Luminaire led Blade Series User manual

INSTALLATION GUIDE FOR BLD
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 1of 3
SAFETY PRECAUTIONS
WARNING - Risk of fire or electric shock. Basic safety precautions should always be
followed when using electrical equipment.
WARNING - This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and operation of the
product and the hazards involved.
WARNING - Disconnect power to all circuits before wiring fixture.
WARNING - Install in accordance with all national, state, and local codes.
WARNING - Do not connect to an ungrounded supply.
WARNING - Read all fixture markings and labels to ensure correct installation of
fixture.
WARNING – Do not apply power to the fixture until the LED Board assembly is
connected to the driver. If power is applied to the fixture prior to connecting the LED
Board assembly to the driver, this will cause the LED Board to fail and void the
warranty.

INSTALLATION GUIDE FOR BLD
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 2of 3
CAN ICES-005 (A) / NMB-005 (A)
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
ISED CANADA STATEMENT / DECLARATION POUR ISDE CANADA
This class A lighting equipment complies with Innovation, Science and Economic
Development (ISED) Canada Standard for radio interference-causing equipment ICES-
005, 5th edition.
Ce matériel d’éclairage de classe A est conforme avec la norme sur le matériel
brouilleur radio NMB-005, 5ième édition, publié par innovation, science et
développement économique (ISDE) Canada.

INSTALLATION GUIDE FOR BLD
RETAIN THESE INSTRUCTION FOR FUTURE USE
One Lithonia Way, Conyers GA 30012 | 1.800.705.SERV (7378) | www.luminaireled.net | © 2020 Acuity Brands Lighting, Inc. All rights reserved.
Page 3of 3
SITE PREPARATION INSTRUCTIONS
1. Mounting surface must be relatively flat. Split face block, natural veneer, or deep grout lines
may require additional preparation such as concrete pads.
2. Fixture is designed to cover a 2x3 electrical box, mounted horizontally - see Figure 2.
3. Wiring must enter in the center of the fixture; prepare recessed junction box in center.
Distance from center hole to the bottom of the fixture will be 0.69”. See Figure 2.
INSTALLATION INSTRUCTIONS
1. Remove Luminaire from carton and check for damage
2. Detach Wall bracket from fixture by loosening (2) screws and sliding apart on a 45oangle.
See Figure 1.
3. Using ¼” hardware (not supplied), attach Wall Mount Bracket to mounting surface. Bracket
must be level. If the mounting surface is slightly curved or warped, it may be advisable to
leave a small amount of play in some of the mounting points as the fixture will pull the
bracket straight when mounted. Use hardware with heads that are no more than ½” diameter.
4. Verify that the power is disconnected from the fixture.
5. Connect all supply wires in accordance with national and local electrical codes.
6. Align fixture over Wall Mount Bracket and push wires through center hole. Fixture should
align from the top of the bracket and will rest on the angled surface. Tighten two mounting
screws to secure fixture to Wall Mount Bracket. See Figure 1.
7. Apply a bead of silicone caulk between the wall and top of fixture as required.
8. Energize and test.
Figure 2
Figure 1
Fixture Housing
Wall Mount
Bracket
Mounting Screws
