Lumiglas VISULEX K55P-Ex User manual

0158
• Description:
The VISULEX K55P-Ex/K55N-Ex is a fixed-lens camera.
During the installation process, the lens of this standard
camera is focused on the outdoor area or facility to be kept
under surveillance (e. g. yard, plant or technical process
elements such as vessels or agitators).
The temperatures specified in the data sheet for the built-in
camera type should be observed so as to ensure trouble-free
operations. A terminal box is provided for connecting the
camera. Important, please note: Under no circumstances
should a camera be used to replace the cover flange or the
complete sight glass fitting, nor should it be used on its own
as a closure for a vessel port.
• Design and field of application:
- Pressure-resistant stainless steel housing with built-in
colour CCD camera, 1/3” CCD sensor, 1 lux photosensitivity,
electronics, and stainless steel mounting
- Approved for Ex zones 1 and 2 as well as zones 21 and 22
• General electrical data:
- Feed voltage to the camera: 12 V/DC ± 10%
- Maximum power consumption: 7.5 W including power
supply unit
- Protection class of camera: IP65 acc. to EN 60529/
DIN VDE 0470, Part 1
- Application temperature range: -10°C to +45°C
(depending on camera module used)
- Protection class of terminal box: IP40
- Ex approval acc. to EC type examination certificate:
BVS 15 ATEX E 056 X
II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIC T80°C Db
• Markings:
The camera has a permanent type plate which is clearly
visible and easy to read. It bears the following data:
- Name and address of manufacturer
- Camera type: K55P-Ex
- Ambient temperature range: -20°C ≤Ta ≥+50°C,
depending on the camera module used
- Certificate number
- Warning – must be observed:
- Do not open when live!
- After deactivating the voltage, wait four minutes before
opening
- Serial number/year of manufacture
- Supply voltage
- Protection class: IP65
- CE symbol/No. of certification body
• Connecting cable:
The connecting cable is to be installed so as to avoid the
occurrence of static charges. The length of the supply cable
has to be max. 1 m.
• Connection:
- The camera is supplied as a unit comprising the camera
and the terminal box.
- Should it be necessary to detach the connecting cable to
improve the cable routing, this can be carried out in the
terminal box.
- The camera should never be operated without the terminal
box because the safety device (fuse) is located in the
terminal box.
F.H.Papenmeier GmbH & Co. KG · division Lumiglas
Talweg 2 · 58239 Schwerte · Germany
phone: [phone] · fax: [phone]
[email protected] · www.lumiglas.de
Installation and Operating Instructions 0093.117.00 b
Attaching the cable in the terminal box
VISULEX Ex Camera K55P-Ex/K55N-Ex
II 2G Ex d IIC T6 Gb
II 2D Ex tb IIIC T80°C Db
VISULEX Camera K55P-Ex
with fixed lens

All dimensions in mm unless stated otherwise. Subject to change without prior notice. 10.15
F.H.Papenmeier GmbH & Co. KG · division Lumiglas
Talweg 2 · 58239 Schwerte · Germany
phone: [phone] · fax: [phone]
[email protected] · www.lumiglas.de
• Replacing the camera and/or electronics:
Any replacement of the camera module should be carried
out by the manufacturer and/or done at the manufacturer’s
works (F.H. Papenmeier GmbH & Co. KG).
• Mechanical installation:
It is essential to read the information sheet “Important
instructions when using sight glass fittings” before commen-
cing installation work.
The camera is attached to the cover flange of a circular sight
glass fitting or flow sight glass or to the slotted cover nut of
a screw-type sight glass using the mounting components.
The lens of the camera should never be exposed to direct
sunlight as this will render it inoperable!
The Visulex camera K55P-Ex/K55N-Ex fits the following
nominal diameters when used together with the appropriate
mounting parts:
• Mounting with hinged bracket:
The hinged bracket is intended for fastening the camera to
the cover flange of a circular sight glass fitting or flow sight
glass or to the slotted cover nut on screw-type sight glass
fittings acc. to DIN 11851.
Type of fitting from DN Hinged
bracket
Flanged
adapter
Circular sight glass fitting
DIN 28120 + DIN 28121 40 + –
Flow indicator sight glasses 50 + –
Screw-type sight glass
fitting in compliance with
DIN 11851
65 –+
80 + +
100 + +
125 + +
The hinged bracket is secured to the required bolt circle
using the M8 screw included in the scope of supply which
fits into a blind hole which has previously been tapped
(by operating company). Alternatively, the hinged bracket
can be welded in place.
• Mounting by flanged adapter collar:
The adapter collar is secured to the slotted cover nut (DIN
11851) by welding or screwing it on. The camera is then
positioned on the flange using the screws included in the
scope of supply.
• Replacement parts:
Part Part No.
Sight glass 1774.078.00
O-ring seal 0862.039.00
• Accessories:
Part Part No.
Camera mounting (hinged bracket) 0354.025.00
Camera mounting (flanged adapter) MV 50 1356.038.00
Camera mounting (flanged adapter) MV 65 1356.039.00
Camera mounting (flanged adapter) MV 80 1356.040.00
Camera mounting (flanged adapter) MV 100 1356.044.00
Camera mounting (flanged adapter) MV 125 1356.041.00
• Maintenance:
- The camera should be kept clean
- After opening the camera, the thread of the screw-type
glass lens and the cover of the terminal box (parts 4 and 5)
should be freshly greased, (e.g. with AEMA-SOL 6 B, made
by A.E. Matthes)
- The glass disc should be cleaned regularly to ensure
optimum camera viewing
- Always use original replacement parts
1 Cable entry gland M20 x 1.5 Ex-d
2 Protective conductor terminal, external
3 Locking screws M4 A2-70
4 Body
5 Connection cover
6 Sight glass
7 Body mounting (hinged bracket)
