QUICK START GUIDE FOR LUMENERA Lg Camera Series
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012
Thank you for purchasing a Lumenera GigE camera. This camera is ready to use, but requires connection
to a network card that supports Giga-bit Ethernet. Please read these instructions in their entirety before
proceeding and then follow the steps below for a quick and easy installation.
Required Tools and Parts:
Recommended PC Specifications:
•1.0 Ghz or higher Pentium III compatible processor
•512 MB RAM memory
Operating system:
•Windows XP (SP3), Windows Vista or Windows 7
•32-bit & 64-bit operating systems are supported
•The computer should also have as a minimum Microsoft .Net Framework 2.0 installed to
be able to continue on with this installation.
Recommendation:
•The computer should have (at least) two network cards: One for the office network connection
and the other to be dedicated to the camera which should be a gigabit Ethernet NIC.
•Items Included in the box:
•Lg model camera.
•Quick Start Guide for Lumenera Lg Camera Series
Camera Set-up and Installation:
1. You must ensure you are logged into the computer with administrator privileges prior to continuing
the installation.
2. Download LgCam Software for Lumenera Industrial product support webpage.
(http://www.lumenera.com/support/downloads/industrial-downloads.php). Please note that a
CD-ROM can be purchased as an optional item when placing the camera order.
3. Lumenera recommends the removal of any previously installed version by using the Windows
Add/Remove Control Panel function, prior to installing a new version.
4. Close all application software that is running and then insert the Lumenera Installer CD into your
CD-ROM drive. The camera should NOT be connected to the computer at this point.
5. Double-click on the installation program, or wait a few moments for the auto-play function to load
the setup program automatically, when installing from the CD.
6. Follow the onscreen prompts to install the software drivers and user application. The installation
script steps are the same whether the installation takes place on a Windows XP, Windows VISTA,
or Windows 7 platforms, whether they are 32-bit or 64-bit.
7. On a Windows VISTA or Windows7 computer, you may see the warning shown above, if the UAC
(User Access Control) is enabled. Respond by clicking the button labeled as Yes.

8. Once the installation setup has completed, click Next to continue with the installation of the
LgCam software.
9. Select the option to accept the license and click Next to continue.
10. Now the install wizard is ready to proceed with the LgCam Software installation. Click Install to
continue.
11. Read warning message from installation program and click OK to continue.
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012

12. Click Next to proceed with 32-bit driver installation.
13. Click Install to proceed with 32-bit driver installation.
14. The 32-bit driver installation is completed; click Finish to proceed with the installation of the
remaining components.
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012

15. Under Windows 64-bit operating system the installation process will prompt you for the installation
of the 64-bit drivers. Click Next to start this required component.
16. Click Install to confirm and proceed with 64-bit driver installation.
17. The 64-bit driver is completed; click Finish to proceed with the installation of next component.
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012

18. The GigE Ethernet drivers will now be installed, please select the proper action with the help of the
drop down box. Note that it is recommended to use “Install eBus Universal Pro Driver”.
19. Confirm your installation choice by clicking the Install button.
20. Click Install to proceed with installation.
21. Installation of the GigE Ethernet driver has been completed. Click Close to complete installation.
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012

22. Before using your GigE camera, please restart your system.
Additional programs:
32bit Operating systems:
•EbDriverTool.exe ‘C:\Program Files\Common Files\Pleora’
•GEVPlayer.exe ‘C:\Program Files\Lumenera Corporation\LgCam Software\Pleora’
•GEVPlayer64.exe ‘C:\Program Files \Lumenera Corporation\LgCam Software\Pleora’
64bit Operating systems:
•EbDriverTool64.exe ‘C:\Program Files\Common Files\Pleora’
•EbDriverTool.exe ‘C:\Program Files (x86)\Common Files\Pleora’
•GEVPlayer.exe ‘C:\Program Files (x86)\Lumenera Corporation\LgCam Software\Pleora’
•GEVPlayer64.exe ‘C:\Program Files (x86)\Lumenera Corporation\LgCam Software\Pleora’
Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012

Lumenera Corporation • 7 Capella Ct. Ottawa, ON, Canada K2E 8A7 • (t) 1.613.736.4077 • (f) 1.613.736.4071 • www.lumenera.com
Technical Assistance Centre: [e-mail]
©2012 Lumenera Corporation, all rights reserved.
Design, features, and specifications are subject to change without notice
V03052012
License Agreement (Software)
This Agreement states the terms and conditions upon which Lumenera Corporation ("Lumenera") offers to license to you (the "Licensee")
the software together with all related documentation and accompanying items including, but not limited to, the executable programs,
drivers, libraries, and data files associated with such programs (collectively, the "Software").
The Software is licensed, not sold, to you for use only under the terms of this Agreement.
Lumenera grants to you the right to use all or a portion of this Software provided that the Software is used only in conjunction with
Lumenera's family of products.
In using the Software you agree not to:
a. decompile, disassemble, reverse engineer, or otherwise attempt to derive the source code for any Product (except to the extent
applicable laws specifically prohibit such restriction);
b. remove or obscure any trademark or copyright notices.
Limited Warranty (Hardware and Software)
ANY USE OF THE SOFTWARE OR HARDWARE IS AT YOUR OWN RISK. THE SOFTWARE IS PROVIDED FOR USE ONLY WITH
LUMENERA'S HARDWARE AND RELATED SOFTWARE. THE SOFTWARE IS PROVIDED FOR USE "AS IS" WITHOUT WARRANTY
OF ANY KIND. TO THE MAXIMUM EXTENT PERMITTED BY LAW, LUMENERA DISCLAIMS ALL WARRANTIES OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY, QUALITY AND FITNESS FOR A PARTICULAR PURPOSE. LUMENERA IS NOT OBLIGATED TO PROVIDE ANY
UPDATES OR UPGRADES TO THE SOFTWARE OR ANY RELATED HARDWARE.
Limited Liability (Hardware and Software)
In no event shall Lumenera or its Licensor's be liable for any damages whatsoever (including, without limitation, incidental, direct, indirect,
special or consequential damages, damages for loss of business profits, business interruption, loss of business information, or other
pecuniary loss) arising out of the use or inability to use this Software or related Hardware, including, but not limited to, any of Lumenera's
family of products.
Please refer to Lumenera’s Warranty online at http://www.lumenera.com/about.php.
Product Warranty
Lumenera Corporation warrants to the original purchaser that our cameras are guaranteed to be free from manufacturing defects for a
period of one (1) year from the original date of purchase.
Should the unit fail during the warranty period, Lumenera will, at its option, repair or replace the failed unit. Repaired or replaced units will
be covered under warranty for the remainder of the original one (1) year warranty period.
This warranty does not apply to units that, after being inspected by Lumenera, have been found to have failed due to customer abuse,
accidents, mishandling, tampering/alteration, improper installation, improper power source, negligence, opening of the enclosure, or if the
serial number has been removed or damaged. This warranty does not cover labor or incurred charges required in removing or installing the
unit, any business interruption, loss of profits/revenues, or any consequential damages.
Units returned to Lumenera beyond the warranty period will be repaired, if possible, and all appropriate material and labor charges will
apply.
Any returning product, specifically those being returned under warranty, must follow the Returned Material Authorization (RMA) process.
Any units being returned are to be properly packaged (in original packing - if possible). Lumenera will not cover damage sustained in
shipping due to improper packing.
For RMA instructions please refer to our website at www.lumenera.com.
