LuxLogic Stealth User manual

LED STEALTH AREA LIGHT
INSTALLATION GUIDES
Connect the AC wire, and then insert
the arm of the slip fitter to the pole.
Tighten the screws on the side of
the arm and then power on.
S: SLIP FITTER MOUNTING
Dimensions of the slip fitter
Step 1 Step 2
7.3” (185mm) 3.1” (79mm)
Proudly Canadian Company

LED STEALTH AREA LIGHT
INSTALLATION GUIDES
T: TRUNNION MOUNTING
Dimensions of the trunnion
Step 1 Step 2
Use the nuts to fix the fixture to the wall aiming at
the expansion screws, and adjust angle of the
bracket and tighten the small screw on the side,
then connect the AC wire.
Drill two holes on the wall corresponding to the
holes on the trunnion, and knock expansion
screws into the holes.
5.4” (136mm)
3.3” (82.5mm)
2.6” (66.5mm)
Ø 0.79” (20mm)
Ø 0.33” (8.5mm)
2.6” (66mm)
2.93” (74.5mm)
Proudly Canadian Company

LED STEALTH AREA LIGHT
6.7” (170mm)
INSTALLATION GUIDES
A1: ARM MOUNTING FOR SQUARE POLE
Arm dimensions
5.1” (130mm)
2” (50mm)
3.2” (80mm)
4-Ø 0.35” (9mm)
Ø 0.7” (18mm)
6” (152.1mm)
2.6” (65.3mm)
Ø 2.5” (65mm)
5.9” (150mm) 5.1” (130mm)
2” (50mm)
Ø 0.7” (18mm)
4-Ø 0.35” (9mm)
0.78” (20mm)
Proudly Canadian Company

LED STEALTH AREA LIGHT
Step 1 Step 2
Connect the AC wire of the fixture and tighten the
water-proof gasket and cover plate on the arm by
screws,then power on.
Drill holes on the square pole corresponding to
the holes on the arm, and use the bolt and nut
plate to fix the fixture to the pole tightly.
INSTALLATION GUIDES
Arm assembly drawing
Formula arm pipe installation
With circular arm
silicone
Cover plate
Bolt Pole Nut Plate
Proudly Canadian Company

LED STEALTH AREA LIGHT
INSTALLATION GUIDES
Step 1
Step 2
Connect the AC wire of the fixture and tighten the
water-proof gasket and cover plate on the arm by
screws,then power on.
Drill holes on the round pole corresponding to the
holes on the arm, and use the bolt and nut plate
to fix the fixture to the pole tightly.
A2: ARM MOUNTING FOR ROUND POLE
Nut Plate
Bolt
Proudly Canadian Company

LED STEALTH AREA LIGHT
INSTALLATION GUIDES
WARNINGS AND CAUTIONS
The product must be installed according to the instructions. Installed by a person familiar with the product,
production and product hazards.
Avoid fire and electric shock. When install the lighting fixtures, you need to understand the electrical characteri
stics. If you are not sure, do not attempt to install. Please contact the electrician.
Understand the structural features and dimensions of lighting before installation
Do not drill holes or change internal lines when install
QUALITY ASSURANCE
Quality assurance is based on proper storage, transportation, installation, using and maintenance
Damages caused by man-made mistake or improper use are not covered by the warranty
Risk of electrical shock!
During the warranty period, the manufacturer will provide appropriate support and repair service according
to the actual situation
