3-YEAR WARRANTY
INSTRUCTION MANUAL
LUXPRO®PSPU721T
2 Heating and 1 Cooling with Dual Fuel Switch
LUX Products Corporation
6000 Commerce Parkway, Suite-I • Mt. Laurel, NJ 08054
[phone] • FAX [phone]
http://www.luxproproducts.com 52077

2LUXPRO®PSPU721T

OOUUTTDDOOOORRWWIIRREELLEESSSSTTEEMMPPEERRAATTUURREE
TTRRAANNSSMMIITTTTEERRAANNDDRREECCEEIIVVEERRKKIITT
LUXPRO®Part No. WTR064
Outdoor Wireless Temperature
Transmitter and Receiver Kit Includes:
Transmitter
Antenna
Receiver Module
2 AA Batteries
U.S. Patent: 6,902,117
Accurately Displays
Current Outdoor Temperature
on the LUXPRO®Thermostat and
Enables Dual Fuel and
Automatic Humidity Capability
3INSTRUCTION MANUAL

LUXPRO®PSPU721T
Introducing the LUXPRO®PSPU721T touch-screen thermostat with 2-stage heating, 1-stage
cooling control and fossil fuel switch
(Available only when combined with LUXPRO®Outdoor Wireless Transmitter and Receiver
Kit. LUXPRO®Part No. WTR064)
•7 Day programmable with 4 events per day
- including fan
•Large, easy to read dot matrix display
•True touch screen technology
•Automatic selection of cool or heat mode
•Programmable fan mode
•Programmable filter monitor
•Programmable installer message
•Customizable full and partial
lock security
•Adjustable differential settings
for multistage installations
•Energy watch calculates kWh consumption
and real time HVAC cost
•Simple mode for non-programmable usage
•Programmable Vacation Mode
4

TABLE OF CONTENTS...................................................................................................................5
GLOSSARY OF TERMS..................................................................................................................6
SELECTING A LOCATION...............................................................................................................7
MOUNTING THE THERMOSTAT TO THE WALL ...............................................................................8
WIRING LEGEND...........................................................................................................................9
WIRING DIAGRAMS ....................................................................................................................10
HOME SCREEN...........................................................................................................................14
CONTROL SCREEN.....................................................................................................................15
THERMOSTAT OPERATION MODES .............................................................................................16
TEMPERATURE CONTROL MODES ..............................................................................................17
FAN OPERATION MODES ............................................................................................................18
GLOSSARY OF TERMS................................................................................................................19
MENU SCREEN...........................................................................................................................20
DATE AND TIME SETTINGS .........................................................................................................22
PROGRAM SETTINGS .................................................................................................................23
ENERGY WATCH .........................................................................................................................24
SET SCREEN OPTIONS ...............................................................................................................25
VACATION MODE........................................................................................................................26
FILTER MONITOR........................................................................................................................27
ADVANCED SETTINGS - FEATURES SETTINGS ............................................................................28
ADVANCED SETTINGS - SYSTEM CONFIGURATION......................................................................30
ADVANCED SETTINGS - DUAL FUEL SWITCH ..............................................................................31
ADVANCED SETTINGS - DIFFERENTIAL SETTINGS ......................................................................32
ADVANCED SETTINGS - TIMER FEATURE ....................................................................................33
ADVANCED SETTINGS - HEAT PUMP ..........................................................................................34
ADVANCED SETTINGS - CALIBRATION ........................................................................................36
SIMPLE THERMOSTAT MODE .....................................................................................................38
TROUBLESHOOTING...................................................................................................................39
IMPORTANT NOTICE ..................................................................................................................40
WARRANTY................................................................................................................................41
TABLE OF CONTENTS
5INSTRUCTION MANUAL

GLOSSARY OF TERMS
6LUXPRO®PSPU721T
CYCLE RATE - Cycle rate is the frequency that heating or cooling equipment is turned on during a
certain period of time. Cycle rate is often given in units of cycles per hour (CPH).
DIFFERENTIAL - Differential is defined as the difference between the cut-in and cut-out points as
measured at the thermostat under specified operating conditions. For example, if the thermostat
turns the heating equipment on at 70 degrees F and turns the heating equipment off at 74 degrees
F, then the differential is 4 degrees F.
PROGRAMMABLE THERMOSTAT - A thermostat with the capability of automatically adjusting tem-
perature set point to pre-selected settings at pre-selected times.
SETBACK - The automatic alteration of the thermostat control point(s) by means other than man-
ually changing the temperature set point.
SET POINT - The desired temperature setting on an electromechanical or electronic thermostat.

Install your LUXPRO®thermostat approximately 5 feet (1.5 meters) above the floor in an area
with good air circulation.
Avoid the following locations:
•Hot or cold air from ducts
•Radiant heat for appliances or sun such as a skylight
•Unheated or uncooled areas: for example an outside wall behind the thermostat.
•Ensure that there is no furniture directly below or beside the thermostat.
SELECTING A LOCATION
7INSTRUCTION MANUAL

MOUNTING THE THERMOSTAT TO THE WALL
8LUXPRO®PSPU721T
1. Make sure to turn off the power supply located at the electrical service panel.
All heating and cooling units should be OFF.
2. Separate the backplate from the thermostat by grasping the unit firmly at the bottom lip and
pulling gently until the two piece are apart.
3. Align the backplate to the wall.
4. Mark the three locations for drilling the 3/16” holes required for the plastic screw anchors.
5. Remove the backplate and drill the three 3/16” holes in these locations.
6. Insert the plastic gyproc screws and ensure that they are snug in the wall.
7. Securely mount the backplate to the wall with the 3 supplied screws.
8. Make the appropriate wire connections based on the specifications of the
household HVAC unit(s). Please refer to Wiring Table to determine the appropriate wire connec-
tions.
9. Place the thermostat on the backplate by firmly but gently from the top aligning the pins with
the screw terminals.
10. Turn on the electricity at the electrical service panel.

TERMINAL EQUIPMENT STANDARD COLOR
Y1 First Heat Pump and AC Yellow
G Fan Green
W2 First Stage Furnace White
OBW Reverse Valve - Second Stage Furnace Orange
RH 24v Red
Y2 Not Used Unknown
C Common Blue
H Not Used Unknown
DH Not Used Unknown
RC 24v Unknown
11 and 12 Not Used
NOTE: The above colors are standard in HVAC industry. The wiring should be confirmed
before installation
WIRING LEGEND
9INSTRUCTION MANUAL

WIRING DIAGRAMS
10 LUXPRO®PSPU721T
I2
1 AIR CONDITIONER
24V
FAN
AC
I1 RC DH H C Y2 RH OBW W2 G Y1
COMMON

HEAT 2
HEAT 1
I2
1 AIR CONDITIONER AND 2 STAGE HEAT
24V
FAN
AC
I1 RC DH H C Y2 RH OBW W2 G Y1
COMMON
HEAT
I2
1 AIR CONDITIONER AND 1 STAGE HEAT
24V
FAN
AC
I1 RC DH H C Y2 RH OBW W2 G Y1
COMMON
WIRING DIAGRAMS
11INSTRUCTION MANUAL

HEAT
REVERSE VALVES
I2
1 HEAT PUMP AND 1 STAGE HEAT
24V
FAN
HP
I1 RC DH H C Y2 RH OBW W2 G Y1
COMMON
WIRING DIAGRAMS
12 LUXPRO®PSPU721T
REVERSE VALVES
I2
1 HEAT PUMP
24V
FAN
HP
I1 RC DH H C Y2 RH OBW W2 G Y1
COMMON

WIRING DIAGRAMS
13INSTRUCTION MANUAL
HEAT
TRANSFORMER
COOL
TRANSFORMER
I2
2 TRANSFORMERS
I1 RC DH H C Y2
CUT
RH OBW W2 G Y1
I2
1 TRANSFORMER
I1 RC DH H C Y2 RH OBW W2 G Y1
HEAT
TRANSFORMER

Current Room
Temperature
Current Outdoor
Temperature
Current Thermostat Operation
Mode
Current Temperature
Control Mode
Current Fan
Operation Mode
Fan Operation Indicator
Vacation Mode Indicator
Security Indicator
Heat setpoint
Cool setpoint
Date
Time
HOME SCREEN
14 LUXPRO®PSPU721T
>> To return to the HOME SCREEN, simply touch the icon at any time!
>> The HOME SCREEN displays the following information:

Change the Temperature Setpoint(s) using -and +buttons.
In AUTO MODE toggle the Heat/Cool button (Heat or Cool will flash
once selected), then raise or lower setpoints as desired.
Select the Thermostat Operation Mode by toggling thermostat operation
mode button.
Select the Temperature Control Mode by toggling the
temperature control mode button.
Select the Fan Operation Mode by toggling the fan operation
mode button.
Access MENU SCREEN to enter into all thermostat features and settings.
Displays Installer Message to review important information.
>> To access the CONTROL SCREEN, simply touch the HOME SCREEN Screen… anywhere!
>> From the CONTROL SCREEN, you can:
1Available only in combination with WIRELESS OUTDOOR TEMPERATURE TRANSMITTER AND RECEIVER KIT (WTR064)
CONTROL SCREEN
15INSTRUCTION MANUAL

THERMOSTAT OPERATION MODES
16 LUXPRO®PSPU721T
>>LUXPRO®thermostat can operate in PROGRAM MODE or can HOLD a fixed temperature.
RUN PROGRAM: the thermostat initiates the 7-day Programmable Temperature
Control Program with 4 independent events per day. To set up a custom tem-
perature control program with customizable Temperature Setpoint and Fan
operation mode, refer to Section PROGRAM SETTINGS (page 23).
HOLD TEMPERATURE: the thermostat regulates the room temperature
as determined by the selected Temperature Setpoint.

>>Based on your HVAC equipment LUXPRO®thermostat can operate in the following temper-
ature control modes - AUTO or HEAT or EMERGENCY HEAT or COOL or OFF
AUTO - the thermostat keeps the room temperature between the selected
HEAT and COOL setpoints by using both the cooling and heating HVAC units.
HEAT - the thermostat only turns on the heating units to regulate room
temperature.
EMERGENCY HEAT - the thermostat enables the emergency heat (if
required).
COOL - the thermostat only turns on the air conditioning to regulate room
temperature.
OFF - the thermostat will not control temperature. the thermostat will con-
tinue to display the current room temperature and outdoor temperature.
TEMPERATURE CONTROL MODES
17INSTRUCTION MANUAL

FAN OPERATION MODES
>>LUXPRO®thermostat can operate the fan in one of the following three modes:
FAN AUTO: The fan runs only when there is a demand for heating or cool-
ing.
FAN ON: The fan runs continuously
FAN INTERMITTENT: The fan runs 10 minutes per 1/2 hour providing a
convenient way to improve air quality and save energy.
When the fan is running, the animated fan icon will appear on the
HOME SCREEN.
LUXPRO®PSPU721T18

INSTRUCTION MANUAL 19
GLOSSARY OF TERMS

MENU SCREEN
>> To access the MENU SCREEN, simply touch MENU from the CONTROL SCREEN.
>> From the MENU page, you can:
Access DATE AND TIME SETTINGS to enter the accurate date and time
Access PROGRAM SETTINGS to pre-program temperature changes
during each day of the week.
Access ENERGY WATCH to display kWh consumption and the dollar cost
of operating the HVAC System
CLEAN SCREEN places the touch screen in a sleep mode for 15 seconds
which allows you to wipe the screen with a dampened cloth.
Access the SET SCREEN menu to change screen properties.
