Installation Instructions
1 | P a g e v 1 . 0 ( 0 5 / 2 0 1 9 )
SOUTHAMPTON EXTERIOR WALL BRACKET WITH MICROWAVE SENSOR
SKU# 239380, 239381, 239382, 239383
Rated Voltage 220-240V~ 50Hz
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.
Warranty
•This luminaire is covered by a 12 month warranty. The warranty is from date of purchase, not the date of installation.
•If the luminaire is not installed by a licensed electrician the warranty will be void.
•Please retain proof of purchase and evidence of installation by a licensed electrician for any warranty claims.
•Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the warranty .
Installation Requirements
•Must be installed by a licensed electrician.
•All wiring and installation of the luminaire must adhere to latest local and national wiring rules.
eg. AS/NZS 3000 Electrical installations.
•This luminaire is a Class I product and must be earthed.
•This luminaire is rated IP23, this must be maintained during wiring and installation.
•Do not exceed the maximum wattage rating.
•Select a suitable location for installation:
−The mounting point must be able to support 2 times the weight of the luminaire.
−This luminaire is protected against water penetration to IP23 standards, which is splashing water at the angle
up to 60°on either side of the vertical.
•Take care not to pull any electrical wires during unpacking as this may damage the connection.
•Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement.
•Check whether the luminaire has been damaged during transport. Do not operate/install any product which
appears damaged in any way. Return the complete product to the place of purchase for inspection, repair or
replacement.
•Ensure power to the circuit you are working on has been switched OFF before commencing any electrical work.
Installation Directions
1. Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material.
2. Use the mounting bracket (B) as a template to mark the screw positions on the wall. Drill holes into the wall.
NOTE: In order to achieve the best performance of the microwave sensor, the ideal mounting height of the
luminaire is between 2M - 3.5M above the detection area.
3. Install the mounting bracket (B) on the wall by using appropriately sized mounting screws (C) and anchors (A).
Ensure the screws and anchors used are suitable for the mounting surface and surrounding environment.
4. Remove the terminal box cover (D) to access the terminal block and connect the mains supply wires.
Mains Supply Wire Luminaire Wires
Earth – Yellow/Green Yellow/Green or
Neutral – Blue or Black Blue or N
Live – Brown or Red Brown or L
Ensure the wires are secure and no bare wires are exposed. Install the cover (D) back onto the terminal box.
Place the terminal box in the cavity (F) at the rear of the frame assembly.
NOTE: A non-corrosive bead of silicone MUST be applied before installation onto the wall ensuring that
no water can run down into the cabling.

Installation Instructions
2 | P a g e v 1 . 0 ( 0 5 / 2 0 1 9 )
5. Install the luminaire onto the mounting bracket (B), then secure by tightening the 2 screws (E) on the side.
6. Install a globe (H - not included) into the lamp holder (G). Do not exceed the maximum wattage rating.
7. Check that all parts are secured tightly before turning the power on.
8. Set up the microwave sensor by the remote control provided (For more details refer to ‘Microwave sensor set up’
section).
Microwave Sensor Set Up
The luminaire includes microwave sensor. The sensor can be set up by the remote control provided as the following.
1. The luminaire must be power on before setting up.
2. Use the remote control to set the parameters. Press ‘reset’ to enter the set-up mode, then follow the below
diagram to set up according to your need.
NOTE: The working distance from the remote control to the luminaire is 1M. Make sure you operate the
remote control within this range while setting up.
NOTE: The light will flicker when pressing any button.
On/Off - Press ‘on/off’, then the microwave sensor will be deactivated and luminaire
will enter on/off mode.
Reset - Press ‘Reset’, then the luminaire will exit the on/off mode and enter the set-up
mode. (Note: The luminaire will enter the sensor mode automatically after set-up.)
Detection area - Press ‘50%’ or ‘100%’ to set the detection area.
100% area = Max. 360°, 5m distance. 50% area = Max. 180°, 2.5m distance.
Daylight sensor
-Press ‘2 / 10 / 50 lux’, the luminaire will turn on if the ambient light is over 2 / 10 /
50 lux once the sensor detects any movement.
-Press disable, then the luminaire will be on once the sensor detects any movement
regardless the lux level of the ambient light.
Hold time
-Press 5s / 1min / 10min, then the luminaire will remain on for 5s / 1min / 10min if
the sensor detects no movement.

Installation Instructions
3 | P a g e v 1 . 0 ( 0 5 / 2 0 1 9 )
Battery Tips and Warnings for the transmitter
There is a button battery (3V CR2025) included in the remote control.
•WARNING – KEEP BATTERIES OUT OF REACH OF CHILDREN.
•CAUTION – Do not ingest battery—Chemical burn hazard.
•If the coin/button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death
due to chemical burns and potential perforation of the oesophagus.
•If you think batteries might have been swallowed or placed inside any part of the body, seek immediate medical
attention.
•If you suspect your child has swallowed or inserted a button battery, immediately call the 24-hour Poisons
Information Centre on 13 11 26 for fast, expert advice.
•Regularly check the product and make sure the battery box lid is correctly secured. If the battery compartment does
not close securely, stop using the product and keep it away from children.
•If the battery box lid has been cracked or damaged, do not continue to use this product.
•Dispose of used batteries immediately and safely (so they cannot be retrieved by children). Flat batteries can still
be dangerous.
•Keep new and used batteries away from children.
•Exhausted batteries are to be removed from the product.
•Batteries shall only be installed or replaced by an adult. Securely tighten the battery box lid after replacement.
•Do not use rechargeable batteries in this product.
•The supply terminals are not to be short-circuited.
•Ensure the batteries are inserted with the correct polarity.
•Remove batteries from the product when not in use for long periods of time.
Safety Tips
•Always ensure the power is OFF and the luminaire has cooled down before performing any maintenance, cleaning,
changing the globe or making any adjustment to the luminaire.
•The luminaire must not be used if the shade has been cracked or damaged. Replace any cracked protective shield.
•To avoid injury or damage to the luminaire
, ensure that power leads and screws are secure before connecting the
power.
•To clean, wipe with a soft damp cloth. Do NOT soak or immerse the product in water or other liquids.
•Ensure that the luminaire does not come in contact with corrosive chemicals/solvents or abrasive cleaners etc.
Specifications
SKU # 239380 239381 239382 239383
Colour CHROME ANTIQUE BLACK CHROME ANTIQUE BLACK
Rated Voltage 220-240V~ 50Hz
Rated Wattage 45W
Lamp Holder ES / E27
IP Rating IP23
Microwave Sensor Max. Detection range & angle: Max.5M ± 2M, 360° Required installation height: 2 – 3.5M
Lux & Time adjustment: 2 / 10 / 50 Lux, 5s / 1min / 10min
Battery of remote
control 3V DC, CR2025 button battery (Included)
Weight 2.5kg 3.7kg
Dimensions H:290mm W:150mm E:205mm H:390mm W:200mm E:258mm
