Luxor/H.Wilson LE54C-B User manual

Luxor LE54C-B 54.25" High
Black 3-Shelf Endura A/V
Utility Cart with Cabinet
Instruction Manual

3 Shelf LP + LE Cart Instructions 08/16/13
Tools Required
Parts List
-Rubber Mallet
1
4 5 6
2 3
A x1
B x1 D x4
D
BAA
C
C
C
B
E
F
C x1
E x4 F x4
Install optional cabinet pack /
pullout shelf / electrical assembly
after step 1
NOTICE:
Leg lengths of leg Emay be
shorter than leg F
Optional uted
legs for units with
cabinet pack

07/08/13
Parts List Tools Required
-Rubber Mallet
Plastic Cart Cabinet
Pack Instructions
Please consult your cart base
unit instructions before starting
IMPORTANT: Flip shelf B,
and lock the 2 locking casters
Dbefore assembling the unit.
D
B
Key
G x1
H x1
J x2 K x2
4
1
5
2
6
3
BB
BB
FJ
J
H
G
A / C

02/22/13
Parts List Tools Required
-Philips Screwdriver
LP + LE Electrical
Assembly Instructions
Attach electric outlet Fto top shelf A, secure with
L bracket Gand cable lock J. Loop outlet cable
Fthrough cable lock Jand the inserts on shelf A.
Screw L bracket Gand cable lock Jonto top shelf
Awith screw Hand a philips screwdriver.
1
F
G
H
H
H
J
A
F x1 G x1
H x3 J x1
