LUXTON HOME PR-8510 User manual

Page 1of 4
Portable Massage Table
PR-8510
USER’S MANUAL

Page 2of 4
Precautionary Instructions
1. Maintain the table periodically. Make sure all screws are secure and the cable has not
deteriorated or frayed. Make sure there are no cracks on the wooden structure.
2. Do not overload the table beyond the recommended weight limit. This could result in serious injury
to the user. This product is tested to hold a max working load of 551 lbs (250kgs). Don’t load
weight over 44 lbs (20kgs) on the headrest cradle and around position of face hole.
3. Be cautious not to tangle the cables with legs or support beams.
4. Do not use alcohol based cleaners when cleaning the vinyl. This could cause damage to the vinyl
material. For PU leather, use dry soft cloth to clean the leather or use PU leather friendly cleaning
agent to clean and dry it quickly.
5. Make sure when using the table that all four legs are at the same level. Using the legs at different
levels can cause the table to be unstable and cause injury.
6. Do not allow children to assemble or disassemble the massage table for you unless under
supervision.
7. Be careful when using sharp objects as they can pierce the covering. Keep the table’s covering
away from being contacted by the sharp items.
1. Handle 2. Support Beam 3. End plate 4. Armrest Outlet
5. Rubber Cover 6. Cable 7. Headrest with cushion 8. Hanged armrest pad
9. Side armrests 10. Face hole 11. Oil Pocket
1. Handle
4. Armrest Outlet
6. Cable
5. Rubber Cover
3. End plate
2. Support Beam
9. Side Armrests
8. Hanged armrest pad
7. Headrest with cushion
11. Oil Pocket pad
10. Face hole

Page 3of 4
Setting Up Your Table
12 3
4 56 7
1. Release the buckle.
2. Lay the table on its side with four rubber stands on the floor, open up the table with four legs
extends as full as possible.
3. Take out all accessories.
4. Lift the table up until all legs are on the floor, to ensure the cables have all been fully extended,
be cautious not to tangle the cables with the legs or support beams.
5. Put accessories into the corresponding outlets, put on the hanged armrest or sling on the
headrest cradle.
6. Release the side handle and press it in once the headrest is adjusted to the required position.
Remarks: If the headrest is too loose to be locked, press the opposite side of side handle and
rotate the handle in clockwise direction to make it firmer and press it in.
7. Now the table is ready for your use.
Re: The height of table is adjustable by turning off the knobs on the leg and take out the movable
leg to adjust the height by choosing the holes on the movable leg, put back onto the leg and
fasten the knobs firmly. Four legs should be done in the same way one by one and make sure all
legs are adjusted into same height level. Don’t apply load over 44 lbs (20kgs) on the position of
face hole and headrest cradle.

Page 4of 4
Fold Up and Carry Along
1. Take out all accessories.
2. Lay the table on its side with four rubber feet on the ground.
3. Put all accessories under the elastic strap under the top veneer.
4. Fold the legs on each end at angle towards inside by pressing the corresponding support beams.
5. Fold the table up and lock the buckle.
6. Put table inside the carry bag and zipper up. Carry the table with carry bag with shoulder belt.
Warning: If the frame/legs/table structure is damaged in anyway, then you should not use this table.
Using this table when damaged may cause harm or serious injury to you or your patient. You should
seek repair immediately.
