Lumel ATS User manual

1. ApplicAtion And construction of the AdApter
ATS adapter is designed for mounting of panel instruments in
accordance with IEC 61554 DIN on TS35 DIN EN 60715 rail or
for transducers of P18 series. The Construction (Figure 1 and 2)
is made of galvanized steel and consists of five parts: the main
sheet, two hooks and two springs.
Figure 1. View of the ATS mount on the DIN rail TS35.
95.9
3. fixing
Panel meter should be fixed in the mounting hole of the ATS
adapter (figure 2a).
a) fixing the panel meter into the adapter
screw clamps
ADAPTER ATS
for din rail ts35
user’s manual
Figure 2.View of the ATS mount on the DIN rail TS35 -
adapter for P18 transducers.
2. AdApter set
The set is composed of:
- adapter ATS 1 pc.
- user’s manual 1 pc.

ATS-09A
60-006-00-00954
b) fixing the set on the DIN rail TS35
c) disassembly of the set
Fix the panel meter into the ATS adapter with screw clamps that
are supplied with the panel meter.
Carry out the required electrical connections of the panel meter.
Fix the set on the DIN rail accordingly to figure 2b in order to latch
the holders on the lower part of the DIN rail TS35.
4. disAssembly
ATS adapter holder design allows for easy disassembly of the set.
In order to do this, simultaneously press the two protruding parts
(at the top or bottom of the holder) and by pivoting the set remove
it from the rail (Figure 2c).
Figure 2. Fixing way of the panel meter into the adapter,
fixing wayand disassembly of the set.
Figure 3. Fixing the transducer of P18X series
into the adapter.
