tube to make sure the passage is clear.
*** A clogged tube can lead to a fire beneath the grill. ***
Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube.
General Information
1. A propane gas cylinder is required for operation.
2.
This gas grill is NOT intended for commercial u se.
50 inches
50 inches

GPC2700JD-Grey
Owner’s Manual 5
Package Contents
Part Description QTY Part Description QTY
A
Bottom panel
1 PC
Q
Grill body
1 PC
B
Left lower frame
1 PC
R
burner
1 PC
C
Front lower panel
1 PC
S
Grease cup
1 PC
D
Right lower frame
1 PC
T
Lid
1 PC
E
Wheel axle
1 PC
U
Lid handle
1 PC
F
Wheel
2 PCS
V
Right side shelf
1PC
G
Wheel cap
2 PCS
W
Left side shelf
1 PC
H
Left upper frame
1 PC
X
Heating plate support
2 PCS
I
Front upper panel
1 PC
Y
Heating plate
1 PC
J
Right upper panel
1PC
Z
Cooking grid
1PC
K
Back panel
1 PC
AB
Warning rack
1 PC
L
Igniter
1 PC
AC
Cylinder clip
1 PC
M
Regulator & Valve assembly
1 PC
AD
Heat insulation panel 1 PC
N
Control panel
1 PC
AE
Heat insulator
1 PC
O
knob
2 PCS
AF
bezel
2PCS
P
Body Hinge
1 PC
AG
Right side handle
1PC

GPC2700JD-Grey
Owner’s Manual 6
Hardware Contents
AA
24pcs
KK
8pcs
BB
2pcs
LL
8pcs
CC
4pcs
MM
8 pcs
DD
30pcs NN
2pcs
EE
24pcs
OO
2pcs
FF
4pcs
PP
2pcs
GG
6pcs
QQ
2pcs
HH
2pcs
RR
1pc
II
8pcs
JJ
8pcs
Hardware listed above is not scaled to exact size.
(A screwdriver is required for assembly and is included for your convenience).
Bolt M6
x
15
M5 Flat Washer
Bolt M6 x 10 Heat Insulation
Washer 5mm
Bolt
M6 x 50
Lock Washer
M6
Small Wing Nut
M5
Heat resistant
washer 30mm
M6 Flat Washer Hair Pin
Bolt M5 x10 Pin
M6 Flat Washer Wrench
Wheel Nut
Bolt M5 x 10
Lock Washer
M5
Screwdriver

GPC2700JD-Grey
Owner’s Manual 7
Assembly Instructions
Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is
fully assembled, go back and check to make certain all the bolts are secure. Tighten again
using the screwdriver provided if
necessary.
Estimated assembly
time: 30 minutes.
Step 1
a) Align the holes on the bottom panel (A) with the holes
on the left lower frame (B) and right lower frame (D).
b) Screw a bolt (CC) along with a lock washer (DD) and
a flat washer (GG) into each pre-drilled hole. Tighten
by screwdriver until secure.
c) Align the holes on the front lower panel (C) with the
holes on the left lower frame (B) and the right lower
frame (D). Screw a bolt (AA) along with a lock washe
r
(DD) and a flat washer (EE) into each pre-drilled hole.
Tighten by screwdriver until secure.
d) Align the hole on the wheel (F) with the hole on left
lower frame (B), insert the wheel axle (E) into the
hole. Then seal with a wheel nut (HH).
e) Cover a wheel cap (G) on each wheel.
Step 2
a) Insert the feet of the right upper frame (J) into
the hole on the right lower frame.
b) Insert the feet of the left upper frame (H) into
the hole on the left lower frame.

GPC2700JD-Grey
Owner’s Manual 8
Step 4
a) Insert the valve shafts of the regulator
& valve assembly (M) into the
pre-drilled holes on the control panel
(N), insert the bezels (AF) onto the
shafts then screw a bolt (II) into each
holes, tighten bolts by screwdriver until
secure.
b) Insert the Knobs (O) on the valve
shafts.
a) Insert the igniter (L) into the pre-drilled
hole in the control panel (N). Tighten
by hand until secure.
b) Align the holes on the control panel
(N) with the holes on the upper frame,
and then screw a bolt (AA), along with
a lock washer (DD) and a flat washer
(EE) into each pre-drilled hole. Tighten
by hand until secure.
c) Tighten all bolts by screwdriver until
secure.
Step 3
a) Place the front upper panel (I) on the front lower
panel. Align the holes on the front upper panel (I)
with the holes on the cart frame, screw a bolt (AA)
along with a lock washer (DD) and a flat washer
(EE) into each pre-drilled hole. Tighten by
screwdriver until secure.
c) Align the holes on the cart back panel (K) with the
holes on the cart frame and screw a bolt (AA) along
with a lock washer (DD) and a flat washer (EE) into
each pre-drilled hole.
b) Tighten all bolts by screwdriver until secure.

GPC2700JD-Grey
Owner’s Manual 9
Step 5
d) Align the holes on the heating plate support (X) with
the holes on the grill body (Q), then screw a bolt
(FF) from the outside of grill body into each
pre-drilled hole. Seal with a heating insulation
washer (LL), a flat washer (KK) and a lock washer
(JJ) onto each bolt, then screw a wing nut (MM)
onto each bolt. Tighten by hand until secure.
e) Tighten all bolts by screwdriver until secure.
Step 6
a) Align the holes on body hinge (P) with the
holes on the grill body, then screw a bolt
(II), along with a heat insulation washer
(LL) into the pre-drilled hole, and then seal
with a flat washer (KK), a lock washer(JJ)
and a wing nut (MM). Tighten by hand until
secure.
b) Align the holes on grill body with the holes
on the upper frame, then screw a bolt (AA),
along with a lock washer (DD) and a flat
washer (EE) into each pre-drilled holes.
Tighten by hand until secure.
c) Tighten all bolts by screwdriver until
secure.
Step 7
a) Put the burner (R) inside the grill body. Make certain the
valve nozzle is inserted into the burner venturi tube well.
b) Align the holes on heat insulation panel (AE) with the
holes under the bottom of grill body.
c) Screw a bolt (BB), along with a lock washer (DD) and a
flat washer (GG) through the heat insulation panel, the
bottom of grill body and into the burner. Tighten by hand
until secure.
d) Connect the ignition wire with the igniter.
e) Tighten all bolts by screwdriver until secure.
f) Hook the grease cup (S) under the grill body.

GPC2700JD-Grey
Owner’s Manual 10
Step 8
a) Align the holes on the heat insulation panel (AD) with
the holes on the lid (T).
b) Insert the pre-assembled bolt in lid handle (U) with a
heat resistant washer (NN) through the holes on lid (T)
and the heat insulation panel (AD), then seal with a flat
washer (EE), a lock washer (DD) and a bolt (AA).
c) Tighten all bolts by hand until secure.
Step 9
a) Put the lid upon the grill body.
b) Align the holes on the lid hinge with the holes on the grill body
hinge, then insert the pin (PP) into the hinge hole.
c) Insert a hair pin (OO) into the hole on each end of the pins to
fasten the lid and grill body.
Step 10
a) Align the holes on the right handle (AG) with the
hole on the right side shelf (V), then screw a bolt
(AA), a flat washer (EE) and a lock washer (DD)
into each pre-drilled hole. Tighten by hand until
secure.
b) Loosen the four pre-installed bolts on the right
upper frame (J) and allow 1/4 bolt’s length to
extend from right upper frame.
c) Align the holes on the right side shelf (V) with the
bolts extended from the right upper frame. Push
down the right side shelf until it locks into place.
d) Repeat the procedure for the assembly of left
side shelf (W).
e) Tighten all bolts by screwdriver until secure.
8 x pre-installed bolt

GPC2700JD-Grey
Owner’s Manual 11
Step 11
a) Put the heating plate (Y) onto the heating plate
support.
b) Put the cooking grid (Z) onto the heating plate.
c) Insert the feet of warming rack (AB) into the holes
on the top lid
Step 12
a) Put the gas tank on the tank
support.
b) Connect the regulator with the
tank. (Please see the procedure
on page 13)
c) Insert the tank clip (AC) into the
holes on the bottom panel and clip
the tank using the tank clip.

GPC2700JD-Grey
Owner’s Manual 12
Fully Assembled View
Operating Your Grill
CAUTION:
Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of
unauthorized parts
can create an unsafe condition and environment.
The propane gas supply cylinder used
must be constructed and marked in accordance with local codes, with either the
Natural Fuel Gas Code, ANSI Z223. NFPA54 or CAN/CGA-B149.2
. Only cylinders with a listed overfill prevention device
(OPD) and marked
“propane” may be used. Cylinders with an OPD will have valve handles with three “lobes” (prongs).
Use only the pressure regulator and hose assembly supplied with the outdoor cooking gas appliance must be used. Replacement
pressure regulators and hose assembly must be those specified by the outdoor cooking gas appliance manufacturer.
Use only
20-pound cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking
appliances.
The cylinder must include a collar to protect the cylinder valve. Do not drop or handle the cylinder roughly. If the
appliance is
not in use, disconnect the cylinder.
Storage
of the appliance indoors is permissible ONLY if the cylinder is disconnected and removed from the appliance. Store
cylinder
outdoors and out of the reach of children. Do not store the cylinder in a building, garage or other enclosed areas.
Never store your cylinder
where temperatures can reach over 51.7 ℃ .
Before connecting, make sure there is no
debris caught in the head of the gas cylinder, regulator valve or in the head of the
burner and burner ports. Connect regulator valve and hand tighten firmly. Disconnect the propane cylinder from the regulator
valve when the
grill is not in use. DO NOT obstruct the flow of combustion air or ventilation air to the grill. Arrange the propane
cylinder
for vapor withdrawal and equipped with a listed overfill prevention device (OPD).
Left Side
Right Side

GPC2700JD-Grey
Owner’s Manual 13
DANGER:
A fire causing death or serious injury may occur if the following is not followed exactly:
Never store or use gasoline or other volatile substances in the vicinity of this grill .
Never store a spare propane cylinder in the vicinity of this grill, or in the vicinity of another potential heat source.
Never fill the propane cylinder beyond 80% full.
This grill is designed to connect to a standard 20 lb L.P. cylinder only, please refer to the Step 12 of assembly instructions for the
installation.
WARNING:
Don’t store spare gas cylinder in or near grill.
Connecting & Disconnecting The Gas Cylinder
LP (Propane) Gas Supply Connection & Disconnecting
1. Always place the propane cylinder on the tank holder under the cart.
2. Always confirm that all burner control knobs are in the OFF position before activating the gas supply.
3. Before connection, be sure that there is no debris caught in the head of the gas cylinder, head of
the regulator valve, or in the head of the burner and burner ports.
4. Always connect the gas supply regulators as follows:
Insert the nipple of the valve coupling into the tank valve and tighten the connection collar
by turning it clockwise with one hand while holding the regulator with the other hand.
(See diagram to right.)
5. Disconnect the propane cylinder from the regulator valve when the grill is not in use.
6. Always confirm that all burner control knobs are in the OFF position before disconnecting the gas supply.
7. Before disconnecting, be sure that the tank valve is in OFF position.
8. Always disconnect the gas supply regulators as followings:
Loosen the connection collar by turning it counter-clockwise with one hand while holding the regulator with the other hand
and take the nipple of the valve out of the tank valve. (See diagram to right)
Do not obstruct the flow of combustion air and ventilation air to the grill.
Keep ventilation openings of the cylinder enclosure free and clear from debris.
9. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Install only the type of dust cap on cylinder valve
outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.
DANGER:
To prevent fire or explosion hazard when testing for a leak:
1. Always perform the “leak test“ as below before lighting the grill and each time the cylinder is connected for use.
2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilated area.
4. Do not use matches, lighters or a flame to check for leaks.
5. Do not use grill until all leaks have been stopped. If you are unable to stop a leak, disconnect the propane supply, call for gas
appliance service or your local propane gas supplier.
Checking for Leaks
1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water.
2.
Make sure control knobs are in the “OFF” position.
3.
Spray some solution on the tank valve up to the regulator connection.
(See diagram to right.)
4.
Inspect the solution at the connections for bubbles. If no bubbles appear, the connection
issecure.
5.
If bubbles appear, you have a leak. Proceed to step 6.
6.
Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured.
7.
Retest with solution.
8.
If you continue to see bubbles, replace the cylinder.

GPC2700JD-Grey
Owner’s Manual 14
Lighting Your Grill
DANGER:
Failure to open lid while igniting the grill’s burners or not waiting five minutes to allow gas to clear if the grill does not light, may
result in an explosion, which could cause serious bodily injury or death.
WARNING:
Never stand with your head directly over the grill when preparing to light the main burners, to prevent possible bodily injury.
Lighting Main Burner
1. Open lid during lighting.
WARNING: Attempting to light the burner with the lid closed may cause an explosion. Make sure there are no
obstructions of airflow to the gas unit. Spiders and insects can nest and clog the burner/venturi tube at the
orifice. A
clogged burner tube can lead to
a fire beneath the appliance.
2.
Make sure all control knobs are in “OFF” position.
3. Turn on gas source or tank valve.
4. Ignite only the burners you wish to use. P ush and turn the knob to “HIGH” then press
the igniter button immediately. The burner should light. If the burner does not light,
repeat 2 or 3 times.
5. If ignition does NOT occur in 5 second turn the burner controls to OFF, wait 5 minutes, and repeat the lighting procedure.
6.
To ignite remaining burners, repeat same procedure.
7. Adjust valve knob(s) to desired cooking temperature.
Using the Lighting Stick to Light the
Main Burners
1.
Insert a match into the end of lighting stick. Light the match.
2. Once lit, place the flame through the hole on grill body to reach the burner ports.
(As the fig shown on right side).
3. Press the valve knob and rotate it counter clockwise to the ‘’HIGH’’ position.
The burner should light immediately. If more than one burner is desired, use the
carry over channel to light each adjacent burner by pressing the valve knob and
rotate it counter –clockwise to the ‘’HIGH’’ position, repeat the same procedure
for
each adjacent burner and continue in sequence until all desired burners are lit .
4. Adjust burners to the desired cooking temperature.
Precautions:
1. After lighting, observe the burner flame. Make sure all burner ports are lit.
2. If the burner flame goes out during operation, immediately turn the gas “OFF”. Open lid
to let the gas clear for at least 5 minutes before re-lighting.
3. Before cooking on the grill for the first time and operate the grill for approximately 15 minutes with the lid closed and the
gas
turned on “HIGH”. This will “heat clean” the internal parts, dissipate odor from the manufacturing process and painted
finish.
4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause
a
fire.
Observe flame
height when lit: Flame should be a blue/yellow color between
1 to 2 inches
high.
2 in.
1 in.
0 in

GPC2700JD-Grey
Owner’s Manual 15
Confirm that the burner is properly lit and that the flame pattern is as desired (see fig. A, B and C below for the proper flame
patterns). If the flame pattern is other than normal, consult the Troubleshooting on page 20 for corrective action.
FIG.A FIG.B FIG.C
Burner installation and adjustment
Flare-ups
“Flare-ups” sometimes occur when food drippings fall onto the hot heat distribution plate or burners and ignite. Some flaring is
normal and desirable as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare-ups is
necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire.
WARNING:
Always monitor the grill closely when cooking and turn the flame level down to LOW or OFF if flare-ups intensify.
Shutting Off Burners
1.
Always turn the valve knob(s)clockwise to the ‘’HIGH’’ position, and then press and turn it to ‘’OFF’’. Never force the knob
without pressing it. This could damage the valve.
2.
Promptly turn the gas supply to the “OFF” position at the propane cylinder.
3.
Close the lid of the grill.
Excess Flow Safety Valve Reset Procedure
● The new regulators are equipped with a safety device that restricts the gas flow in the event of a gas leek. However,
unsafe practices of grill operation could activate the safety device without having a gas leak.
● A sudden shut off of the gas flow typically occurs if you open the LP tank valve rapidly, or if one or more of the burner
control knobs is in an open position when opening the LP tank valve.
● This procedure effective with all LP Tank sizes as well as Natural Gas. When performing the procedure on a Natural Gas
model, simply substitute "Natural Gas valve" for "LP Tank
● To ensure the procedure is safely and successfully performed, please carefully follow these instructions:
1. Close the LP tank valve.
2. Turn all burner control knobs to the OFF position.
3. Disconnect the regulator from the LP tank.
4. Open the lid of the grill.
5. Turn burner control knobs to HIGH.
6. Wait at least 1 minute.
Normal: Soft blue flames with yellow
tips between I inch - 2 inches high. Out of adjustment: Noisy hard blue flames – too much air.
Poor combustion: Wavy, yellow
flames- too little air.
1. Release the screw on venturi tube.
2. Adjust the flame by turning the collar
on head of venturi tube from back side
of the grill and do not take apart the
venturi tube.
3. Tighten the screw and make certain it
is secured.
1. Overlap 14 mm between
venturi tube and nozzle
when assembling.
2. Keep the center line of
venturi tube and nozzle
on one line.
Hook should face upwards.

GPC2700JD-Grey
Owner’s Manual 16
7. Turn burner control knobs OFF.
8. Wait for at least 5 minutes.
9. Re-connect the regulator to the LP tank.
10. Slowly turn the LP tank valve ¼ turn at a time and have the valve all the way open.
11. With the lid open: For grill with ignition button: turn on only ONE burner control knob to the HIGH position. Ignite
the grill by pushing the ignition button. For grill with an automatic ignition: Push down the control knob you want to
light, turn counterclockwise until you hear the ignition click.
12. After the first front burner is lit, turn on the other control knob(s) to the HIGH position. If you have more than two
burners, turn them on only ONE AT A TIME.
13. When all front burners are lit, close the grill lid.
14. Wait for 10-15 minutes; the temperature should reach 400 – 450°F.
WARNING:
The cylinder valve always has to be in the horizontal position, to ensure that only the propane vapor is withdrawn.
CORRECT WRONG WRONG WRONG
Care and Maintenance
IMPORTANT
Always allow to completely cool off before covering your grill to prevent corrosion from condensation.
CAUTION:
All cleaning and maintenance should be done when the grill is cool, with the fuel supply turned off at the control dial and the
propane cylinder disconnected. DO NOT clean any grill part in a self-cleaning
oven. The extreme heat will damage the finish.
Cleaning
Burning off the grill after every use (approx. 15 minutes) will keep excessive food residue from building up. Cleaning the grill
before and after cooking is recommended.
Recommended cleaning
materials :
Mild dishwashing liquid detergent Hot water
Nylon cleaning pad Wire brush
Paper clip Putty knife/scraper
Compressed air
DO NOT use cleaners that contain acid, mineral spirits or xylene.
Outside surfaces
Use a mild dishwashing detergent and hot water solution to clean. Rinse thoroughly with water.
Inside surface
If the inside surface of the grill lid has the appearance of peeling paint, baked on grease has turned to carbon and is flaking off.
Clean thoroughly
with a strong solution of detergent and hot water. Rinse with water and allow it to completely dry.
Interior of grill bottom – Remove residue using brush, scraper and/or cleaning pad. Wash with a dishwashing detergent and
hot
water solution. Rinse with water and let dry.
Cooking Grates – The porcelain grates have a glass-like composition that should be handled with care. Use a mild
dishwashing detergent or baking soda and hot
water solution. Non-abrasive scouring powder can be used on stubborn stains.
Rinse
with water.
Heat Plates – Clean residue with wire brush and wash with soapy water. Rinse with water.
Grease Cup – Periodically empty the grease cup and clean with a dishwashing detergent and hot water solution.

GPC2700JD-Grey
Owner’s Manual 17
Refer to the Excessive flow safety
valve
reset procedure on page 15
Cleaning the Burner Assembly
1. Turn gas off at the control knobs and propane tank.
2. Remove cooking grates and heat plate.
3. Remove grease cup.
4. Remove burner by unscrewing nut from beneath burner “foot” using a screwdriver and pliers.
5. Lift burner up and away from the gas valve orifice.
6. Clean inlet (venturi tube) of burner with small bottle brush or compressed air.
7. Remove all food residue and dirt on outside of burner surface.
8. Clean any clogged ports with a stiff wire (such as an opened paper clip).
9. Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make
certain the gas valve orifices are correctly
positioned, pointing straight into burner inlet (venturi tube). Also, check
position of spark electrode.
Troubleshooting
Problem Possible Cause Prevention/Cure
Tank out of gas
Excess flow safety device may have
been activated
B urner will not light using knobs or
igniter.
Wires and/or electrode covered with
cooking
residue.
Electrode and burners are wet.
Electrode
cracked or broken –
sparks at crack.
Wire loose or disconnected.
Clean wire and /or electrode with
rubbing
alcohol.
Wipe
dry with cloth.
Replace
electrode.
Reconnect
wire or replace electrode/
wire assembl
y
.
Burner will not light using a match.
No gas flow.
Coupling
nut and regulator not fully
connected.
Obstruction of gas flow.
Disengagement
of burner to valve.
Spider
webs or insect nest in venturi.
Burner ports clogged or blocked.
.
Irregular flame pattern, flame does
not
run the full length of burner.
Burner ports are clogged or blocked.
Clean burner ports.
Flame is yellow or orange.
Flame blow out.
New burner may have residual
manufacturing
oils.
Spider webs or insect nest in venturi.
Food residue, grease or seasoning salt on
burner.
Poor alignment of valve to burner
venturi.
High
or gusting winds.
Low
on propane gas.
Excess
flow valve tripped.
Burn grill for 15 minutes with the lid
closed.
Clean venturi.
Clean burner.
A
ssure burner venturi is properly
engaged
with valve.
Turn
front of grill to face wind or
Increase flame height.
Replace or refill propane tank.
Refer
to the Excessive flow safety valve
reset
procedure on page 15.
Sudden drop in gas flow or
reduced
flame height.
Check if propane tank is empty. If
empty,
replace or refill. If propane tank is not
empty, refer to Excessive flow safety valve
reset procedure on page 15.
Turn the coupling nut about one-half to three
quarters additional turn until solid stop.
Tighten by hand ONLY - do not use tools.
Clear burner tubes.
Check for bent or kinked hose.
Reengage
burner and valve.
Clean
venturi.
Clean burner ports.
Check
for gas in propane tank.

GPC2700JD-Grey
Owner’s Manual 18
Warranty Program
Proof of purchase is required to access this warranty program, which is in effect from the date of purchase. If unable to provide
proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees.
Full 30-Day Warranty
Any missing parts can be replaced at no charge within 30 days from the date of purchase with a valid proof of purchase.
Limited Warranty
1-Year Limited Warranty on stainless steel tube burners.
1-Year Limited Warranty on all parts in regards to damage affecting the operation of the gas grill.
Warranty Provisions:
- This warranty is non-transferable and does not cover failures due to misuse or improper installation or maintenance.
- This warranty is for replacement of defective parts only. We are not responsible for incidental or consequential damages
or
labor costs.
- This warranty does not cover chips and scratches of porcelain or painted surfaces, nor does it cover corrosion or
discoloration
due to misuse, lack of maintenance, hostile environment, accidents, alterations, abuse or neglect.
- This warranty does not cover damage caused by heat, abrasive and chemical cleaners, resulting in chipped porcelain
enamel parts or
any damage to other components used in the installation or operation of the gas grill.
The original consumer-purchaser will be responsible for all shipping and handling charges of parts replaced under
the terms of this limited warranty. If unable to provide proof of purchase or if the warranty has expired, customers will
also be subject to parts fees.
Some provinces do not allow the limitation or exclusion of incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have
other
rights that vary from province to province.
If you have any questions related to the product or warranty, please call our customer service center at
1-877-877-630-5396,
10 :00 A.M. to 19:00 P.M. (EST), Monday through Friday.
Printed in China
Flare-up.
Persistent grease fire.
Grease buildup.
Excessive fat in meat.
Excessive cooking temperature.
Grease
trapped by food buildup
around
burner system.
Clean grill.
Trim fat from meat before grilling .
A
djust (lower) temperature accordingly.
Turn knobs to OFF. Turn gas OFF at
propane
tank. Leave lid in closed position
and let fire burn out. After grill cools,
remove and clean all parts.
Flashback [fire in burner tubes].
Burner and /or burner tubes are locked .
Clean burner and/or burner
t
ube(s).
Inside of lid is peeling – like paint
peeling.
Check inside of lid.
Baked on grease buildup has
turned to carbon and is flaking off.
Clean thoroughly.
Irregular flame.
A
ir flow is not correct. Correct
Flame blue
with yellow tips, 1-2”
high. Too little air: wavy yellow or
orange flames. Too much air:
noise blue flames.
If flames are yellow or orange – open flap
at the end of the venturi tubes in
1/8 in. increments until flames are
correct.
If flames are blue and noisy – close flap at
the
end of the venturi tubes in
1/8 in. increments until flames are
correct.
*Propane Models must be open a
minimum
of 1/8 in.
Manufactured by:
Lucas BBQ Co., Ltd.
R. 508 Eking Building, Liaobu Town, Dong Guan City,
Guang
Dong,
China
.
