Luxli orc-cello-10 User manual

To obtain warranty coverage, contact the Luxli Customer Service
Department to obtain a return merchandise authorization (“RMA”)
number,and return the defective product to Luxli along with the RMA
number and proof of purchase.Shipment of the defective product is
at the purchaser’s own risk and expense.
For more information or to arrange service,visit www.luxlilight.com or
call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
LUXLI is a registered trademark of the Gradus Group.
© 2018 Gradus Group LLC.All Rights Reserved.
One-Year Limited Warranty
This LUXLI product is warranted to the original purchaser to be free
from defects in materials and workmanship under normal consumer
use for a period of one (1) year from the original purchase date or
thirty (30) days after replacement, whichever occurs later.The warranty
provider’s responsibility with respect to this limited warranty shall be
limited solely to repair or replacement, at the provider’s discretion, of
any product that fails during normal use of this product in its intended
manner and in its intended environment. Inoperability of the product
or part(s) shall be determined by the warranty provider. If the product
has been discontinued, the warranty provider reserves the right to
replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by
misuse, neglect, accident, alteration, abuse, improper installation
or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED
WARRANTIES,INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.This
warranty provides you with specic legal rights, and you may also
have additional rights that vary from state to state. GG2
Precautions FCC Compliance Statement
• Please read and follow these instructions, and keep this manual
in a safe place.
• Keep this product away from water and ammable gases or liquids.
• Use only the correct, recommended voltage.
• Do not attempt to disassemble or repair this product.
• Clean this product with only a soft, dry cloth.
• To avoid damage to this product, be careful not to overtighten or
improperly thread any of the threaded ttings.
• All images are for illustrative purposes only.
This device complies with part 15 of the FCC rules.Operation is subject
to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including
interference that may cause undesired operation.
Important: Changes or modications to this product not authorized by
Gradus Group could void the electromagnetic compatibility (EMC)
and wireless compliance and negate your authority to operate the
product. This product has demonstrated EMC compliance under
conditions that included the use of compliant peripheral devices
and shielded cables between system components.It is important that
you use compliant peripheral devices and shielded cables between
system components to reduce the possibility of causing interference
to radios, televisions, and other electronic devices.
Conduct an orchestra of lights.
The Luxli Orchestra series can produce a dazzling symphony of light.
Synchronize LED light units of all sizes,choose from millions of possible
colors,apply lighting effects from three selectable modes,and control
them instantly with the powerful Conductor mobile app.
The Cello 10-inch multicolor LED light features a highly accurate
and remarkably versatile RGBW LED panel.The light is equipped with
Bluetooth 4.2 LE that pairs with your tablet or smartphone the moment
you open Luxli’s Conductor mobile app.Whether controlled via the
app or the intuitive interface on the unit itself, the Cello will illuminate
your creative vision with endless possibility.
For the latest version of the Conductor mobile app,rmware updates,
and a PDF of the full user manual, as well as videos and ideas for
creative uses for the Cello, visit luxlilight.com.
www.luxlilight.com
Troubleshooting
• When the battery level is very low, the Cello will limit the LED panel’s
output in order to preserve battery life. If you notice the light is
dimming, you’ll need to change the battery as soon as possible.
• If you encounter any problems, rst try turning the device off and
then on.
• If the problem persists, remove the battery for 15 seconds, and
then restart.
• Go to www.luxlilight.com to make sure you have the most recent
rmware update. If a new rmware version is available, follow
instructions on how to download it to your light.
QUICKSTART GUIDE

Overview User Interface
Back:
1. Battery slot (use Sony L-Series-compatible battery)
2. Battery release button
3. Adjustment dial
4. Brightness dial
5. LCD screen
CCT Mode
Correlated color temperature (CCT) mode allows you to accurately
adjust the color temperature from 3,000 to 10,000 K.
RGB Mode
RGB mode lets you dial in almost any color by scrolling through the
entire color wheel.
Warnings
The Cello calculates battery life as a function of your brightness setting:
the battery life increases as you decrease the power output.
The LED panel will dim, but operation will
continue.
The LED panel will shut off.
The LED panel will shut off, but settings can
still be adjusted.
The Cello remains in search mode until it is paired with a Bluetooth
device.Once the device is disconnected, the Cello returns to search
mode.
Filter Mode
Filter mode allows you to apply colored gels to your current CCT setting.
• Scroll: Adjusts the color temperature in 50 K increments.
• Press: Switches between tungsten balance (3200K) and daylight
balance (5600K).
• Scroll: Adjusts the brightness from 100% to 0%.
• Press:Turns off the LED panel without powering down.
• Scroll: Scrolls through the color spectrum in 1° increments.
• Press: Cycles through 100% to 20% saturation level in 10%
increments.
• Scroll: Adjusts the brightness from 100% to 0%.
• Press:Turns off the LED panel without powering down.
• Scroll: Scrolls through all installed gels.
• Press: Switches between 3200, 5600, and 6500K white-balance
color temperatures.
• Scroll: Adjusts the brightness from 100% to 0%.
• Press:Turns off the LED panel without powering down.
Bottom:
6. Mode selector button
7. Power button
8. 1/4-20 mount
9. DC power input (power adapter not included)
10. Micro USB port for rmware updates (Visit luxlilight.com for details.)
Also Included
• Shoe-mount ball head
• NP-F750 battery
Bluetooth Status Indicators
Search Mode Connected
BATTERY LOW
BATTERY EMPTY
OVERHEAT
Specications
Light panel 176 RGBW LED
Bluetooth version 4.2 LE
Battery mount Sony L-Series
DC power input 2.1 mm 7–15 V
Dimensions (W × H × D) 9.5 × 3.7 × 0.8 in. (24 × 9.3 × 2 cm)
Weight 13.9 oz. (394 g)
• Battery charger
• Quickstart guide
CELLO
7-15 V
7000K
98%
98%
240˚
SAT
B
100%
98%
Aqua Blue 270
7000K
1 2
4
6 7 9 108
53
