LYINTL WS-602WF User manual

2 Channel WIFI & Bluetooth Wireless Coaxial In-ceiling Speaker
4 Channel WIFI & Bluetooth Wireless Coaxial In-ceiling Speaker
WS-602WF
WS-602WF
WWW.LYINTL.COM

※ Be sure to read the instructions in this section carefully before use.
※ Make sure to observe the instructions in this manual as the conventions of safety symbols
and messages regarded as very important precautions are included.
※ We also recommend you keep this instruction manual handy for future reference.
When Installing the Unit
※ Do not expose the unit to rain or an environment where it may be splashed by water or other
liquids,as doing so may result in fire or electric shock.
※ Use the unit only with the voltage specified on the unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
※ Do not cut, kink, otherwise damage nor modify the power supply cord. In addition, avoid using the
power cord in close proximity to heaters, and never place heavy objects -- including the unit itself -- on
the power cord, as doing so may result in fire or electric shock.
※ Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a slanted
surface. Doing so may result in the unit falling down, causing personal injury and/or property damage.
When the Unit is in Use
※ Should the following irregularity be found during use,immediately switch off the power,disconnect
the power supply plug from the AC outlet and contact your nearest dealer.Make no further attempt to
operate the unit in this condition as this may cause fire or electric shock.
·If you detect smoke or a strange smell coming from the unit.
·If the unit falls, or the unit case breaks.
·If the power supply cord is damaged (exposure of the core, disconnection, etc.)
·If it is malfunctioning (no tone sounds.)
Thank you for purchasing our Wifi & Bluetooth Wireless Ceiling Speakers.
Please carefully follow the instructions in this manual to ensure long,trouble-free use of the equipment.
Packaging Contents
Page 1
SAFETY PRECAUTIONS
WARNING
Active master speaker
........................................................................
1
Passive slave speaker
.........................................................................
1
Manual
Power adapter
............................................................................................
...................................................................................
1
1
ACTIVE SPEAKER SERIES
2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

Description & Feature
Page 2
The WiFi & Bluetooth Speaker System utilizes a master/slave speaker configuration,in the master speaker
there is a 2 (or 4) channel Class D stereo power amplifier with speaker outlets to power the Slave speaker.
This WiFi speaker system is compatible for Android,iOS with APP control WiFi audio for independent control of
music content by multiple users via APP Streaming music directly from smartphone.
Also designed with built-in Bluetooth receiver,and an AUX input (3.5mm port) is available to
connect with additional audio source device.
These speakers utilize coaxial ceiling speaker system of 6" PP cone woofer and 1" titanium dome
tweeter,supported by a professional 2-way crossover,all these outstanding features make the loudspaekers
deliver realistic accurate low and reproduce high frequencies with extreme accuracy to allow for superior sound
and clear intelligibility in a variety of ceiling environments.
Ideal for use in your living room,bedroom,hotel room,entertainment area,office,workspace,show room,restaurant
etc.
※Built-in digital Class D amplifier 2*30W or 4*30W
※Built-in WiFi wireless music streaming receiver.
※Built-in Bluetooth wireless music streaming receiver.
※Equipped with one Aux Input via 3.5mm port.
※100V input available for connection with 100V pa system.
※2-way coaxial system containing one 6" woofer and one 1" tweeter.
※DC 24V power supply with AC adapter.
※Flush-mount dog ears installation.
※Attractive color ABS resin finish with white metal grille suits any decor.
AUX
IN
ACTIVE SPEAKER SERIES 2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

Page 3
Specification
1 2 3
45678
1. DC24V power input: allows to insert the output connector of the adapter
2. 100V line input: ready for connection with 100V pa system
3. Aux input (3.5mm): allows for connection with additional audio source device
4. Amplified signal output: ready for connection with the slave speaker
5 & 6. These two outputs are available to expand for 4CH speaker system
7. Power adapter: this adapter supplies DC24V to the master speaker
8. Audio input of slave speaker: ready for connection with the master speaker
Connection Ports
Rated Power 2*30W@8Ω
Amplifier Channel 2 Channel
Amplifier Type Digital Class D
Frequency Response 80Hz-20KHz(±3dB)
THD <0.05% at 1kHz,1/3 rated power
S/N >70 dB
Speaker Driver Woofer 6"*1 + tweeter 1"*1
Power Consumption 50W
Installation In-ceiling
Material ABS enclosure,metal clamps
Power Supply DC24V
Dimension Φ230*155mm
Cutting Hole Φ200mm
Net Weight 3.20kg (1+1)
ACTIVE SPEAKER SERIES
2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com
Model Number WS-602WF WS-604WF
4*30W@8Ω
4 Channel
100W
5.80kg (1+3)

WIFI & APP OPERATIONS
GETTING STARTED
Connect the active master speaker with the passive slave speaker using a desired length cable.
TURNING ON THE ACTIVE MASTER SPEAKER
To turn this unit ON, plug in the power cord.When the unit turns on, the indicator light will flash Red.
In order to connect this device to your Wi-Fi, you need to know your network credentials.
MINIMUM REQUIREMENTS
This device is compatible with iPhone, iPod Touch and iPad devices running on iOS 6.0 or later and
Android 2.3.3 or later.
NETWORK REQUIREMENTS
To access music services, Internet radio, and any digital music stored on your smart device or DLNA
enabled Network-Attached Storage (NAS) device, your network must meet the following requirements:
NOTE: If you want to stream music through built-in App features such as Spotify,you will need to
have a high speed internet connection. (Playback experience may differ depending on your
internet connection speed.)
• If you are going to use the MUZO Player App on Android or iOS devices, a Wi-Fi Network will be
required.
• You need to have your Wi-Fi network SSID and password.
• Your network configuration should not be in isolation mode.
This Wi-Fi Speaker uses the public MUZO Wireless Hi-Fi System
CONNECT YOUR WI-FI SPEAKER TO YOUR NETWORK VIA MUZO PLYAER APP.
• Install the MUZO Player App to your Smartphone or Tablet.
• Ensure that your Smartphone is connected to the same network that you are going to connect your
Wi-Fi to.
• Open the MUZO Player App and you will see the Figure 1.
• Select ‘Add Device’ at the bottom of the screen then you will see the Figure 2.
• Select ‘MUZO Cobblestone’ then you will see the Figure 3.
MUZO Playe r
Figure 1 Figure 2 Figure 3
The Wi-Fi speaker’s Service Set Identifier(SSID) is: ex. “Linkplay_XXXX”
Page 4
ACTIVE SPEAKER SERIES 2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

• Enter the MUZO Player APP,you will see the Figure 7.
• Select your Wi-Fi SSID and input its password,then ‘Continue’,when connected successfully you will
see the Figure 8.
• Select ‘Next’,a pop up menu Figure 9 will come up and you can select the name from pre-defined
names or write a desired name for your unit. This will help you to easily differentiate units from one
other on different locations(You cannot have two units with same name in the MUZO Player App).
• As the Figure 10 shows,press the icon ‘ ’ to enter the DEVICE LIST as the Figure 11,
• Select ‘Settings’ then you will see Figure 4.
• Select the Wi-Fi speaker’s SSID,ex. “Linkplay_XXXX”,then you will see the Figure 5.
• Select ‘CONNECT’ then you will see the Figure 6.
• Select ‘NO’you will see Figure 7,then press triangle ‘ ’ to exit the Wi-Fi discovery menu.
Figure 8 Figure 9 Figure 10
Figure 4 Figure 5 Figure 6 Figure 7
Page 5
ACTIVE SPEAKER SERIES
2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

WIFI & APP OPERATIONS
Figure 11
• Press the icon ‘ ’ to enter the main screen as the Figure 12,in this menu we can select ‘Add
More Services’ to configure which music services you want to display on your main screen list.
Now you can play and enjoy your music!
Figure 12
INSTRUCTIONS OF PLAYING MUSIC
Through ‘My Music’, you can access the music that you have saved on your iOS or Android device’s
internal storage. You can also access music stored in music server.There are other options such as
“recently played” and user created playlists etc.
In iOS, only music sync from your iTunes are accessible by the MUZO player. It is grouped by artists,
album, playlists, or track. In each category, it is in alphabetical order. On Android device, all the music
in the device is accessible, and it can be grouped by folder too.
My Music
Spotify
You can control music play through your Spotify app. Go to the Connect screen and select your
Speaker. For example, ‘Family Room’ Once you connect, you can stream Spotify to any room
connected with a WiFi speaker.
In order to use Spotify on your WiFi speakers you need to install Spotify on your connected Smartphone
or Tablet. Go to the App Store or the Play Store and search for the Spotify App. Install the App and login
into your account. If you do not have an account you will need to set one up.
iHeartRadio
iHeartRadio allows you to stream radio stations to your WiFi speaker. Enter the menu and select
‘iHeartRadio’. Select ‘Genre’ to choose the genre of radio you would like to listen to or select ‘Country’
and then the ‘Region’ to select localized radio stations.
Page 6
ACTIVE SPEAKER SERIES 2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

AirPlay
You can play music through AirPlay on your iOS device. To do this you need to ensure that your iOS
device and the WiFi speakers are connected to the same Wi-Fi network. Swipe up from the bottom of
your iOS device and select ‘AirPlay’. Select your WiFi speaker and start playing your music.
NOTE: On multi-channel mode when you have two or more WiFi speaker together, selecting AirPlay will
play the selected music on all the speakers. Ensure that you increase the volume on the unit when
listening to music on AirPlay.
TIDAL
TIDAL is the perfect match for the WiFi speaker, streaming music in lossless, high fidelity audio quality,
ensuring the best sound experience possible. Add high definition music videos, curated editorials by
music journalists, artists and experts, and so much more.
NOTE: Currently only available on iOS.
TuneIn
TuneIn allows you to stream different channels of music and streaming talk radio. Enter the menu and
select ‘TuneIn’. Afterwards you will be prompted to localize or select a genre of music to begin playing.
TTPOD
TuneIn allows you to stream different channels of music and streaming talk radio. Enter the menu and
select ‘TuneIn’. Afterwards you will be prompted to localize or select a genre of music to begin playing.
QQMusic
With millions of tracks on QQMusic, the right music is always at your fingertips whether you’re working
out, playing or relaxing. Diversified ways are here to discover music you will love. The latest hits, the
artists or DJs you like, intelligent recommendation based on your listening history, your next favorite
songs are waiting for you.
NOTE: Currently only available on iOS.
QINGTINGFM
Enjoy live radio, news, music, fiction, comic, and podcast radio service.
NOTE: Currently only available on iOS.
Page 7
ACTIVE SPEAKER SERIES
2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

CHECK WI-FI STRENGTH
To achieve smooth streaming experience, your WiFi Speaker should have good network connection
with your connected router. When connected with Wi-Fi, please check the Wi-Fi strength when you
have problem with streaming experience. The steps to check the Wi-Fi strength are as follows:
1. Enter the DEVICE LIST menu.
2. Select the gear ‘ ’ icon on the WiFi speaker you want to check,then you will see the Figure 13.
3. Select “Speaker Info” to see if your Wi-Fi connection is good enough as the Figure 14.
Figure 13 Figure 14
SPEAKER WI-FI PASSWORD PROTECTION
Figure 15
If you don't want the speaker to be public,you can encrypt it by enabling“Add Password
Protection”,
FACTORY RESET (Figure 16)
If you want to restore factory settings,select the“Restore Factory Settings” at the bottom of
SPEAKER INFO menu to confirm.
Figure 16 Figure 17
FIRMWARE UPDATE Figure 17 ( )
If you see a “New” icon next to the setting button, it means a new firmware is available for your unit.
In order to apply this firmware, tap on “New” and you will see a pop up message. Select upgrade and
wait until the device upgrade process finishes.
NOTE: Do not conduct any other operation via the phone or the speaker unit while the firmware update
is in progress.
Device List
Page 8
ACTIVE SPEAKER SERIES 2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com

ALARM CLOCK(Figure 18)
Figure 18
The alarm lets you wake up to your own music from the iTunes library or your subscribed music services.
You can set several alarms and specify for each alarm which days they should wake you up and which
playlist to use.
Figure 19
SLEEP TIMER(Figure 19)
You can set a timer on your device and set a sleep timer for it to turn off.
WEB BASED WI-FI SETUP
• Open the Wi-Fi Discovery Menu on your Smartphone or Tablet and look for the Speaker Service Set
Identifier (SSID), ex. “Linkplay_XXXX”.
• Select to connect your device to the Speaker hotspot network
• Open a web browser on your Smartphone or Tablet and input ‘10.10.10.254’ into the URL bar. This will
lead you to the Speaker Wi-Fi setup page.
• Select your network from the list of available networks and input your home Wi-Fi password.
• Your device will disconnect from the Speaker network and the Speaker will then connect to your Wi-Fi
network.
• Your device will say “Connected” to indicate that your Speaker has successfully connected to your
Wi-Fi network.
Wi-Fi Discovery Menu Connecting the speaker to Wi-Fi network
CONNECT SPEAKER TO WI-FI NETWORK (Figure 20)
Figure 20
Page 9
ACTIVE SPEAKER SERIES
2 / 4 Channel 6" WIFI & Bluetooth Wireless In-ceiling Speaker
http://www.lyintl.com
